SVAT WSE201 User manual

SVAT ELECTRONICS
Now
You Can See
Wireless Outdoor Color
Security Camera System
COMPLETE SYSTEM
Instruction Manual
Model #
WSE201
www.svat.com

WSE201 www.svat.com
SVAT ELECTRONICS
Now
You Can See

Graphic Symbol Explanation:
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to
alert the user to the presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT
TO RAIN OR MOISTURE
WSE201 www.svat.com
SVAT ELECTRONICS
Now
You Can See
PRODUCT W
PRODUCT WARRANTY ARRANTY & REGISTRA & REGISTRATION TION
Please visit our website at www.svat.com to apply for your
products warranty registration.
The warranty registration for is located under the support tab on the SVAT website.
We take quality very seriously. This is why all of our products come with a one year warranty from the
original purchase date against defects in workmanship and materials.
If you have warranty or support issues please contact us using any of the following methods:
SVAT Electronics USA SVAT Electronics Canada Phone: [phone]
2315 Whirlpool St., Unit 333 4080 Montrose Road Fax: [phone]
NIagara Falls, New York Niagara Falls, ON Email: [email protected]
USA 14305 Canada L2H 1J9 Website: www.svat.com
Warranty Terms
1. SVAT products are guaranteed for a period of one year from the date of purchase against defects in
workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price
at SVAT's option.
2. When service is required, the warranty is validated by the submission of a fully completed warranty card.
3. This warranty becomes void if the product shows evidence of having been misused, mishandled or tampered
with contrary to the applicable instruction manual.
4. Routine cleaning, normal cosmetic and mechanical wear and tear are not covered under the terms of this
warranty.
5. The warranty expressly provided for herein is the sole warranty provided in connection with the product itself
and no other warranty, expressed or implied is provided. SVAT assumes no responsibilities for any other
claims not specifically mentioned in this warranty.
6. This warranty does not cover the shipping cost, insurance or any other incidental charges.
7. You MUST call SVAT before sending any product back for repair. You will be given a Return Authorization
number. When returning the product for warranty service, please pack it carefully in the original box with all
supplied accessories, and enclose your original receipt or copy, and a brief explanation of the problem
(include RA #).
8. This warranty is valid only in Canada and the U.S.A.
9. This warranty card cannot be re-issued.
CAUTION
RISK OF ELECTRIC SHOCK, DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.

WSE201 1
SVAT ELECTRONICS
Now
You Can See
T
TABLE OF CONTENTS ABLE OF CONTENTS
WHAT IS INCLUDED ............................................................1
WHAT IS COMPATIBLE ........................................................1
FEATURES............................................................................2
THINGS TO CONSIDER ......................................................2
INSTALLING THE CAMERA ................................................3
INSTALLING THE RECEIVER ..............................................3
ADVANCED FEATURES ......................................................4
OPERATING MODES ..........................................................5
TROUBLESHOOTING ..........................................................6
SPECIFICATIONS..............................................................7-8
NOTES ..................................................................................9
WHA
WHAT IS INCLUDED T IS INCLUDED
WHA
WHAT IS COMP T IS COMPA ATIBLE TIBLE
The WSE201 is compatible with TVs, VCRs, DVRs, computers and other SVAT systems including:
- Mounting Hardware
- 1 Year Warranty
- Instruction Manual
- Online/Toll Free Tech Support
1 Wireless Receiver
Portable Battery Clip
1 Wireless Camera Mounting Bracket
WSE201C WSE103C GX515 GX522 ClearVu DVRs
4 PIN DIN to
RCA Wire (male) 2 Power Adapters

WSE201 2
SVAT ELECTRONICS
Now
You Can See
Congratulations on your purchase of the WSE201. The WSE201 consists of a
wireless receiver and a wireless bullet-hole camera, and is an ideal product for
covert monitoring in your home or business.
FEA
FEATURES TURES
• 2.4GHz wireless technology
• Bullet-hole color camera with night vision
• Both audio and video output
• Camera meets IP54 standard for outdoor use
• Expandable - supports up to 3 cameras
• Manual or auto switching between cameras
• Adjustable cycle time cameras
• Battery operable for portable monitoring
THINGS T
THINGS TO CONSIDER BEFORE INST O CONSIDER BEFORE INSTALLA ALLATION TION
For best performance, follow these simple guidelines:
• Camera(s) should be installed between 8 and 13 feet above the area to
be monitored
• For best transmission, avoid installations where there are thick walls or major
obstructions between the camera and receiver
• Ensure there are no obstructions in the camera's view, to maximize viewing area.

WSE201 3
SVAT ELECTRONICS
Now
You Can See
INST
INSTALLING THE CAMERA ALLING THE CAMERA (TRANSMITTER) (TRANSMITTER)
1. Unpack the camera.
2. The camera's channel number can be set by unscrewing the lens part of camera to
open the lens cover, and adjusting the dip switches.
3. Decide whether the camera will be wall-mounted or sit on a desk/table top. If wall
mounting, use the mounting hardware in the package. The camera can be adjusted
for either mounting scenario by rotating the camera to the required position.
4. If using the 9V camera power adapter, just connect power jack. Make sure the
camera is positioned no more than 5 1/2 feet from an AC power outlet.
INST
INSTALLING THE RECEIVER ALLING THE RECEIVER
MAIN OPERATION
1. Connect one end of the cable (4 PIN DIN) to the back of the receiver, and the yellow
plug (RCA composite) to the VIDEO IN jack of your TV/VCR/DVR. If you are using
this system with a camera that supports audio, also plug in the red and white
RCA plugs.
2. Plug the receiver's power supply into the power jack located on the back of the unit
and plug the power adapter into any power outlet.
3. Place the receiver either on top or near your TV. Rotate the antenna to a
vertical position.
4. Set your TV to VIDEO INPUT mode to view your camera.
5. For recording camera footage using your VCR, see advanced features.

WSE201 4
SVAT ELECTRONICS
Now
You Can See
AVOIDING INTERFERENCE
The 2.4 GHz video signals pass easily through your home's interior walls, but the signal
may be reflected by power wires or plumbing inside the wall. If reception is poor, moving
the camera or receiver may fix this problem. Houses with steel frames may experience
interference as well. Microwave ovens, cordless phones and wireless routers are the
most common source of interference. Try to avoid mounting the receiver near these or
other sources of RF interference.
ADVANCED FEATURES
Multi-Camera Operation
The WSE201 is designed to work with up to 3 cameras. Additional cameras are sold
separately (indoor - WSE103C / outdoor - WSE201C).
*IMPORTANT
When using more than one camera, make sure you assign each camera a specific
channel (1-3). The channel switch is located on the front of the camera.
Accordingly the DIP switch located on the back of the receiver should be adjusted to
reflect the channel in use.

WSE201 5
SVAT ELECTRONICS
Now
You Can See
OPERATING MODES
The system can be set to operate in one of 2 modes: AUTO or MANUAL. The desired
operating mode can be selected using the buttons on the front panel of the receiver.
Auto
Pressing the AUTO button places the system into auto mode. In this mode, the system
automatically cycles through all active cameras. When a camera detects motion above
the preset level, your television will display the picture from that camera for a few
seconds, and the beeper will sound. To avoid searching the channels that do not have
cameras/transmitters assigned to them, set those corresponding dip switches (located on
the back panel of the receiver) to the OFF position.
The dwell/cycle time (time taken to switch between cameras) is preset to four seconds
and can be adjusted between 2-30 seconds. To adjust the dwell/cycle time, press both
the AUTO and MANUAL buttons at the same time for each second you would like to add.
Release the buttons, and the LED light will flash green for each second that was added
to the dwell time. Increasing the dwell/cycle time past 30 seconds will revert it back to 2
seconds.
Manual
To view a specific camera on the receiver, press the MANUAL button. The receiver will
switch to a different camera each time the MANUAL button is pressed. There are 3 LEDs
on the front of the receiver, and the appropriate LED will light up to indicate the camera
that is active. For example, if you press the manual button to view camera 2, the middle
LED will be lit. To avoid searching the channels that do not have cameras assigned to
them, set those corresponding dip switches (located on the back panel of the receiver) to
the OFF position.
CONNECTING TO A VCR
You can connect a VCR to the system to allow recording of your camera footage. To
connect the receiver to a VCR for recording purposes, use the RCA adapter cable and
connect the appropriate ends to the A/V Out jack on the receiver, and the other
corresponding ends to the audio and video inputs of the VCR.

WSE201 6
SVAT ELECTRONICS
Now
You Can See
TROUBLESHOOTING
TROUBLESHOOTING
If you are having trouble operating this product, please consult the guide below
This device complies with part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Problem Solution
No camera picture 1. Check all connections and AC adapters.
2. Ensure camera(s) and receiver are set to
correct channels.
2. Make sure camera is within range of
the receiver.
Blank TV screen 1. Make sure the receiver is switched ON.
2. Make sure the AC adapter is plugged in
3. If using batteries for the camera, make sure
they are charged.
4. Make sure your TV is set to the Video
Input channel.
5. Ensure the RCA plugs are connected to both
the receiver and the back of your TV/VCR.
Interference on camera
1. Make sure each camera is within range, and
that no obstructions are blocking the signal.
2. Try repositioning the camera, receiver, or both
to improve the reception quality.
3. Reposition other nearby equipment
transmitting on the 2.4 GHz frequency.

WSE201 7
SVAT ELECTRONICS
Now
You Can See
SPECIFICA
SPECIFICATIONS TIONS
INDOOR RECEIVER
Number of Cameras Supported ....................3
Wireless Frequency........................................2.4GHz
Channel Frequencies ....................................2.414, 2.432, 2.468
Motion Activated Alert ....................................Compatible
Audio Activated Alert ......................................Compatible
Output terminal ..............................................4 PIN DIN to RCA
Auto-Scanning................................................Yes
Housing Material ............................................ABS plastic
Housing Color ................................................Graphite Grey
Operating Temperature ..................................-40F ~ 1040F
Operating Humidity ........................................Less than 85%
Receiver Power Input ....................................DC 9V 300mA
Power Adapter Input ......................................AC 120V 60Hz
Dimensions ....................................................3.25" x 1.0" x 5.0"
Weight ............................................................0.32 lbs
OUTDOOR CAMERA
Image sensor..................................................1/4" CMOS color
Outdoor use....................................................Yes
IP Rating ........................................................IP54
Maximum Wireless Range (Line of Sight) ..........300ft
Optimum Wireless Range (Line of Sight)............100ft
Wireless Frequency........................................2.4GHz
Wireless Channel Frequencies ......................2.414, 2.432, 2.468
Resolution ......................................................360 horizontal TV Lines
Night Vision ....................................................Yes
Number of IR LEDs and Range ....................8, up to 10ft
IR LED control................................................Auto, CDS Sensor
Min. Illumination ............................................0 lux
Battery Operable ............................................Yes, 9V
Viewing Angle ................................................69 Degrees
TV System......................................................NTSC

WSE201 8
SVAT ELECTRONICS
Now
You Can See
Focal Length ..................................................6.0mm
Focus Type ....................................................Fixed
Microphone ....................................................Yes
Motion Detection ............................................No
Audio Activation..............................................No
Sun Shield ......................................................No
Housing Material ............................................Aluminum
Housing Color ................................................Midnight Black
Electronic shutter speed ................................1/60-1/15,000 sec
Signal/Noise Ratio..........................................48dB
Power LED Indicator ......................................No
Camera Bracket ............................................Yes
Operating Temperature ..................................-40F to 1040F
Operating Humidity ........................................Less than 85%
Camera Power Input ......................................DC 9V 300mA
Power Adapter Input ......................................AC 120V 60Hz
Dimensions ....................................................3.25" L x 1.2" D
Weight ............................................................0.5 lbs

WSE201 9
SVAT ELECTRONICS
Now
You Can See
NOTES
NOTES

WSE201 www.svat.com
SVAT ELECTRONICS
Now
You Can See
SV
SVA AT SUPPORTS CRIME ST T SUPPORTS CRIME STOPPERS OPPERS
Crime Stoppers programs are operated as non-profit charities and are managed by a
volunteer board of directors who raise funds and pay rewards to individuals who
anonymously call with information that helps solve crime.
Rewards are paid for tips that lead to the arrest and indictment of people charged with
felony offenses, and to date Crime Stoppers statistics show a conviction rate of
approximately 95%.
To receive more information about Crime Stoppers or to make a charitable donation
please fill in the fields on the back of this page, cut on the dotted line and mail in.
PLACE
POSTAGE
HERE
CRIME STOPPERS INTERNATIONAL
P.O. Box 614 Arlington, Texas U.S.A 76004-0614

WSE201 www.svat.com
SVAT ELECTRONICS
Now
You Can See
SV
SVA AT SUPPORTS CRIME ST T SUPPORTS CRIME STOPPERS OPPERS
To receive more information about Crime Stoppers or to make a charitable donation
please fill in the fields below, cut on the dotted line and mail in.
NAME:_____________________________________________ PHONE:_____________________________________ ADDRESS:_________________________________________ CITY:________________________________________ PROV/STATE:__________________ COUNTRY:_____________________ POSTAL/ZIP CODE:__________________ E-MAIL ADDRESS:_________________________________________________________________________________ Charitable donations can be made to “CSI” by returning this card in an envelope with your check or money order to the address on the other side.
Amount $__________________
THANK YOU
CRIME STOPPERS INTERNATIONAL
Crime Stoppers International is an organization of community based civilian Crime Stoppers programs, which assist police in solving crime. You can find more information about Crime Stoppers at www.c-s-i.org Local Crime Stoppers programs are partnerships between the public, media and local policing organizations. Each program is run by a citizen board, whose purpose is to advertise a local telephone number, which anonymous persons can call with information regarding a crime. Callers (tipsters) may be eligible for a cash reward for their information. If your community does not have a Crime Stoppers program and would like information about starting one, return this card with the following information.

WSE201 www.svat.com
SVAT ELECTRONICS
Now
You Can See

SVAT ELECTRONICS
Now
You Can See
Model #
WSE201
www.svat.com
www
www.svat.com .svat.com
Disclaimer
SVAT does not endorse any of SVAT products for any illegal
activities. SVAT is not responsible or liable in any way
shape or form for any damage, vandalism, theft or any
other action that may occur while a SVAT product is in use
by the purchaser.
