Super Circuits MDVR21SD Series User manual

www.supercircuits.com MDVR21SD_RM
1
MDVR21SD
Advanced Solid State Mobile DVR
User Manual
Thank you for using our video recorder. This manual is applicable for 1ch, 2ch and 4ch SD Video Recorder. Please
read this User’s Manual carefully to ensure that you can use the device correctly and safely. The contents of this
manual are subject to be changed without notice.

www.supercircuits.com MDVR21SD_RM
2
Important notice:
1. Please read over all cautions.
2. Please keep this manual for reference in the future.
3. Please notice all warning information.
4. Please strictly follow the instructions in this manual while operating.
5. Please NEVER put this device under the place which is easily poured by water.
6. Please do NOT use abrasive chemicals, cleaning solvents or strong detergents to clean the device. Wipe the
device with a soft and dry cloth.
7. Please do NOT get the gate of airiness heat exchange closed.
8. Please leave the device far away from hot and high temperature environment.
9. Install the device with the accessories coming with it.
10. Please take care when moving the device, make sure of security, and avoid being damaged by dropping from
high place.
11. Call for qualified maintenance man to repair when needed.
12. The device can only be installed horizontally. Installed vertically or out of the horizontal could hurt person or
damage the device or/and its parts.
Warning
This device is NOT of waterproof; to prevent it from any accident of fire or
electric shock, please do NOT put any container with water on the device or
nearby. Do not expose the device to moisture, or extreme temperatures.
This lightning flash with
arrow symbol within an
equilateral triangle is
intended to alert users
that there might be
uninsulated dangerous
voltage which may cause
To prevent from the risk of
electric shock, do NOT
remove top cover or back
cover. There is NO
user-serviceable part
inside. Ask for service from
qualified maintenance man.
The exclamation point within
an equilateral triangle is
intended to alert users the
important operating and
maintenance(servicing)
instructions in this manual.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

www.supercircuits.com MDVR21SD_RM
3
TABLE OF CONTENTS
MDVR21SD ADVANCED SOLID STATE MOBILE DVR.................................1
1.GENERALINTRODUCTION....................................................................................5
2.PRODUCTFIGURES...............................................................................................7
2.1FRONTPANEL.........................................................................................................................................................................7
2.2REARPANEL............................................................................................................................................................................8
2.3WIRELESSREMOTECONTROLLER................................................................................................................................................9
3.INITIALSETUP......................................................................................................9
3.1TAMPER‐PROOFCASEMOUNTING..............................................................................................................................................9
3.2POWERCONNECTION.............................................................................................................................................................11
3.2.1.UseIgnitionSwitchtoTurnOn/OffDVRSystem.......................................................................................................11
3.2.2,TurnOn/OffDVRSystemAutomatically..................................................................................................................11
3.3CAMERACONNECTION...........................................................................................................................................................12
3.4SENSORHARNESSCONNECTION...............................................................................................................................................14
GPSConnection(Option)....................................................................................................................................................14
3.5EVENTBUTTONANDCABLECONNECTION(OPTION)....................................................................................................................15
4.MAINSYSTEMOVERVIEW..................................................................................16
5.BASICOPERATIONANDMENUSYSTEM..............................................................17
5.1SDCARDFORMATTING...........................................................................................................................................................17
5.2CHOOSERECORDINGMODE....................................................................................................................................................18
5.3FILELENGTH.........................................................................................................................................................................19
5.4RECORDINGQUALITY..............................................................................................................................................................19
5.5STARTRECORDING.................................................................................................................................................................21
5.6PLAYBACKOPTION.................................................................................................................................................................22
5.6.1PlaybackfilesonDVRsystem....................................................................................................................................22
5.6.2Playbackthefilesonmanufacturer’sPCPlaybackSoftware.....................................................................................25
5.7,FILEBACKUP........................................................................................................................................................................25
5.8ALARMRECORDING...............................................................................................................................................................25
5.8.1SetupTheAlarmAction.............................................................................................................................................25
5.8.2PostEventRecord......................................................................................................................................................27
5.9MOTIONDETECTION..............................................................................................................................................................28
5.9.1SetMotionDetectionZone........................................................................................................................................28
5.9.2SetMotionDetectionAction.....................................................................................................................................28

www.supercircuits.com MDVR21SD_RM
4
5.9.3SetMotionSensitivity................................................................................................................................................29
6.0VIDEOLOSTALARM...............................................................................................................................................................30
6.1SCHEDULERECORDING...........................................................................................................................................................30
6.2VIDEOSYSTEMSETTING..........................................................................................................................................................31
6.3SETDATEANDTIME...............................................................................................................................................................32
6.3.1SetDateDisplayFormat............................................................................................................................................32
6.3.2SetTheTimeZone.....................................................................................................................................................32
6.3.3SetDateandTime.....................................................................................................................................................32
6.4CONFIGURATIONSETUP..........................................................................................................................................................33
6.5USERLEVELANDPASSWORDSETTING........................................................................................................................................34
6.6NETWORKSETTING................................................................................................................................................................35
6.7MOTOR.............................................................................................................................................................................36
6.7.1Set“LICENSEID”and“LINE”......................................................................................................................................36
6.7.2GetSpeedfromGPS..................................................................................................................................................37
6.7.3GetSpeedfromSpeedometer....................................................................................................................................39
6.8MANAGETHEPOWER.............................................................................................................................................................41
6.8.1,Useignitionswitchtoturnon/offtheDVRsystem...................................................................................................41
6.8.2,TurnOn/OffDVRSystemAutomatically..................................................................................................................42
6.9USEPTZ..............................................................................................................................................................................43
6.9.1PTZControl................................................................................................................................................................43
6.9.2Renamethecamera..................................................................................................................................................44
6.9.3VideoAdjustment......................................................................................................................................................44
6.10GPSSETTING(OPTION)........................................................................................................................................................45
6.11EVENTBUTTON&CABLESETTING(OPTION)............................................................................................................................45
6.12FIRMWAREUPDATE..............................................................................................................................................................48
6.13USINGWI‐FIMODULE(OPTION)...........................................................................................................................................49
7.CONNECTION&INSTALLATIONCABLES..............................................................53
7.1POWERSUPPLYCABLE............................................................................................................................................................53
7.2VIDEO&AUDIOINPUT/OUTPUTCABLE...................................................................................................................................54
7.3SENSORHARNESS..................................................................................................................................................................55
8.SPECIFICATION...................................................................................................57
9.LISTOFSTANDARDACCESSORIES.......................................................................58
10.TROUBLESHOOTING........................................................................................59

www.supercircuits.com MDVR21SD_RM
5
1. General Introduction
The MDVR21SD series mobile digital video recorder is a compact, full-featured recording system that uses a SD card
as a storage device. The recorder unit and associated accessories are specifically designed for operation in a mobile
environment.
The MDVR21SD system, used in conjunction with the cameras, records up to four channels of full-motion video and
audio data to a Class 4 (minimum) SD card. The firmware-driven menu system provides a simple method for
configuring the unit’s operation as well as searching for and viewing previously recorded AV records.
Regulatory Compliance
The MDVR21SD complies with CE and Part 15 of the FCC interference limits for Class B digital devices FOR HOME OR
OFFICE USE. These limits are designed to provide reasonable protection against harmful interference. Operation of this
device is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Product Description
The MDVR21SD unit consists of the following major components:
Standard Components and Features
Extruded aluminum case (the case is anodized in cobalt blue).
Front and rear panels.
Mother Board.
Power, AV input and output cables.
Power input 2 amp fuses (2).
Tamper proof and lockable security enclosure.
Panel lock with (2) keys for locking the security enclosure.
Wireless remote controller.
Removable SD card, Class 4, minimum (customer supplied).
Optional Components and Features
GPS speed and location data overlay.
Wired remote cable for non line-of-sight DVR operations.
Extension cable for easy connection and installation.
Product Main Features
Embedded operating system, assuring reliability and system integrity.
Records up to four channels of full-motion color video with corresponding audio tracks.
H.264 High Profile video compression.
Total Record resource up to 100/120 D1 frame/second.
Lockable security enclosure.
Front panel USB2 port for recording to a flash card as an optional storage device.
Ignition sense that provides DVR power-on in recording mode when the bus is started.
Power-off delay record when the bus is shut-down with operator-selected delay times.

www.supercircuits.com MDVR21SD_RM
6
Video And Audio
H.264 High Profile video compression, real time recording (25 fps (PAL) / 30 fps (NTSC) for each channel. Frame
rate adjustable for each channel.
Audio compression: G.711 codec. This codec offers high compression with high quality audio.
D1 resolution for each channel, which means each channel support 720x576 (PAL)/720x480 (NTSC).
Support 4 channel real time D1 video and 4 channel audio recording.
Local video and audio real time playback.
GPS Time Synchronization & Time Zone
Synchronize the DVR system time with GPS automatically
Support All Time Zones Worldwide
Support DST (Daylight Saving Time)
Power Management
Reliable power management, wide voltage: +8VDC~+40VDC; The power input is protected against short
positive transient (1500 watts peak pulse power capability with a 10x1000 us waveform); The power input is
protected against negative voltage. Applicable for vehicles with +12V or +24V battery.
The recorder provides each camera with stable +12V DC power; DVR can detect the short cut on power circuit.
Can use ignition to control the power.
DVR can monitor battery voltage after Ignition off, and auto into sleep mode when voltage is bellow specified
level.
Recording mode
Continuous record.
Support schedule recording.
Support alarm recording.
Support motion detection recording.
Support 2 recording mode, composite mode and separate mode.
Speed and Vehicle status recording
Record vehicle speed and car id with audio and video.
Support 5 sensors, can be connected to speed, ignition, brake, return, right turn, left turn light etc.
Over-speed alarm.
Specified screen can be full screen displayed when return sensor trigged.
SD card plug and play
Support SDHC card within 32GByte.
Support SDXC card more than 64GByte (Maxim 2048GByte)
Support plug and play for SD card when not recording and playing.
Note: If you remove the SD card while recording or playing, it might cause the damage of the file on
SD card. While recording or playing, the yellow light on the front panel will be on. So please stop
recording or playing until the yellow light is off if you need to remove the SD card.
Multiple player supported
You may use manufacturer’s PC Playback Software or any of the following third party media player to play back the
record file.
VLC media player (version1.0.0 or above);
Storm player (Version 2009 or above);
Winamp (Version 5.531 or above).

www.supercircuits.com MDVR21SD_RM
7
2. Product Figures
2.1 Front Panel
①：SD Card Slot
②：Status Lights (Power, Run, Alarm, SD Card, Record Status)
③：Stop Button: For stop recording.
④：LANC Port: For connection to an Event Cable or a wired remote IR sensor harness (option)
: Infra-Red receiver window.
⑥：USB Port: Can be used as a secondary recording device, such as a flash memory card. This port cannot be used
as a direct access link to a PC, however.
⑦：Network Port (RJ45).
Get to know the status of DVR system by the indication of LED lights:
1. PWR (Green) 2. RUN (Green) Status/Description
Always On Blinking MDVR21SD is on & running
Blinking with RUN by turns Blinking with PWR by turns Ignition is not enabled and MDVR21SD is OFF.
Blinking together with RUN Blinking together with PWR Ignition sense is not enabled & MDVR21SD is
running. Unit will turn OFF when “Delay Time”
setting is reached.
Blinking every 3 seconds Off Select PWR on the remote control to restart.
3. ALARM (Red) Status/Description
On Alarm input when BEEP is set as “ON”. Audible alarm (beep) when enabled.
Off No alarm.

www.supercircuits.com MDVR21SD_RM
8
4. SD (Red) Description
On Writing data to the SD Card.
Off Not writing – inactive.
5. REC (Yellow) Description
On Recording data. CAUTION: Do not attempt to remove the SD card while SYS
mode is active. Select “STOP” on the front panel or remote control to stop
recording.
Off Not recording.
2.2 Rear panel
①：Power, Ground and ACC input.
②：AV input 1(including audio input 1, video input 1 and power output for camera 1)
③：AV input 2(including audio input 1, video input 1 and power output for camera 2)
④：AV input 3(including audio input 1, video input 1 and power output for camera 3)
⑤：AV input 4(including audio input 1, video input 1 and power output for camera 4)
⑥：AV output (including audio output, video output and power output)
⑦：1x speed sensor, 3x sensors inputs, 2x RS232 port, 1x RS485 port and 1x 5V DC output.
The sockets on rear panel are of Molex Micro-Fit 3.0 (Model No.: Molex 0430450200). The
definition of all sockets are given as below:

www.supercircuits.com MDVR21SD_RM
9
2.3 Wireless Remote Controller
How to use the remote:
1) Press <MENU> to enter DVR system menu or sub menu. You can also use <MENU> to select among
different value in the submenu. You can also use <MENU> as <OK>;
2) Press <UP/DOWN/LEFT/RIGHT> button to move between the different menu item;
3) Press <OK> to save and exit the current menu. Press <ESC> to cancel and exit the current menu. If you modify
something in the menu, recorder will prompt a window to ask you to save or cancel your modification;
4) Press <VIDEO> to toggle among different video channel;
5) Press <AUDIO> to toggle among different audio channel;
6) To delete character in the edit control, you can press < >;
7) Press <POWER> for a while to turn on/off the recorder.
3. Initial Set Up
3.1 Tamper-proof Case Mounting
1) Use a power drill and screws supplied to fix the bottom cover of the tamper-proof case in the right place inside
the vehicle.
1. Power
2. Alarm
3. Digits
4. Record
5. Stop
6. Play
7. Audio Toggle
8. Up
9. Video Toggle
10. Left/Backspace
11. Menu/Enter
12. Right
13. ESC
14. Down
15. OK to confirm
16. Fast Forward
17. Next
18. Pause/Step
19. Fast Backward
20. Previous
21. OSD

www.supercircuits.com MDVR21SD_RM
10
2) Put the DVR system inside the bottom cover, and load a SD Card.
NOTE: The lock jumper of SD Card should be in OFF position. Kingston Class 4 or above, Transcend
Class 6 or above is recommended for fast write speed.
3) Close with the top cover and lock it with keys supplied.

www.supercircuits.com MDVR21SD_RM
11
3.2 Power Connection
3.2.1. Use Ignition Switch to Turn On/Off DVR System
3.2.2, Turn On / Off DVR System Automatically
NOTE
1. The DVR uses DC power input, please be very careful when connecting to the “+” and “-” of the power supply.
2. Wide voltage range of 8V-32V for the DVR. The DVR may be damaged if the voltage comes too high. And the
DVR may not work if the voltage comes too low.
3. Power of the DVR should be supplied by the car battery.
4. Power consumption of the DVR can be 60W when the engine starts. All the cables for connecting from power to
the DVR should be thick enough for current over 5 Amperes.

www.supercircuits.com MDVR21SD_RM
12
5. To protect the battery frombeing damaged of short circuit, the fuse should be placed very closed to the “+” pole
of car battery.
3.3 Camera Connection
Two different kinds of Audio & Video Cables for option:
1) 4-pin threaded cable with male connector for each camera (Pin 1: 12V power, Pin 2: GND, Pin 3: Audio Input,
Pin 4: Video Input).
With extension cable (3m, 5m and 10m option):

www.supercircuits.com MDVR21SD_RM
13
NOTE: The camera should with 4-pin female connector to match this cable. The DVR system will
provide stable 12V DC power to each camera, and record video and audio (if the camera is with
microphone built-in). This type of connection cable is highly recommended. It saves both installation
time and cost.
2) AV Input cable with BNC (Video, in yellow), RCA(Audio, in white) and DC connectors for each camera:

www.supercircuits.com MDVR21SD_RM
14
3.4 Sensor Harness Connection
GPS Connection (Option)
PIN Description
3 RXD2: Data receive
5 GND: Ground
9 +5V DC: Power output

www.supercircuits.com MDVR21SD_RM
15
3.5 Event Button and Cable Connection (Option)

www.supercircuits.com MDVR21SD_RM
16
4. Main System Overview

www.supercircuits.com MDVR21SD_RM
17
5. Basic Operation and Menu System
5.1 SD Card Formatting
For a brand new SD Card of SDHC standard, it can be used directly. But with situations listed below, you’re required
to format it before using:
1) If the SD Card is of SDXC standard (like a 64GB SD Card), the defaulted file format is exFAT, which will not be
recognized by the DVR system. You have to format it by using FAT32 file system on your PC. Partition Manager,
which can be downloaded from internet free of charge, is recommended to be used for fast formatting and
batch processing.
2) If the SD Card is never formatted, or the file system is corrupted, you may have to format it before using. This
can be done on your PC by using FAT32 file system, or format it on the DVR system itself by following steps
given below:
3) Insert the SD Card into the SD Card slot on front panel of the DVR system;
4) Press <MENU> by remote to enter the DVR system menu;
a) Choose “STORAGE” and press <MENU> to enter its sub-menu.
b) Go to “FORMAT” and press <MENU> to get ready for formatting.

www.supercircuits.com MDVR21SD_RM
18
The format process will take some time, please wait. You will see the capacity of SD card after formatting.
5.2 Choose Recording Mode
Two recording modes for option: Composite Mode and Separate Mode. The defaulted recording mode is
“Separate Mode”. You can change to “Composite Mode” by steps given as below if needed:
a) Press <MENU> by remote;
b) Choose ”RECORD” to enter it sub-menu;
c) Set the “CHANNEL MODE” as ”COMPOSITE MODE” ;
d) Press <MENU> to confirm;
e) Press <ESC> to save and exit.

www.supercircuits.com MDVR21SD_RM
19
5.3 File Length
Options for file length: 5mins, 10mins, 15mins, 20mins, 30mins, 45mins and 60mins. The defaulted file length is 5
minutes. The maximum file length is 60 minutes.
5.4 Recording Quality
Press <MENU> to enter the DVR system menu, choose “RECORD” and enter its sub-menu, go to “RECORD
SETTINGS” and press <MENU> to enter.
1) Setting Menu for Composite Mode:

www.supercircuits.com MDVR21SD_RM
20
2) Setting menu for Separate Mode:
