Multimedia Speaker System 2.1
C2-15

ENG
1
Operation Manual C2-15
Technical support is on www.sven.fi
1
2
2
2
3
3
4
5
6
7
CONTENTS
1. INTRODUCTION ....................................................................................
2. SAFETY PRECAUTIONS ..........................................................................
3. PACKAGE CONTENTS ............................................................................
4. SPECIAL FEATURES ..............................................................................
5. LOCATING ...........................................................................................
6. DESCRIPTION OF SUBWOOFER DESIGN .....................................................
7. REMOTE CONTROL ................................................................................
8. INSTALLATION AND OPERATION GUIDE ......................................................
9. TROUBLE SHOOTING ............................................................................
10. TECHNICAL SPECIFICATION ...................................................................
Congratulations on your purchase of the Sven speaker system!
Please read this operation manual before using the unit and retain this operation manual in safe place
for future reference.
COPYRIGHT
© 2011. SVEN Company Ltd. Version 1.0 (V 1.0).
This manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this manual more exact, some discrepancies may occur. The
information of this manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damages which have arisen from the information,
contained in the given manual.
UNPACKING
Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damages; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
ATTENTION!
Do not switch on acoustic system immediately after you bring it in a room from environment with
negative temperature!
Unpacked acoustic system should be placed in conditions of room’s temperature at least 4 hours.

ENG
2
Multimedia Speaker System 2.1
1. INTRODUCTION
C2-15 Multimedia Speaker System 2.1 (MSS) designed to play music and sound games, movies
etc. The subwoofer has built-in power amplifier, due to which it can be connected to virtually any
audio source (CD/DVD-player, TV, PC, etc.) without using an additional power amplifier. There is
remote control in package.
2. SAFETY PRECAUTIONS
•To avoid electric shock do not open MSS and do not perform repairs by yourself.
•Do not allow circuit of wires (including grounded ones) between speakers, power amplifier or
ground, for it causes damage of power amplifier output stage.
•Do not put foreign objects inside the holes of MSS. Make sure that needles, hair pins, coins,
insects etc. do not get inside.
•Protect MSS from high humidity, water and dust. Do not locate it in areas with high
level of humidity and dust.
•Protect MSS from heating: do not locate it near a heat source or expose to direct sunlight.
•Do not use gasoline, alcohol or other solvents when cleaning, since they may damage stained
surface of MSS. Clean it with dry soft cloth only.
•If MSS does not operate, unplug it and refer to service personnel.
3. PACKAGE CONTENTS
•Subwooofer — 1 pc
•Speakers — 2 pcs
•Signal cable mini-jack to mini-jack ( Ø 3.5 mm) — 1 pc
•Remote control — 1 pc
•AAA battery for remote control — 2 pcs
•Operation manual — 1 pc
•Warranty card — 1 pc
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.

ENG
3
Operation Manual C2-15
4. SPECIAL FEATURES
•Built-in transformer power supply
•Timbre and volume control
•Stereo input for various audio devices
•Remote control
•Magnetic shielding
•MDF case of subwoofer and satellites
5. LOCATING
•Place speakers symmetrically to the listener at the distance not less than one meter. Subwoofer
emits non-directional sound, therefore it can be located in any place of the room, where it will sound
to the best advantage.
•Place speaker system far away from TV sets, as insignificant image distortion in supersensitive
monitors and TV sets is possible.
6. DESCRIPTION OF SUBWOOFER CONSTRUCTION
aSUB: Bass control knob
bVOLUME: Volume control knob
cTREBLE: Treble control knob
dInfrared receiver display
ePhase inverter
fINPUT: Audio source input
gR: Right speaker input
hL: Left speaker input
iPOWER: POWER On/Offswitch
jPower cable
Fig. 1. Subwoofer
front panel
a
b
c
d
e
Fig. 2. Subwoofer
rear panel
C2-15
f
g
h
i
j

VOL+VOL-
TRE-
TRE+
SUB-
SUB+
MUTE a
b
c
d
aMUTE: MUTE button
bTRE+/TRE-: Treble control buttons
cSUB+/SUB-: Bass control buttons
dVOL-/VOL+: Volume control buttons
7. REMOTE CONTROL
Installation of batteries inside remote control
• Open battery compartment on rear panel of remote
control.
• Install batteries from the set matching polarity.
• Close battery compartment.
Notes:
• Use remote control at an angle not less than
30 degrees at a distance not less than 7 meters.
• Direct remote control at infrared receiver display
on subwoofer.
• If remote control is not working, check for bat-
teries and replace discharged batteries for new
ones.
• Pull out batteries from remote control, if you are
not going to use them for a long time (more than a
week).
Fig. 3. Remote control
ENG
4
Multimedia Speaker System 2.1

ENG
5
Operation Manual C2-15
8. INSTALLATION AND OPERATION
C2-15 Multimedia Speaker System can be connected to virtually any audio source: DVD/CD, PC
sound card, etc. (see fig. 4 below).
• Before connecting make sure that speaker system is switched off. Then connect built-in acoustic
cables to outputs on the rear panel of subwoofer (see connection diagram above).
• To connect speaker system to audio source, stereo signal cable mini-jack to mini-jack (stereo
jack Ø 3,5 mm) should be used. Insert one end of the cable into the audio input on the rear panel of
subwoofer, and insert the other end of the cable into audio source input (stereo jack Ø 3,5 mm).
Notes. Sound is directly dependent on accuracy and reliability of the cable connections.
Recommended to use cables that are supplied complete with speakers.
• To connect speaker system to CD/DVD-players, stereo signal cable mini-jack (Ø 3,5 mm) to
2*RCA (not included) should be used; its RCA jacks should be connected to outputs of
DVD/CD-players. If such a cable is not available, use adapter mini-jack (Ø 3,5 mm) to 2*RCA
(optional).
• Insert plug of power cable j(see fig. 2) on rear panel of subwoofer into the socket.
• Shift POWER On/Offswitch into ON position ion rear panel of subwoofer.
• Adjust volume level to its minimum by turning VOLUME control knob bon the front panel of
subwoofer counterclockwise as far as it would go.
• Adjust volume level by turning VOLUME control knob bon the front panel of subwoofer or by
pressing buttons VOL+ or VOL- don remote control (see fig. 3).
• Adjust treble level by turning TREBLE control knob con the front panel of subwoofer or by
pressing buttons TRE+ or TRE- bon remote control.
Fig. 4. Connection diagram
C2-15
signal cable mini-jack
to mini-jack Ø 3.5 mm
DVD/CD/MP3, TV
subwoofer
rear panel
left
speaker
right
speaker
COMPUTER
PLAYER

ENG
6
Multimedia Speaker System 2.1
10. TROUBLE SHOOTING
If none of the above methods can not solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
MSS does not
turn on.
No sound.
There is too quiet
sound of speakers.
Distortion of
sound.
Sound is produced
by one of the
channels only.
Remote control is
not working.
Cause
MSS is not connected to the mains outlet.
Power switch is off.
Volume level is set at minimum value.
Improperly connected audio source.
Volume level is set at minimum value.
Large amplitude of the input signal.
Improperly connected speakers to audio
source.
The battery is discharged.
There is direct sunlight.
Obstacle between remote control and
subwoofer receiver.
Solution
Check the connection.
Turn on the switch.
Adjust volume control knob.
Connect audio sources correctly.
Adjust volume control knob.
Turn down source volume
and MSS volume.
Check the connection of
speakers.
Change battery for new one.
Change location of subwoofer or
remote control.
Change the subwoofer or remote
control location.
• Adjust bass level by turning BASS control knob aon the front panel of subwoofer or by pressing
buttons SUB+ or SUB- con remote control.
• MUTE feature allows to turn off/on sound of speaker system. To turn on sound, press MUTE
button aon remote control.
Notes:
• If speaker system has not been used for a long time, please mind to switch off POWER i
(position OFF) on subwoofer rear panel and pull out its plug jfrom the socket.
• To enhance sound quality, use Line-Out output of sound card.

ENG
7
Operation Manual C2-15
Parameter, measurement unit
Output power(RMS), W
subwoofer
satellites
Frequency range, Hz
subwoofer
satellites
S/N ratio, dB
Diameter, mm
subwoofer
satellites
Voltage, V/Hz
Dimensions (of one speaker) (W хH хD), mm
subwoofer
satellites
Weight, kg
Value
45 (25 + 2 х10)
25
2 х10
30 – 200
60 – 20 000
≥70
Ø 133
Ø 38 + Ø 102
~220/50
182 х313 х335
131 х242 х135
8.6
10. TECHNICAL SPECIFICATION
Notes:
•Technical specification given in this table is supplemental information and can not give
occasion to claims.
•Technical specification is subject to change without notice due to improvement of SVEN
production.

Модель: C2-15
Импортер вРоссии: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите в
гарантийном талоне или на сайте www.sven.fi
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Модель: C2-15
Постачальник/імпортер вУкраїні: ТОВ «СВЕН Центр».
Київська область, м. Переяслав-Хмельницький,
вул. Героїв Дніпра, 31.
Призначення, споживчі властивості та відомості
про безпеку товару див. укерівництві зексплуатації.
Умови гарантійного обслуговування дивіться в
гарантійному талоні або на сайті www.sven.fi
Гарантійний термін: 12 міс.
Строк служби: 5 років.
Товар сертифіковано/має гігієнічний висновок.
Шкідливих речовин не містить.
Зберігати всухому місці.
Виготовлено під контролем «Свен Скандинавія
Лімітед», 48310, Фінляндія, Котка, Котолахдентіє, 15.
Зроблено вКитаї.
Produced under the control of Oy Sven Scandinavia Ltd.
15, Kotolahdentie, KOTKA, Finland, 48310.
Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. C2-15
Multimedia Speaker System 2.1
