Sunjoy L-DN1318SAL User manual

Congratulations on your purchase of our SUNJOY Deep Seating Item.
Our clear, easy to follow, step-by-step instructions will guide you through the assembly process from
start to finish.
WARNING:
 Keep all children and pets away from assembly area. Children and pets should be supervised
when they are in the area of the 3-seat Sofa construction.
 Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house,
overhanging branches, laundry line or electrical wires.
 Some parts may contain sharp edges. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of personal injury and damage to the
product. Please read all instructions before assembly and use.
 Check all bolts for tightness before use and periodically check and tighten bolts as necessary.
 Assemble on level ground.
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and
easy operation. Keep this manual for future reference.
For technical assistance on assembly or replacement parts, call Sunjoy Industries at 1-866-578-6569
from 8:30AM to 5:30PM EST, or email us at [e-mail], or visit
www.sunjoyonline.com for assistance.
Assemly Instructions
Item# L-DN1318SAL (Sofa)

Parts List
No.
Description
Qty
A1
Left Armrest
Right Armrest
Backrest
Seat Board
1
A2
B
C
1
1
1
·
D
E
F
G
Steel Support Bar
Seat Cushion
Back Cushion
Lumbar
1
3
3
3
AA
BB
Bolt M6x60
4
Spring Washer M6
19
CC
DD
EE
Flat Washer M6
Bolt M6x15
Bolt M6x25
19
4
2
FF
GG
Bolt M6x35
Hex Key M6
11
1
Step 1: Attach Seat Board (C) to Backrest (B) and lock them by Bolt (AA), Spring
Washer (BB), Flat Washer (CC) and Hex Key (GG). Do not lock tightly.

Step 2: Attach Steel Support Bar (D) to Seat Board (C) and lock them by Bolt (FF), Spring
Washer (BB), Flat Washer (CC) and Hex Key (GG). Do not lock tightly.
Step 3: Attach Steel Support Bar (D) to Left Armrest (A1) by Bolt (DD), Spring Washer (BB), Flat
Washer (CC) and Hex Key (GG) as shown in Fig 1. Do not lock tightly.
Attach Backrest (B) to Left Armrest (A1) by Bolt (EE) and Hex Key (GG) as shown in Fig 2. Do
not lock tightly.
Attach Seat Board (C) to Left Armrest (A1) by Bolt (FF), Spring Washer (BB), Flat Washer (CC)
and Hex Key (GG) as shown in Fig 3. Do not lock tightly.

Step 4: Attach Steel Support Bar (D) to Right Armrest (A2) by Bolt (DD), Spring Washer
(BB) and Flat Washer (CC) and Hex Key (GG) as shown in Fig 1. Do not lock tightly.
Attach Backrest (B) to Right Armrest (A2) by Bolt (EE) and Hex Key (GG) as shown in Fig
2. Do not lock tightly.
Attach Seat Board (C) to Right Armrest (A2) by Bolt (FF), Spring Washer (BB), Flat
Washer (CC) and Hex Key (GG) as shown in Fig 3. Lock all the bolts tightly.
Step 5: Set Seat Cushion (E), Back Cushion (F) and Lumbar (G) on the sofa as shown
above

Care & Maintenance
Before using, clean the 3-seat Sofa completely with a soft dry towel. When not in use, wipe
free of any dirt or loose objects, wash with a mild solution of soap and water; rinse
thoroughly and dry completely. Do not use strong detergent or abrasive cleaners. When
not in use, recommend the use of patio furniture covers.
Limited Warranty:
Sunjoy Industries warrants to the original purchaser that this item is free from defects in
workmanship and materials for a period of 1 year from the date of purchase, provided the
item was factory-sealed at the time of purchase and is maintained with care and used only
for personal, residential purposes. Should any manufacturing defect arise within this
warranty period, Sunjoy Industries will repair or replace (at our option) any defective
merchandise upon proof of purchase; however, transportation and delivery costs, as well
as payments to a third party for assembly or disassembly of the item, remain the
responsibility of the purchaser. A purchaser of an "open box," previously-returned, or
"clearance" item, as well as original purchasers outside of the warranty period, may obtain
replacement parts from Sunjoy Industries for products in current production, at nominal
cost.
Exclusions:
Items used for commercial, contract, or other non-residential purposes, or items damaged
due to acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion
or rusting of hardware is not covered. Proof of purchase (dated register receipt) is required
for warranty claims. Warranty is to the original purchaser and is non-transferable. Any
replacement of warranted items will be in the original style and color, or a similar style and
color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may
not apply. This warranty gives you specific rights, and you may also have other rights,
which vary from state to state.
Please do not return this product to the store. For technical assistance on assembly or
replacement parts, in the continental U.S., you can call us toll-free at 1-866-578-6569 from 8
a.m. to 5 p.m. CST Monday – Friday. In the continental Canada, you can call us toll-free at 1-
844-SUNJOY1(1-844-786-5691) from 8 a.m. to 5 p.m. CST Monday – Friday. You can also
send us an email to [e-mail] or visit www.sunjoyonline.com to place your
order or fax your parts replacement order form together with your purchase receipt to 1 (740)
283-3549 for assistance.
Made in China
