SVAT CLEARVU3 User manual

SVAT ELECTRONICS
now you can see
Model #:
CLEARVU3
www.svat.com
Records up to 2 Years
320GB HDD
COMPLETE SYSTEM
1 YEAR
WARRANTY
Manufacturer Defects
8.5" Ultra Slim
LCD Monitor
8 Hi-Res
CCD Cameras
WEB READY 16CH DVR SYSTEM
w/ 8 Outdoor Night Vision CCD Color Cameras and 8.5" LCD Monitor

SPECIFICATIONS (for more detailed specications visit www.svat.com)
INDOOR DVR
Functionality.........................................................Simplex
Video Compression................................................MJPEG
Live Resolution......................................................NTSC : 704 X 480 / PAL: 704 X 576
Recording Frame Rate...........................................30FPS
RecordingTime .....................................................750 Days (0.5 Frames Per Second)
Recording Qualities...............................................Low/Medium/High
Storage Capacity ...................................................Max 500GB (HDD), 320GB included
Video Format.........................................................NTSC/PAL
Live Display...........................................................Single / Quad / 9-Split / 16 - Split
Network LAN IP.....................................................Dynamic, Static
Network Connection .............................................10/100 BaseT Ethernet (RJ-45)
Back-up.................................................................CF Card, Max 4GB
Play Search Mode..................................................Time/Date/Event List
OSD Language Display ..........................................Multi-Language
Time and Date Stamp Display................................Yes
Password Protection..............................................Yes, Menu Password
Operating System..................................................Proprietary
Automatic Overwrite Option .................................Yes
Power Input ..........................................................12V/4.2A
LCD MONITOR
Display..................................................................8.5" Color LCD
Resolution.............................................................480 x 234
Video Inputs..........................................................2x 3.5mm jack RCA to 3.5mmWire
Audio Input...........................................................2x 3.5mm jack RCA to 3.5mm Wire
Audio Output ........................................................1x 3.5mm headphone jack
LCD Prole Ratio....................................................16:9, 4:3
Response Time(ms)...............................................Tr:24/Tf:36 (max)
Languages ............................................................English, Russian, German, Italian, Arabic, Dutch,
Spanish, Portuguese, French
SpeakerWattage...................................................0.3W x 2
Power Input ..........................................................DC 12V 1200mA
OUTDOOR CAMERA (CV67)
Camera Type..........................................................Bullet
Image Sensor ........................................................1/4" Color Sharp CCD
Resolution.............................................................420 TV Lines
IP Rating ...............................................................IP65
Focal Length..........................................................3.6mm
Focus Type .............................................................Fixed
Night Vision...........................................................Yes
Number of IR LEDs and Range...............................12, up to 15ft
IR LED Control........................................................Automatic (CDS Sensor)
Min. Illumination..................................................0 lux
Video Output.........................................................60ft 4 PIN DIN to RCA Video/Power Wire
TV System .............................................................NTSC
Viewing Angle.......................................................60 Degrees
Housing Material...................................................Anodized Aluminum
OperatingTemperature .........................................-14°F ~ 122°F
Camera Power Input..............................................DC 12V 300mA
DIMENSIONS
Monitor: 9" x 7.5" x 5.25" ~ 1.65lbs
DVR: 17" x 11.75" x 3.3" ~ 8.75lbs
Camera: 5.5"x 2.44" x 5" ~ 0.75lbs
Model #:
CLEARVU3
www.svat.com
SVAT, CLEARVU and“now you can see”are
trademarks of SVAT Electronics.
©2008 SVAT Electronics
All Rights Reserved
WHAT IS INCLUDED WITH THIS SYSTEM?
UPC #
CLEARVU3 ~ 871363006578
1 DVR
(320GB HDD)
8 Outdoor Night Vision
Cameras
8.5" Ultra Slim
LCD Monitor
1 Remote Control for
LCD Monitor
Software CD
• 10 RCA to BNC Connectors
• 10ft RJ-45 Ethernet Cable
• 1 RCA Female to 3.5mm (male) A/V Wire
• 1 Power Adapter for LCD Monitor
• 1 10ft RCA to RCA (male) A/V Wire
• 1 Power Adapter for DVR
WEB READY 16CH DVR SYSTEM w/ 8 Outdoor Night Vision CCD Color Cameras & 8.5" LCD Monitor
8x 60ft 4 PIN DIN to
RCA (male) Video/
Power Wires
SVAT Electronics
Toll Free: 1.866.946.7828
now you can see
WHERE DO I USE THIS?
At home to watch your:
• Garage • Backyard
• Property • Driveway
At work to watch your:
• Entrance Ways • Employees
• Parking Lot • Warehouse
1
2
9
10
11
677
8
3
21
20
36 37
38
39 40
41 43
42
44
22
19
30 32 33 34 35
31
23
2928
27
26
25
24
4
512
13
14
15
16
17
18
46
47 48
49
50
51
52
45
LCD MONITOR
1. LCD Screen
2. Power Button
3. AV2 In Port
4. AV1 In Port
5. 3.5mm Headphone Jack
6. DC Power Input (12V)
7. Speakers
8. Mounting Rails
9. Mounting Hole
10. AV1/AV2 Buttons
11. Pics Button
12. Auto Button
13. Volume Increase Button
14. Volume Decrease Button
15. Up Arrow Button
16. Down Arrow Button
17. Menu Button
18. Mute Button
CCD CAMERAS
19. Sun Shield
20. Infrared (IR) LEDs
21. CDS Sensor
22. Camera Housing
23. Camera Mount
24. Connection to Audio/Video Wire
16 CHANNEL DVR RECORDER
25. LED Indicator - Power, HDD Activity
26. Removable/Lockable HDD Casing
27. Camera Channel Select (16)
28. Record Button
29. Stop Button
30. Play Button
31. Pause Button
32. Split Button
33. Auto Sequencing Button
34. Search Button
35. Menu Button
36. Exit/Info Button
37. Enter/Display Button
38. CF Card Slot
39. Left Button
40. Right Button
41. Up Button
42. Down Button
43. LED Indicators
44. BNC Video Inputs (16)
45. DC Power Input (12V)
46. Alarm Input/Output Port
47. Audio Inputs
48. RCA Audio Output
49. BNC Video Output
.
60ft Extension Wire
Ends on the 60ft extension wire.
Power (red), &Video (yellow)
RCA to BNC Connector
Connects RCA cameras to the video inputon
the back of the DVR
50. Ethernet Port
51. BNC SPOT Video Output
52. Cooling Fan
CV67 Cameras Do Not Support Audio
320GB 16CH DVR RECORDING CHART
0.5 1 2 4 7.5 15 30
750 375 150 180 95 25 12
650 325 130 65 35 15 8
375 185 90 45 25 12 6
Low (days)
Med (days)
High (days)
QUALITY
FRAME RATE PER SEC.
SVAT ELECTRONICS
now you can see
• 8 Power Adapters for Cameras
• 1 Year Warranty
• Quick Start Guide
• Instruction Manual
• 4 Window Warning Stickers
• Online/Toll Free Support
NOTE: Product May Appear DierentThan Shown.
