Superfire VAMPIRE V1-C User manual

Specifications
18300 MT. BALDY CIRCLE
FOUNTAIN VALLEY, CA 92708-6122
SUREFIRE.COM
Patents: RE40125, 8,182,109
Revision C 2-2018
71-01-1018
V1-C-BK
V1-C VAMPIRE
®
RED-LIGHT/INFRARED (IR) OUTPUT LED
V1-C-BK
BODY
LED
ASSEMBLY
TAILCAP
USER MANUAL
Output (Red)
(IR)
Runtime* (Red)
(IR)
Weight
Length
Bezel Diameter
0.4 lumens
100 mW
100 hrs
8 hrs 45 min
3.1 oz (88 g)
4.18 in (10.6 cm)
1.06 in (2.7 cm)
V1-C
*All performance claims tested to ANSI/NEMA FL-2009 standard.
SUREFIRE NO-HASSLE GUARANTEE
We’ll do what it takes to keep your SureFire gear running smoothly. SureFire
warrants that if you — our customer — purchase one of our products, and
we determine that it is defective in material and/or workmanship during your
lifetime, we will repair or replace it — no hassle!
Our warranty does not cover consumables or normal wear-and-tear — things
like batteries draining, headbands and headpads wearing out, ink cartridges
running out, and switches wearing out — or damage resulting from abuse,
alterations, unauthorized repairs, or use contrary to SureFire’s user manuals.
Should you need a replacement product, Surefire reserves the right to replace
an obsolete product with a current production, like model. In the event that any
issue with a SureFire product is not covered under this warranty SureFire can
arrange to have the product repaired for a reasonable fee.
STANDARD DISCLAIMER
Except as specified above or prohibited by applicable law: all express or implied conditions
and warranties, including, without limitation, any implied warranty or condition of
merchantability or fitness for a particular purpose, or accuracy of any informational
content, are hereby excluded and disclaimed by SureFire; and in no event will SureFire
be liable for any special, direct, indirect, consequential, incidental or punitive damages
howsoever arising and regardless of the theory of liability, even if advised of the possibility
of such damages. Products, prices, availability, specifications, and offers are subject to
change or cancellation at any time without notice.
WARRANTY CLAIMS
For claims, contact Customer Service at 714-545-9444 to obtain a Return
Merchandise Authorization number (RMA#). Then package the unit carefully
and send to (no CODs):
SureFire, LLC.
Repairs Department, RMA#____
17680 Newhope, Suite B
Fountain Valley, CA 92708
SureFire will pay any reasonable shipping costs to return the unit to you.

INTRODUCTION
The ultra-compact, dual-spectrum V1 Vampire allows selection
between red light and infrared illumination, generated by a single
all-LED head, with no IR filter required. A self-locking bezel selector
ring sets the spectrum, red light or IR, and the light is activated
by pressing or clicking the tailcap switch. The V1 Vampire runs
on a single 123A lithium battery and is constructed of aerospace
aluminum that’s Mil-Spec hard anodized for extreme durability.
LOCKOUT TAILCAP
The V1 Vampire features a lockout tailcap, which prevents accidental
activation during storage or transport. The tailcap may need to be
enabled prior to light operation.
To enable, rotate tailcap clockwise until light activates when tailcap
pushbutton is pressed, providing momentary-on light output.
To lock out tailcap, rotate counterclockwise until light will not
activate when pressed.
LIGHT OPERATION
NOTE: Unit is shipped in the “OFF” position to prevent activation
of the light.
1. To select red LED, rotate knurled portion of the bezel clockwise (with
bezel pointed away from you) until indicator dot aligns with RD and
the head clicks in to position (Fig. 1).
2. To select IR LED, rotate knurled portion of the bezel counter clock
wise (with bezel pointed away from you) until indicator dot aligns
with IR and the head clicks in to position (Fig. 2).
V1-C VAMPIRE®
Light Activation
In RD mode, press or click pushbutton switch for the 0.4 lumen
output. In IR mode, press or click pushbutton switch for the
100 mW output.
BATTERY REPLACEMENT
Most SureFire illumination tools ship preloaded with batteries. To load
or replace batteries:
1. Unscrew head and remove.
2. Remove old batteries and dispose of properly.
3. Insert new battery with positive (+) terminals oriented forward.
4. Replace head and screw on until hand tight.
MAINTENANCE
Use a clean, dry cloth to wipe off body and window. Periodically clean
and lubricate threads. Apply a thin coat of non-migrating, silicon-based
lubricant to O-rings (do not use petroleum-based lubricants which
can harm O-rings). For additional tips on maintaining your SureFire
illumination tool, visit www.surefire.com/faqs-maintenance.
ACCESSORIES
SureFire makes a full line of accessories for most of its illumination tools.
For a complete listing, visit www.surefire.com/partsaccessories.
ENABLE
DISABLE
FIGURE 2FIGURE 1
