Sunco WRAPAROUND 5" User manual

www.suncolighting.com
[phone] CUSTOMER SERVICE
[email protected]
SALES
[email protected]
163 W Cochran St,
Simi Valley, CA 93065
Still having trouble? Contact us!
SUNCO’S WRAPAROUND 5”
Install Guide and Manual
EASY INSTALLATION Junction Box Installation
Turn off circuit breaker that provides power to
the light switch for the recessed lights.
If replacing a fixture, remove existing fixture and
make a sketch of wiring configuration (by color) or
mark wires with masking tape for identification.
Remove the diffuser from the lamp base.
Open the junction box and take out the cables
from the lamp base, connect the wires:
•Live to Live (black);
•Neutral to Neutral (white);
•Ground to Ground (yellow/green).
Secure the wires with the wire nuts, and fold
them into the junction box.
Mounting surface must be able to support
the weight of the fixture.
Depending on your lighting plan, space the
fixtures accordingly.
•Link up to 4 Fixtures.
Install the two screws (AA) into the junction
box.
Leave 1/4” of screws exposed to accommodate
lamp base.
Attach the Lamp Base to the junction box by
aligning the holes on the Lamp Base with the
screws on the junction box.
Turn Lamp Base clockwise to lock into place
and tighten screws to ensure the fixture is
secure.
Turn Power OFF
1.
4.
6.
7.
2.
3.
5.
8.
9.
Wattage
Voltage
Suitable for Locations Ingress
Lumens
40W
120/277V
Damp
4500
Weight
Warranty
3.50lbs
7 years
SPECIFICATION
WARNING
10.
11.
AA
Junction
Box
A
A
Required Tools: Drill, Ladder, Tape
Measure, Pencil, Stud Finder
All electrical connections must be in accordance with local and
National Electric Code (N.E.C.) standards. Consult a qualified electrician
if you are unfamiliar with proper electrical wiring connections. Please
review instructions carefully before proceeding.
WARNING: Risk of fire or electric shock. Don’t alter, relocate or remove
wiring during installation. Don’t install directly over a heat source.
NOTE: When first turned on wait about 1 minute for the circuitry
to calibrate. Not for use with dimmers.
F
a
bc
Put the diffuser (cover) back on
a) Align one end then slowly press down;
b) Push the diffuser to the corner of the lamp base;
c) Lock the diffuser with the aluminium base.
Turn on circuit breaker and the test light.
2.
1.
3.
LINKING INFORMATION
Use provided linking cords to connect multiple
fixtures to one outlet;
Link up the 8 Fixtures;
For protection, place plastic end caps on the ends
of any final fixtures in the linking line.
2.
1.
3.

www.suncolighting.com
[phone] CUSTOMER SERVICE
[email protected]
SALES
[email protected]
163 W Cochran St,
Simi Valley, CA 93065
Still having trouble? Contact us!
SUNCO’S WRAPAROUND 5”
Install Guide and Manual
Sunco is proudly based in the USA, offering quality products
at affordable prices backed by industry-leading warranties.
EASY INSTALLATION Keyhole Installation
COMPONENTS
Turn off circuit breaker that provides power to
the light switch for the recessed lights.
If replacing a fixture, remove existing fixture and
make a sketch of wiring configuration (by color) or
mark wires with masking tape for identification.
DRYWALL MOUNTING
If the mounting holes go through drywall without a stud,
drill four small pilot holes by a 1/8” drill bit (not included)
and install wall anchors (DD) into the holes with a
hammer (not included).
Install the four wood screws into the mounting surface
but leave about a 3/8” gap between the screw head and
mounting surface.
Use a screwdriver to punch out one of the
knocked holes and take out the cables from
the lamp base.
Mounting surface must be able to support
the weight of the fixture.
Remove the diffuser from the lamp base.
Attach the Lamp Base by aligning the
knockout holes on the Lamp Base with the
mounting location.
Mark the 4 keyhole slots at each end of the
housing.
WALL SETUP MOUNTING
If the mounting holes go through wall studs, drill four
small pilot holes using a 5/32” drill bit (not included) for
the wood screws.
Install the four wood screws into the mounting surface
but leave about a 3/8” gap between the screw head and
mounting surface.
Turn Power OFF
1.
4.
6.
2.
3.
5.
7.
8.
Required Tools: Drill, Ladder, Tape
Measure, Pencil, Stud Finder
Remove the shrink wrap from the end of the
wires, connect to the supply wires using the
wire nuts provided.
•Live to Live (black);
•Neutral to Neutral (white);
•Ground to Ground (yellow/green).
2.
1.
3.
Insert the four screws into the keyhole slots and
slide the lamp base (a) in the direction in which
the screw heads rest over the narrow part of the
keyhole slot.
Once the fixture is supported, tighten the screws
until the fixture is secured to the mounting surface.
Add C washer for extra protection - not included.
9.
Take out the
cables
Mark these locations
(mounting surface)
Drywall
Drywall mounting Wall stud mounting
Pilot hole
Wall stud
10.
a
bc
Put the diffuser (cover) back on
a) Align one end then slowly press down;
b) Push the diffuser to the corner of the lamp base;
c) Lock the diffuser with the aluminium base. 2.
1.
3.
Turn on circuit breaker and the test light.
11.
Wire nuts
Turn Power ON
2x
Screws
3x
Wire Nuts
4x
Wood Screws
4x
Wall Anchors
2x
End Caps
2x
Linking Cables
