Sumitomo Lynx-CustomFit LYNX2-FC User manual

Copyright © 2011 Sumitomo Electric Industries, LTD.
SM : G.652, G.657
MM : MM50(OM2), MM50(OM3), MM50(OM4), MM62.5(OM1)
The Lynx-Custom it® Splice-On Connector is designed and
manufactured to assure personal safety. Improper operation
can result in bodily injury and serious damage to this product.
Please read and observe all warnings instructions given in this
operation manual.
Wear safety glasses to protect your eyes when
handling optical fiber.
Never look into the end of a microscope or optical
cable connected to an optical output device that is
operating. Laser radiation is invisible, and direct
exposure can severely injure the human eye.
Alcohol is flammable, causes irritation and is harmful
if swallowed or inhaled. Keep alcohol away from
heat, sparks, skin, and avoid contact with eyes.
In the case of the work at the high place, please be
careful not to drop an assembling tool.
Lynx-Custom it® Splice-On Connector Ver. 2
- LYNX2-FC for 250um or 900um Tight Buffered Fiber -
Installation Manual
!
!
!
1. Improper assembly will result in a loss of performance.
Please read instructions given in this operation manual
and the operation manual of the fusion splicer.
2. Never touch the fiber of the stub. It has been inspected
in the factory.
3. The product is sensitive to dirt or dust. Do not take out
any parts from the package until it is to be used.
4. The characteristic will be influenced by the fiber
cleaved surface condition. Please use a cleaver which
has a good cleaving characteristic.
5. Do not remove the dust cap until the connector has
been completely assembled in order not to cause an
high insertion loss due to them.
For your safety operatio
!
Precautio s
Compositio Assembli g Tools
Holder (Fiber Side)
for 900um tight buffer for 250um fiber
LYNX2-UML-S HS-09 HS-025 LYNX2-S-LB5
Fusio Splicer
T-Q101-CA(71C), etc.
Fiber Cleaver
C-6S-C, etc.
Jacket remover
JR-M03, etc.
Recomme ded Program
Splicer iber Splicing Program Heater Program
T-25eS SM SM1: SM 1C Lynx
or PS (60mm)
MM MM1: MM 1C
T-39 H SM LYNX-SM Lynx
or PS (60mm)
MM LYNX-MM
T-Q101-CA
(T-71C)
SM Standard SM Lynx
or 60mm 0.9
MM MM 50&62.5
Please perform Arc test prior to the splicing operation.
(See the operation manual of the splicer.)
* iber for testing is not included in the kit.
Please check fiber type inside the field fiber.
ETK1123070A
Holder Type Cleave length: 10mm
Below equipment or tool are examples.
Disposable
Holder (*1)
Dummy
Cap
ront
Parts
Rear
Stopper
errule
Subassembly
Boot
urcation
Tube
Protection Sleeve
and Spring
(*1) 1 pc / 100 connectors
Either one holder is required.
North Caroli a (USA)
Sumitomo Electric Lightwave Corp.
78 Alexander Drive, P.O. Box 13445, RTP, NC 27709
TEL [phone]
http://www.sumitomoelectric.com/
Yokohama (Japa )
Sumitomo Electric I dustries, Ltd.
(Lightwave Network Products Divisio )
1, Taya-cho, Sakae-ku, Yokohama 244-8588, Japan
TEL [phone], http://global-sei.com/fttx/
Lo do (UK)
Sumitomo Electric Europe Ltd.
220 Centennial Avenue, Elstree, Herts. WD6 3SL, UK
TEL [phone]
http://www.sumielectric.com/

Copyright © 2011 Sumitomo Electric Industries, LTD.
LYNX2- C for 250um or 900um Tight Buffer
Assembly Procedure ETK1123070A
(1) Slide Rear Parts o to the
fiber.
I sert fiber i to
this hole
(2) Slide Protectio Sleeve o to the
fiber.
(3) Remove the fiber coati g.
Approx. 35mm (JR-M03)
0.9 to 0.25mm
0.25 to 0.125mm (4) Clea the fiber with li t-
free clea i g wipe.
Moiste ed
with alcohol
(5) Set the fiber o the holder. Co firm the positio
Good
No Good
No Good
Do ot touch
bare fiber
1. Place
3. Slide
Clea rubber clamp
a d blade regularly
(6) Cleave the fiber (FC-6S)
No gap
(7) Set fiber holder o the splicer
(left side).
Grasp here to
pick up
Do ot touch
bare fiber
(8) Pick up the stub a d set the stub o the plastic holder. (9) Set stub holder o the splicer
(right side).
Place fiber o
V-groove ge tly If the positio of the fiber is wro g,
set the fiber or stub agai .
(10) Fusio Splice.
Lightly holdi g assembly to preve t be di g
(11) Ope the stub a d fiber holders.
Lightly mai tai i g te sio to
preve t be di g
(12) Pick up the spliced fiber.
No twisti g
(13) Slide Protectio u til it covers the projectio of
the fla ge.
(14) Set Sleeve i to the heater.
No twisti g
(15) Co firm the positio before
heati g. Sleeve at ce ter
of heater
No gap
Butto to
start heati g
(16) Heat Protectio Sleeve.
Ly x heater program ru s a fa to
cool the sleeve after heati g
(17) Pick up Sleeve.
Be careful for hot sleeve,
spri g a d fla ge eve after
the cooli g by fa .
!
2. Close
Push to
close
Lightly mai tai i g
te sio o fiber
Right side first The left side
No twisti g
Left side first
The right side
Butto to
start splici g
Place fiber o
V-groove ge tly
Wi dow Wi dow
Alig wi dows a d dot
APC - Red dot
PC/UPC - Black dot
(18) Put Fro t Parts. (19) Remove Dummy Cap.
Cut Tether
Complete
(A) Set Fusio Co ditio
Push “power
key” for more
than 1 sec.
“Main Menu”
Select iber Type Select “ iber Type”, then “Return”.
(B) Perform Arc Test
Select “Arc Test”
Then perform the arc test
according to the
instruction.
* iber for testing is not
included in the kit.
Please check fiber type
inside the field fiber.
“Main Manu”
Select Sleeve Type
Select Sleeve Type
Then “Return”
See the operatio ma ual of each splicer. These are the example of T-Q101-CA (T-71C).
