Installation Manual

for SunEdison SilvantisTM 72-cell Photovoltaic Modules

Silvantis P300 Silvantis M330/F330/D330

Table of Contents

1.0 INTRODUCTION............................................................................................................................. 2

2.0 PHOTOVOLTAIC MODULES PRODUCT CODE....................................................................... 2

3.0 MODULE OVERVIEW.................................................................................................................... 2

3.1 MAINTENANCE................................................................................................................................ 2

3.2 STORAGE, UNPACKING, AND HANDLING......................................................................................... 3

3.3 SAFETY........................................................................................................................................... 3

4.0 MECHANICAL INSTALLATION................................................................................................... 4

4.1 PLANNING AND DESIGN.................................................................................................................. 4

4.2 MODULE INSTALLATION OPTIONS FOR MOUNTING LOCATIONS...................................................... 4

4.3 MODULE INSTALLATION USING CENTER MOUNTING BRACKETS.................................................... 4

4.4 MECHANICAL INSTALLATION WARNINGS........................................................................................ 7

4.5 ADDITIONAL MOUNTING METHODS................................................................................................ 7

5.0 ELECTRICAL INSTALLATION....................................................................................................... 8

5.1 PLANNING AND DESIGN.................................................................................................................. 8

5.2 MODULE WIRING............................................................................................................................. 8

5.3 GROUNDING.................................................................................................................................... 9

5.3 OPTION A: METAL LUG....................................................................................................................10

5.3 OPTION B: RACKING MANUFACTURER INTEGRATED GROUNDING METHODS ...................................11

5.3 OPTION C: BOLT WIRE ASSEMBLY....................................................................................................11

5.3 OPTION D: ALTERNATIVE GROUNDING............................................................................................12

5.4 ELECTRICAL INSTALLATION WARNINGS...........................................................................................12

6.0 DISCLAIMER OF LIABILITY.......................................................................................................... .12

7.0 MECHANICAL AND ELECTRICAL PARAMETERS AND SPECIFICATIONS........................ 13

7.1 SILVANTIS P300 DETAILS.................................................................................................................. 13

7.2 SILVANTIS M330/F330/D330 DETAILS................................................................................................ 14

8.0 APPENDIX......................................................................................................................................15

8.1MODULEDETAILS.................................................................................................................................15

8.2 CENTER CLAMP MODULE INSTALLATION ILLUSTRATIONS...............................................................16

8.3 MODULE CLAMP DRAWINGS............................................................................................................16

8.4PRE-MOUNTEDCABLESANDCONNECTORS.......................................................................................17

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

Customer Service

SunEdison Products Singapore PTE. LTD.

11 Lorong 3 Toa Payoh

Block B Jackson Square 4th Floor

Singapore 319579

Fax: (65) 6681-9301

Email: [email protected]

Website: www.sunedison.com

1 of 17

1.0 INTRODUCTION

The purpose of this guide is to provide general information regarding the proper installation and handling of SunEdison

photovoltaic modules that serve residential, commercial, and industrial segments. System design, construction, and

commissioning should be performed by qualified personnel only.

To ensure system integrity, designers, installers and operators must meet all mechanical and electrical requirements for

the system and its components. It is the responsibility of the system designer and installer to ensure that all codes and

requirements are followed as well.

Please review all the sections that pertain to proper installation of modules listed in this guide. The instructions detailed in

this guide must be followed throughout the module’s lifetime deployment. If you need additional information about the safe,

proper use and handling of SunEdison photovoltaic module products, please contact SunEdison.

2.0 PHOTOVOLTAIC MODULES PRODUCT CODE

3.0 MODULE OVERVIEW

SunEdison Silvantis Photovoltaic modules consist of a series of electrically interconnected crystalline silicon solar cells that are

sealed within a laminated sheet of tempered glass superstrate* and EVA/back-sheet substrate. These laminates are secured

inside an aluminum frame to provide rigidity and a means for attachment to mounting sub-structures. The frames should not

be modified or removed. * Tempered glass may have AR coating.

• Photovoltaic modules are designed and constructed for outdoor use. Do not submerge modules in water at any time.

• The front and back of each module is labeled with a product bar code. Do not cover, remove or deface these labels.

This may be required for product identification.

• Damage to the glass surface or the anti-reflective coating can impact the power output and overall efficiency of the

system. Scratches, handling marks, or any damage to the glass surface must be avoided.

• For best performance and to avoid potential issues, keep the front side of the module clean and free of obstructions

including covers, tape, adhesives, paint and debris.

3.1 MAINTENANCE

Check modules, glass, and frames for damage. Regularly inspect all SunEdison solar modules for safe electrical connections,

sound mechanical connections, and freedom from shading and corrosion. If dirt or debris buildup becomes excessive,

periodically clean the glass only with a soft cloth using mild, non-abrasive detergent and water. When using mild cleaning

liquids, a neutral pH in the range of 6.0 to 8.0 is recommended. Chemicals with pH less than 6.0 or greater than 8.0 should

be avoided as it may damage the glass surface and or the AR coating. Please consult with system designer to decide the

cleaning and inspection frequency according to local environmental conditions.

Do not power wash or use harsh cleaning materials or objects such as scouring powder, steel wool, scrapers, blades, or other

sharp instruments to clean the glass surface of the module. Use of such materials will invalidate the product warranty.

WARNING: Use caution when cleaning the back surface of the module to avoid penetrating the substrate materials.

2 of 17

P280ByC P285ByC P290ByC P295ByC P300ByC P305ByC

M310ByC M315ByC M320ByC M325ByC M3330ByC M335ByC

F310ByC F315ByC F320ByC F325ByC F330ByC F335ByC

D310ByC D315ByC D320ByC D325ByC D330ByC D335ByC

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

SilvantisTM P300

Multicrystalline Modules

SilvantisTM M330

Monocrystalline Modules

SilvantisTM F330

Monocrystalline Modules

SilvantisTM D330

Monocrystalline Modules

3.2 STORAGE, UNPACKING, AND HANDLING

• Packaged modules must be stored in a dry and ventilated area.

• Packaged modules must not be exposed to rain, snow, hail or other environmental conditions that may compromise the

packaging material and the modules.

• Packaged modules must be on appropriate provided pallets and must not be stacked more than two pallet high for

storage.

• Once the modules are opened, store modules in a dry and ventilated room.

• Modules should never be stored in a wet environment.

• Upon unpacking, do not carry a module by its wires or junction box. Only carry a module by its frame with two or more

people.

• Precaution should be taken to avoid damage to the glass surface with or without anti-reflective coating due to improper

handling during storage or unpacking.

• Keep all electrical contacts clean and dry.

• All modules are manufactured with a sealed junction box and pre-attached cables and locking connectors. These

components should not be modified or tampered with in any way.

• Do not allow unauthorized persons near the installation site or storage area of modules.

• Do not place modules on top of one another.

• Do not place any load on the module or twist the module frame.

• Do not stand, step, walk, or jump on the module.

• Do not drop or place objects on the modules such as tools.

• Do not handle modules with bare hands and avoid scratches, handling marks or any damage, especially to the front

glass of the module, backsheet, or electrical components.

• Do not mark the modules with sharp instruments.

• Do not leave a module unsupported or unsecured.

• Do not modify module frames in any way.

3.3 SAFETY

The following safety guidelines and best practices should be followed:

• All installations must be performed in compliance with all applicable regional and local electrical codes or other national

or international electrical standards.

• Use insulated tools during installation, troubleshooting and maintenance of photovoltaic modules.

• Wear suitable protection to prevent direct contact with module’s electrical output and mechanical sharp edges.

• Cover the front of the modules with an opaque material to stop production of electricity when installing or working with

a module or wiring.

• Modules connected in a series should not be disconnected under illumination. Disconnecting modules under

illumination may cause electrical arcing which may result in burns, fires or other problems.

• Follow industry best practices when commissioning, troubleshooting, disconnecting, or connecting a PV system.

• Troubleshooting should include planning, checking, disconnecting, cause seeking, replacement, and record keeping.

• Do not install or handle the modules or their components when they are wet or during periods of high wind.

• Do not attempt to disassemble, repair, or open any part of the module including junction box or sub-components.

• Do not artificially concentrate sunlight on a module.

• Do not install or handle any broken modules. If a module is broken, or the back sheet is torn, contact with the surface or

frame can cause an electrical shock.

• Do not wear rings, jewelry, watches, or other metallic items while working with photovoltaic modules.

3 of 17

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

4.0 MECHANICAL INSTALLATION

4.1 PLANNING AND DESIGN

• Before installation, check to ensure all sub-structure will accommodate expected system loads. This includes and is not

limited to roof, foundations, mechanical structure, and mechanical connections.

• For roof installations, utilize a fire-resistant roof covering rated for the application.

• Mechanical structures should not contact the module backsheet under any expected load conditions

• Consider the following factors during system design, which will influence performance:

a) SunEdison solar modules produce the most power when they are pointed directly at the sun, and should be tilted for

optimum system performance.

b) Proximity to obstructions such as: walls, buildings, trees, groundcover, snow cover, or dust and debris that have the

potential to shade or damage the modules.

c) Elevated temperatures will decrease energy yield, so designs should ensure adequate airflow across the back of the module.

d) Allow a minimum spacing of 10 mm between modules for thermal expansion.

4.2 MODULE INSTALLATION OPTIONS FOR MOUNTING LOCATIONS

For bolt and clamp mounting locations and allowable load capacities, please refer to Table on page 5.

• Each module should be mounted using four bolts through the mounting holes on the rear side of the module, or with four

clamps over the front side.

• Depending on the desired load capability of the array, modules may be mounted either perpendicular or parallel to the structure

rails. Clamps can be mounted anywhere inside of the safe mounting range for each case illustrated below in table 4.2A

• If using bolts, four mounting holes are provided on the rear side the module frame as shown in Appendix 8.1. Use a bolt

stack no smaller than ¼"-20 or M6, with two flat washers and a locking washer as shown in Appendix 8.2.

• To ensure an adequate clamping area, all clamps used must comply with the minimum clamping dimensions specified in

Appendix 8.3. All fasteners used to fix the modules with clamps should be no smaller than ¼”-20 or M6.

• To provide adequate fixing or clamping force, torque the minimum recommended fasteners to 6.2 - 8.9 N·m (4.6 - 6.6 ft·lb).

• All other structural dimensions, such as clamp and rail thickness, should be sized appropriately for the intended site load.

4.3 MODULE INSTALLATION USING CENTER MOUNTING BRACKETS

• Modules may also be mounted using center clamps as shown in Appendix 8.2, for use with trackers.

• Module clamps for center mounting must be based on SunEdison approved extrusion and hardware.

• For module loads higher than 2400 Pa, module clamps and hardware must be pre-approved by SunEdison.

• SunEdison approved center clamps utilizing M8 bolts are to be tightened to 9.2-11.9 N·m (6.8-8.8 ft·lbs).

4 of 17

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

CASE 3

5 of 17

MOUNTING CONFIGURATIONS

LOAD

PARAMETERS

CASE 1

Maximum

Rear Load:

2400 Pa

or 50 psf

Maximum

Front Load:

5400 Pa

or 113 psf

Mounting Color Code: Mounting Hole Location Module Rail Fixed Clamp Mount Clamp Mount Range

A – 394 mm

B – 248 mm

C – 444 mm

Fixed Clamp Mount location:

Clamp mount allowable range:

Clamp Mount

Locations:

Fixed clamp

location for

5400 Pa

front load

Clamp Mount Locations:

Clamp mount allowable range

Case 3, option 1

FRONT VIEW

BACK VIEW

CASE 2

DETAILS

Maximum

Rear Load:

2400 Pa

or 50 psf

Maximum

Front Load:

5400 Pa

or 113 psf

Maximum

Rear Load:

2400 Pa

or 50 psf

Maximum

Front Load:

2400 Pa

or 50 psf

CASE 1: Structural rails

running perpendicular to

the length of the module

should be fixed via bolts at

the mounting holes between

each long side frame, or

Clamps can be mounted

at the Fixed Clamp Mount

location as shown in the

color code key.

CASE 2: Structural rails

running parallel to the

length of the module should

be fixed via bolts at the

mounting holes on each

long side frame, or Clamps

can be mounted anywhere

within the Clamp Mount

Range as shown in the color

code key.

CASE 3: Structural rails

running perpendicular to the

length of the module should

be fixed via bolts at the

mounting holes between each

long side frame, or Clamps

can be mounted anywhere

within the Clamp Mount

Range as shown in the color

code key.

MODULE

ILLUSTRATION

Bolt Mount

Locations

BACK VIEW

FRONT VIEW

Bolt Mount

Locations

Clamp Mount

Locations:

Clamp mount

allowable

range

BACK VIEW

OR Case 3, option

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

CASE 3

6 of 17

MOUNTING CONFIGURATIONS

Mounting Color Code: Clamp Mount Range

D - 305 mm

E - 610 mm

Clamp mount allowable range:

Maximum

Rear Load:

2400 Pa or 50 psi

Maximum

Front Load:

5400 Pa or 113 psi

CASE 4: A structural rail

running perpendicular to

the length of the module

should be fixed between

each long side frame.

Clamps can be mounted

at the Fixed Clamp Mount

location as shown in the

color code key.

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

CENTER MOUNT CLAMPING

(AP90/ATI TRACKERS ONLY)

5 of 16

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

Center Mount Clamping (AP90/ATI Trackers Only) Maximum

Rear Load:

2400 Pa or 50 psi

Maximum

Front Load:

5400 Pa or 113 psi

CASE 4

Module Color Code:Module Color Code: Clamp Mount Range

CLAMP MOUNT

LOCATIONS

MOUNTING CONFIGURATIONS LOAD PARAMETERS

Clamp

Locations

Version 17

D–305 mm

E– 610 mm

Clamp mount allowable range:

CASE 4:A structural rail

running perpendicular to

the length of the module

should be fixed between

each long side frame.

Clamps can be mounted

at the Fixed Clamp Mount

location as shown in the

color code key.

BACK VIEW

4.4 MECHANICAL INSTALLATION WARNINGS

• Installation and maintenance should be performed by qualified personnel only.

• Use insulated tools during installation, troubleshooting and maintenance of photovoltaic modules.

• Installers should adhere to all applicable local, regional, and national codes and regulations when designing and

constructing the photovoltaic system.

• Do not stand or walk on any surface of the modules. Do not place any objects or load on the surface of the modules.

• Precaution should be taken to avoid damage to the glass surface with or without anti-reflective coating due to improper

handling during installation.

• Mechanical structures should not contact the module backsheet under any expected load conditions.

• Additional mounting holes may not be drilled in the frame, glass or backsheet.

• Ensure that frame weep holes (see Appendix 8.1) are not obstructed by the mechanical installation.

• Mechanical installation of the module shall not cause the frame to torque more than 1 1/2".

4.5 ADDITIONAL MOUNTING METHODS

Use of the PanelClaw system (Part Number 500000501 and 500000701) is permitted with SunEdison solar PV modules.

Structures manufactured by PanelClaw Inc. use a special clamp, or "claw" designed to attached to the flange

of the PV module at all four corners, on the two short frame ends. PanelClaw is ULcertified for electric

bonding and grounding. See the PanelClaw installation guide for proper grounding management. For proper placement,

attach a claw over the module frame flange at each of the four designated locations and tighten the screw so that the

claws are flush with the long and short ends of the module flange. This mounting method has been tested to a maximum

rating of 50 psf in the negative and positive direction. See case two and three from above as well as the PanelClaw installation

guide for information on the installation of the clamps. The PanelClaw should only be used on modules with flanges of 30 mm.

Use of the SunEdison AP90 Single Axis Tracker is authorized for use as well. Please refer to the AP90 installation guide for

specific instructions. Installation guides can be found on the SunEdison website www.sunedison.com

7 of 17

Figure 1: Illustrations of the Panel Claw

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

5.0 ELECTRICAL INSTALLATION

5.1 PLANNING AND DESIGN

• All modules are manufactured with a sealed junction box and pre-attached cables and locking connectors. These

components should not be modified or tampered with in any way.

NOTE: Installers shall ensure that the polarized locking connectors are from the same supplier when connected on the

same string. Do not mix polarized interlocking connectors from different manufacturers—including connections at the

inverter, combiner boxes, and modules. Doing so will void the warranty. Refer to section 8.4 for connector types.

• Ensure connectors are clean and dry before establishing connection.

• Ensure that all wire, fusing and disconnects are appropriately sized for the system design according to national,

regional, and local codes.

• Electrical characteristics are within plus or minus 5% of rated values for Isc, Voc, Impp and Vmp. Pmax ranges between

-0/+5W at standard test conditions (STC). However, modules will operate under conditions which may be significantly

different than STC. SunEdison suggests multiplying specified ratings by a minimum of 1.25 or more when specifying

the system and balance of system components. Refer to local codes before planning and design of the system.

• Determine the maximum number of modules connected in series using the following formula: Ns = Vmaxs / Vocm

Where:

Nsequals the maximum modules in series

Vmaxsequals the maximum system voltage

Please refer to module data sheet for actual Vmax rating, as some models are rated for 1000 V UL and 1000 V

IEC.

Vocmequals the module open circuit voltage at coldest conditions for the site (refer to local codes)

WARNING: Installers shall adhere to all applicable local, regional, and national codes and regulations when designing

and constructing the photovoltaic system.

NOTE: In colder climates, it may be necessary to further reduce the maximum number of modules in series by using

Vocmat the minimum expected operating temperature.

5.2 MODULE WIRING

• The module includes wires and polarized locking connectors from the junction box on the back of the module. Field

replacement of connectors or cables must be avoided and it will invalidate the product warranty. Polarized locking

connectors of the same type and make are needed for all series string wiring. The maximum operating temperature of

wires and connectors should not exceed 85ºC.

• When installing panels in landscape orientation, use of the 1.3 meter lead lengths will ensure enough cable length to

make adjacent, module-to-module, string connections, assuming a maximum spacing of 50 mm between adjacent

modules.

• When installation panels in portrait orientation, use of the .55 or 1.0 meter lead lengths will ensure enough cable length

to make adjacent, module-to-module, string connections, assuming a maximum spacing of 50 mm between adjacent

modules.

8 of 17

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

9 of 17

• Always wire modules so that proper polarity is maintained. Avoid placing excessive tension on the cables.

• There is no limit to the maximum number of series strings that can be combined in parallel. However, when doing so,

each string must include overcurrent protection with a maximum rating of 15A. SunEdison recommends the use of DC

rated fuses or overcurrent protection devices with the appropriate maximum voltage rating.

• Do not connect modules directly to a parallel bus.

• The cross-sectional area of cable and the connector type must be selected to align with the overall system design

and should include the maximum short circuit current of the system, maximum operating temperatures, and cable run

lengths.

• For field connections, use at a minimum #12 AWG/4 mm2wires insulated for a minimum of 85°C. Use copper wire only.

5.3 GROUNDING

The frame of the PV module as well as any exposed metal components that can become energized by the PV system

MUST be connected to an equipment grounding connector to prevent electrical shock. Refer to section 250 of the

NEC for specific instructions on grounding. Even when local regulations, codes, or standards do not require safety

related grounding, SunEdison highly recommends grounding all PV module frames in order to maintain a zero-voltage

potential between electrically conductive equipment and the earth in all scenarios. Proper grounding is obtained by

bonding all exposed metal equipment to each other by using a properly sized equiptment grounding conductor (EGC).

SunEdison PV modules use a coated aluminum frame for corrosion resistance. In order to ensure proper grounding

the coating must be punctured by the grounding method. A grounding wire composed of copper with a minimum

guage of 12 AWG is recommended to carry the electrical ground load. Consult applicable codes to see if a larger

diameter conductor is required. The potential for corrosion due to the electrochemical reaction between two

dissimilar metals in contact is minimized if the voltage potential between the two metals is low. The grounding

method must not allow for the direct contact of dissimilar metals with the frame of the module, which would result in

galvanic corrosion. UL 1703 recommends metal combinations not exceed a voltage potential of 0.5 Volts.

The frame has predrilled holes marked with a grounding sign as illustrated below. These holes should be used

exclusively for grounding purposes, and may not be used for any other purpose. Do not drill additional holes or

modify existing holes in the frame.

WARNING: Only negative grounding circuits (negative polarity to ground) shall be used within the array design.

Transformerless inverters with floating grounding are not acceptable.

Figure 2: Image of the grounding holes

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

5.3 OPTION A: METAL LUG

SunEdison recommends using a copper or tin plated grounding lug that is rated for outdoor use and uses no smaller than a #12

wire. The use of a copper split bolt connector is authorized for use as well.

• Attach the grounding lug to the frame as follows and shown below in Figure 3:

Step 1: Uses stainless steel metric/english set only. The following is the minimum hardware metric (left) and english (right) required

by SunEdison.

Step 2: Place the grounding lug over the grounding hole on the exterior of the module frame.

Step 3: Place a star washer directly between the bottom of the grounding lug and the exterior surface of the frame.

Step 4: Place a bolt through the lug, star washer and frame grounding hole.

Step 5: Secure the lug to the frame using a flat washer, split washer and nut.

Step 6: Torque the bolt stack to approximately 1.5-2.3 N·m (or 1.1-1.7 ft·lbs) to ensure the star washer scratches the anodized

frame.

10 of 17

METRIC SET

- Stainless Steel Bolt M4

- Stainless Steel Nut M4

- Stainless Steel Flat Washer M4

- Stainless Steel Spring Washer M4

- Stainless Steel Lock-Toothed Washer M4

- Stainless Steel Slotted Washer M4

ENGLISH SET

- Stainless Steel Bolt #8-32

- Stainless Steel Nut #8-32

- Stainless Steel Flat Washer #8-32

- Stainless Steel Spring Washer #8-32

- Stainless Steel Lock-Toothed Washer #8-32

- Stainless Steel Slotted Washer #8-32

Figure 3: Grounding Lug Assembly

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

5.3 OPTION B: RACKING MANUFACTURER INTEGRATED GROUNDING METHODS

SunEdison modules can be grounded by bonding PV modules to a grounded racking system. Integrated grounding methods

must be appropriately certified to UL standards and must be in accordance with the specified instructions of the respective

manufacturer. SunEdison recommends using the BURNDY WEEBs integrated rack grounding, part numbers WEEB-ADC and

WEEB-ADR. These devices use 304 stainless steel and electrically grounds the module to the supporting structure and contain

specialized teeth to penetrate anodized aluminum for a proper electrical connection to the supporting structure. Should you choose

a rack integrated method that is not approved by UL please contact SunEdison before proceeding to determine compatibility.

5.3 OPTION C: BOLT WIRE ASSEMBLY

1. A grounding bolt assembly, of at least minimum reccommended size (see Option A) must be attached at one of the designated

aforementioned grounding hole locations. Using only stainless steel hardware, insert a stainless steel bolt first through the

stainless steel cup washer, and then through the grounding hole.

2. Loosely add a stainless steel backing nut and a toothed lock washer to the bolt.

3. Bend the EGC into an Omega (Ω) shape to tightly fit between the partially installed bolt head and cup washer. The EGC shall be

exclusively in contact with the steel.

4. Tighten the bolt to approximately 35 in·lbf (4 N·m) of torque. The toothed washer must penetrate the coated aluminum.

5. Route the correctly sized EGC wire in such a way to avoid contact with the module's frame.

11 of 17

Figure 4: Grounding Lug Assembly

Figure 5: Bolt Wire Assembly

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

12 of 17

5.3 OPTION D: ALTERNATIVE GROUNDING

• All other code compliant frame grounding methods that are certified to UL contact SunEdison for approval.

5.4 ELECTRICAL INSTALLATION WARNINGS

• Installation and maintenance should be performed by qualified personnel only.

• Use insulated tools during installation, troubleshooting and maintenance of photovoltaic modules.

• Installers should adhere to all applicable local, regional, and national codes and regulations when designing and

constructing the photovoltaic system.

• Photovoltaic modules produce DC electrical energy from light. When illuminated, each module can have a DC potential

of greater than 45V and should be handled with care.

• Disconnecting modules under illumination may cause electrical arcing which may result in burns, fires, or other

problems. Modules connected in series should not be disconnected under illumination.

• Always use a wire management system that keeps wires and cables out of direct contact with edge surfaces which

could cut or damage the insulation. Do not allow wires to rest on the ground or roof surface.

• The module junction box should not be opened or modified in any way in the field.

• Do not use mirrors, lenses, or other techniques to magnify or concentrate additional light on the module.

6.0 DISCLAIMER OF LIABILITY

The information in this manual is based on SunEdison’s knowledge and experience and is believed to be accurate. However, all

information in this manual (without exception) including recommendations and specifications does not constitute a warranty,

expressed or implied. SunEdison reserves the right to change the manual, the module, or specifications without prior notice.

The product warranty shall be VOID if handling and installation of the product does not conform to SunEdison’s written

installation instructions, or if the product has been reworked, repaired or otherwise modified in a manner not previously

authorized by SunEdison in writing, or if the product is installed in an environment for which it was not designed. SunEdison

shall not be liable for special, indirect, consequential, contingent or incidental damages related to or arising from the

installation or use of the product by purchaser under any circumstances.

SunEdison assumes no responsibility for any product application or use which is beyond SunEdison’s direct control.

SunEdison does not accept responsibility and expressly disclaims liability for loss, damage, or expense arising out of or in any

way connected to such installation, operation or maintenance of the product.

International Product Certifications:

IEC 61215, IEC 61730, CE, UL 1730, and Safety Class II certifications ensure that SunEdison solar products operate safely and

comply with global electrical, performance, reliability, and fire safety codes.

Certification

• IEC 61215 certified by TÜV SÜD

• IEC 61730 certified by TÜV SÜD to ensure electrical safety

• Stringent outgoing quality acceptance criteria benchmarked to industry standards

• UL1703 listed by CSA for US and Canada

Environmental AB8 (-50°C to +40°C)

Fire Resistance Rating Class C

SunEdison Modules are certified by:

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

13 of 17

7.0 MECHANICAL AND ELECTRICAL PARAMETERS AND SPECIFICATIONS

7.1 SILVANTIS P300 DETAILS

ELECTRICAL CHARACTERISTICS

All electrical data at STC: 1000 W/m2, AM1.5, 25ºC

Electrical characteristics measurement tolerance is ±5% and power is -0/+5W

y indicates manufacturing location: M = Malaysia, C = Canada, D = Europe, T = Taiwan, P = PRC, X = Mexico

TEMPERATURE COEFFICIENTS AND PARAMETERS

Temperature coefficients may vary by ±10%

IV CURVES AT MULTIPLE TEMPERATURES [1000 W/m2]

Current (A)

Voltage (V)

1050

15 20 25 30 35 40 45 50

15°C

25°C

35°C

45°C

P280BMC P285BMC P290BMC P295BMC P300BMC P305BMC

P280BCC P285BCC P290BCC P295BCC P300BCC P305BCC

P280BDC P285BDC P290BDC P295BDC P300BDC P305BDC

SilvantisTM P300

Multicrystalline Modules

1000 W/m2800 W/m2

600 W/m2

400 W/m2

200 W/m2

IV CURVES AT MULTIPLE IRRADIANCES [25°C]

Current (A)

Voltage (V)

1050

15 20 25 30 35 40 45 50

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

46 ± 2

-0.45

-0.33

+0.5

-40 to +85

1000 (UL & IEC)

9.10

-0/+5

Nominal Operating Cell Temperature (NOCT) (°C)

Temperature Coefficient of Pmax (%/°C)

Temperature Coefficient of Voc (%/°C)

Temperature Coefficient of Isc (%/°C)

Operating Temperature (°C)

Maximum System Voltage (V)

Limiting Reverse Current (A)

Maximum Series Fuse Rating (A)

Power Range (W)

Model #

Rated Maximum Power Pmax (W)

Open-Circuit Voltage Voc (V)

Short Circuit Current Isc (A)

Module Efficiency (%)

Max Power Point Voltage Vmpp (V)

Max Power Point Current Impp (A)

P280ByC P285ByC P290ByC P295ByC P300ByC P305ByC

280 285 290 295 300 305

44.0 44.4 44.7 45.1 45.3 45.4

8.60 8.65 8.71 8.95 9.00 9.05

14.3 14.6 14.8 15.1 15.4 15.6

34.7 34.9 35.4 35.7 36.0 36.3

8.08 8.16 8.20 8.26 8.34 8.41

14 of 17

7.2 SILVANTIS M330/F330/D330 DETAILS

TEMPERATURE COEFFICIENTS AND PARAMETERS

Temperature coefficients may vary by ±10%

M310ByC M315ByC M320ByC

M325ByC M330ByC M335ByC

D310ByC D315ByC D320ByC

D325ByC D330ByC D335ByC

F310ByC F315ByC F320ByC

F325ByC F330ByC F335ByC

ELECTRICAL CHARACTERISTICS

All electrical data at standard test conditions (STC): 1000 W/m2, AM1.5, 25ºC

Electrical characteristics may vary by ±5% and power by -0/+5W

Listed specifications are subject to change without prior notice.

SilvantisTM M330

Monocrystalline Modules

SilvantisTM D330

Monocrystalline Modules

SilvantisTM F330

Monocrystalline Modules

y indicates manufacturing location: M = Malaysia, C = Canada, D = Europe, T = Taiwan, P = PRC, X = Mexico

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

Current (A)

Voltage (V)

1050

1000 W/m2

800 W/m2

600 W/m2

400 W/m2

200 W/m2

15 20 25 30 35 40 45 50

15°C

25°C

35°C

45°C

Current (A)

Voltage (V)

1050

15 20 25 30 35 40 45 50

IV CURVES AT MULTIPLE IRRADIANCES [25°C] IV CURVES AT MULTIPLE TEMPERATURES [1000 W/m2]

47.0 ± 2

-0.45

-0.33

0.05

-40 to +85

1000 (UL & IEC)

9.10

-0/+5

Nominal Operating Cell Temperature (NOCT)(°C)

Temperature Coefficient of Pmax (%/°C)

Temperature Coefficient of Voc (%/°C)

Temperature Coefficient of Isc (%/°C)

Operating Temperature (°C)

Maximum System Voltage (V)

Limiting Reverse Current (A)

Maximum Series Fuse Rating (A)

Power Range (W)

Model #

Rated Maximum Power Pmax (W)

Open-Circuit Voltage Voc (V)

Short Circuit Current Isc (A)

Module Efficiency (%)

Max Power Point Voltage Vmpp (V)

Max Power Point Current Impp (A)

M310ByC

F310ByC

D310ByC

M315ByC

F315ByC

D315ByC

M320ByC

F320ByC

D320ByC

M325ByC

F325ByC

D325ByC

M330ByC

F330ByC

D330ByC

M335ByC

F335ByC

D335ByC

310 315 320 325 330 335

45.3 45.7 45.9 45.9 46.2 46.4

9.16 9.23 9.26 9.27 9.28 9.29

15.8 16.1 16.4 16.7 16.9 17.1

36.2 36.6 37.0 37.3 37.7 37.9

8.57 8.63 8.72 8.72 8.77 8.85

8.0 APPENDIX

8.1 MODULE DETAILS

15 of 17

THE ENGINEERING DRAWING SHOWN BELONGS TO THE FOLLOWING

LISTED SILVANTIS MODULE SERIES: P300 & M/D/F330

A 990 39.0

B 1,976 77.8

C 50 2.0

D 30 1.2

E 22 0.9

Module Dimensions

Dimension MM INCH

F 950 37.4

G 1,188 46.8

H *(BMC) 1,000 39.4

Mounting Hole Spacing

Dimension MM INCH

Cable Length

PHYSICAL PARAMETERS

Module Weight (kg)G 22.0

Frame Material Anodized Aluminum

Glass (mm) 3.2 Tempered ARC glass

Connector S418 BizLink/Amphenol PV Connector

Cable length Tolerance - 2.5 mm + 52.5 mm

*(1,300 [51.2] option available upon request,

please contact your local sales representative

for more information)

Dimension tolerance range for:

A ±3 mm, B ±3 mm and C ±0.3 mm

H (BCC) 1,300 51.2

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

Bolt Stack Details

Center Mount Option

8.0 APPENDIX

8.2 CENTER CLAMP MODULE INSTALLATION ILLUSTRATIONS

8.3 MODULE CLAMP DRAWINGS

16 of 17

A 6.35 0.3

B 38 1.5

Module Clip Dimensions

Dimension MM INCH

Minimum Support Dimensions

C 50 2.0

D 15 0.6

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

8.0 APPENDIX

8.4 PRE-MOUNTED CABLES AND CONNECTORS

Mounting Configuration Pre-mounted cables Pre-mounted connectors

Type TUV – PV1-F & UL – PV wire locking polarized connectors

Cross section 4.0 mm² 4 mm dia.

Max. current 30 A at 85°C IEC 25 A and UL 20 A

Max. system voltage IEC 1000 V DC/ UL 1000 V IEC 1000 V DC/ UL 1000 V

Temperature rating -40°C to +90°C -40°C to +85°C

Qualification TUV 2PFG & UL PV wire EN 50521 & UL for PV sys

Module Model Number Connector Type

SE-MxxxByC-3w S418 BizLink PV Connector

SE-MxxxByC-3z Amphenol Helios H4 PV Connector

SE-DxxxByC-3w S418 BizLink PV Connector

SE-DxxxByC-3z Amphenol Helios H4 PV Connector

SE-FxxxByC-3w S418 BizLink PV Connector

SE-FxxxByC-3z Amphenol Helios H4 PV Connector

17 of 17

2013 M330/F330/D330 P290 Install Guide_32

States and certain other countries. All other trademarks mentioned in this document are the property of their respective owners. The use of the word partner does not imply a

partnership relationship between SunEdison and any other company.

w can be 4, 5, 6, 7, 8, 9

z can be A or B

For more information about SunEdison, please visit www.SunEdison.com.

Installation Manual: SunEdison Silvantis P300 | M330/F330/D330

This manual suits for next models

Table of contents
