Supermicro SBI-4429P-T2N User manual

SBI-4429P-T2N
SuperBlade Module
User’s Manual
Revision 1.0d

SBI-4429P-T2N SuperBlade Module User’s Manual
ii
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The
vendor assumes no responsibility for any inaccuracies that may be contained in this document, and
makes no commitment to update or to keep current the information in this manual, or to notify any person
or organization of the updates. Please Note: For the most up-to-date version of this manual, please
see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described
in this manual at any time and without notice. This product, including software and documentation, is the
property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction
of this product is not allowed, except as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY
OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER, INC. SHALL NOT HAVE
LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT,
INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR
RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara
County in the State of California, USA. The State of California, County of Santa Clara shall be the
exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not
exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in industrial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the manufacturer’s instruction manual, may cause harmful interference with radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which case you
will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning
applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”.
Manual Revision 1.0d
Release Date: March 20, 2020
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy
any part of this document. Information in this document is subject to change without notice. Other
products and companies referred to herein are trademarks or registered trademarks of their respective
companies or mark holders.
Copyright © 2020 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!

iii
:
Preface
About this Manual
This manual is written for professional system integrators, Information Technology
professionals, service personnel and technicians. It provides information for the
installation and use of the Supermicro SuperBlade®system’s SBI-4429P-T2N
SuperBlade module. Installation and maintenance should be performed by experienced
professionals only.
Manual Organization
Chapter 1: Introduction
The first chapter provides a checklist of the main components included with
SBI-4429P-T2N SuperBlade module and describes their main features.
Chapter 2: System Safety
You should familiarize yourself with this chapter for a general overview of safety
precautions that should be followed when installing and servicing SBI-4429P-T2N
SuperBlade module.
Chapter 3: Setup and Installation
Refer to this chapter for details on installing the SBI-4429P-T2N SuperBlade module
into the SuperBlade chassis. Other sections cover the installation and placement of
memory modules and the installation of hard disk drives into the blade module.
Chapter 4: Blade Module Features
This chapter coves features and component information about SBI-4429P-T2N
SuperBlade module. Included here are descriptions and information for mainboard
components, connectors, LEDs and other features of the blade module.
Chapter 5: BIOS
BIOS setup is covered in this chapter for SBI-4429P-T2N SuperBlade module.
Appendix A: BIOS POST Codes
BIOS POST Codes for SBI-4429P-T2N SuperBlade module are explained in this
appendix.
Secure Data Deletion
A secure data deletion tool designed to fully erase all data from storage devices can be
found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/
wftp/utility/Log9_Secure_Data_Deletion_Utility/

i
Table of Contents
Chapter 1 Introduction.......................................................................1-1
1-1 Overview.............................................................................................1-1
1-2 Product Checklist of Typical Components.....................................1-1
1-3 Blade Module Features ....................................................................1-2
Processors ..............................................................................................1-2
Memory ................................................................................................... 1-2
Storage ...................................................................................................1-3
RAID .......................................................................................................1-3
Enclosure Requirements.........................................................................1-3
Density ....................................................................................................1-3
Unique Password.................................................................................... 1-3
1-4 Contacting Supermicro.....................................................................1-4
Chapter 2 Standardized Warning Statements.....................2-1
2-1 About Standardized Warning Statements .....................................2-1
Warning Definition...................................................................................2-1
Installation Instructions ...........................................................................2-3
Circuit Breaker ........................................................................................2-4
Power Disconnection Warning................................................................2-5
Equipment Installation............................................................................. 2-6
Restricted Area .......................................................................................2-7
Battery Handling .....................................................................................2-9
Redundant Power Supplies ..................................................................2-10
Backplane Voltage ................................................................................2-11
Comply with Local and National Electrical Codes.................................2-12
Product Disposal...................................................................................2-13
Hot Swap Fan Warning .........................................................................2-14
Power Cable and AC Adapter ..............................................................2-15
Chapter 3 Setup and Installation.................................................3-1
3-1 Overview.............................................................................................3-1
3-2 Installing Blade Modules ..................................................................3-1
Powering Up a Blade Unit.......................................................................3-1
Powering Down a Blade Unit ..................................................................3-1
Removing a Blade Unit from the Enclosure ............................................3-2
Removing/Replacing the Blade Cover ....................................................3-2
Installing a Blade Unit into the Enclosure ...............................................3-2

SBI-4429P-T2N SuperBlade Module User’s Manual
ii
3-3 Processor Installation .......................................................................3-4
Overview of the Processor Socket Assembly .........................................3-5
Overview of the Processor Heatsink Module (PHM)...............................3-6
Attaching the Processor to the Narrow Processor Clip to Create the
Processor Package Assembly ................................................................3-7
Attaching the Processor Package Assembly to the Heatsink to Form the
Processor Heatsink Module (PHM).........................................................3-8
Preparing the CPU Socket for Installation ............................................3-10
Removing the Dust Cover from the CPU Socket ..................................3-10
Removing the Processor Heatsink Module (PHM) from the Motherboard...
3-12
3-4 On-board Battery Installation.........................................................3-13
3-5 Memory Installation.........................................................................3-13
Populating Memory Slots ......................................................................3-13
DIMM Installation ..................................................................................3-16
3-6 Hard Disk Drive Installation ...........................................................3-18
3-7 Installing the Operating System....................................................3-19
PXE Boot ..............................................................................................3-19
Installing via Virtual Media (Drive Redirection) .....................................3-19
3-8 Management Software ...................................................................3-19
3-9 Configuring and Setting up RAID .................................................3-20
Chapter 4 Blade Module Features..............................................4-1
4-1 Control Panel .....................................................................................4-2
Power Button ..........................................................................................4-2
4-2 Mainboard........................................................................................... 4-3
CMOS Clear............................................................................................4-5
Jumper Settings ...................................................................................... 4-5
4-3 Blade Unit Components ...................................................................4-5
Memory Support .....................................................................................4-6
Hard Disk Drives .....................................................................................4-6
Chapter 5 BIOS.......................................................................................5-1
5-1 Introduction.........................................................................................5-1
System BIOS ..........................................................................................5-1
How To Change the Configuration Data .................................................5-1
Starting the Setup Utility .........................................................................5-1
5-2 BIOS Updates....................................................................................5-2
5-3 Running Setup ................................................................................... 5-2

iii
Table of Contents
5-4 Main BIOS Setup...............................................................................5-3
5-5 Advanced Setup ................................................................................5-5
5-6 Event Logs Setup............................................................................5-19
5-7 IPMI Setup........................................................................................5-21
5-8 Security .............................................................................................5-23
5-9 Boot ...................................................................................................5-25
5-10 Save & Exit.....................................................................................5-27
Appendix A Updating BIOS Using KVM Console..............A-1

1-1
Chapter 1: Introduction
Chapter 1
Introduction
1-1 Overview
This user’s manual covers the SBI-4429P-T2N blade module. This blade module is a
compact self-contained server that connects into a pre-cabled enclosure that provides
power, cooling, management and networking functions. One enclosure for the
SBI-4429P-T2N blade module can hold up to 14 blade units in the 4U SBE-414E-222/
422 or SBE-414EB-222 model enclosures (4x2200W power supplies required for full
enclosure capacity).
In this manual, “blade system” refers to the entire system (including the enclosure and
blades units), “blade” or “blade unit” refers to a single blade module, “Node” refers to a
single node in each blade module and “blade enclosure” is the chassis that the blades,
power supplies and modules are housed within.
Please refer to our web site for information on operating systems that have been
certified for use with the SuperBlade (www.supermicro.com/products/superblade/).
Note: For your system to work properly, please follow the links below to download all
necessary drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety information: ttp://www.supermicro.com/about/policies/
safety_information.cfm
• If you have any questions, please contact our support team at:
[e-mail]
Note: A complete list of safety warnings is provided on the Supermicro web site at
http://www.supermicro.com/about/policies/safety_information.cfm.
1-2 Product Checklist of Typical Components
Your blade module ships with its B11DPT mainboard already installed in its chassis.
Memory, hard disk drives and the CPU must all be installed by the user after shipment.
See Chapter 3: "Setup and Installation" on page 3-1 for details on installation of these
components.
Typical support modules for systems with the SBI-4429P-T2N blade module when
mounted in an 4U enclosure system include the following:
• MBM-CMM-FIO CMM Module (1)
• MBM-XEM-002 10G switches (up to 2)
• MBM-GEM-004 1G switches (up to 2)

SBI-4429P-T2N SuperBlade Module User’s Manual
1-2
1-3 Blade Module Features
Table 1-1 lists the main features of the SBI-4429P-T2N blade module. See the
proceeding section for components typically included in a blade system and other
optional components. Specific details for the SBI-4429P-T2N blade module are found in
Chapter 4: "Blade Module Features" on page 4-1.
Processors
The SBI-4429P-T2N SuperBlade module supports two Intel FCLGA 3647 scalable
family processors series processors grouped two per node.
Refer to the Supermicro web site for a complete listing of supported processors (http://
www.supermicro.com/products/superblade). Please note that you will need to check the
detailed specifications of a particular blade module for a list of the CPUs it supports.
Details on installation of the processor into the SBI-4429P-T2N SuperBlade module are
found in Chapter 3: "Setup and Installation" on page 3-1.
Memory
The SBI-4429P-T2N SuperBlade module has twelve 288-pin DIMM sockets that can
support up to 384 GB of RDIMM/LRDIMM DDR4 2400/2666/2933 MHz speed, 8 GB, 16
GB and 32 GB size SDRAM 1.2V memory per node. Memory is interleaved, which
requires modules of the same size and speed to be installed in groups (of two or three).
Table 1-1. SBI-4429P-T2N SuperBlade Module Specification Features
Mainboard B11DPT (proprietary form factor)
Processors Two Intel™ FCLGA 3647 scalable family processors for each node. Please refer
to our web site for a complete listing of supported processors.
UPI Speed UPI up to 10.4 GT/s
Chipset One Intel C622 chip set for each node
Graphics Controller Integrated Aspeed AST 2500 VGA Graphics chip for each node
BIOS 256 Mb SPI Flash EEPROM with AMI® BIOS for each node
Memory Capacity
Supports up to 384 GB of VLP RDIMM/LRDIMM DDR4 2400/2666/2933 MHz
speed and 8 GB, 16 GB and 32 GB size SDRAM memory in twelve 288-pin
DIMM sockets for each node. See https://www.supermicro.com/support/
resources/memory/X11_memory_config_guide.pdf for details.
Hard Drive Bays Includes two hot-swap drive bays for 2.5" SATA/SSD/NVMe disk drives and one
M.2 connector supports 80-mm M.2 SSDs.
Add-on Cards The SBI-4429P-T2N blade module uses the AOM-SB414-01-P add-on card.
System Weight 15 lbs (6.8 kg)
System Dimensions 1.75 x 6.5 x 23.5” (44.45 x 165.1 x 596.9 mm)

1-3
Chapter 1: Introduction
Please refer to the Supermicro web site for a list of supported memory
(www.supermicro.com/products/superblade). The detailed specifications for a blade
module will contain a link to a list of recommended memory sizes and manufacturers.
Details on installation of memory modules into the SBI-4429P-T2N SuperBlade module
are found in Chapter 3: "Setup and Installation" on page 3-1.
Storage
The SBI-4429P-T2N SuperBlade module has two HDDs in front-mounted easy
removable hot-swap carriers.
See Chapter 3: "Setup and Installation" on page 3-1 for storage installation details.
RAID
Each SBI-4429P-T2N blade module supports up to two hard drives, which may create
either a software RAID 0 and 1 system for the blade module.
Enclosure Requirements
The SBI-4429P-T2N blade module requires one of the following enclosures to run in:
• 4U SBE-414E-222/422
• 4U SBE-414EB-222
The SBI-4429P-T2N blade module also requires a power supply in the enclosure to run
the blade module. Available SuperBlade power supplies can be found on the
Supermicro website at https://www.supermicro.com/products/SuperBlade/powersupply/.
Density
A maximum of 14 blade modules may be installed into a single blade enclosure. Each
blade enclosure is a 4U form factor, so a standard 42U rack may accommodate up to
ten enclosures with 140 blade modules, or the equivalent of 140 1U servers. With the
inclusion of ten CMM modules, this would occupy up to 150U space in a conventional
1U server configuration.
Unique Password
Supermicro ships standard products with a unique password for the BMC ADMIN user.
This password can be found on a label on the motherboard. For more information,
please refer to our website at https://www.supermicro.com/en/support/
BMC_Unique_Password and https://www.supermicro.com/support/
BMC_Unique_Password_Guide.pdf for further information.See the illustration below for
the location of the Unique Password (UPWD) on the service tag mounted on the blade
module.

SBI-4429P-T2N SuperBlade Module User’s Manual
1-4
Figure 1-1. Service Tag Location on a Blade Module
Service Tag

1-5
Chapter 1: Introduction
1-4 Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: [phone]
Fax: [phone]
Email: [email protected] (General Information)
[email protected] (Technical Support)
Web Site: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
‘s-Hertogenbosch, The Netherlands
Tel: [phone]
Fax: [phone]
Email:
[email protected] (General Information)
[email protected] (Technical Support)
[email protected] (Customer Support)
Asia-Pacific
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 23511
Taiwan (R.O.C)
Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [email protected]
Tel: [phone]
