Sunny SF-B1712 User manual

BELT DRIVE INDOOR CYCLING
BIKE
SF-B1712
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: [email protected] or 1- 877 - 90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this
equipment correctly. It is important to read this entire manual before assembling and
using the equipment. Safe and effective use can only be achieved if the equipment is
assembled, maintained, and used properly. It is your responsibility to ensure that all users
of the equipment are informed of all warnings and precautions.
1. Before starting any exercise program, you should consult your physician to determine
if you have any medical or physical conditions that could put your health and safety at
risk or prevent you from using the equipment properly. Your physician’s advice is
essential if you are taking medication that affects your heart rate, blood pressure, or
cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your
health. Stop exercising if you experience any of the following symptoms: pain,
tightness in your chest, irregular heartbeat, shortness of breath, lightheadedness,
dizziness, or feelings of nausea. If you do experience any of these conditions, you
should consult your physician before continuing with your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult
use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or
carpet. To ensure safety, the equipment should have at least 2 feet (60 CM) of free
space all around it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The
safety of the equipment can only be maintained if it is regularly examined for damage
and/or wear and tear.
6. Always use the equipment as indicated. If you find any defective components while
assembling or checking the equipment, or if you hear any unusual noises coming from
the equipment during exercise, discontinue use of the equipment immediately and do
not use until the problem has been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that
may become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 265 pounds (120 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/or damage to the product or property, proper lifting and
moving are required.
12.Your product is intended for use in cool and dry conditions. You should avoid storage
in extreme cold, hot or damp areas as this may lead to corrosion and other related
problems.
13.This equipment is designed for indoor and home use only; it is not intended for
commercial use.

2
EXPLODED DIAGRAM
75
76
66
66
67
66
6
5
4
12
13
14
5
4
8
9
3
6
10
43
44
40R
42R
41R
51
51
60
59
58
57
56
46
55
48 50
49
47
65
64
64
65
63
73
67
66
74
66
29
27 28
52
31
33
34
35
36
37
38
39
30
31 32 34
36
37
35
38 39
1
3
2
7
21
20
25 26
24
23
41L
42L
40L
43 44
45 46 47
10
11
11
50 53 54
51
51 51 51 62
64
64
65
65
68
73
22
31
71
70
69
70
72
71
70
69
70
72
51
51
51
77
66
74
74 74
67
66
67
66
22
23
24
27
28
51
62
51
13
13
13
13
19
15
16
17
13
18
61
51
78
78

3
PARTS LIST
No.
Description
Spec.
Qty.
No.
Description
Spec.
Qty.
1
Handlebar
1
40L/R
Pedal
2
2
Handlebar Post
1
41L/R
Nylon Nut
9/16*20*H8*S19
2
3
Screw
M5*10*S4
2
42L/R
Crank
2
4
Washer
d10*Φ40*4
2
43
Crank Cap
2
5
L-shaped Knob
M10*25
2
44
Nut
M10*1.25*H7.5*S1
4
2
6
End Cap
2
45
Cover for Middle
Axle
1
7
Seat Post
1
46
C-clip
d20
2
8
Seat Column
1
47
Bearing
6004-RZ
2
9
Seat
1
48
Inner Belt Cover
1
10
Bushing
2
49
Plastic Washer
Φ10*Φ30*6
2
11
Knob
M16*1.5*15*Φ49
2
50
Screw
ST4.8*16*Φ10
2
12
Tension Knob
1
51
Screw
ST4.2*13*Φ8
13
13
Nut
M10*H7*S17
6
52
Water Bottle Holder
1
14
Brake Rod
1
53
Blanking Plate
1
15
Bushing
1
54
Front Cover
1
16
Spring
Φ2.0*Φ15*60*N12
1
55
Wave Washer
d20*Φ26*0.3
1
17
Nut
1
56
Belt Wheel
1
18
Nut
M6*H14*S10
1
57
Middle Axle
1
19
Nut
M10
4
58
Screw
M10*20*S6
4
20
Brake Board
t7*138.3*28
1
59
Belt
1
21
Woolen Felt
1
60
Outer Belt Cover
1
22
Screw
M5*10*Φ8.5
2
61
Cushion
1
23
Bolt
M6*12*S10
2
62
Screw
M6*12*Φ12
2
24
Washer
d6*Φ12*1.2
2
63
Rear Stabilizer
1
25
Rubber Pad
1
64
Foot Leveler
4
26
Spring Piece
1
65
End Cap
J80*40*18
4
27
Washer
d5*Φ10*1
2
66
Washer
d8*Φ16*1.5
8
28
Screw
M5*16
2
67
Screw
M8*55
4
29
Main Frame
1
68
Front Stabilizer
1
30
Inertial Wheel
1
69
Transportation
Wheel
2
31
Bearing
6202Z
3
70
Bearing
608ZB Φ8
4
32
Inertial Axle
1
71
Screw
M6*12*S5
2
33
Spacer
Φ20*Φ15.1*28
1
72
Screw
Φ7.8*30
2
34
Nut
M12*1*H6*S19
2
73
Shipping Tube
2
35
Adjusting Screw
M6*55*Φ12*5
2
74
Screw
M8*20
4
36
Nut
M6*H5*S10
2
75
Allen Wrench
S6
1
37
Nut
M6*H6*S10
2
76
Spanner
S14-15-17
1
38
Spacer
Φ18*Φ12.2*6
2
77
Spanner
S10-13-17-19
1
39
Nut
M12*1*H19.5*S19
2
78
Washer
d5*Φ10*1
2

4
HARDWARE PACKAGE
#66 d8* 16*1.5 4PCS
#67 M8*55 4PCS
#5 M10*25 1PC
#4 d10* 40*4 1PC
#77 S10-13-17-19 1PC
#76 S14-15-17 1PC#75 S6 1PC
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the part(s)
needed:
✓The model number (found on cover of manual)
✓The product name (found on cover of manual)
✓The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST” (found near
the front of the manual)
Please contact us at [email protected] or 1 - 877 - 90SUNNY
(877-907-8669).

5
ASSEMBLY INSTRUCTIONS
We value your experience using Sunny Health and Fitness products. For assistance with
parts or troubleshooting, please contact us at [e-mail] or
1-877-90SUNNY (877-907-8669).
#75 S6 1PC
#66 d8* 16*1.5 4PCS
#74 M8*20 4PCS
29
66
74
73
66
74
73
66
74 66
74
#75 S6 1PC
#66 d8* 16*1.5 4PCS
#67 M8*55 4PCS
29
66
67
63
68
66
67
66
67
66
67
STEP 1:
Remove Shipping Tubes (No. 73) from
Main Frame (No. 29) by removing 4
Screws (No. 74) and 4 Washers (No.
66) with Allen Wrench (No. 75).
You can save these parts for future
packaging and transportation of the bike
if desired. {Screws (No. 74), Washers
(No. 66), Shipping Tubes (No. 73)}
STEP 2:
Attach Front Stabilizer (No. 68) and
Rear Stabilizer (No. 63) to Main Frame
(No. 29) using 4 Screws (No. 67) and 4
Washers (No. 66). Tighten and secure
with Allen Wrench (No. 75).

6
We value your experience using Sunny Health and Fitness products. For assistance with
parts or troubleshooting, please contact us at [e-mail] or
1-877-90SUNNY (877-907-8669).
5
4
7
8
29
#5 M10*25 1PC
#4 d10* 40*4 1PC
#11 M16*1.5*15* 49 1PC
11
9
5
4
2
1
29
#5 M10*25 1PC
#4 d10* 40*4 1PC
11
#11 M16*1.5*15* 49 1PC
STEP 3:
Insert the Seat Post (No. 7) into Main
Frame (No. 29) and secure with [seat
adjustment] Knob (No. 11).
Remove L-shaped Knob (No. 5) and
Washer (No. 4) on Seat Column (No. 8).
Attach Seat (No. 9) onto Seat Post (No.
7) using L-shaped Knob (No. 5) and
Washer (No. 4) that were removed.
STEP 4:
Insert Handlebar Post (No. 2) into Main
Frame (No. 29) and secure with
[handlebar adjustment] Knob (No. 11).
Attach Handlebar (No. 1) onto
Handlebar Post (No. 2) using L-shaped
Knob (No. 5) and Washer (No. 4).

7
We value your experience using Sunny Health and Fitness products. For assistance with
parts or troubleshooting, please contact us at [e-mail] or
1-877-90SUNNY (877-907-8669).
29
52 27 28
#28 M5*16 2PCS
#27 d5* 10*1 2PCS
27 28
#76 S14-15-17 1PC
29
40L
42L
40R
42R
S15
#41L/R 9/16*20*H8*S19 2PCS
41R
41L
S19
#77 S10-13-17-19 1PC #76 S14-15-17 1PC
STEP 5:
Remove pre-assembled 2 Screws (No.
28) and 2 Washers (No. 27) from Main
Frame (No. 29). Then,attach Water
Bottle Holder (No. 52) to Main Frame
(No. 29) using 2 Screws (No. 28) and 2
Washers (No. 27) that were removed.
Tighten and secure with Spanner (No.
76)
STEP 6:
WARNING! Read instructions carefully as
improper assembly may cause permanent
damage to your bike.
Turn the Tension Knob (No. 12) all the
way to the right until the crank arm is
immobilized.
Remove 2 Nylon Nuts (No. 41L/R)
located on the Pedals (No. 40L/R).
Left Pedal: Turn Left Pedal (No. 40L)
counter-clockwise into Left Crank (No.
42L). Once properly screwed in place, use
Spanner (No. 76) to hold the bolt of the
pedal and screw Left Nylon Nut (No. 41L)
clockwise onto the thread end of Left
Pedal (No. 40L) securely with Spanner
(No. 77).
Right Pedal: Turn Right Pedal (No. 40R)
clockwise into Right Crank (No. 42R).
Once properly screwed in place, use
Spanner (No. 76) to hold the bolt of the
pedal and screw Right Nylon Nut (No.
41R) counter-clockwise onto the thread
end of Right Pedal (No. 40R) securely
with Spanner (No. 77).
The assembly is complete!

8
ADJUSTMENTS GUIDE
#76 S17
#76 S14-15-17 1PC
A
B
13
64
12
5
11
7
5
11
7
Fig.8
ADJUSTING THE BALANCE
In order to achieve a smooth and comfortable ride, you must ensure
that the stability of the bike is secured. If you notice that the bike is
unbalanced during use, you should adjust the foot levelers located
beneath the Front and Rear Stabilizers of the bike. To do so, use
Spanner (No. 76)to loosen Nut (No. 13)by turning it clockwise
(direction A). With the nut loosened, rotate the Foot Leveler (No.
64) until it sits level with the surface that the bike is on. When you
have finished adjusting the foot leveler, use Spanner (No. 76)to
re-tighten the Nut (No. 13) by turning it counter-clockwise (direction
B). If required, repeat this process to adjust the remaining feet.
ADJUSTING THE RESISTANCE
Adjust the resistance of the bike using the Tension Knob (No. 12).
Increase the level of resistance by turning the Tension Knob (No.
12)to the RIGHT (clockwise), decrease the level of resistance by
turning the Tension Knob (No. 12)to the LEFT (counter-clockwise).
Push down on the Tension Knob (No. 12)for the emergency brake.
ADJUSTING THE SEAT
An appropriate seat height helps to ensure your exercise efficiency
and reduce the risk of injury. Adjusting the seat forward or backward
can help you work out different body muscle groups.
With one pedal in the upward position, place your foot in the toe clip
and get on the bike. If your leg is bent too much, you should move
the seat up. If your foot cannot touch the pedal or your leg is too
straight, you should move the seat down.
Loosen the [seat adjustment] Knob (No. 11)to raise or lower Seat
Post (No. 7) to the desired position. Make sure Knob (No. 11)
secures into the desired hole.
Loosen L-shaped Knob (No. 5) to move the seat forward or
backward to the desired position. Once the position is located,
firmly secure L-shaped Knob(No. 5) by turning clockwise.

9
11
Figure A
5
Figure B
12
11
ADJUSTING THE HANDLEBAR
Loosen the [handlebar adjustment] Knob (No. 11)to raise or lower
the handlebar to the desired position. Make sure the Knob (No. 11)
settles into the desired hole and secure it firmly by turning
clockwise. See Figure A.
Loosen the L-shaped Knob (No. 5) to move the handlebar forward
or backward to the desired position. Once the handlebar is in the
desired position, firmly secure the L-shaped Knob (No. 5) by
turning clockwise. See Figure B.
ADJUSTING THE PEDAL STRAP
Place the ball of each foot in the toe clips so the front of your shoe
fits securely in the toe clip cage. Rotate one foot to within arm’s
reach and pull the strap until the top clip cage fits your shoe
securely. Insert the strap back into the hoop of the toe clip.
Repeat this process for the other foot.
DISMOUNTING THE BIKE
WARNING! Do not dismount the bike or remove your feet from the
pedals until the pedals have stopped completely. You can stop the
flywheel at anytime by pushing down on Tension Knob (No. 12).
MOVING THE BIKE
To move the bike, first ensure that the handlebar is properly
secured. If the handlebar is loose, tighten the Knob (No. 11)to
secure it. Next, stand at the front of the bike so that you’re directly
in front of the handlebar. Firmly grasp and hold each side of the
handlebar, place one foot on the front stabilizer and tilt the bike
towards you until the transportation wheels on the front stabilizer
touch the ground. With the wheels on the ground, you can transport
the bike to the desired location with ease.

10
MAINTENANCE INSTRUCTIONS
This is general information for daily, weekly and monthly maintenance to be performed on your bike.
Version 3.5
DAILY MAINTENANCE
After each exercise session, wipe down all
the equipment: seat, frame, and
handlebars. Pay special attention to the
seat post, handlebar post, and belt/chain
guard. Sweat is very corrosive and may
cause problems that require parts
replacement later.
1. Get on the bike and engage the drive
train.
2. Pay attention to any vibrations felt
through the pedals. If you feel any
vibrations, you may need to tighten the
pedals, bottom bracket, or adjust the
drive belt/chain tension.
3. Use a wrench to tighten the pedals until
they are secure.
MONTHLY MAINTENANCE
1. Check if all hardware is secure, such as:
water bottle holder, flywheel nuts, belt/chain
guard bolts, brake caliper lock nuts, and
brake caliper tension rod nuts.
2. Inspect the brake tension rod for signs of
wear such as missing threads. Clean and
lubricate the brake tension rod.
3. Clean and lubricate the seat post, handlebar
post and seat slider. Remove any buildup of
foreign material.
WEEKLY MAINTENANCE
1. Inspect moving parts and tighten the
hardware.
2. Inspect pull pin frame fittings to make
sure the fittings are secure. Loose
frame fittings may strip out threads over
time and cause extensive damage.
3. Clean and lubricate pop pin assemblies.
Pull on the pin and spray a small
amount of lubricant onto the shaft.
4. Tighten the seat hardware to make sure
the seat is level and centered.
5. Brush and treat the resistance pads.
Remove any foreign material that may
have collected on the pads. Spray the
pads with silicone lubricant. This helps
to reduce noise from friction between
the pads and the flywheel.
6. Visually inspect the bottom bracket, toe
clips and toe straps. If any of them are
loose or disconnected, attach and
tighten.
LEATHER BRAKE PAD CARE (If Applicable)
1. Perform this maintenance when the brake
pad is first installed and for the life of the
brake pad. Following these simple guidelines
can increase the life of your brake pads.
2. Some brake pad assemblies are
pre-lubricated. Squeeze the brake pad. If
lubricant is released, then the pad has been
pre-lubricated.
3. If the brake pad is dry, then coat the brake
pad with 3-n-1 oil. Brush the leather with a
clean, wire bristle brush, and then apply the
oil. The oil should be allowed to soak in to the
pad. Repeat 4-5 times until the pad is
saturated, but not dripping with oil. When the
pad is saturated, it will no longer absorb oil.
4. Inspect the brake pad weekly and lubricate if
needed. The pad should not have a glazed
appearance. If the pad appears glazed, then
brush it with wire brush and apply lubricant as
needed. If any of the sponge padding is
showing through the leather pad, the brake
pad should be replaced.
