Summit STC6 User manual

Write Serial Number here:
________________________
Freestanding Countertop Wine Cooler
Models: STC6
STC12
Owner’s Manual
BEFORE USE, PLEASE READ AND FOLLOW
ALL SAFETY RULES AND OPERATING INSTRUCTIONS
Felix Storch, Inc.
An ISO 9001:2015 registered company
Summit Appliance Division
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com

2
TABLE OF CONTENTS
Important Safeguards ........................................................3 –5
Installation Instructions ..........................................................6
Before using your appliance .............................................6
Installation of your appliance ...........................................6
Storage ...........................................................................6
Installation of drainage pipes ..........................................6
Operating Your Appliance .................................................7 –9
Recommended temperatures for chilling wine ................7
Control panel .............................................................7 –8
Demo mode ....................................................................8
Defrosting ................................................................. 8 - 9
Temperature alarm function ............................................9
Care and Maintenance ...........................................................10
Cleaning your appliance ...............................................10
Power failure...................................................................10
Transporting your appliance ..........................................10
Energy-saving tip ..........................................................10
Problems with Your Appliance (Troubleshooting) ..............11
Limited Warranty ...................................................................12

3
IMPORTANT SAFEGUARDS
Read all instructions before using the appliance.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear
of appliance.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter,
and do not use an extension cord.
It is recommended that a separate circuit, serving only your appliance, be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion.
Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
Do not connect or disconnect the electric plug when your hands are wet.
Unplug the appliance or disconnect the power before cleaning or servicing. Failure to do so can
result in electrical shock or death.
Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified technician.
Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or

4
any other appliance. The fumes can create a fire hazard or explosion.
Use two or more people to move/install the refrigerator. Failure to do so can result in back or
other injury.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical connections in accordance with state and
local codes. A standard electrical supply (115VAC 60 Hz), properly grounded in accordance
with the National Electrical Code and local codes and ordinances, is required.
Do not kink or pinch the power supply cord of the appliance.
The fuse (or circuit breaker) size should be 10 amps or higher.
It is important for the appliance to be leveled in order to work properly. You may need to make
several adjustments to level it.
Although the unit has been tested at the factory, due to transit and storage, you should clean
the appliance before use.
Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may
damage or discolor the interior.
This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which
is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it
increase the greenhouse effect. Care must be taken during transportation and setting up of the
appliance that no parts of the cooling system are damaged. Leaking coolant can ignite and may
damage the eyes.
In the event of any damage:
-Avoid open flames and anything that creates a spark,
-Disconnect from the electrical power line,
-Air the room in which the appliance is located for several minutes, and
-Contact the Service Department for advice.
The more coolant there is in an appliance, the larger the room it should be installed in. In the
event of a leakage, if the appliance is in a small room, there is the danger of combustible gases
building up. For every ounce of coolant, at least 325 cubic feet of room space is required. The
amount of coolant in the appliance is stated on the data plate on the back of the appliance. It is
hazardous for anyone other than an authorized Service Person to carry out servicing or repairs
to this appliance.
Take serious care when handling, moving, and using the appliance to avoid either damaging
the refrigerant tubing or increasing the risk of a leak.

5
Replacing component parts and servicing shall be done by factory authorized service
personnel so as to minimize the risk of possible ignition due to incorrect parts or improper
service.
DANGER! Risk of child entrapment!
When you dispose of the appliance, take off the door and leave the shelves in place so that
children may not easily climb inside.
Make sure the coolant circuit, particularly the heat exchanger at the back/bottom of the unit is
not damaged.
The recycle symbol on the product or its packaging indicates that this product
is not to be handled as normal household waste and it is to be taken to a
recycling collection point for electrical and electronic goods.
The appliance must be positioned so that the plug is accessible after
installation.
- SAVE THESE INSTRUCTIONS -

6
INSTALLATION INSTRUCTIONS
Before Using Your Appliance
Remove the exterior and interior packing.
Before connecting the appliance to the power source, let it stand upright for approximately 2
hours. This will reduce the possibility of a malfunction in the cooling system from handling
during transportation.
Clean the interior surface with lukewarm water using a soft cloth.
Installation of Your Appliance
This appliance is designed for free standing installation.
Leave at least 4" of space at the back, sides, and top of the unit to ensure adequate ventilation.
Place your appliance on a surface that is strong enough to support it when it is fully loaded. To
level your appliance, adjust the front leveling legs at the bottom.
Locate the appliance away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extremely cold ambient temperatures may also cause the unit not to perform
properly.
Avoid locating the unit in moist areas.
Plug the appliance into an exclusive, properly installed and grounded wall outlet. Do not under
any circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified and authorized
products service center.
Storage
For Model: STC6
This appliance can load 6 bottles whose diameter is less than 105mm.
For Model: STC12
This appliance can load 12 bottles whose diameter is less than 81mm.
Installation of drainage pipes
1. Remove the drain hose and pipe clamp from the accessory bag.
2. Install the drain hose, which is shown in Figure 1.
3. Set the drain hose onto the drain pipe that is reserved at the back of the product, as shown in
Figure 2.
4. Move the pipe clamp to the proper position and tighten the drain hose, as shown in Figure 3.

7
OPERATING YOUR APPLIANCE
Recommended temperatures for chilling wine
Red Wines: 15 ~ 18°C (59 ~ 64.4°F)
Dry / White Wines:9 ~ 14°C (48.2 ~ 57.2°F)
Sparkling Wines: 5 ~ 8°C (41 ~ 46.4°F)
The appliance should be placed where the ambient temperature is between 18 and 32°C (65
and 90°F). If the ambient temperature is above or below this range, the performance of the unit
may be affected. Placing your unit in extremely cold or hot conditions may cause interior
temperatures to fluctuate.
Connect power cord to a properly grounded outlet.
This appliance is equipped with Memory IC –should there be a power interruption, unit will
auto recover to the last setting.
Control Panel
Setting the temperature Control
Adjustable temperature: 5°C to 20°C (41°F to 68°F)
Set the desired temperature by pressing the corresponding buttons, to increase or to
decrease. Each press is a 1-degree increment or decrement. Once released, set temperature
will flash for approximately 5 seconds, then revert back to display the internal temperature.
To view your set temperature, press either the or button once and LED display will
flash set temperature for 5 seconds.
The appliance has the capability to display temperature in either Celsius or Fahrenheit. To
change the temperature scale, press and hold both buttons simultaneously for approx.
3 seconds.
Note: The temperature inside may vary slightly depending on whether or not the interior bulb is
ON or OFF and where the bottles are located.
ECO mode:
Press and hold the button for 3 seconds to enter or exit ECO mode.
In this mode, the interior LED light, the compressor indicator and the temperature value on
the display panel will be turned off and the symbol °will illuminate on the upper left corner of °C
/ °F.

8
Light / Lock
LED lamp brightness mode: with Memory IC (when unit restarts after power failure unit, will
auto recover to last setting), the default brightness is 100%.
Each time the button is pressed, the brightness of the LED will be cycled through the
four positions (100%, 75%, 50%, OFF)
Press and hold for 3 seconds to lock or unlock the control panel.
ON/OFF Power / Mute
To turn the appliance on or off, press and hold the ON/OFF button for 3 seconds.
When the high/low temperature alarm is activated, the buzzer will sound continuously. Press
one time to turn off the alarm.
LOCK
If illuminated, indicates the control panel is locked.
RUN
When unit’s compressor is running, this indicator light will illuminate to signify that cooling mode is
currently in operation.
Demo mode
Press and hold buttons , and simultaneously for 10 seconds to enter or exit
demo mode.
In this mode, the display panel can operate settings, but the temperature is a fixed display 12°C
(54°F) and all fans plus the compressor will not start.
Defrosting
The unit defrosts automatically in normal operating conditions.
The evaporator behind the rear wall of the unit defrosts automatically. Water will drain through
the drain pipe from the back of the product. Users need to bring the water to the drain or find an
appliance to load the water. (If loading with an appliance, you need to pay attention to clearing
the water regularly)
However, frost may accumulate on the evaporator if the unit is repeatedly opened in a high
heat or high humidity location. If this frost pattern does not clear within 24 hours, your unit will
require manual defrosting.
Mandatory defrost mode: Press the and at one time for 10 seconds to enter the
compulsory defrost mode.
NOTE:
If the unit is unplugged or turned off, or if there has been a power failure, you must wait 5
minutes before restarting the unit. If you attempt to restart before this time delay, the appliance
will not start.

9
When you use the appliance for the first time, or restart it after it has been shut off for a long
time, there could be a few degrees variance between the temperature you select and the one
indicated on the display. This is normal and due to the length of inactivation time. Once the
appliance has been running for a few hours, everything will be back to normal.
Temperature Alarm Function
If the ambient temperature is ≥30°C (86°F) for 2 hours, the high temperature alarm will be
activated, the LED will display "HH", the buzzer will sound continuously, the cooling system
continues to work. The display returns to normal when the high temperature condition is relieved.
If the ambient temperature is <0°C (32°F) for 1 hour, the low temperature alarm will be activated,
the LED will display "LL", the buzzer will sound continuously, the cooling system will stop working.
The display returns to normal when the low temperature is relieved.
NOTE:
It is normal that the cabinet shows “HH” or “LL” from time to time. If it occurs frequently or lasts
for a long time, you can restart the unit by unplugging it, then re-plugging after 5 minutes. If
the problem occurs again after restarting, please contact customer service.
Before reconnecting the power, wait 3 to 5 minutes. Otherwise you could damage your
appliance. If you attempt to start the appliance before the end of this time delay, the appliance
will not turn on.
If you turn on the appliance for the first time or after a restart, or after it has been out of
operation for a long time, there may be a temperature difference between the temperature
inside the appliance and that on the LED display. This is a normal event caused by the
duration of the activation period. Leave the appliance turned on for several hours and the
temperature will stabilize during operation.

10
CARE AND MAINTENANCE
Cleaning Your Appliance
1. Turn off the power, unplug the appliance, and remove all items.
2. Wash the inside surfaces with a warm water and baking soda solution. The solution should
consist of about 2 tablespoons of baking soda to a quart of water.
3. Wring excess water out of the sponge or cloth when cleaning the area of the controls or any
electrical parts.
4. Wash the exterior of the cooler with a warm solution of mild liquid detergent. Rinse well and
wipe dry with a clean soft cloth.
Power Failure
Most power failures are corrected within a few hours. If your power is going to be off for a longer
period of time, you need to take the proper steps to protect your contents.
Transporting Your Appliance
If you need to move your appliance once the box has been discarded:
1. Securely tape down all loose items inside your appliance.
2. Turn the adjustable legs up to the base to avoid damage.
3. Be sure the appliance stays secure in the upright position during transportation. Also protect
the outside of the appliance with a blanket or similar item.
Energy-Saving Tip
The appliance should be located in the coolest area of the room, away from heat-producing
appliances and out of direct sunlight.
CALIFORNIA CARB/SNAP DISCLOSURE For products manufactured after January, 1, 2019:
*Retail food refrigeration equipment manufactured after January 1, 2019, designed to store and display chilled
goods for commercial sale, and that use HFC-134a/R134a refrigerant are not for sale in California.
**This product uses eco-friendly hydrocarbon refrigerant and fully complies with California CARB regulations.
However, we are required by California Law to provide the previous disclosure statement in every product sold
in California.
This equipment is prohibited from use in California with any refrigerants on the 'List of Prohibited Substances' for
that specific end-use, in accordance with California Code of Regulations, title 17, section 95374. This disclosure
statement has been reviewed and approved by Felix Storch, Inc. and Felix Storch, Inc. attests, under penalty of
perjury, that these statements are true and accurate.
This product does not use any refrigerants on the “List of Prohibited Substances.”

11
PROBLEMS WITH YOUR APPLIANCE
You can solve many common problems easily, saving you the cost of a possible service call. Try
the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM
POSSIBLE CAUSE
REMEDY
Appliance does
not operate.
The unit defrosts automatically in normal
operating conditions.
The appliance is turned off.
Tripped circuit breaker or a blown fuse.
Connect the appliance.
Switch on the appliance.
Switch on the circuit breaker or
replace the fuse.
Appliance is not
cold enough.
The temperature is not set correctly.
The ambient temperature could require a
lower temperature setting.
The condenser is too dirty.
The ventilation opening is blocked or too
dusty.
Check the set temperature.
Set a lower temperature.
Clean the condenser when
necessary.
Clear the obstructions and wipe off
the dust.
Appliance turns
itself on and
off frequently.
The room temperature is higher than
average.
A large number of bottles has been
added to the unit.
Put the appliance in a cooler place.
Leave the appliance to work for a
while until the set temperature has
been reached.
The light does
not work.
Appliance is not connected to a power
supply.
Tripped circuit breaker or a blown fuse.
The light was switched off on the control
panel.
Connect the appliance.
Switch on the circuit breaker or
replace the fuse.
Switch on the light.
Vibrations
The appliance is not properly level.
Level the appliance with the
adjustable feet.
The appliance
seems to
make too
much noise.
The rattling noise may come from the flow of the refrigerant, which is normal. As each
cycle ends, you may hear gurgling sounds caused by the flow of refrigerant in your
appliance.
If temperature fluctuations occur, the contraction and expansion of the inner walls may
cause popping and crackling noises.
The appliance is not properly level.
Level the appliance with the
adjustable feet.
Display “E1”,
“E2”.
“E1”or “E2”indicates that the air
temperature sensor has failed.
Call for service.
NOTE: This appliance is intended to be used exclusively for the storage and display of wines in
restaurants, hotels, bars and other commercial settings.

12
LIMITED WARRANTY
WARNING: This product can expose you to chemicals including Nickel (Metallic)
which is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov
Note: Nickel is a component in all stainless steel and some other metallic compositions.
ONE-YEAR LIMITED WARRANTY
Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and
maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts
and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service
company. Outside the 48 states, all parts are warranted for one year from manufacturing defects. Plastic parts and
cabinets are warranted to be manufactured to commercially acceptable standards, and are not covered from damage
during handling or breakage.
5-YEARS COMPRESSOR WARRANTY
1. The compressor is covered for 5 years.
2. Replacement does not include labor.
ITEMS WARRANTOR WILL NOT PAY FOR:
1. Service calls to correct the installation of your appliance, to instruct you how to use your appliance, to replace or
repair fuses or to correct wiring or plumbing.
2. Service calls to repair or replace appliance light bulbs. Consumable parts (such as filters) are excluded from
warranty coverage.
3. Damage resulting from accident, alteration, misuse, abuse, fire, flood, acts of God, improper installation, installation
not in accordance with electrical or plumbing codes, or use of products not approved by warrantor.
4. Replacement parts or repair labor costs for units operated outside the United States.
5. Repairs to parts or systems resulting from unauthorized modifications made to the appliance.
6. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in
accordance with published installation instructions.
DISCLAIMER OF IMPLIED WARRANTIES –LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALLBE PRODUCT REPAIR AS PROVIDED
HEREIN. IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, ARE LIMITED TO ONE YEAR. WARRANTOR SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES. SOME STATES DO NOTALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR LIMITATIONS ON THE DURATION OF IMPLIEDWARRANTIES OF MERCHANTABILITY OR FITNESS, SO THESE EXCLUSIONS
OR LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER RIGHTS, WHICH VARY FROM STATE TO STATE.
FELIX STORCH, INC.
770 Garrison Avenue
Bronx, NY 10474
Phone: [phone]
Fax: [phone]
www.summitappliance.com
For parts and accessory ordering,
troubleshooting and helpful hints, visit:
www.summitappliance.com/support
Printed in China
