Sunricher Universal Series User manual

Universal series DALI dimmer 70040013
Function introduction
Important: Read All Instructions Prior to Installation
12-36V DC power input
Common Anode output(+)
• DO NOT install with power applied to device.
• DO NOT expose the device to moisture.
Product Data
Safety & Warnings
CH 1:R output(-)
CH 2:G output(-)
CH 3:B output(-)
CH 4:W output(-)
Manual set button
Digital display
2 groups DALI/Push
input & output
• Manual /automatically DALI address setting
• DALI address digital indicate
• Four channels, can set addresses from one to four.
• To work with power repeater to expand output power unlimitedly.
• Waterproof grade: IP20
• In compliance with IEC 62386-101:2014, IEC 62386-102:2014, IEC 62386-207 Ed2.
• Built-in DALI-2 interface, DALI DT6 device
• Match all DALI systems in the market
Set DALI Address Manually Via Buttons
1.1. Press and hold down any of the two buttons until numeric digital display flashes, then release the button.
1.2. Click any of the two buttons once to select a digit, click again to change the digit until the desired DALI
address appears. Click first button to set “tens” position and second button to set “units” position. The address
can be set from 00~63.
1.3. Then press and hold down any of the 2 buttons until the numeric digital display stops flashing to confirm the
setting.
Note: DALI address can be manually assigned from 00-63-FF, by factory defaults, no DALI address is
assigned for the dimmer, and the display shows . Setting DALI address as will reset the
dimmer to factory defaults.
Operation
Input
Voltage Remarks
Output
Current
12-36VDC Constant voltage
4x(60-180)W
4x5A
Output
Power
12-48VDC Constant current
4x(4.2-16.8)W
4x350mA
12-48VDC Constant current
4x(8.4-33.6)W4x700mA
No.
1
2
3
Size(LxWxH)
166x53.4x23mm
166x53.4x23mm
166x53.4x23mm
2mA
DALI
Consumption
2mA
2mA
0.1%-100%
Dimming
Range
0.1%-100%
0.1%-100%
Ambient
Temperature
-20℃ ~ +50℃
-20℃ ~ +50℃
-20℃ ~ +50℃
DALI DIMMER
0-6 0-9
1-
2-
3-
4-
LED
DA
DA
DA
DA
DALI DALI
V-
V-
V+
V+
DC INPUT
12-36V
2
PUS H DIM
L
N
DA
DA
1 2
2. Set DALI Address Quantity
2.1. Press and hold down both of the two buttons until numeric digital display flashes, then
release the button.
2.2. Click first button to select “1A”, “2A”, “3A” or “4A” which means 1 address, 2 addresses, 3
addresses or 4 addresses.
2.3. Then press and hold down any of the 2 buttons until the numeric digital display stops
flashing to confirm the setting.
For example, when we set address to 22:
When select 1A, all four channels will be the same address 22.
When select 2A, channel 1 & 3 will be the same address 22, channel 2 & 4 will be the same
address 23.
When select 3A, channel 1, 2, 3 will be address 22, 23, 24 respectively, and channel 4 address is
also 24.
When select 4A, channel 1, 2, 3, 4 will be address 22, 23, 24, 25 respectively.
3. DALI Address Assigned by DALI Masters
DALI address can also be assigned by DALI Master controller automatically, please refer to user manuals of
compatible DALI Masters for specific operations.
Note: The digital display will show When the DALI master is assigning addresses.
4. Push Dimmer Mode
While connected with a AC push switch, the digital display will show “PD” which means Push Dimmer Mode,
operations under Push Dimmer Mode are as follows:
4.1. Click the button to switch ON/OFF
4.2. Press and hold down the button to increase or decrease light intensity to desired level and release it, then
repeat the operation to adjust light intensity to opposite direction. The dimming range is from 1% to 100%.
4.2. Memory function after power off or power failure enables the device to memorize the status before power
off while power on again.
• Radio Frequency Interference according to EN 55015:2013
• Immunity standard according to EN 61547:2009
• TÜV Rheinland marked, CE marked
Conformity & Standards
DALI Master
Wiring Diagram
L
N
GV+
V-
OUTPUT
INPUT
AC Power
50/60Hz
12V/24V/36V
CV PSU
If Conn ect wit h RGBW LE D Strip
V+ V+
R- R-
G- G-
B- B-
W- W-
V+ V+
1- V-
2- V-
3- V-
4- V-
If Conn ect wit h Singl e Color L ED Strip
V+ V+
WW WW
CW CW
WW WW
CW CW
If Conn ect wit h Dual Co lor LED S trip
DALI DIMMER
0-6 0 -9
1-
2-
3-
4-
LED
DA
DA
DA
DA
DAL I DALI
V-
V-
V+
V+
DC IN PUT
12- 36V
PUSH DI M
L
N
DA
DA
DALI DIMMER
0-6 0 -9
1-
2-
3-
4-
LED
DA
DA
DA
DA
DAL I DALI
V-
V-
V+
V+
DC IN PUT
12- 36V
PUSH DI M
L
N
DA
DA
DALI DIMMER
0-6 0 -9
1-
2-
3-
4-
LED
DA
DA
DA
DA
DAL I DALI
V-
V-
V+
V+
DC IN PUT
12- 36V
PUSH DI M
L
N
DA
DA
1) With DALI Bus

166 mm
53.4 mm
23 mm
Product Dimension
L
N
GV+
V-
OUTPUT
INPUT
AC Power
50/60Hz
12V/24V/36V
CV PSU
DALI DIMMER
0-6 0 -9
1-
2-
3-
4-
LED
DA
DA
DA
DA
DAL I DALI
V-
V-
V+
V+
DC IN PUT
12- 36V
V+ V+
1- V-
2- V-
3- V-
4- V-
If Conn ect wit h Singl e Color L ED Strip
AC PUSH
SWITCH
N
L
2) With Push Dim
