Supplies4Heat Woburn User manual

Pipe centres left to right =
Pipe centres from wall =
Depth from wall =
width of radiator plus valves
70mm
120mm
Drawings
Pipe Centres
www.supplies4heat.co.uk 01342 306880
Aluminium Radiator in White
Horizontal and Vertical
Please read these instructions and terms and conditions carefully
prior to installation. Failure to do so may invalidate the warranty.
Woburn
Fitting Instructions
Drawing 2 - Bracket Positions
2 x Right Hand
Brackets
2 x Left Hand
Brackets
Diverter Installation
WOB_IR_1.0
Drawing 1 - Bush Configurations
Tighten ‘S’
Anti-clockwise
Tighten ‘D’
Clockwise
Bushes for the Woburn are handed. The bushes are marked
with an ‘S’ which goes on the left, and a ‘D’ which goes on
the right (shown below).
With the brackets firmly fixed and level, the radiator is
lowered directly onto the brackets. When commissioning
your radiator on an indirect/closed system we recommend
using a suitable quality and quantity of mixed metal
inhibitor to protect against scale & corrosion. Damage
caused to systems not protected by a suitable inhibitor
will not be covered by manufacturer’s guarantee.
You should have:
• 1 Radiator
• 4 Wall Brackets
• 1 Manual Airvent
• 1 Blanking Plug
• Spring Diverter
You will need:
• Tape measure
• Electric drill and bits
• Spirit level
2. Contents
5. Hang & Commission
Radiator
Technical Specifications
Materials Aluminium.
Connections ½” flow and return.
Test pressure 9 Bar
Testing authority EN442
Maximum operating pressure 6 Bar
Maximum working temperature 110ºC
Packaging Wrapped in polythene & boxed.
You will have been supplied with at least four brackets (see
drawing 1 overleaf). The brackets are typically positioned
one section in from either end with extra brackets spaced at
equal distances between these two (see drawing 2 overleaf).
Mark and fix the 2 top brackets checking they are level. Hang
radiator in position and mark the location of the 2 bottom
brackets and fix in place. Brackets should be fixed using
suitable drill bit, screws and plugs.
PLEASE NOTE:
It is essential that all brackets are level and square prior to
hanging the radiator to ensure a vertical alignment for
connecting the pipework.
4.Fix Brackets
All products must be inspected once removed
from the packaging and your point of
purchase notified within 28 days of delivery
of any scratches, blemishes or other damage.
Your point of purchase will then agree
appropriate action.
Imperfect radiators should therefore not be
fitted and we will not accept responsibility
for replacement of scratched or damaged
radiators once they have been fitted. This
includes any consequential loss or cost of
fitting.
If we are not notified within 28 days of the
date on the signed delivery note then it will be
deemed that we have fully complied with our
obligations and claims will not be considered.
Failure to comply with any of the above
may invalidate any claims. We recommend
that after you check the product on delivery
that it is stored in its packaging to prevent
damage prior to installation, we cannot
accept responsibility for items damaged after
delivery.
For full details of our Terms and Conditions
please visit www.supplies4heat.co.uk or call
us on 01342 306880.
Terms & Conditions
This product is guaranteed for 10 years. As we are not the manufacturers of this product
we will take all reasonable endeavours to make over to you the benefit of any warranty
or guarantee given by the manufacturer.
The guarantees in all cases are subject to the products being installed in accordance with
British and or European standards as well as these fitting instructions. The guarantees in
all cases are restricted to the free of charge replacement or repair of the failed product
only. Our liability will under no circumstances extend beyond the repair or replacement
of the product supplied by us. Claims for either labour in replacement or damage to
property are not admissible. Any goods that are returned, in the event of a problem,
will belong to us.
Guarantees & Liabilities
1. Unpack & Inspect
This product should have reached you in perfect condition.
Please carefully unpack and inspect this radiator and
all fittings. Your point of purchase must be notified of
any shortages or damage within 28 days of delivery.
For further information please see terms and conditions at
the bottom of the page.
3. Fit Diverter (vertical models only)
The diverter can be installed on either end but must be on
the flow side, it is installed by pushing the cap firmly in the
waterway, and until it locates against the barrel nipple and
is retained in place by the bush. Please refer to diagram
overleaf.
PLEASE NOTE: To reduce the possibility of noise caused by rapid heating and cooling
of aluminium radiators; adequate capacity for expansion must be provided within
the overall heating system. Systems using micro bore pipework must have adequate
pressure and flow rates for the number and style of radiators on the system.
www.supplies4heat.co.uk 01342 306880
A brand of ; Italy’s leading manufacturer of design led radiators.
