Sunjoy 1203060001-A User manual


CountryofOrigin:Malaysia

























Foranyquestionsorissuesaboutourproduct
CallSunjoyCustomerService
1(866)578‐6569
8:00AMEST–8:00PMPST

ASSEMBLY INSTRUCTION
ITEM#: 1203060001-A

 2/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com



Pleasefollowthesimplestep‐by‐stepassemblyInstructions.
Checkandensurealltheparts,fittingsandhardwarearepresentbeforediscardinganypackaging. 
Oneortwopeoplearerequiredforthisassembly.
Pleasereadallinstructionscarefullybeforeassemblyandusage.Basicsafetyprecautionsshouldalways
befollowedtoreducetheriskofpersonalinjuryanddamagetoequipment.
Advisabletowearprotectiveglovesduringassembly.
Assemblethisproductontheflatsurface.
Assembleallpartslooselybeforetighteninganybolts. 
RetainthisAssemblyInstructionforfuturereference.








WHAT IS COVER？
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect
providedtheitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.

















Safety Information
CAUTION: Do not climb on top of the product. Falling off the product may result in
serious injury.
NOTICE: For indoor use only
Warranty: 1 Year
TOOLS NEEDED

 3/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com




KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.
ONEORTWOPERSONIS/ARENEEDEDFORTHEINSTALLATIONWORK.
IMPORTANT

 4/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
EXPLODED DRAWING

 5/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
PartsList 

Part Part Number Description Qty Part Image
#1 P21308A10015 Front Drawer Panel 1 2
#2(L) P21311B10015 Left Drawer Panel 1 2
#2(R) P21312B10015 Right Drawer Panel 1 2
#3 P21305C10015 Back Drawer Panel 1 2
#4 P21305D10015 Bottom Drawer Panel 1 2
#5 P21309A10015 Front Drawer Panel 2 2
#6(L) P21313B100115 Left Drawer Panel 2 2
#6(R) P21314B100115 Right Drawer Panel 2 2
#7 P21306C100115 Back Drawer Panel 2 2


 6/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com

#8 P21306D10015 Bottom Dawer Panel 2 2
#9 P21108A10015 Left Panel 1
#10 P21109A10015 Right Panel 1
#11 P02404A10015 Upper Riser 1
#12 P02303A10015 Upper Connection
Frame 1
#13 P02405A10015 Bottom Riser 1
#14 P02304A10015 Bottom Connection
Frame 1
#15 P11708A10015 Shelf 1
#16 P21208A10015 Back Panel 1 1
#17 P21209A10015 Back Panel 2 1

 7/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
#18 P02104A10015 Towel Bar Holder 2
#19 P02104B10015 Towel Bar 1
#20 P12305A10015 Table top 1































 8/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com





HardwarePack 
Part Part Number Description Qty Add Part Image
AA H00002A12 Allen Key Size 4 1 0

BB H06050C13 Bolt M6*50 2 1

CC H06070C13 Bolt M6*70 16 2 
DD P90601B01002 Multi Fit M6*13 16 2 
EE P90401C10000 Dowel M8*30 4 1

FF P90101C01002 Cam Ø 15*12 12 2

GG P90102C01002 Cam Bolt M6*34 12 2

HH H10030A11 Screw #8*32 28 3

JJ P90001D03000 Door Knob 2 0

KK H10025A12 Screw M4*25 2 1 
LL P90301C01002 Caster Wheel
With Lock 2 0

MM P90302C01002 Caster Wheel 2 0

NN P91201A10015 Wood Button
Ø14.5 16 2

A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size

9/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
STEP 1 :Assembling the Upper Connection Frame
1x
P12305A10015
1x
P02303A10015
4x
P90102C01002
P90102C01002
4x

10/20
CountryofOrigin:MalaysiaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
(
STEP 2 : Connecting the Left Panel and Towel Ba
r
1x
P21108A10015
2x
1x
P02104A10015
P02104B10015
H06050C13
H06070C13
2x
2x
