SUNTEC LRC2000 User manual

Press once to enter set thermostat mode
then press the ---- or + to set thermostat
temperature.
Su
ntec
®
LRC 2000
Infrared Heater
Operation is very simple, just position the heater about 6 inches
from a wall and plug it in. On front panel of the heater you will
notice a control panel. It controls the operation of the heater.
You can use the remote controller to turn the heater on
and off, set the timer, temperature and bypass the ther-
mostat. See the remote control panel for details.
Thermostat
Press to set, in 1 hour increments, a shut
off time. You can cycle through to get
back to 0. This feature must be reset to
0 when used for normal operation. If the
time as been set it will continue to turn
off at the indicated hour.
On/Off Button
Remote Controller
The first time you turn on the heater it may not start . If this happens
the ambient temperature in the room my be higher then the default
temperature setting in the heater thermostat. PRESS the Temp then
the + button until the temperature reading on the front panel is set
to above the ambient room temperature, the heater will come on.
The thermostat is designed to maintain the room temperature
within 3 degrees. This means the heater will turn off when the
temperature you set the thermostat for is reached and will turn on
when the temperature drops 2-3 degrees.
The temperature displayed on the heater thermostat will vary from
the temperature displayed on the main house furnace. This is due to
the difference in the temperature of the air at the main house and
Suntec heater thermostats. The air around the Suntec thermostat
will be of a higher temperature in most cases than the air around
the main house thermostat. This is because the main system is off
and the Suntec is warming and re-circulating the air. There could be
a difference of as much as 10 degrees.This is normal and reflects
the accuracy and the efficiency of Suntec.
HEAT same as “By Pass” on controller
+Press to raise the thermostat
_Press to lower the thermostat
The first time you set
the thermostat the
display will show a higher
than ambient tempera-
ture. This is the default.
Press the --- button to
bring down the tempera-
ture to the degrees(F) that
you want the thermostat
to maintain. The termo-
stat is designed to operate
in a + or -- range of 3
degrees. You can set the
thermostat to maintain
any temperature within 3
degrees.
TIME
TEMP
Press to bypass the thermostat.
The heater will stay on until you
press the Heat button again or
turn off the heater with the power
switch.
Thermostat Display
Press to bypass the thermostat.
The heater will stay on until you
press the Heat button or turn off
the heater with the power switch.
By Pass
same as “HEAT” on panel
Questions call 1-888-499-8120
10 AM to 6 PM EST
IMPORTANT ..... READ THIS
The LRC 2000 series is Suntec’s top of the line infrared
heater and comes with a remote control. The Infrared
technology we use in the LRC 2000 produces warm air
that blends with the air in your rooms. This recirculation
produces a warm environment at a very economical cost.

Keep the heater 3 feet away from combustible materials such
as furniture, pillows, bedding, papers, clothes and curtains.
The front exhaust vent of the heater is hot when in operation
do not touch it.
Before unplugging the heater turn the heater power switch off
(located on front of unit)
If heater cord is damaged or the heater malfunctions unplug
the cord from the AC outlet. Contact a service facility.
The heater is not intended to be used outdoors or in bath-
rooms or in locations with standing water.
The front and back vents of the heater must not be obstructed
by any surface or wall. Keep the area in front of the heater
clear of any objects. Position the heater so its back is at least
6 inches from any wall or surface. The intake vent on the back
of the heater must not be obstructed.
Any modification or non-authorized repair voids any and all
warranties.
The heater requires 120 Volts AC at 15 amps (1500 watts) do
not connect the heater to a circuit that is rated less then 15
amps at 120 Volts AC. If connected to a power strip the total
load on the power strip must not exceed its rated amps (cur-
rent). Any extension cords used to connect the heater to AC
must be rated at more than 1500 watts(15 amps).
Warning
Improper use could result in electric shock, fire and injury
to people.
Operating Instructions
Suntec warrants this product free from defects in material
and workmanship for 3 years from provable date of pur-
chase in continental United States and Canada.
Within this warranty period, Suntec will repair or replace, at
its option, defective parts at no charge,provided the product
is returned, freight prepaid, in a shipper approved packing
with proof of purchase. A check or money order made pay-
able to “Suntec Warranty Repair” in the amount of $65.00
for shipping and handling charges must be included along
with a return address.
Before returning an item, please call the toll free number
listed below for a return authorization number. You will also
be given a shipping address that is close to you. Allow 2-3
weeks for return shipping.
This warranty does not cover improper installation, misuse,
abuse or neglect on the part of the owner. Warranty is also
invalid in any case that the product is taken apart or ser-
viced by an unauthorized service station.
This warranty gives you, specific legal rights, which may
vary from state to state and country. It does not cover areas
outside of the United States or Canada.
Warranty
1-888-499-8120
Administration of Suntec Warranty
1372 South 6th Street, Louisville, KY 40208
The Administration office does not accept returns sent to It. All
items are returned by the carrier.
Warranty
Made in China
Operating instructions
Please read prior to installing the Heater
LRC2000
Su
ntec
®
Questions Call 1-888-499-8120
Email [email protected]
For technical questions go to www.suntec.us
REV H
