Sumitomo Lynx-CustomFit LYNX2-MPO User manual

Fusion Splicer
Type-Q101-M12
(T
-
71M12)
Fiber Cleaver
FC-6RM etc.
Jacket
Remover
JR
-
6
Fiber older
F M-12
(For 12c Fiber)
Fiber older
F M-8
(For 8c Fiber)
The Lynx-CustomFit® Splice-On Connector is designed and
manufactured to assure personal safety. Improper operation
can result in bodily injury and serious damage to this product.
Please read and observe all warnings instructions given in this
operation manual.
Wear safety glasses to protect your eyes when
handling optical fiber.
Never look into the end of a microscope or optical
cable connected to an optical output device that is
operating. Laser radiation is invisible, and direct
exposure can severely injure the human eye.
Alcohol is flammable, causes irritation and is harmful
if swallowed or inhaled. Keep alcohol away from
heat, sparks, skin, and avoid contact with eyes.
In the case of the work at the high place, please be
careful not to drop an assembling tool.
LynxLynx--CustomFitCustomFit®® SpliceSplice--OnOn ConnectorConnector Ver. 2 Ver. 2
-- LYNX2LYNX2--MPOMPO forfor RoundRound CordCord withwith 12 or 8 12 or 8 ndividualndividual FibersFibers --
InstallationInstallation ManualManual
!
!
!
1. Improper assembly will result in a loss of performance.
Please read instructions given in this operation manual
and the operation manual of the fusion splicer.
2. Never touch the fiber of the stub. It has been inspected
in the factory.
3. The product is sensitive to dirt or dust. Do not take out
any parts from the package until it is to be used.
4. The characteristic will be influenced by the fiber
cleaved surface condition. Please use a cleaver which
has a good cleaving characteristic.
5. Do not remove the dust cap until the connector has
been completely assembled in order not to cause an
high insertion loss due to them.
For your safety operation
!
Precautions
Composition
Disposable
Assembling Tools
ETK1123092D
Below equipments and tools are required.
Furcation
Rear Parts
(T
-
71M12)
JR
-
6
(For 12c Fiber)
(For 8c Fiber)
Fiber Alignment Tool
FA-03
Cord Tool
LYNX2-CORDTOOL-
2&3
Kevlar Cutter
North Carolina (USA)
Sumitomo Electric Lightwave Corp.
78 Alexander Drive, P.O. Box 13445, RTP, NC 27709
TEL [phone]
http://www.sumitomoelectric.com/
Yokohama (Japan)
Sumitomo Electric ndustries, Ltd.
(Lightwave Network Products Division)
1, Taya-cho, Sakae-ku, Yokohama 244-8588, Japan
TEL [phone], http://global-sei.com/fttx/
London (UK)
Sumitomo Electric Europe Ltd.
220 Centennial Avenue, Elstree, erts. WD6 3SL, UK
TEL [phone]
http://www.sumielectric.com/
SMF : G.652, G.657
MMF : MM50(OM2), MM50(OM3), MM50(OM4), MM62.5(OM1)
Disposable
older (*1)
Dust Cap
Front
ousing
w/Spring
Rear
Stopper
MT STUB
Boot
Protection
Sleeve
(*1) 1 pc / 100 connectors
Recommended Program
Please perform Arc test prior to the splicing operation.
(See the operation manual of the splicer.)
*Ribbon fiber for testing is included in the connector kit.
Please check fiber type inside the field fiber.
Dummy Cap
w/ Tether
SM Low Loss SM Std. Loss MM62.5 OM1 MM50 OM2 MM5010GOM3
8 degree Polish Flat Polish
Yellow Green Beige Black Aqua
Polish Surface and ousing Color
Furcation
Tube
Copyright © 2011 Sumitomo Electric Industries, LTD.
Rear Parts
Spiral
Tube
Splicer Fiber Splicing Program eater Program
Type-Q101-M12
(T-71M12)
SMF 12c SM12c
Lynx MPO
SMF 8c SM8c
MMF 12c MM12c
MMF 8c MM8c

LYNX2LYNX2--MPO for Round Cord with 12 or 8 Individual FibersMPO for Round Cord with 12 or 8 Individual Fibers
AssemblyAssembly ProcedureProcedure ETK1123092D
(A) Set Fusion Condition (B) Perform Arc Test
See the operation manual of T-71M12.
(1) Slide Rear Parts onto
the cord.
(2) Mark at 150mm from the end
of the cord.
(3) Mark Slit by LYNX2-CORDTOOL-2&3.
Set the cord on “3mm” groove.
Set the marking point
at the edge of top
(4) Fold the slit outer sheath and Kevlar
backward. Hold them by a mending tape.
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12
Method A End A BL OR GR BR SL W RD BK YL VI PK AQ
End B BL OR GR BR SL W RD BK YL VI PK AQ
Method B End A BL OR GR BR SL W RD BK YL VI PK AQ
End B AQ PK VI YL BK RD W SL BR GR OR BL
Method C End A BL OR GR BR SL W RD BK YL VI PK AQ
End B OR BL BR GR W SL BK RD VI YL AQ PK
Another
(ex. Corning)
End A BL OR GR BR SL W RD BK YL VI PK AQ
End B AQ PK VI YL BK RD W SL BR GR OR BL
Table 1. Fiber Alignment. (See Appendix.)
(5) Fiber standing in line according to Table 1.
The way to align the order in hand
every
4
fiber
might
be
easy.
Push “power
key” for more
than 1 sec.
Arc Test “ON”.
Then perform the arc test
according to the instruction.
*Fiber for testing is included
in the kit.
Please check fiber type
inside the field fiber.
“Main Menu”
Select Fiber Type Select “Fiber Type”, then “Return”. “Main Manu”
Select Sleeve Type
Select Sleeve Type
Then “Return”
For 8c For 12c
Copyright © 2011 Sumitomo Electric Industries, LTD.
(9) Set ribbon fiber on Fiber holder.
(10) Remove Coating (JR-6)
1. Place
3. Slide
Clean rubber clamp
and blade regularly
(12) Cleave the fiber (FC-6M)
No gap
(13) Set fiber holder on the splicer
(left side).
2. Close
Place fiber on
V-groove gently
Spring
(Remove from
Front Parts)
Protection
Sleeve
CH1 Fiber
Front Side
Stainless Steel
Bottom Side
Make sure the
orientation of Sleeve
CH1 Fiber
Front Side
＞
＞＞
＞25mm
(11) Fiber Cleaning.
Moistened
with alcohol
(8) Slide Rear Parts, Spring and Protection
Sleeve onto the ribbon fiber.
(6) Ribbon Processing.
1. Apply Adhesive
2. Put an adhesion department with a
sponge 3. Move a slide stage
No Bending
No gap between fibers
4. Completion
130mm
>30mm
(7) Cut the fiber to be 130mm and confirm the
length of ribbonized is 30mm or more.
every
4
fiber
might
be
easy.
Ribbon End
Marking
Marking

LYNX2LYNX2--MPO for Round Cord with 12 or 8 Individual FibersMPO for Round Cord with 12 or 8 Individual Fibers
AssemblyAssembly ProcedureProcedure ETK1123092D
No twisting No gap
Button to
start heating
Lynx heater program runs
a fan to cool the sleeve
after heating
Lightly maintaining
tension on fiber
Right side first Then left side
Lightly maintaining tension to
prevent bending
Left side first Then right side
Lightly maintaining tension
to prevent bending
Place fiber on
V-groove gently
f the position of the fiber
is wrong, set the fiber or
stub again.
Sleeve and Spring
should be out of
the cover.
Protection
Sleeve
Spring
(21) Set Sleeve into the heater. (22) Confirm the position before heating. (23) Heat Protection Sleeve.
(17) Slide the sleeve to
the holder.
(19) Pick up the spliced fiber.
No twisting
(20) Slide Protection Sleeve to
MT STUB.
No twisting
(18) Open the cover of the holder.
UP
Grasp here
Do not touch bare fiber
(14) Pick up MT STUB and set the stub on the plastic
holder.
(15) Set stub holder on the
splicer (right side).
(16) Fusion Splice.
Push to
close
UP should be
upper side
Touch Start icon
Copyright © 2011 Sumitomo Electric Industries, LTD.
after heating
(27) Put Front Housing.(24) Spiral & Pick up the cord.
Rotate counter-clockwise.
(25) Disassemble Rear Parts.
Rear
Stopper
Kevlar Stopper
and Boot
MT STUB Dummy CAP
(26) Slide Rear Parts and remove
Dummy Cap.
(28) Slide Kevlar Stopper. Trim the slit outer sheath.
No Thread
Get the parts/components closer
to each other and straighten the
fibers covered with the Kevlar in
the Sheath
Rotate Kevlar Stopper
with holding Kevlar on
Housing
Make sure that
the fibers with
Kevlar are not
twisted.
Kevlar
Stopper
(29) Secure Kevlar by screwing of Kevlar Stopper & Cut excess Kevlar
Boot
(30) Put Boot.
Cut Kevlar here
Complete
Spiral Tube
Approximately
middle position
Don’t go over the thread. Cut Sheath here
Do not bend（Fiber Kevlar Sheath）
Window Ridge
Align Window and Ridge
Front Parts
Rear Stopper
Cap
Tube

MPO for Round Cord with 12 or 8 Individual FibersMPO for Round Cord with 12 or 8 Individual Fibers
Polarity manual for LYNX2Polarity manual for LYNX2
--MPOMPO ETK1123092D
LYNX2LYNX2--
MPO for Round Cord with 12 or 8 Individual FibersMPO for Round Cord with 12 or 8 Individual Fibers
Appendix:Appendix:
Polarity manual for LYNX2Polarity manual for LYNX2
