Sumake PN-5332P User manual

SUMAKE PNEUMATIC TOOLS
3/8" Square Drive Non-Shut Off
Oil Pulse Tool Pistol Type
PN-5332P
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Specification:
Free Speed 5,600 r/min
Square 3/8” (9.5 mm)
Bolt Capacity 5/16-3/8” (M8-M10)
Torque 14.8-23.6 ft-lb (20-32 Nm)
Air Consumption 0.43 m³/min (15.1 ft³/min)
Overall Length 6.3” (160 mm)
Air Hose (I.D.) 0.4” (12 mm)
Air Pressure 90 psi (6.3 bar)
Net Weight 2.07 lbs (0.94 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2 Noise ISO 15744 Remark
Sound Pressure Level
Load: 78.6 dB(A)
Load:
2.0 m/s²Sound power level
load: 89.6 dB(A)
Uncertainty
K= 1.5 m/s²Uncertainty
K= 3dB
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
PN-5332P-S-1404A-CPF

ECDECLARATION OF CONFORMITY
We: SUMAKE INDUSTRIAL CO., LTD.
4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan
declare in sole responsibility that the equipment
Equipment：3/8" SQUARE DRIVE NON-SHUT OFF OIL PULSE TOOL PISTOL TYPE
Model/ Serial No.：PN-5332P
to which this declaration applies, complies with these normative documents:
Machinery Directive: 2006/42/EC
and conforms to the following EN standard,
EN ISO 12100: 2010
EN ISO 11148-6:2012
Name and Signature/Position Date and Place
2013/6/28
MikeSu–ManagingDirector Taipei, Taiwan
PN-5332P-D-1404A-CPF

OIL-IMPULSE TOOLS INSTRUCTION MANUAL
Warning! It might be dangerous to operate the tool, if the instructions supplied are not followed.
Before using, installing, repairingor changing accessories, read and understand these instructions.
The tool is designed to tighten threaded fasteners utilizing an Oil-filled mechanism to deliver hydraulic
pressure pulses.
Operator’s Instruction Manual
Air Pressure
Tool is designed to be operated under the working air pressure of 5~6 bar = 0.5~0.6 MPa.
Air Hose & Fitting
Correct Hoses (the shorter, the better) and Fittings should be used for safety operation and correct
performance.
Dry & CleanAir
Air Filter and Lubricator should be used and preferably sited in a position. within there (3) meters of the tool.
Dust. corrosive fumes and/or excessive moisture can ruin the motor of the tool.
Socket
Connect female square drive Socket and Anvil by depressing Retainer Pin with small screwdriver or similar
tool.
Reverse Lever
Set Reverse Lever to “R” for clockwise or to “L” for counter-clockwise rotation.
Air Supply
Connect the tool to the air line and make sure there is sufficient air pressure supplied.
Torque Adjustment
Warning! Disconnect the air supply before torque adjustment!!
Remove Allen Head Plug for torque adjusting hole in the Front Casing.
Rotate anvil manually until Relief Valve Spindle is exposed directly through the hole.
Turn Relief Valve Spindle clockwise to increase torque, and counter-clockwise to decrease the output torque.
After this setting, use torque tester to check the current output torque.
Maximum torque
Turn Relief Valve Spindle clockwise until it stop then turn counter-clockwise half round.
Caution! Never remove Round Head Oil Plug in Oil Pulse Unit which causes oil Leakage and
power-down.
Throttle Trigger/Lever
Grip the handle firmly and pull Throttle Trigger or Lever slowly to start fastening operation.
ExhaustAir
Adjust the direction of the exhaust air with Silencer to the best position for Eye and ear protection. Silencer
can be turned 360 degree.
Warm Up
In case of low temperature, oil action may not be generated in the first use due to viscosity of hydraulic fluid.
Warm up the pulse unit approximately ten (10) seconds by fixing Anvil on the vise before starting fastening
operation.
Maintenance
●Lubrication
Do not lubricate the tool with flammable or volatile liquids such as kerosene, diesel or jet fuel.
For Air Motor: Supply light Turbine Oil properly through Air Inlet or line lubricator before and after every
operation.
For example, Mobil Turbine Oil #32, Shell Turbine Oil #32, and/or equivalents.
For Bearing: Supply high quality Grease properly.
For example, Shell Alvania No.2, Mibilplex 2, and/or equivalents.
Disposal of tool
The tool is made of steel, aluminum alloy casting iron, plastic and rubber
When disposing the tool, make sure not to cause pollution to human being and environment.
●Overhaul
It is recommended that change the fluid in hydraulic cylinder after every 150,000 fastenings or 3 months
whichever comes first. It is also recommended at such time, to apply grease on bearings in the air motor.
If the presence of water is noted, it is recommended that a small amount of oil shall be run through the air
motor to wash any rust in the air motor.
It is recommended to inspect oil pulse unit every after 200,000 fastening cycles or 6 months whichever
comes first for damage or wearing of inner sealing materials. Replace damaged or worn sealing materials
and fluid in the oil pulse unit shall be changed.
The inspection and overhaul requires trained personnel.
When the tool torque has dropped to less than 90% from pre-set torque. overhaul is required by trained
personnel as oil leakage may be supposed.
Do not attempt to increase torque by adjusting the relief valve spindle as sudden torque drop may occur
after this adjustment.
Ensure that the data plate and labels on the tool are kept in a legible condition. Replace any damaged
date plate and label.
Maintenance and repair records should be kept on all tools.
For further information, contact with your nearest ZIPP distributor or to ZIPP in Taiwan.
PN-SERIES-I-1404A-CP

PN-5332P
PARTS LIST
No. Parts No. Descri
p
tion Q't
y
No. Parts No. Descri
p
tion Q't
y
1 PN5332P-01 Pistol 1 30 PN5332P-30 LinerCa
p
1
2 PN5332P-02 O-Rin
g
2 31 PN5332P-31 Pin 4
3 PN5332P-03 Rotor 1 32 PN5332P-32 Back-u
p
Rin
g
1
4 PN5332P-04 Rotor Blade 9 33 PN5332P-33 X-Rin
g
1
5 PN5332P-05 Bearin
g
1 34 PN5332P-34 Oil Screw 1
6 PN5332P-06 Front Plate 1 35 PN5332P-35 O-Rin
g
3
7 PN5332P-07 C
y
linder 1 36 PN5332P-36 O-Rin
g
2
8 PN5332P-08 Rear Plate 1 37 PN5332P-37 Pin 1
9 PN5332P-09 Connection Sets 1 38 PN5332P-38
A
d
j
ust Screw 1
10 PN5332P-10 S
p
rin
g
Pin 1 39 PN5332P-39 O-Rin
g
1
11 PN5332P-11 Throttle Bushin
g
1 40 PN5332P-40 Blade S
p
rin
g
2
12 PN5332P-12 Valve Washer 1 41 PN5332P-41 Liner Plate 1
13 PN5332P-13 Throttle Gri
p
1 42 PN5332P-42 Drive Blade 2
14 PN5332P-14 S
p
rin
g
Pin 1 43 PN5332P-43 Liner Casin
g
1
15 PN5332P-15 O-Rin
g
1 44 PN5332P-44 Liner 1
16 PN5332P-16 O-Rin
g
1 45 PN5332P-45 Main Shaft 1
17 PN5332P-17 Orientation S
p
rin
g
1 46 PN5332P-46 Touch off 1
18 PN5332P-18 Valve Shaft 1 47 PN5332P-47 Touch off S
p
rin
g
1
19 PN5332P-19 Valve Rod 1 48 PN5332P-48 Touch off Cover 1
20 PN5332P-20 Ball 1 49 PN5332P-49 Liner S
p
indle 1
21 PN5332P-21 Silencer 1 50 PN5332P-50 Transmission Plate 1
22 PN5332P-22
A
ir Filter 1 51 PN5332P-51 Front Casin
g
1
23 PN5332P-23 Exhaust Block Set 1 52 PN5332P-52 Screw Plu
g
1
24 PN5332P-24 Exhaust Bod
y
1 53 PN5332P-53 Bushin
g
1
25 PN5332P-25 O-Rin
g
1 54 PN5332P-54 Ke
y
Rin
g
1
26 PN5332P-26 O-Rin
g
2 55 PN5332P-55
A
ir Inlet 1
27 PN5332P-27 Back-u
p
Rin
g
1 56 PN5332P-56 Wrench 1
28 PN5332P-28 Pin 1 57 PN5332P-57 Wrench 1
29 PN5332P-29 Rubber Gri
p
1PN-5332P-P-1404A-CP
3/8" SQUARE DRIVE NON-SHUT OFF OIL PULSE TOOL PISTOL TYPE
