Supermicro MicroBlade MBI-6119G-C2 User manual

MBI-6119G-C2
MicroBlade™ Module
User’s Manual
Revison 1.0b

MBI-6119G-C2 MicroBlade Modules User’s Manual
ii
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The
vendor assumes no responsibility for any inaccuracies that may be contained in this document, and
makes no commitment to update or to keep current the information in this manual, or to notify any person
or organization of the updates. Please Note: For the most up-to-date version of this manual, please
see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described
in this manual at any time and without notice. This product, including software and documentation, is the
property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction
of this product is not allowed, except as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT,
INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR
RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara
County in the State of California, USA. The State of California, County of Santa Clara shall be the
exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not
exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in industrial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the manufacturer’s instruction manual, may cause harmful interference with radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case you
will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning
applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
Manual Revison 1.0b
Release Date: June 25, 2020
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy
any part of this document. Information in this document is subject to change without notice. Other
products and companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 2020 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!

iii
Preface
About this Manual
This manual is written for professional system integrators, Information Technology
professionals, service personnel and technicians. It provides information for the
installation and use of the Supermicro MBI-6119G-C2 and MBI-6119G-T4 MicroBlade
modules. Installation and maintenance should be performed by experienced
professionals only.
The only difference between the MBI-6119G-C2 and MBI-6119G-T4 MicroBlade
modules is that the MBI-6119G-C2 MicroBlade module uses the B2SS1-CF
motherboard and SAS3 HDD drives, while the MBI-6119G-T4 MicroBlade module uses
the B2SS1-F motherboard and SATA3 HDD drives.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with the
MicroBlade modules and describes their main features.
Chapter 2: System Safety
You should familiarize yourself with this chapter for a general overview of safety
precautions that should be followed when installing and servicing the MicroBlade
modules.
Chapter 3: Setup and Installation
Refer to this chapter for details on installing the MicroBlade modules into the MicroBlade
chassis. Other sections cover the installation and placement of memory modules and
the installation of hard disk drives into the blade module.
Chapter 4: Blade Module Features
This chapter coves features and component information about the MicroBlade modules.
Included here are descriptions and information for mainboard components, connectors,
LEDs and other features of the blade module.
Chapter 5: BIOS
BIOS setup is covered in this chapter for the MicroBlade modules.
Appendix A: BIOS POST Codes
BIOS POST Codes for the MicroBlade modules are explained in this appendix.

MBI-6119G-C2 MicroBlade Modules User’s Manual
iv
Secure Data Deletion
A secure data deletion tool designed to fully erase all data from storage devices can be
found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/
wftp/utility/Log9_Secure_Data_Deletion_Utility/

v
Table of Contents
Chapter 1 Introduction.......................................................................1-1
1-1 Overview.............................................................................................1-1
1-2 Blade Module Features ....................................................................1-2
Processors ..............................................................................................1-2
Memory ................................................................................................... 1-2
Storage ...................................................................................................1-3
RAID .......................................................................................................1-3
Density ....................................................................................................1-3
BMC Password .......................................................................................1-3
1-3 Contacting Supermicro.....................................................................1-4
Chapter 2 Standardized Warning Statements.....................2-1
2-1 About Standardized Warning Statements .....................................2-1
Warning Definition...................................................................................2-1
Installation Instructions ...........................................................................2-3
Circuit Breaker ........................................................................................2-4
Power Disconnection Warning................................................................2-5
Equipment Installation.............................................................................2-6
Restricted Area .......................................................................................2-7
Battery Handling .....................................................................................2-9
Redundant Power Supplies ..................................................................2-10
Backplane Voltage ................................................................................2-11
Comply with Local and National Electrical Codes.................................2-12
Product Disposal...................................................................................2-13
Hot Swap Fan Warning .........................................................................2-14
Power Cable and AC Adapter ..............................................................2-15
Chapter 3 Setup and Installation.................................................3-1
3-1 Overview.............................................................................................3-1
3-2 Installing MicroBlade Modules ........................................................3-1
Powering Up a MicroBlade Module Unit .................................................3-1
Powering Down a MicroBlade Module Unit.............................................3-1
Removing a MicroBlade Module Unit from the Enclosure ......................3-2
Installing a Blade Unit into the Enclosure ...............................................3-2
3-3 Onboard Battery Installation............................................................3-3
3-4 Processor and Heatsink Installation...............................................3-4

MBI-6119G-C2 MicroBlade Modules User’s Manual
vi
Installing the Processor(s) ......................................................................3-4
Installing a Heatsink................................................................................3-6
Removing a Heatsink..............................................................................3-7
3-5 Memory Installation...........................................................................3-8
Populating Memory Slots ........................................................................3-8
DIMM Installation ....................................................................................3-9
3-6 Hard Disk Drive Installation ...........................................................3-10
3-7 Installing the Operating System....................................................3-10
Installing via PXE Boot..........................................................................3-10
Installing via Virtual Media (Drive Redirection) .....................................3-10
Chapter 4 MicroBlade Module Features .................................4-1
4-1 Control Panel .....................................................................................4-2
Power Button ..........................................................................................4-3
LED Indicators ........................................................................................4-3
4-2 Motherboard.......................................................................................4-4
Jumpers ..................................................................................................4-7
CMOS Clear............................................................................................4-7
4-3 Blade Unit Components ...................................................................4-8
Memory Support .....................................................................................4-9
Hard Disk Drives .....................................................................................4-9
Chapter 5 BIOS.......................................................................................5-1
5-1 Introduction.........................................................................................5-1
System BIOS ..........................................................................................5-1
How To Change the Configuration Data .................................................5-1
Starting the Setup Utility .........................................................................5-1
5-2 BIOS Updates....................................................................................5-2
5-3 Running Setup ...................................................................................5-3
5-4 Main BIOS Setup...............................................................................5-4
5-5 Advanced Setup ................................................................................5-5
5-6 Event Logs Setup............................................................................5-16
5-7 IPMI Setup........................................................................................5-17
5-8 Security .............................................................................................5-19
5-9 Boot ...................................................................................................5-21
5-10 Save & Exit.....................................................................................5-22

vii
:
Appendix A AMI UEFI BIOS POST Codes..............................A-1
A-1 Checkpoint Ranges ..........................................................................A-1
A-2 Standard Checkpoints......................................................................A-2
A-3 OEM-Reserved Checkpoint Ranges .............................................A-9

MBI-6119G-C2 MicroBlade Modules User’s Manual
viii
Notes

1-1
Chapter 1
Introduction
1-1 Overview
This user’s manual covers the MBI-6119G-C2 MicroBlade module. These MicroBlade
module are compact self-contained servers that connect into pre-cabled enclosures that
provide power, cooling, management and networking functions. One enclosure for these
MicroBlade module can hold twenty-eight blade units. These MicroBlade module use
the Intel Xeon E3-1200 v5 processor.
In this manual, “blade system” refers to the entire system (including the enclosure and
blades units), “blade”, “MicroBlade” or “blade unit” refers to a single MicroBlade module
and “blade enclosure” is the chassis that the MicroBlades, power supplies and
MicroBlade modules are housed within.
Please refer to our web site for information on operating systems that have been
certified for use with the MicroBlade (http://www.supermicro.com/products/nfo/
microblade.cfm).
Note: For your system to work properly, please follow the links below to download all
necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• If you have any questions, please contact our support team at:
[e-mail]
Note: A complete list of safety warnings is provided on the Supermicro web site at
http://www.supermicro.com/about/policies/safety_information.cfm.

MBI-6119G-C2 MicroBlade Modules User’s Manual
1-2
1-2 Blade Module Features
Table 1-1 lists the main features of the MicroBlade module. See the proceeding section
for components typically included in a blade system and other optional components.
Specific details for the MBI-6119G-C2 MicroBlade module are found in Chapter 4:
MicroBlade Module Features" on page 4-1.
Processors
The MBI-6119G-C2 MicroBlade module supports a single H4 (LGA 1151) Intel Xeon
E3-1200 v5 series processor in a H4 (LGA 1151) socket embedded in the motherboard.
This system uses the Intel C236 chipset.
Refer to the Supermicro web site for a complete listing of supported processors (http://
www.supermicro.com/products/microblade). Please note that you will need to check the
detailed specifications of a particular blade module for a list of the CPUs it supports.
Details on installation of the processor into the MBI-6119G-C2 MicroBlade module is
found in Chapter 3: Setup and Installation" on page 3-1.
Memory
The MBI-6119G-C2 MicroBlade module has four 288-pin DIMM sockets that can
support up to 64 GB of DDR4 2133 MHz speed, 16 GB size, 1.2 V voltage 2RX8 ECC
VLP UDIMM memory. Memory is interleaved, which requires modules to be of the same
size and speed.
Please refer to the Supermicro web site for a list of supported memory http://
www.supermicro.com/products/microblade The detailed specifications for a blade
module will contain a link to a list of recommended memory sizes and manufacturers.
Details on installation of memory modules into the MBI-6119G-C2 MicroBlade module is
found in Chapter 3: Setup and Installation" on page 3-1.
Table 1-1. MBI-6119G-C2 MicroBlade Module Specification Features
Motherboard B2SS1-CPU (MBI-6119G-C2) (proprietary form factor)
Enclosures MBE-628E-xxx and MBE-314E-xxx
Chassis Specifications Chassis Dimensions (HxWxD): 1.2" x 4.94" x 23.2" (30.48-mm x
125.476-mm x 589.28-mm), Gross Weight: 5.01 lbs (2.27 kg)
Processors One Intel Xeon E3-1200 v5 embedded in a H4 (LGA 1151) socket on the
motherboard
BIOS 128 Mb SPI Flash EEPROM with AMI® BIOS
Memory Capacity Supports up to 64 GB of DDR4 2133 MHz speed and 16 GB size, 1.2 V
voltage 2RX8 ECC VLP UDIMM memory in four 288-pin DIMM sockets
Hard Drive Bays Supports up to two SSD or two SAS3/SATA3 Spindle HDD 2.5" drives

1-3
Chapter 1: Introduction
Storage
The MBI-6119G-C2 MicroBlade module can have either two SSD or two SAS3/SATA3
Spindle HDD 2.5" drives internally mounted for storage or for installation of the blade’s
operating system. The MBI-6119G-C2 MicroBlade module uses SAS3 drives for its
system. See Chapter 3: Setup and Installation" on page 3-1 for storage installation
details.
RAID
The MBI-6119G-C2 MicroBlade module supports up to two SSD or two SAS3/SATA3
Spindle HDD drives so RAID 0, 1 and 10 is supported.
Density
A maximum of twenty-eight blade modules may be installed into a single blade
enclosure. Each blade enclosure is a 6U form factor, so a standard 42U rack may
accommodate up to seven enclosures with 196 blade nodes or the equivalent of 196 1U
servers. With the inclusion of up to fourteen CMM modules and up to twenty-eight
Gigabit Ethernet switches this would occupy up to 238 space in a conventional 1U
server configuration.
BMC Password
For security, each blade unit is assigned a unique default BMC password for the ADMIN
user. It can be found on a sticker on the blade service tab, and a sticker on the
motherboard. The sticker also displays the BMC MAC address. For more information,
refer to our website at https://www.supermicro.com/en/support/
BMC_Unique_Password. The service tab and an example sticker are illustrated below.
Service Tab
Password
Sticker

MBI-6119G-C2 MicroBlade Modules User’s Manual
1-4
1-3 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
‘s-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email:
[email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 23511
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]w
Tel: [phone]

2-1
Chapter 2: Standardized Warning Statements
Chapter 2
Standardized Warning Statements
2-1 About Standardized Warning Statements
The following statements are industry standard warnings, provided to warn the user of
situations which have the potential for bodily injury. Should you have questions or
experience difficulty, contact Supermicro's Technical Support department for
assistance. Only certified technicians should attempt to install or configure components.
Read this appendix in its entirety before installing or configuring components in the
Supermicro chassis
These warnings may also be found on our website at http://www.supermicro.com/
about/policies/safety_information.cfm.
Warning Definition
Warning!
This warning symbol means danger. You are in a situation that could cause
bodily injury. Before you work on any equipment, be aware of the hazards
involved with electrical circuitry and be familiar with standard practices for preventing
accidents.
警告の定義
この警告サインは危険を意味します。
人身事故につながる可能性がありますので、いずれの機器でも動作させる前に、
電気回路に含まれる危険性に注意して、標準的な事故防止策に精通して下さい。
此警告符号代表危险。
您正处于可能受到严重伤害的工作环境中。在您使用设备开始工作之前，必须充分意识到
触电的危险，并熟练掌握防止事故发生的标准工作程序。请根据每项警告结尾的声明号码
找到此设备的安全性警告说明的翻译文本。
此警告符號代表危險。
您正處於可能身體可能會受損傷的工作環境中。在您使用任何設備之前，請注意觸電的危
險，並且要熟悉預防事故發生的標準工作程序。請依照每一注意事項後的號碼找到相關的
翻譯說明內容。

MBI-6119G-C2 MicroBlade Module User’s Manual
2-2
Warnung
WICHTIGE SICHERHEITSHINWEISE
Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu
Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den
Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor
Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen
Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de
manipular cualquier equipo, considere los riesgos de la corriente eléctrica y
familiarícese con los procedimientos estándar de prevención de accidentes. Al final de
cada advertencia encontrará el número que le ayudará a encontrar el texto traducido en
el apartado de traducciones que acompaña a este dispositivo.
GUARDE ESTAS INSTRUCCIONES.
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation
pouvant entraîner des blessures ou des dommages corporels. Avant de travailler sur un
équipement, soyez conscient des dangers liés aux circuits électriques et
familiarisez-vous avec les procédures couramment utilisées pour éviter les accidents.
Pour prendre connaissance des traductions des avertissements figurant dans les
consignes de sécurité traduites qui accompagnent cet appareil, référez-vous au numéro
de l'instruction situé à la fin de chaque avertissement.
CONSERVEZ CES INFORMATIONS.
ןונקתתורהצהאהרהז
ןה תואבה תורהצהאינפמ שמתשמה תא ריהזהל תנמ לע ,היישעתה ינקת יפ לע תורהזהלבח
ה וא תולאש שיו הדימב .תירשפא תיזיפי,יהשלכ היעבב תולקתרוציל שיהכימת תקלחמ םע רשק
רידגהל וא ןיקתהל םיאשר דבלב םיכמסומ םיאנכט .ורקימרפוס לש תינכטתאה.םיביכר
אורקל שי.ורקימרפוס יזראמב םיביכרה תרדגה וא תנקתה ינפל ואולמב חפסנה תא
. ﻲﻓ ﻚﻧانأ ﻦﻜﻤﯾ ﺔﻟﺎﺣﻲﻓ ﺐﺒﺴﺘﺗﺔﺑﺎﺻاﺔﯾﺪﺴﺟ ﺰﻣﺮﻟا اﺬھﻲﻨﻌﯾﺮﻄﺧ !ﺮﯾﺬﺤﺗ
نأ ﻞﺒﻗيأ ﻰﻠﻋ ﻞﻤﻌﺗتاﺪﻌﻣ،ﻛﻢﻠﻋ ﻰﻠﻋ ﻦﻦﻋ ﺔﻤﺟﺎﻨﻟا ﺮطﺎﺨﻤﻟﺎﺑﺮﺋاوﺪﻟا
ﺔﯿﺋﺎﺑﺮﮭﻜﻟا
ﻛوﺔﯾارد ﻰﻠﻋ ﻦرﺎﻤﻤﻟﺎﺑتﺎﺳﺔﯿﺋﺎﻗﻮﻟاﻟﻊﻨﻤعﻮﻗويأثداﻮﺣ
ﻢﻗر مﺪﺨﺘﺳانﺎﯿﺒﻟاصﻮﺼﻨﻤﻟاﺔﯾﺎﮭﻧ ﻲﻓﺮﯾﺬﺤﺗ ﻞﻛرﻮﺜﻌﻠﻟﺎﮭﺘﻤﺟﺮﺗ

2-3
Chapter 2: Standardized Warning Statements
안전을 위한 주의사항
경고 !
이 경고 기호는 위험이 있음을 알려 줍니다 . 작업자의 신체에 부상을 야기 할 수 있는
상태에 있게 됩니다 . 모든 장비에 대한 작업을 수행하기 전에 전기회로와 관련된 위험
요소들을 확인하시고 사전에 사고를 방지할 수 있도록 표준 작업절차를 준수해 주시기
바랍니다 .
해당 번역문을 찾기 위해 각 경고의 마지막 부분에 제공된 경고문 번호를 참조하십시오
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwings symbool betekent gevaar. U verkeert in een situatie die lichamelijk
letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich
bewust te zijn van de bij een elektrische installatie betrokken risico's en dient u op de
hoogte te zijn van de standaard procedures om ongelukken te voorkomen. Gebruik de
nummers aan het eind van elke waarschuwing om deze te herleiden naar de
desbetreffende locatie.
BEWAAR DEZE INSTRUCTIES
Installation Instructions
Warning!
Read the installation instructions before connecting the system to the power
source.
設置手順書
システムを電源に接続する前に、設置手順書をお読み下さい。
警告
将此系统连接电源前 , 请先阅读安装说明。
警告
將系統與電源連接前，請先閱讀安裝說明。
Warnung
Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen
lesen.
¡Advertencia!
Lea las instrucciones de instalación antes de conectar el sistema a la red de
alimentación.

MBI-6119G-C2 MicroBlade Module User’s Manual
2-4
Attention
Avant de brancher le système sur la source d'alimentation, consulter les directives
d'installation.
시스템을 전원에 연결하기 전에 설치 안내를 읽어주십시오 .
Waarschuwing
Raadpleeg de installatie-instructies voordat u het systeem op de voedingsbron aansluit.
Circuit Breaker
Warning!
This product relies on the building's installation for short-circuit (overcurrent)
protection. Ensure that the protective device is rated not greater than: 250 V,
20 A.
サーキット・ブレーカー
この製品は、短絡（過電流）保護装置がある建物での設置を前提としています。
保護装置の定格が 250V、20A を超えないことを確認下さい。
警告
此产品的短路 ( 过载电流 ) 保护由建筑物的供电系统提供 , 确保短路保护设备的额定电流不
大于 250V,20A。
警告
此產品的短路 ( 過載電流 ) 保護由建築物的供電系統提供 , 確保短路保護設備的額定電流
不大於 250V,20A。
Warnung
Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw.
Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der
Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt.
¡Advertencia!
Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del
edificio. Asegúrese de que el dispositivo de protección no sea superior a: 250 V, 20 A.
Attention
Pour ce qui est de la protection contre les courts-circuits (surtension), ce produit dépend
de l'installation électrique du local. Vérifiez que le courant nominal du dispositif de
protection n'est pas supérieur à :250 V, 20 A.
אורקל שירוקמל תכרעמה רוביח ינפל הנקתה תוארוה תאחתמ.
ﻟا تادﺎﺷرإ ﺮﻗاﺐﯿﻛﺮﺘﻞﯿﺻﻮﺗ ﻞﺒﻗﻰﻟإ مﺎﻈﻨﻟاﺔﻗﺎﻄﻠﻟ رﺪﺼﻣ

2-5
Chapter 2: Standardized Warning Statements
경고 !
이 제품은 전원의 단락 ( 과전류 ) 방지에 대해서 전적으로 건물의 관련 설비에 의존합니
다 . 보호장치의 정격이 반드시 250V( 볼트 ), 20A( 암페어 ) 를 초과하지 않도록 해야
합니다 .
Waarschuwing
Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische
installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan
250V, 20A.
Power Disconnection Warning
Warning!
The system must be disconnected from all sources of power and the power
cord removed from the power supply module(s) before accessing the chassis
interior to install or remove system components.
電源切断の警告
システムコンポーネントの取り付けまたは取り外しのために、シャーシー内部にアクセ
スするには、
システムの電源はすべてのソースから切断され、電源コードは電源モジュールから取り
外す必要があります。
警告
在你打开机箱并安装或移除内部器件前 , 必须将系统完全断电 , 并移除电源线。
警告
在您打開機殼安裝或移除內部元件前，必須將系統完全斷電，並移除電源線。
Warnung
Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt
sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den
Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu
entfernen.
לע ךמתסמ הז רצומנגההתעינמל םינבמב תנקתומהיכ אדוול שי .ילמשח רצק
רצקה ינפמ ןגמה רישכמהילמשחהמ רתוי אל אוה-
250 V, 20 A
ﺞﺘﻨﻤﻟا اﺬھﻰﻠﻋ ﺪﻤﺘﻌﯾتاﺪﻌﻣﺔﯾﺎﻤﺤﻟاةﺮﯿﺼﻘﻟاﺮﺋاوﺪﻟا ﻦﻣﺎﮭﺘﯿﺒﺜﺗ ﻢﺗ ﻲﺘﻟاﻲﻓ
ﻰﻨﺒﻤﻟا
20A, 250V : ﻦﻣ ﺪﻛﺄﺗنأﻢﯿﯿﻘﺗزﺎﮭﺠﻟاﻟاﻲﺋﺎﻗﻮﺲﯿﻟﻦﻣ ﺮﺜﻛأ

MBI-6119G-C2 MicroBlade Module User’s Manual
2-6
¡Advertencia!
El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico
quitado de los módulos de fuente de alimentación antes de tener acceso el interior del
chasis para instalar o para quitar componentes de sistema.
Attention
Le système doit être débranché de toutes les sources de puissance ainsi que de son
cordon d'alimentation secteur avant d'accéder à l'intérieur du chassis pour installer ou
enlever des composants de systéme.
경고 !
시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시
전원 공급장치로부터 연결되어있는 모든 전원과 전기코드를 분리해주어야 합니다 .
Waarschuwing
Voordat u toegang neemt tot het binnenwerk van de behuizing voor het installeren of
verwijderen van systeem onderdelen, dient u alle spanningsbronnen en alle
stroomkabels aangesloten op de voeding(en) van de behuizing te verwijderen.
Equipment Installation
Warning!
Only trained and qualified personnel should be allowed to install, replace, or
service this equipment.
機器の設置
トレーニングを受け認定された人だけがこの装置の設置、交換、またはサービスを許
可されています。
警告
只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。
警告
只有經過受訓且具資格人員才可安裝、更換與維修此設備。
יילמשח קותינ ינפמ הרהזא
!הרהזא
למשחה תורוקמ לכמ תכרעמה תא קתנל שיריסהל שיוקפסהמ ילמשחה לבכ תא
נקתה ךרוצל זראמה לש ימינפה קלחל השיג ינפלתרסה ואת.םיביכר
ﻞﺼﻓ ﺐﺠﯾمﺎﻈﻨﻟاﻊﯿﻤﺟ ﻦﻣردﺎﺼﻣﺔﻗﺎﻄﻟاﺔﻟازإوءﺎﺑﺮﮭﻜﻟا ﻚﻠﺳﻦﻣةﺪﺣوداﺪﻣا
ﺔﻗﺎﻄﻟاﻞﺒﻗ
ﻰﻟإ لﻮﺻﻮﻟاﺔﯿﻠﺧاﺪﻟا ﻖطﺎﻨﻤﻟاﻟﻞﻜﯿﮭﻠﺔﻟازإ وأ ﺖﯿﺒﺜﺘﻟتﺎﻧﻮﻜﻣزﺎﮭﺠﻟا

2-7
Chapter 2: Standardized Warning Statements
Warnung
Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem,
qualifiziertem Personal gestattet werden.
¡Advertencia!
Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo.
Attention
Il est vivement recommandé de confier l'installation, le remplacement et la maintenance
de ces équipements à des personnels qualifiés et expérimentés.
경고 !
훈련을 받고 공인된 기술자만이 이 장비의 설치 , 교체 또는 서비스를 수행할 수 있습니
다.
Waarschuwing
Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door
geschoold en gekwalificeerd personeel.
Restricted Area
Warning!
This unit is intended for installation in restricted access areas. A restricted
access area can be accessed only through the use of a special tool, lock and
key, or other means of security. (This warning does not apply to workstations).
アクセス制限区域
このユニットは、アクセス制限区域に設置されることを想定しています。
アクセス制限区域は、特別なツール、鍵と錠前、その他のセキュリティの手段を用い
てのみ出入りが可能です。
警告
此部件应安装在限制进出的场所，限制进出的场所指只能通过使用特殊工具、锁和钥匙或
其它安全手段进出的场所。
警告
此裝置僅限安裝於進出管制區域，進出管制區域係指僅能以特殊工具、鎖頭及鑰匙或其
他安全方式才能進入的區域。
!הרהזא
שר דבלב ךמסומ תווצתא ףילחהל ,ןיקתהל יא.דויצה רובע תוריש תתל וא דויצה
ﻦﯿﺑرﺪﻤﻟاوو ﺐﯿﻛﺮﺘﻟلاﺪﺒﺘﺳاوأﺔﻣﺪﺧزﺎﮭﺠﻟا اﺬھ ﺢﻤﺴﯾ نأ ﺐﺠﯾﻂﻘﻓﻦﯿﻠھﺆﻤﻟا ﻦﯿﻔظﻮﻤﻠﻟ

MBI-6119G-C2 MicroBlade Module User’s Manual
2-8
Warnung
Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der
Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und
Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich.
¡Advertencia!
Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo
puede obtenerse acceso a una de estas áreas mediante la utilización de una
herramienta especial, cerradura con llave u otro medio de seguridad.
Attention
Cet appareil doit être installée dans des zones d'accès réservés. L'accès à une zone
d'accès réservé n'est possible qu'en utilisant un outil spécial, un mécanisme de
verrouillage et une clé, ou tout autre moyen de sécurité.
경고 !
이 장치는 접근이 제한된 구역에 설치하도록 되어있습니다 . 특수도구 , 잠금 장치 및 키
, 또는 기타 보안 수단을 통해서만 접근 제한 구역에 들어갈 수 있습니다 .
Waarschuwing
Dit apparaat is bedoeld voor installatie in gebieden met een beperkte toegang. Toegang
tot dergelijke gebieden kunnen alleen verkregen worden door gebruik te maken van
speciaal gereedschap, slot en sleutel of andere veiligheidsmaatregelen.
תתלבגומ השיג םע רוזא
!הרהזא
תרזעב תנתינ השיגה .השיג תלבגה םהב שיש םירוזאב הדיחיה תא ןיקתהל שי
.('דכו לוענמ ,חתפמ) דבלב החטבא ילכ
. ﺺﯿﺼﺨﺗةﺪﺣﻮﻟا هﺬھﻲﻓ ﺎﮭﺒﯿﻛﺮﺘﻟﻖطﺎﻨﻣةرﻮﻈﺤﻣ ﻢﺗ
ﺻﻮﻟا ﻦﻜﻤﯾﻰﻟإ لﻮﺔﻘﻄﻨﻣةرﻮﻈﺤﻣﻂﻘﻓماﺪﺨﺘﺳا لﻼﺧ ﻦﻣ،ﺔﺻﺎﺧ ةادأ
وأيأﻼﻟ ىﺮﺧأ ﺔﻠﯿﺳونﺎﻣﻷ حﺎﺘﻔﻣو ﻞﻔﻗ
