studioduc knox tall bookcase User manual

knox tall bookcase
a how-to guide that won’t leave you in tears
ASSEMBLY INSTRUCTIONS

parenting is hard.
this is easy.
no really, it is.
MADE HERE™
MADE SAFE MADE SMART
MADE WELL™

want to watch this assembly IRL?
(acronym challenged? that means “in real life”.)
open the camera on your phone and place it over the
QR code below to see our NYC studio dream team do all
the heavy lifting (just kidding, there is none!)
or go to ducducnyc.com/pages/assembly-instructions
if you’re already using your phone, just click the
orange button below!
ASSEMBLY VIDEO CHANNEL

thank you for selecting a
studio duc product!

please check contents against the components list in these
instructions. also, please ensure there was no damage that may
have occurred in shipping.
if any components are missing or you find any damage, please
contact ducduc before continuing.
read all the instructions before use.
pay close attention to the safety warnings in these instructions.
a minimum of two people is required to safely assemble and
move the bookcase. do not attempt to move this bookcase
alone — dragging or sliding it across a floor may cause structur-
al damage.
MAINTENANCE:
please remember to securely tighten all bolts and fasteners, and
periodically check to make sure every component is properly
and securely in place and all bolts and fasteners are tight.
CLEANING:
do not scratch or chip the finish. do not use abrasive chemicals
for cleaning. clean with mild soap on a soft rag. rinse and dry
thoroughly. if you ever refinish this furniture, be sure to use only
a non-toxic finish specified for children’s furniture.
KEEP INSTRUCTIONS FOR FUTURE USE

WHAT’S IN THE BOX:
A1
R side
A2
L side
B
back
D
fixed shelf
F (x2)
adjustable shelf
C
bottom
G (x4)
foot
H (x8)
shelf pin
E
top

DB2
drawer box back
DB5
drawer box bottom
J
hammer cap
K (x9)
metal
spring pins
L
safety strap
kit
DB1
drawer face
DB3
L drawer box side
DB4
R drawer box side
DB6
knox pull hardware
DB7
screw for knox pull
WHAT’S IN THE BOX:
I (x6)
screws

WHAT YOU’LL NEED:
20 minutes
(or less)
2 people
plus a dog for moral support
(unless you’re a cat person)
household hammer or
rubber mallet
a soft surface to assemble on
(like a rug or some of the corrugate
box your piece arrived in)
phillips head screwdriver

lean bottom (C) against a wall as shown.
beginning in one corner, take a foot (G) as seen below, and insert the bolt located on foot
(G) into the brackets on bottom panel (C). Twist until the foot is fully secure, and repeat for
all feet (G) provided.
2
1
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

grab your household hammer and locate the parts listed below.
3a
3b
J
hammer cap
K (x9)
metal
spring pins
A1
R side A2 L side B back
apply hammer cap (J) to the head of your household hammer. starting with R side (A1), line
up metal spring pins (K) with the holes located at the top of the panel. fully tap each metal
spring pin (K) into all of the holes. use the remaining spring pins (K) to repeat the same step
on L side (A2) and back (B).
A1
R side
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

insert connectors on back (B) into slots on R side (A1). push down at the connection to lock
into place. if needed, tap with hammer and hammer cap (J) to lock into place
5
4lean R side (A1) against a wall as shown.
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

insert connectors on back (B) into slots on L side (A2). push down at the connection to lock
into place.
6
gently lay the partially assembled case on its back as shown.
7
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL
locate bottom panel (C) with
attached feet (G) before moving
on to the next step.
wait!

8insert connectors on both side panels (A1 + A2) into slots on bottom panel (C). push
down or tap with hammer and hammer cap (J) to lock into place.
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

9lower fixed shelf (D) into the case. align the three pins at the back of the fixed shelf (D)
with the 3 holes on the back (B) of the bookcase. push down or use hammer with ham-
mer cap (J) to lock into place.
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL
D
fixed shelf
important!
before locking into place, be
sure that the holes circled
above are facing the bottom
panel (B) of the bookcase.

10 use screws (I) and your phillips head screwdriver to secure fixed shelf (D) to each side of the
bookcase interior.
11 with a friend, flip partially assembled case into upright position. line up holes of top (E)
with the connectors of side panels (A1 + A2) and back panel (B). tap with hammer and
hammer cap (J) to lock into place.
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL
I (x6)
screws
phillips head
screw driver

12a now we build the drawer! starting with drawer face (DB1) facing down, insert connectors
of both drawer box side panels (DB3 + DB4) into slots on drawer face (DB1). push down at
the connections to lock into place.
12b rotate the partially assembled drawer box as shown. slide drawer box bottom (DB5) into
place using grooves on the drawer box side panels (DB3 + DB4) as guides. be sure glide
hardware on bottom panel (DB5) is positioned outside the drawer interior and toward
the drawer face (DB1) as shown.

12c again, rotate partially assembled drawer box as shown. insert connectors of drawer box
back (DB2) into slots on drawer box sides (DB3 + DB4). push down at the connections to
lock into place. use hammer and hammer cap (J) if needed.
12d using a phillips screwdriver and screw (DB7), attach the pull hardware (DB6) to the front
of the drawer face.
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

13a pull drawer glides out to extended position as shown.
place the assembled drawer box onto extended glides as shown. from underside of
drawer, use hands to pull each glide forward until it locks into connection with glide
hardware attached to drawer box bottom (DB5). the drawer will be secure when you
hear a click on each connection. once secured, push drawer box in to close.
13b
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

14a
14b
insert 8 shelf pins (H) into holes on both sides (A1 + A2) at desired heights.
one at a time, place adjustable shelf (F) on top of 4 shelf pins (H) so it sits secure and
level.
still confused? click to watch the assembly video ASSEMBLY VIDEO CHANNEL

15
the last step for your tall bookcase is to install the
safety strap included in the box. reference the separate
instructions enclosed in the envelope.
safety strap installation
