Sunricher SR-2805RGB User manual

Wall Panel RF RGB Dimmer
Feature
SR-2805RGB/SR-2805DRGB/SR-2805RGB(IT)/SR-2805RGB(US)
Parameter
Installation
SR-2805RGB SR-2805DRGB
SR-2805RGB
Power supply
Part No. Iuput Voltage Remarks
Current
SR-2501RGB 12-36VDC Constant voltage
3x(60-180)W
3x5A
Output
SR-2501RGBEA 12-36VDC Constant voltage
3x(96-288)W3x8A
Remote
Part No. Operation Voltage Operation
Frequency
SR-2805RGB 3VDC 434MHz/868MHz
Receiver
SR-2502RGB 12-36VDC Constant current
3x(4.2-12.6)W
3x350mA
SR-2503RGB 12-36VDC Constant current
3x(8.4-25.2)W3x700mA
Remarks
RF Wireless
SR-2805DRGB 3VDC 434MHz/868MHz RF Wireless
SR-2805RGB(IT) 3VDC 434MHz/868MHz RF Wireless
SR-2805RGB(US) 3VDC 434MHz/868MHz RF Wireless
1)Receiver Connection Diagram for Single Unit
2) Connection Diagram for Multiple UnitsReceiver
Power Supply
12-36VDC
LN
110V-230VAC
PUSH
Power Supply
12-36VDC
LN
110V-230VAC
4x5A
Wiring diagram
SR-2805RGB is wall rotary RF dimmer with 256 levels logarithmic dimming from 0.1-100%, which is suitable for
dimming /RGB(W) led light.
Simple and friendly use for dimming and switching ON/OFF for 1zone controlled.
SR-2501RGB
RF Easy Dimme r
R
GB
Lea rni ng Key
GND
Pus h
Swi tch
SR-2501RGB
RF Easy Dimme r
R
GB
Lea rni ng Key
GND
Pus h
Swi tch
SR-2501RGB
RF Easy Dimme r
R
GB
Lea rni ng Key
GND
Pus h
Swi tch
SR-2501RGB
RF Easy Dimme r
R
GB
Lea rni ng Key
GND
Pus h Swi tch
Long time span battery for 2 years
Wireless, easy to change battary
SR-2805DRGB
Power supply

Please pair remote and receiver, after finishing connecting receivers with LED lights correctly, base on
diagram above.
1. Press shortly the learning Key on the receiver,then push the rotary button .Once successfully learn,
the LED lights will blink on the receiver. Do the same for the other receivers if you use them, you can add as
many optional receivers as you want.
2.
Adjust dim brightness by the rotary button from left to right 0.1-100%
Adjust dim brightness by the rotary button from right to left 100-0.1%
Long press rotary button, the light will be 100% brightness
Double click rotary button, it will change color of RGB light.Double click again, will enter into dimming
brightness mode.
Short press once rotary button to switch ON/OFF.
Operation
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
