ASSEMBLY INSTRUCTION
ITEM#: 1203060005-C

 2/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com



Pleasefollowthesimplestep‐by‐stepassemblyInstructions.
Checkandensurealltheparts,fittingsandhardwarearepresentbeforediscardinganypackaging. 
Oneortwopeoplearerequiredforthisassembly.
Pleasereadallinstructionscarefullybeforeassemblyandusage.Basicsafetyprecautionsshouldalways
befollowedtoreducetheriskofpersonalinjuryanddamagetoequipment.
Advisabletowearprotectiveglovesduringassembly.
Assemblethisproductontheflatsurface.
Assembleallpartslooselybeforetighteninganybolts. 
RetainthisAssemblyInstructionforfuturereference.








WHAT IS COVER？
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect
providedtheitemismaintainedwithcareandusedonlyforpersonal,residentialpurposes.

















Safety Information
CAUTION: Do not climb on top of the product. Falling off the product may result in
serious injury.
NOTICE: For indoor use
Warranty: 1 Year
TOOLS NEEDED

 3/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com




KEEPTHISINSTRUCTIONMANUALFORFUTUREREFERENCE.
ONEORTWOPERSONIS/ARENEEDEDFORTHEINSTALLATIONWORK.
IMPORTANT

 4/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
EXPLODED DRAWING

 5/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
PartsList 

Part Part Number Description Qty Part Image
#1 P12301A10011 Table Top 1

#2P21101A10012 Left Panel 1

#3P21101B10012 Right Panel 1

#4P21201A10012 Back Panel 1

#5P11701A10012 Upper Shelf 1

#6P11702A10012 Bottom Shelf 1

#7P02102A10012 Towel Bar Holder 2

#8P02101A10012 To wel B ar 1

#9P21301A10012 Front Drawer Panel 1



 6/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com

#10
P21302A10012 Left Drawer Panel 1

#11
P21302B10012 Right Drawer Panel 1

#12 P21303A10012 Back Drawer Panel 1

#13
P21304A10012
Bottom Drawer
Panel 1





























 7/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com





HardwarePack 
Part Part Number Description Qty Add
Hardware Part Image
AA H06030C12 Bolt M6*30 4 1

BB H08047K13 Screw M5*47 4 1

CC H11030J12 Screw M4*30 16 4

DD P90401A10000 Dowel Ø6*30 10 2

EE H13001C12 Spring Washer M6 4 1 
FF H12001C12 Flat Washer M6 4 1

GG P90101A01002 Cam Bolt M6*32 4 1

HH P90101B01002 Cam Ø15*12 4 1 
II P90001A01004 Handle 1 0 
JJ H00002C13 Allen Key Size 4 1 0

KK H09010A14 Bolt M4*10 2 1

LL P90301A01002 Caster Wheel With
Lock
2 0 
MM P90301B01002 Caster Wheel 2 0 
A
ctual Size
A
ctual Size
A
ctual Size
A
ctual Size

8/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
STEP 1 :Inserting the Cam Bolts
1x
P21101B10012
1x
P21101A10012
P90101A01002
2x

9/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
STEP 2 : Assembling the Towel Bar
H11030J12
H08047K13
P02102A10012
P02101A10012
2x
1x
2x
1x
H00002C13
4x

10/19
CountryofOrigin:ChinaCall1(866)578‐6569forassistance. 
Orvisitusatwww.sunjoyonline.com
STEP 3 : Connectin
g
the Towel Bar
1x
P21101A10012
P90101A01002
2x
