SUNLU SL Series Manual

文件编号：3D打印机013B说明书 尺寸：210*148mm（双面印刷） 材质：128克铜版纸

Guide Book
TM

SHSH Series 3D Printer
Guide Book
【To make Top-quality 3D Printer】
This guide book is based on 3D printer model SL-0113B.
It is also applicable for SL-012B、SL-014B and SL-015B.
Please check SD memory card for detailed instruction、
tutorial video and Cura software.
SL Series 3D Printer Guide

Dear Value Customers:
Thank you for choosing our products. For the best experience, please read the instructions carefully before operating the
printer. Our 3D teams are always ready to provide you with assistance. Please contact us via the phone number or e-mail
address provided at the end when you meet any problems while using our printer.
For a better experience in using our product, you may learn how to use the Printer in the following ways:
1.View the accompanied instructions and videos on the SD card.
2.Visit our official website at www.sunlugw.com You will find relevant software/hardware information,contact details and
operation and maintenance instructions on the website.
Notes
Keep hands away from the nozzle or heating bed during printing. Preventing from burns.
Do not use any other power cables except the one supplied. Use a grounded three-prong power outlet.
Do not reach to printing area while printer is working in case of personal injury.
Shut down the power source in any emergent cases.
The Filaments recommended by the manufacturer are preferred as to avoid clogging in the extrusion head or Printer damage.
Printer works at violent vibration or any unstable places may cause poor printing quality.
Clean the Printer frequently. Usually clean it while power-off, clean the body of the machine with a cleaner or alcohol to clean
the platform su rface before every print.
Machine works unattended is not recommended.
01

Contents
1.Parameters
2. General List
3. Device Installation
4. Filament Support Installation
5. Power Switch Examination
6. Screen/Knob Information
7. Filament Loading
8. Bed Leveling
9. Software Installation
10. Software Parameter Settings
11. Operational Demonstration
12. Troubleshooting
............................................................................... 3
............................................................................... 4
..................................................................... 5
.................................................. 6
...................................................... 7
........................................................ 8
.................................................................... 10
............................................................................. 11
............................................................... 12
................................................. 13
................................................... 14
...................................................................... 16
02

1.Parameters
Print Principle
Print Size
Print Accuracy
Nozzle QTY
Nozzle Diameter
Print Speed
Recommended Filament
Nozzle Max Temp
Heating Bed
Software
Input Format
Output Format
Connecting
Power Parameter
Machine Size
Net Weight
FDM
310×310×400(mm)
±0.01mm
Single Nozzle
Equipped with 0.4mm、0.3mm & 0.2mm (Optional)
20-100mm/s(Recommended: 50mm/s)
1.75mm PLA, ABS, PETG, HIPS,WOOD, PLA Carbon Fiber
260℃
Yes
Cura
STL .OBJ .AMF
Gcode
TF Card、USB
115V/230V AC,50/60HZ
600×490×640（mm）
12KG
03

2.General List
1. X Limit Switch 4. Controlling Box 7. Display 10. Z Stepper 13. Extruding Motor
2. Nozzle Kit 5. TF Slot and USB Port 8. Base Frame 11. Power Switch 14. Filament Support
3. Platform 6. Controlling Knob 9. Gantry Frame 12. Voltage Switch 15. X Stepper
1
2
3
4 5 6 7 8
9
10 11 12 13 14
15
04

05
3.Device Installation
Step1：Unwrap the machine and cut off the cable tie.（Pic 1）;
Step2：Put the square-shaped nuts into the slots of each side of gantry frame(Pic 2&Pic 3). Put up gantry frame and
make M5*8 screw through T-shaped fixing block with the nuts of each side of gantry frame(Pic 4).
Step3: Put down gantry frame like(Pic 5) and install 4 pcs of M5*25 bolts connecting base frame
and gantry frame. Finally screw M5*8 bolts tightly(Pic 6).
Pic1 Pic2 Pic3
Pic4 Pic5 Pic6
Pic2

06
4.Filament Support Installation
Step1：Filament support spare parts shows in Pic 7.
Step2：Unwrap the support and put the M3 nuts into the slots which is circled(Pic 8).
Then connect with other two bigger boards with M3 screws(Pic 9 & Pic 10).
Step3：Load filament like Pic 11 and make sure the filament always loading from upside like Pic 12.
Pic7 Pic8 Pic9
Pic10 Pic11 Pic12

07
5.Power Switch Examination
Step1：Select the correct input voltage to match your local mains (230V or 115V)(Pic 13，Pic 14)
Damage can occur if voltage is set incorrectly.
Pic13 Pic14
Voltage Switch

08
6.Screen/Knob Information
Knob Information
1.Current Temp of Nozzle
2.Print Progress
3.Current Location of Nozzle
4.Setting Temp of Nozzle
5. Setting Temp of Heating Bed
6. Part Cooling Fan Speed
Push
Turn
Ok/Enter Sub Menu
Change Option/Value
7.Current Temp OF Heating Bed
8.Print Time
9.Prompt Message
4
5
6
7
8
9
1 2 3

09
Menu Sub Menu Explanation
Info Screen Main Return
Prepare
Move Axis Moving X,Y,Z axis
Auto Home Return to the origin
Level Bed Leveling bed
Disable Stepper Moving X,Y,Z by hands
Preheat PLA Preheat PLA temperature
Preheat ABS Preheat ABS temperature
Cool Down Cool down the nozzle
Control Temperature Control nozzle & heating bed temperature and
fan speed
Restore Failsafe Restore factory settings

7. Filament Loading
Step1：Nozzle preheating（PLA：195℃，ABS：220℃）, Menu → Control → Temperature → Nozzle →
Setting Temp.（>190℃）.
Step2：Press and hold the extruder lever then insert the 1.75mm filament through the small hole of the extruder.
Continue feeding until you see filament come out the nozzle.(Pic 15, Pic 16).
Please make sure that the end point is about 45 degree angle.(Pic 14 )
Pic14 Pic15 Pic16
Hold down
10

11
8. Bed Leveling
Step1：Menu → Prepare → Level bed → Level bed → Click to begin.
Step2: Move the nozzle the front/left leveling screw and adjust the platform height by turning the knob underneath.
Use a piece of A4 paper (standard printer paper) to assist with the adjustment, making sure that the nozzle lightly
scratches the paper.
Step3: Complete the adjustment of the screw on all 4 corners.
Step4: Repeat above steps 1-2 times if necessary.
Paper is just scratched lightly by nozzle

12
9. Software Installation
Step1: Double click the Cura icon to install the Cura Slicing Software from SD Car. Please follow below instructions.

13
10. Software Parameter Settings
Open Cura software，Please follow the below instruction to finish all required settings.

11. Operational Demonstration
Step1: Open software Cura and load printing file.
Step2: Finish the settings and parameters.
Step3: Store the printing file in English.
14

15
Step4: Apply a layer of solid glue evenly on the glass platform.
Step5: Insert SD card → Select Print from SD → Select printing file.

16
12. Troubleshooting
A. The first layer of the model is not sticky platform:
1. Check if the slice parameters are correct.
2. Check if the printed area is coated with special solid glue.
3. Check if the distance between the nozzle and the glass is too large and re-level.
4. Check if the temperature of heating bed is appropriate for the current consumable.
B. Nozzle extrusion abnormality:
1. Check if the filament is knotted or the diameter is too small or too large.
2. Check if the printing temperature is suitable for the current filament.
3. Check if the distance between the nozzle and the glass is too small, block the nozzle, and it
is difficult to extrude.
4. Check for impurities on the extruder gear that have not been cleaned.
C. Auto home with abnormal sound:
1) Check if the limit switch can be triggered normally, try to adjust the position of the limit switch.
2) Check if the limit switch signal line is loose.
3) Check if the motor wiring is loose.
D. Model misplacement:
1) Print speed is too fast, try to reduce the print speed
2) For the model to be warped, refer to item A.
