Vehicle Tracker
User Manual
Preface
Thank you for purchasing our products. This deliberately edited manual is to introduce the tracker
with the complete technical data and the instructions showing how to operate the device smoothly and
correctly. Make sure to read this manual carefully before using this product. Most problems could be
solved through the explanations and the troubleshooting tips. Once you finish reading it, keep it handy
for necessary reference. Please note that specification and information are subject to changes without
prior notice in this manual. Any change will be integrated in the latest release. The manufacturer
assumes no responsibility for any errors or omissions in this document.
1

Shenzhen SUNSKY Technology Limited
2
Content
Ⅰ. Preface…………………………………………... 1
Ⅱ. Attentions……………………………………….. 2
ⅢHardware description…..…………………….… 3
Ⅳ. Main function……………………………….….. 3
Ⅴ. Set up………………………………………...….. 4
Ⅵ. Installation diagram………………………...….. 7
Ⅶ. Installation……………………………….….…... 7
Ⅷ. Application…………………………………….… 9
Ⅸ.Specification………………………………....……10
Ⅹ.Command set………………………………………11

Shenzhen SUNSKY Technology Limited
Attention
1. Make sure to read this manual carefully before using this product.
2. Please insert the SIM card before installing, and make sure the SIM card has no password,
otherwise the tracker will not work normally.
3. Please make sure that all the cables of the tracker has been connected rightly, and then connect the
tracker to host power. Must not install or take down the tracker when it is power on. If you found
any troubles or omissions about the connections of cables, please cut off power first, otherwise you
will easily damage the tracker.
4. The tracker works in wireless communications, so please cut off the host power before your
vehicles entering fuel depot and dangerous material place.
5. The tracker’s work voltage is 9V-30V. Please use the tracker in the scope of work voltage.
6. The host of GPS tracker is a low-power wireless transmitter and receiver. It receives and sends radio
frequency signal when it is working.
7. To avoid electromagnetic interference or uncompatible configuration, please stop using your tracker
in the noticed place.
Vehicle Tracker
◆Hardware Description
1. Host Tracker
3

Shenzhen SUNSKY Technology Limited
4
2. Start up
Put the SIM card in place and installed the tracker in the car, the red indicator is on. About 40
seconds, the unit will begin to work and acquire the GSM signals as well as the GPS signals, and the
red indicator will keep flashing every 2 seconds when the GSM module is no communication. When
the blue indicator is light, the unit has been located.
◆Main functions
1. Positioning and Tracking: Through the on-line Positioning Platform or the cell phone to locates at
times, and get the working status. You can choose the Positioning Platform by yourself.
2. Triggering Emergency Alarm: When there is a emergency happened on the vehicle, you can put on
the button and the installed unit will send out alarm to the authorized numbers.
3. Remote controlling oil and circuit: you can control the oil and circuit via the unit by SMS in
anywhere and anytime.
4. Remote Monitoring: In anywhere and anytime, call the phone number in the unit, when it connects,
you can monitor the sound around 5 meter.
5. Movement Alert: Send SMS to the unit to start the movement alert function. When the vehicle is
moving, the unit will send the movement alert to all authorized numbers.
6. Overspeed Alert: Send SMS to the unit to start the movement alert function. When the vehicle is
overspeed, the unit will send the overspeed alert to all authorized numbers.
7. Geo-fence: Set up a geo-fence for the unit to restrict its movements within a district. The unit will
send the message to all authorized numbers when it breaches the district.
8. Restart the unit: send SMS to resume the default of unit.
9. Auto Track: You can set up auto track by SMS or on-line positioning platform.
10. Mileage statistics; ACC checking; cutting off power and alarm.
11. Compatible with the original anti-theft alarm: It will send SMS alarm after the original anti-theft
alarm warning.
﹡Modify the IP and Port of Communication Protocol for different on-line positioning platform
◆Set up

Shenzhen SUNSKY Technology Limited
5
1．Initialization
Send “begin + password” in SMS to the unit, it will reply “begin ok” and initialize all the
settings. (Default password: 123456)
2. Add authorized number
Send SMS “admin123456 13612345678”."admin" as instruction, "123456" as password,
"13612345678" as authorized number. It will reply “admin ok!”.
3. Delete authorized number
Send SMS “noadmin123456 13612345678”."noadmin" as instruction, "123456" as password,
"13612345678" as deleted number. It will reply “noadmin ok!”.
4. Change the Password
Send SMS: “password + old password + space + new password” to change the password.
For example: Send SMS “Password123456 138138”. "password" as instruction, "123456"as old
password, "138138" as new password. Password must be six digits. Tracker’s initial password is
123456.
5. Resume the initial password
If you forget your password, you can resume the initial password 123456.
Send “resumepassword”to the tracker, the tracker will resume the initial password. If there is no
authorized numbers, all numbers can resume initial password. If there is already authorized numbers,
only the authorized numbers can resume initial password.
6. Control Oil
Send SMS “stopoil+password” to control oil. For example send SMS: stopoil123456
"stopoil" as instruction, "123456"as password.
To supply the oil again, send SMS “supplyoil+password” to the unit. For example, send
SMS “Supplyoil123456” to the tracker. "Supplyoil" as instruction, "123456" as the password.
7. Control Circuit
Send SMS “stopelec+password” to control circuit. For example send SMS: “stopelec123456”.
"stopoil" as instructions, "123456" as the password.
To supply the circuit again, send SMS “supplyelec+password” to the unit. For example, send
SMS “Supplyelec123456” to the tracker. "Supplyelec" as instruction, "123456" as password.
8. Monitor mode
There are three modes for monitor.
1) All Monitor Mode: Send SMS “AllMonitor”to the unit, the unit will return to this mode. In this

Shenzhen SUNSKY Technology Limited
6
mode, any number can monitor this unit.
2) Restrict Monitor Mode: Send SMS “RestrictMonitor”to the unit, the unit will return to this mode.
In this mode, authorized number can monitor this unit.
3) Close Monitor Mode: Send SMS “CloseMonitor”to the unit, the unit will return to this mode. In
this mode, all numbers can not monitor this unit.
9. Movement alert
Set up: The user can send SMS “Move + password” to the unit, then the unit will reply “move
ok!” .In case of such a movement, it will send SMS “Move” along with a Geo-info to the number.
For example, send SMS “Move123456” to the unit. "Move" as instructions, “123456”as password.
Cancel: Send SMS “nomove+password” to deactivate the movement alert.
10. Overspeed alert
Set up: Send SMS “speed+password+space+080” to the unit (support the speed is 80km/h).
For example, send SMS “speed123456 080”. "speed" as instruction, "80" as limit speed, “123456”as
password.
Cancel: Send SMS “nospeed+password” to deactivate the overspeed alert.
11. Geo-fence
Set up a geo-fence for the unit to restrict its movements within a district. The unit will send the
message to the authorized numbers when it breaches the district.
Set up: The user can Send SMS “stockade + password + space + MinLatitude, MinLongitude;
MaxLatitude, MaxLongitude” to unit to set the restricted district. In case of breach, it will send SMS
“stockade! + geo-info” to the authorized numbers.
For example send SMS “stockade123456 22.548123, 114.081234; 22.549123, 114.082234” to the
unit.
Remark: The first latitude & longitude is coordinate of min of the Geo-fence, while the second latitude
& longitude is the coordinate of the max. It will alarm one time in each setting.
Cancel: Send SMS “nostockade + password” to deactivate this function.
This function will be out of effect after the unit moves outside the district.
12 . Restart the tracker.
Send SMS “reboot+password” to the tracker. For example“reboot123456”.The tracker will be
restarted. It will reply “system will reboot...”.
13. Enquiry Positioning
Send SMS “position” to the unit, then the unit will send SMS with real-time longitude and latitude to
the cell phone.
14. Auto track
Send SMS “at30sum5” to the unit, it will reply “Auto track set ok.” and report a Geo-info at 30

Shenzhen SUNSKY Technology Limited
7
seconds intervals for 5 times: The max intervals is 65535 seconds. You can send “at30sum0” for
heaps of times.
Send“noat123456”to the tracker, it will reply “Cancel auto track ok.”. And the tracker will stop send
messages.
15. Modes switch between “track” and “monitor”
The default mode is “track”. Send SMS “monitor + password” to the unit, and it will reply “monitor
ok!” and switch to “monitor” mode. For example send SMS: “monitor123456”. In this mode, you can
monitor tracker by call tracker card number.
Send SMS “tracker + password” to the unit, it will reply “tracker ok!” and restore to “track” mode.
For example send SMS “tracker123456”. In this mode, you can get position SMS by call tracker.
16. Modes switch between “telephone” and “web”
Set up: Send SMS “web + password” to device. For example, the password is 123456. Send SMS
“web123456” to the device, the device will reply SMS “set web ok”. After this, the tracker will report
the GPS data to IP address.
If you want to send GPS data to telephone, you can send SMS “telephone + password” to device, the
device will reply “set telephone ok”. And then, the device will send GPS data to your telephone by
SMS. (The default is sending the GPS data to the telephone)
17. Modify IP address and port
The IP address and port of the tracker can be modified and transferred data to other platform. Send
SMS “ IP + ip address + PORT + port value” to the unit. If the platform’s IP address and port is
123.67.87.9 and 344, send SMS “ip 123.67.87.9port344” to the tracker. It will reply “set IP address
and PORT ok.”. After this, device will send GPS data to this IP and Port.
18. Set Device ID number
This command uses only for GPRS communication. Default device ID is the same. In order to
identify device for platform, must set device ID for every device. Send SMS “number + tracker
ID number” to the tracker. For example “number13612345678”.
19. Set APN
In order to send GPS data to IP address, you still must set mobile network Access Point Name
(APN). If you don’t know the APN, you can consult local network service supplier. The format of set
APN is “APN + password +space + apn value”. For example you send SMS “apn123456 cmnet” to
the device. The device will reply SMS “Set APN ok.” .
20. Set GPRS user name and password
Some country must be set GPRS user name and password for GPRS communication. The format of
set GPRS user name and password is “user + space + GPRS user name + space + GPRS password”.
For example, “user name 123456”, “user” is command, “name” is GPRS user name, “123456” is

Shenzhen SUNSKY Technology Limited
GPRS password. After send SMS, tracker will reply “Set GPRS User and Password ok . ” .
21. Set country time zone
In the default, tracker reply position SMS time is UTC time. After you can set zone time, tracker
will reply the time of your country. The format is “zone + password + space + time zone value”. For
example, “zone123456 8” is set east 8 time zone. Time zone value ranges from -12 to 12. One time
zone stands for one hour. “zone123456 -8” is set west 8 time zone. After send SMS, tracker will reply
“Set Time Zone OK.”.
22. Set Web
In order to see your website in each replying Geo SMS, for example your website is
www.webs***.com, then send “home123456 www.webs***.com”.Then it will reply “set home ok”,
when you want to cancel it, just send “nohome123456”, it will reply SMS ”cancel home ok”.
◆Installation diagram of The Tracker
8

Shenzhen SUNSKY Technology Limited
9
◆GPS Vehicle Tracker Installation
GPS tracker should be installed by technical professional of local service centre. Without
permission, the user cann’t repair and move the tracker randomly. If users do, any unfortunated
damage should be compensated by himself.
Installation steps (caution: the following installation should under no power, otherwise will be
dangerous)
1.Power supply line: The red wire connects 12V“+”;Black wire connects to 12V“-”
2. Wire for cutting off oil of the tracker
Yellow wire connects the relay pin 86; 85 pin connect to 12 V DC , 87a pin and 30 pin in series
power supply circuits. Caution: Wrong connection of yellow wire will damage the tracker.
3. Wire for cutting off circuit of the tracker
White wire connects relay pin 86; 85 pin to 12 V DC, 87a pin and 30 pin are in series power supply
circuits. Caution: Wrong connection of yellow wire will damage the tracker.
4. Emergency triggering alarm
The blue wire connects the positive of the alarm button, and the black wire connects the negative of
the alarm button.
◆Application
1. Vehicle Rental/Special Tracking System
2. Finance and Insurance Business Tracking System
3. Car Commanding and Dispatching System
4. Heavy Construction Vehicles Tracking Device
5. Shipping Cargoes Tracking
◆Specs.
Content Specs.
Dim. 87 * 64 * 26 (mm)

Shenzhen SUNSKY Technology Limited
10
Weight 495g
Network GSM/GPRS/GPS
Band 900/1800/1900MHz or 850/900/1800/1900MHz
GPS chip SiRF III chip
GSM/GPRS Module SIM300 or SIM340
GPS sensitivity -159dBm
GPS accuracy 5 m
Time To First Fix
Reacquisition 0.1s
Cold status 45s
Warm status 35s
Hot status 1s
Work Voltage DC 9V－30V
Battery Chargeable changeable 3.7V / 1.2Ah Li-ion battery
Standby work current < 30mA
Storage Temp. -40°C to +85°C
Operation Temp. -20°C to +70°C
Humidity 5%--95% non-condensing
◆Command Set
No. Function SMS Reply
1 Initialization Begin123456 Begin ok
2 Add Number Admin123456 13612345678 Admin ok
3 Delete Number Noadmin123456
13612345678 Noadmin ok
4 Change
password Password123456 138138 Change password ok
5 Resume
password resumepassword Resume password ok
Stopoil123456 Stop oil ok
6 Control oil Supplyoil123456 Supply oil ok
Control circuit Stopelec123456 Stop electricity ok

Shenzhen SUNSKY Technology Limited
11
7 Supplyelec123456 Supply electricity ok
AllMonitor Set all monitor ok
RestrictMonitor Set restrict monitor ok
8
Set monitor
mode CloseMonitor Set close monitor ok
Move123456 Move ok
9 Movement alert
Nomove123456 Cancel move ok
Speed123456 080 Speed ok
10 Overspeed alert
Nospeed123456 Cancel speed ok
Stockade123456
coordinate;coordinate Set stockade ok 11 Geo fence alert
Nostockade123456 Cancel stockade ok
12 Restart tracker Reboot123456 System will reboot
13 Enquiry position position Geo info
At30sum5 Auto track set ok
14 Auto track Noat123456 Cancel auto track ok
Tracker123456 Tracker ok15 Set call response
Monitor123456 Monitor ok
Telephone123456 Set telephone ok16 Set auto track
mode Web123456 Set web ok
17 Change IP and
PORT Ip112.33.44.211port2332 set IP address and PORT ok
18 Set device id Number13612345678 set number ok
19 Set APN Apn123456 cmnet Set apn ok
20 Set GPRS user name and
password
User name pass Set GPRS user name and password ok
21 Set time zone Zone123456 8 Set time zone ok
22 Set web Home123456 www.web.com Set home ok
