INSTRUCTION MANUAL
for Ceramic Glass
Electric Cooktop Models
CR2110 CR2110TK15
CR2110WH CR2110WHTK15
CR2220 CR2220TK15
CR2220WH CR2220WHTK15
Felix Storch, Inc.
Summit Appliance Division
An ISO 9001:2015 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance .com
Please read these instructions in their entirety before
installation and use of your cooktop.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

1
Table of Contents
Product Specifications ......................................................................................2
Safety Instructions.........................................................................................3 - 4
Installation Instructions for Ceramic Glass Cooktops .............................5 - 11
Step #1: Unpacking the Cooktop ...............................................................5
Step #2: Check the Electrical Supply Requirements .................................6
Step #3: Countertop Preparation ..........................................................7 - 9
Step #4: Installing the Cooktop ..........................................................9 - 10
Step #5: Electrical Connection ................................................................11
Step #6: Final Preparations Prior to Use .................................................11
Operation....................................................................................................12 - 13
Cookware.................................................................................................12
Heating Elements.....................................................................................12
Controls & Indicators................................................................................13
Cleaning.............................................................................................................13
Limited Warranty...............................................................................................15

2
Product Specifications
All models have double burners.
CR2110:
120V AC –two 6” (140 mm) burners @ 1200 watts each
CR2220:
220V AC –two 6” (140 mm) burners @ 1200 watts each
Overall dimensions: 11¾” x 19⅝” x 2⅛”
(300 mm x 500 mm x 55,3 mm)
Cutout dimensions: 11⅛” x 19¼”
(282 mm x 490 mm)
WH in the model number suffix indicates model has a white ceramic glass
cooktop. Others are black.
TK15 in the model number suffix indicates that the model includes a Trim
Kit that allows the unit to fit into a 15” wide cutout.
For future reference, please record your cooktop’s Model and
Serial Numbers (on bottom of unit) of here:
Model____________________________________
Serial Number______________________________

3
SAFETY INSTRUCTIONS
Read this section BEFORE operating the cooktop.
This cooktop, like all appliances, has the potential to create safety
problems through careless and improper use. Please observe all of
the following safety precautions.
Proper Installation
Be sure your appliance is properly installed and grounded by a qualified
technician.
Never use your appliance for warming or heating the room.
Do not leave children alone.
Children should never be left alone or unattended in the area where the
appliance is in use. They should never be allowed to sit or stand on any part
of the appliance. Do not store items of interest to a child in cabinets above
cooktop. Children climbing on the cooktop to reach such items could be
seriously injured.
Wear proper clothing/apparel.
Loose-fitting or hanging garments should never be worn while using the
appliance.
User Servicing
Do not repair or replace any part of the appliance. If service ever becomes
necessary, this appliance should be serviced by AUTHORIZED
PERSONNEL ONLY or call SUMMIT Customer Service at 1-800-932-4267.
Keep flammable materials away from the cooktop.
Do not store plastic material (such as plastic utensils) in storage areas
beneath cooktop.
Plastic items with low melting temperatures should not be stored under, over
or near the cooktop.
Do not soak removable heating elements.
Heating elements should never be immersed in water.
Do not immerse the cooktop in any liquid.
Do not use water on grease fires.
Smother fire or flame or use dry chemical or foam-type extinguisher.
Use only dry potholders.
Damp potholders on hot surfaces may result in burns from steam. Do not let
potholder touch the heating elements on the appliance. Do not use a towel
or other bulky cloth in place of a potholder.

4
Do not cook on a broken cooktop.
If your cooktop should break, cleaning solutions and spillovers may penetrate
the broken cooktop and create a risk of electric shock. Immediately contact
an authorized service center or call the SUMMIT Customer Service at 1-800-
932-4267.
Clean cooktop with caution.
If a wet sponge or cloth is used to wipe spills on a hot cooking surface, be
careful to avoid steam burns. Some cleaners produce noxious fumes if
applied to a hot surface. Read the cleaner label for details prior to use.
DO NOT TOUCH HEATING ELEMENTS.
The heating elements on the cooktop may be hot even if they are dark in
color. These areas may be hot enough to cause burns. Never touch heating
elements until they have had sufficient time to cool. Likewise, never allow
clothing or flammable materials to come in contact with heating elements or
the cooktop surface until they have had sufficient time to cool. Other
surfaces of the appliance may become hot enough to cause burns.
Use proper pan size.
This appliance is equipped with one or more 6"-diameter surface units.
Select utensils having flat bottoms large enough to cover the surface unit
heating element. The use of undersized utensils will expose a portion of the
heating element to direct contact and may result in ignition of clothing.
Proper relationship of utensil to burner will also improve efficiency.
Never leave surface units unattended at high heat settings.
Boil-over causes smoking and greasy spillovers that may ignite.
Utensil handles should be turned inward and not extend over adjacent
surface units.
To reduce the risk of burns, ignition of flammable materials, and spillage due
to unintentional contact with the utensil, the handle of a utensil should be
positioned so that it is turned inward, and does not extend over adjacent
surface units.
These cooktops are for HOUSEHOLD USE ONLY.
- SAVE THESE INSTRUCTIONS -

5
Contour Cooktop
Cooktop carrier
Installation Instructions
for Ceramic Glass Cooktops
Step #1
Unpacking the Cooktop
Carefully unpack the cooktop from its shipping container. If possible, retain
the original shipping carton and protective packaging in the event the unit
ever has to be returned for service.
Verify and identify the package contents. The following items should be
included in the carton. If any components are missing or damaged, call
SUMMIT immediately.
●Ceramic glass cooktop
●Mounting brackets (2 pcs)
●Mounting screws (2 pcs)
●Cooktop carriers (4 pcs)
●Mounting screws for cooktop carriers (8 pcs)
●Self-adhesive sealant strip
NOTE: A model with TK15 in the suffix includes a 15-inch wide stainless steel
frame in the package.
Fig. 1
IMPORTANT
Save this documentation for review by local inspector.
This appliance must be properly installed and grounded by
a qualified technician.
Mounting brackets
Mounting screws
Seal
Ceramic glass cooktop

6
Step #2
Check the Electrical Supply Requirements
This product must be installed in accordance with national, state and local
electric codes. The following table provides the correct voltage, amperage
and frequency that must be supplied to the cooktop.
SUMMIT
Model #
Maximum
Connected
Load
Required
Power Supply
Input
Minimum
Wire Size
CR2110/
WH/TK15
2400 Watts
120V
AC/25A/60Hz
#12 AWG
CR2220/
WH/TK15
2400 Watts
220V
AC/10A/60Hz
#16 AWG
The supply must be from an individual grounded circuit that is protected by
a circuit breaker and rated per the specifications for the various models as
shown in the table above.
WARNING: INSTALLATIONS MUST COMPLY WITH ALL LOCAL,
STATE AND NATIONAL ELECTRICAL CODES.
Failure to comply with the applicable codes may result in fire,
property damage, personal injury or death.
If the electric power supply does not meet the product
specifications, consult with a licensed electrician before
proceeding with installation.

7
Step #3
Countertop Preparation
Please read this section prior to making cutout for the cooktop.
It is important to plan ahead for installation of the cooktop, keeping the
following dimensions in mind (please refer to Fig. 2).
A. 13 inches maximum depth of overhead
cabinets
B. 36 inches is minimum height of countertop
above floor
C.The minimum flat countertop surface that
the cooktop will rest upon must be equal
to or greater than the overall cooktop
dimensions (refer to the following pages
for overall cooktop dimensions).
D.30 inches minimum clearance between
the top of the cooking surface and the
bottom of an unprotected wood or metal
cabinet or 24 inch minimum clearance
when the bottom of wood or metal cabinet
is protected by not less than ¼-inch-thick
flame retardant millboard covered with not
less than No. 28 MSG sheet steel, 0.015-inch-thick stainless steel,
0.024-inch-thick aluminum or 0.020-inch-thick copper.
E. 1-inch minimum from backsplash of countertop to edge of glass (refer to
the following pages for overall cooktop dimensions).
Do not install closer than ½ inch (12 mm) from any adjacent surface!
WARNING: To eliminate the risk of burns by reaching over
heated surface units, cabinet storage space located above
surface units should be avoided. If cabinet storage is
necessary, the risk can be reduced by installing a range
hood that projects horizontally a minimum of 5” beyond
the bottom of the cabinets.
Fig. 2

8
Before making the countertop cutout, check for clearance. Check to see if
the cooktop will clear the front and side walls of the base cabinet. It is also
important to provide enough ventilation.
Adequate ventilation of the space below the countertop must be provided
to ensure proper operation of the cooktop. Heat transferred from the
cooktop bottom pan during operation will overheat an improperly ventilated
area.
Fig. 3
Allow a 2” minimum clearance between the bottom of the metal pan of the
cooktop and any combustible surface located below, i.e.: the upper edge of
a drawer installed below the cooktop (refer to Fig. 3). Failure to provide
proper clearances and ventilation may result in a fire hazard.
Cooktop dimensions and countertop cutout dimensions are shown below:
NOTE: If your cutout is closer to 15” than 11⅞” wide, you should be using one of
our TK15 model cooktops.
2 inch (51 mm) minimum
Models CR 2110, CR2220 and variations
Fig. 4

9
NOTE: When making the countertop, radius the corner of the cutout (1/4”
radius is typical). This will prevent cracking of the countertop. Follow
manufacturer’s instructions regarding minimum corner radius and
reinforcement of corners.
Step #4
Installing the Cooktop
Attach the cooktop carriers by the screws as shown in Fig.8.
After this, stick on the self-adhesive sealant as described below. The
special seal prevents liquid from infiltrating into the cabinet. Additionally the
cooktop should be bedded to the countertop using a soft bedding
compound that will prevent damage if later removal for service is
necessary. The mounted special seal prevents this damage. Strictly
comply with the following instructions in order to correctly apply this seal:
●Detach the seals from their backing, checking that the transparent
protection still adheres to the seal itself.
●Turn the cooktop over and correctly position the seal under the edge
of the cooktop itself so that the outer side of the seal perfectly
matches the outer peripheral edge of the cooktop (refer to Fig. 5).
The ends of the strips must fit together without overlapping.
●Fix the seal to the cooktop evenly and securely, pressing it in place
with the fingers.
To install TK15 models: For wider cutouts, use the stainless steel frame
supplied with your TK15 cooktop. Lay a thin bead of bedding compound along
the edge of the cutout, and then lay the frame over this, pressing down to
Fig. 5
