Surround Air XJ-3800 User manual

Intelli-Pro Air Purifier
(Model: XJ-3800)
Instruction Manual
(Please read before using air purifier)
Surround Air Division
Indoor Purification Systems, Inc.
334 Marshall Way, Suite C
Layton, Utah 84041
Toll Free: 888.812.1516
PH: 801.444.0606
FX: 801.991.4838
Web: www.surroundair.com
Email: [e-mail]

lPlug Type: US 120V (120VAC/60HZ)
lPower: 80W
lHEPACleaning Efficiency: 99.97%
lDimensions: 24 x 13.5 x 10 (in)
lWeight: 15 lbs.
lMaximum Air Volume: 106 cfm
lUV wavelength: 254 nm (germicidal wavelength)
lOdor and dust sensors for automatic air quality control.
lSensors indicate when to replace filters and clean collector grid.
lUV light and negative ion indicator sensors.
lLong-lasting, high-efficiency HEPAfilter - 99.97% collection rate.
lElectrostatically-charged plasma cell traps pollutants like a magnet.
lActivated Carbon Filter to adsorb chemicals, cigarette smoke and odors.
lPhotocatalytic Filter (TiO2) to remove airborne chemicals, odors and bacteria.
lGermicidal UV (Ultraviolet) Lamp to destroy micro-organisms.
lNegative Ion Generator to circulate air-cleaning negative ions throughout the room.
lWashable pre-filter to collect larger particles and to prolong the life of the other filters.
lPowerful yet quiet fan for maximum air circulation.
1. To prevent electric shock, do not dismantle, repair or modify this product beyond the instructions given
in this manual. In case of malfunction, please contact Surround Air.
2. Do not use in places where flammable and explosive materials are stored.
3. Do not allow foreign objects into this device. High voltage inside the device may cause electric shock.
4. To avoid interference, this device should be placed at least 3 feet away from computers, televisions or
radios.
5. Do not cover this device with fabrics or any other materials.
6. Do not use in places where flammable and explosive materials are stored. Do not subject to sunlight or
high-temperature objects. Significant rises in internal temperature may cause fire or deformation of the
outer shell. Stop operation when temperature exceeds 104oF.
6. Do not block the air inlet or outlet.
7. Do not move the device while it is in operation.
8. Make sure that all filters are in place before operating.
9. To prevent short-circuit or electric shock hazard, do not place the device in places that are wet or
where water may potentially enter the unit.
10. Before unplugging the device, turn the power off, along with all control functions.
11. Do not operate if the power cord is damaged.
12. To prevent fire or electric shock, unplug the machine from the electrical outlet under the following
conditions: when it is not operated for long periods, while cleaning or replacing filters or UV bulbs, or
when the machine is being moved.
Specifications
Functions
Cautions

Diagram - External
Control PanelControl Panel
Control PanelControl Panel
Control Panel

Diagram - Internal

lSince the Intelli-Pro uses a fan, and generates a strong current of air out the top of the unit, it is not
necessary to place the unit at a high elevation. It can be placed on the floor, on a table, a
countertop, or anywhere else it rests sturdily and comfortably.
lThe back of the Intelli-Pro should be at least 8 inches away from the wall to prevent discoloration
of the wall. Also, there should not be any obstructions above the air outlet on top of the unit.
There should be at least 2 feet of space between the top of the air purifier and any object or
surface above it.
lKeep the Intelli-Pro at least 3 feet away from computers, televisions, and sensitive electrical
equipment, and two feet from occupants in the room while in operation.
lTo the extent possible, it is optimal to place the Intelli-Pro in areas: 1) nearest the source of
airborne pollutants, 2) where airborne pollution is strongest, and 3) where affected persons spend
most of their time.
Placement
Before Using
1. Run the unit for a couple hours or more.
2. During this time, also increase ventilation in the room as much as possible, even opening a
window if the air outside is at least fairly clean.
3. Unplug the Intelli-Pro, then immediately plug it in, turn it on, and resume operation.
Note: Unplugging the Intelli-Pro, then plugging it in again resets the clean air sensor’s memory. By first
ensuring the air is as clean as possible, and then immediately resetting, the sensor will be more
accurate once you resume normal operation.
