Sunjoy L-DN899SAL-A User manual

Assembly Instructions
TABLE
Item# L-DN899SAL-A
Our clear, easy-to-follow, step by step instructions will guide you through the project from start to finish. The final
product will be a quality piece that will assemble easily and give years of enjoyment.
IMPORTANT:
Please read instructions thoroughly before assembly. Familiarize yourself with the inventory of parts and the
accompanying illustrations to assure safe and proper assembly.
Repeated assembly can weaken the locking ability of the washers. Periodically check all bolted connections on
your product to make sure they are tight and secure. Please keep the instructions for future reference.
WARNING:
Begin assembly not less than 6 feet from any obstruction such as a fence, garage, house, overhanging branches,
Some parts may contain sharp edges.
Keep children away from assembly are
Check all nuts and bolts for tightness before and during usage.

Parts list:
Assembly Instructions:
No.
Description
Qty
A
Table top
1
B
Table Leg
4
C
Support ring
1
D1
Lighting unit
1
D2
Lighting unit top ring
1
E
Glass top
1
AA
Inner hex bolt 1/4” x 20
8
BB
Inner hex bolt 1/4” x 35
8
CC
Spring washer φ1/4”
16
DD1
Flat washer φ1/4” (big)
8
DD2
Flat washer φ1/4” (small)
8
EE
1/4”Hex key
1
Step 1: Connect Table top (A) and Leg (B) by using
bolt (AA), spring washer (CC) and big flat washer
(DD1). Please do not fully tighten the bolts here.
Step 2: Connect Leg (B) and Support ring (C) by
using bolt (BB), spring washer (CC) and small flat
washer (DD2). Then fully tighten all the bolts by
using hex key (EE).
DD2
A
B
C
BB
CC
A
D1
D2
B
C
E
DD1
B
CC
AA

BATTERY/LIGHTING UNIT INSTRUCTIONS:
CARE AND MAINTENANCE:
Immediately remove any spot or stain.
Wash with mild soap. Then rinse with water and air dry.
Do not use strong solvents or bleach as they may damage the surface.
Use an outdoor cover to extend the life of your patio set.
Disassemble the lighting unit for storage to extend its working life.
TROUBLE SHOOTING:
Problem
Possible Cause
Corrective Action
Can’t align the bolt holes.
Other components are
over-tightened.
Loosen the other bolts and realign
the holes before screwing again.
Step 3: Turn over the the whole assembled piece.
Place glass top (E) with the smooth surface facing
upwards on slate table top (A), locate lighting unit
(D1) under glass top (E) through the central hole and
fix with lighting unit top ring (D2).
Now your table is ready for use.
D2
D1
E
1. Six AAAbatteries are sold separately.
2. When you install new batteries, open the battery cover
according to labeling on battery compartment. Then, put the
batteries on top of the band and align batteries according to
the labeling as Fig.1.
3. Remove the batteries by pulling off the band.
4. Switch thelight unit on/off by turning the top Ring X at the
top of the lighting unit as Fig.2.
Fig.2
Fig.1

SAFETY INFORMATION!
WARNING:
Do not mix old and new batteries. Do not mix alkaline, standard (Carbon-Zinc), or rechargeable
(Nickel-Cadmium) batteries.
If you find any noise, excessive temperature or leakage from a battery, please discard.
When not using the unit for a considerable period of time, disconnect the batteries from the unit for storage.
If battery power is weak during use, switch off the device and dispose of batteries.
CAUTION:
Assemble on a soft, non-abrasive surface.
Don’t fully fasten the bolts until all bolts are in place.
Changes or modifications not approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
LIMITED WARRANTY:
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship
of your item provided the item is maintained with care and used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1) year.If any
defect is found, please call our customer service department at 1-866-578-6569 for help. The manufacturer will
not cover transportation or delivery costs, or compensate the individual or any outside party for assembling or
disassembling the product. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
EXCLUSIONS: Items used for commercial, contract, or other non-residential purposes, or items damaged due to
acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not
covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to the original
purchaser and is non-transferable. Any replacement of warranted items will be in the original style and color, or a
similar style and color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not apply. This
warranty gives you specific rights, and you may also have other rights, which vary from state to state.
For technical assistance on assembly or replacement parts call Sunjoy Industries at 1(866)
578-6569 from 8:30 AM to 5:30 PM EST or Email [e-mail] or visit
www.sunjoydirect.com to place your order or fax your parts replacement order form together
with your purchase receipt to 1 [phone] for assistance.

Assembly Instructions
SWIVEL - CHAIR
Item# L-DN899SAL-A
Our clear, easy-to-follow, step by step instructions will guide you through the project from start to finish. The final
product will be a quality piece that will assemble easily and give years of enjoyment.
IMPORTANT:
Please read instructions thoroughly before assembly. Familiarize yourself with the inventory of parts and the
accompanying illustrations to assure safe and proper assembly.
Repeated assembly can weaken the locking ability of the washers. Periodically check all bolted connections on
your product to make sure they are tight and secure. Please keep the instructions for future reference.
WARNING:
Read and follow all Warnings &Assembly Instructions before attempting to assemble.
Begin assembly not less than 6 feet from any obstruction such as a fence, garage, house, overhanging branches,
laundry line, or electrical wires.
Some parts may contain sharp edges. Wear protective gloves as necessary.
Keep children away from assembly area.
Assemble on level ground.
Do not over tighten any of the bolts or nuts, but do tighten each bolt and nut until firm.
Check all nuts and bolts for tightness before and during usage.

Parts List:
Hardware List:
No.
Description
Qty
A
Chair body
1
B
Triangle
support
1
C
Chair base
1
D
Foot rest ring
1
No.
Description
Size
qty
AA1
Bolt (pre-assemble)
1/4”x28
3
AA2
Bolt (pre-assemble)
1/4”x30
2
BB
Bolt (pre-assemble)
1/4”x35
2
CC
Bolt
1/4”x45
4
DD
Bolt
5/16”x40
4
EE
Foot pad (pre-assemble)
¢19x20
4
FF
Flat washer
(4pcs pre-assemble)
1/4”
8
GG
Spring washer
(4pcs pre-assemble)
1/4”
8
HH
Flat washer
5/16”
8
II
Spring washer
5/16”
4
JJ
nut
5/16”
4
KK
Large washer
25x65x4.0
2
LL
Hex key
1/4”
1
MM
Wrench
5/16”
2
D
B
A
C

DD
II
KK
B
II
HH
JJ
A
II
HH
JJ
DD
II
KK
A
B
Fig.2
HH HH
Fig2
Fig.2: Place chair body (A) face down on a non-abrasive
surface and fix the triangle support (B) to the chair body as
Fig.2-2 by using bolt (DD), flat washer (HH), large washer
(KK), spring washer (II) and nut (JJ) in order. Fully tighten all
the bolts by using wrench.
Note: The triangle support (B) must be in the same
direction as Fig.2-1.
Fig.1: Place the chair base (C) on a level
surface, put the foot rest ring outside of the
base as Fig.1 and fix them by using bolt
(CC), spring washer (GG) and flat washer
(FF). Fully tighten all the bolts by using
hex key.
Fig.1
CC GG FF
C
D

CARE AND MAINTENANCE:
Immediately remove any spot or stain.
Wash with mild soap. Then rinse with water and air dry.
Do not use strong solvents or bleach as they may damage the surface.
Use an outdoor cover to extend the life of your patio set.
LIMITED WARRANTY:
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship
of your item provided the item is maintained with care and used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of one (1) year. If any
defect is found, please call our customer service department at 1-866-578-6569 for help. The manufacturer will
not cover transportation or delivery costs, or compensate the individual or any outside party for assembling or
disassembling the product. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
EXCLUSIONS: Items used for commercial, contract, or other non-residential purposes, or items damaged due to
acts of nature, vandalism, misuse, or improper assembly are not covered. Corrosion or rusting of hardware is not
covered. Proof of purchase (dated register receipt) is required for warranty claims. Warranty is to the original
purchaser and is non-transferable. Any replacement of warranted items will be in the original style and color, or a
similar style and color if the original is unavailable or has been discontinued. As some states do not allow
exclusions or limitations on an implied warranty, the above exclusions and limitations may not apply. This
warranty gives you specific rights, and you may also have other rights, which vary from state to state.
For technical assistance on assembly or replacement parts call Sunjoy Industries at 1(866)
578-6569 from 8:30 AM to 5:30 PM EST or Email [e-mail] or visit
www.sunjoydirect.com to place your order or fax your parts replacement order form together
with your purchase receipt to 1 [phone] for assistance. Made in China
Made in China
Fig.3: Insert the triangle support (B) into the holes of chair base
(C) as figure.
Now your swivel chair is ready for use.
B
C
Fig.3
