Sven ms-906 User manual

www.sven.fi
OPERATION
MANUAL
2.1 Multimedia Speaker System
m s - 9 0 6

ENG
1
Operation Manual M S - 9 0 6
CONTENTS
1. INTRODUCTION .................................................................... ................
2. SAFETY PRECAUTIONS ............................................................................
3. PACKAGE CONTENTS ..............................................................................
4. SPECIAL FEATURES .................................................................................
5. LOCATING .............................................................................................
6. SUBWOOFER REAR PANEL ...............................................................
7. INSTALLATION AND OPERATION GUIDE .......................................................
8. TROUBLESHOOTING ..................................................................... ........
9. TECHNICAL SPECIFICATIONS .......................................................... .........
Technical support is on www.sven.fi
Congratulations on your purchase of the Sven speaker system!
Please read this operation manual before using the unit and retain this operation manual in a safe
place for future reference.
COPYRIGHT
© 2011. SVEN Company Ltd. Version 1.0 (V 1.0).
This manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this manual more exact, some discrepancies may occur. The
information in this manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this manual.
UNPACKING
Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
ATTENTION!
Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
2
2
2
2
3
3
3
5
5

ENG
2
2.1 Multimedia Speaker System
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
1. INTRODUCTION
MS-906 2.1 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies etc. The MSS has a built-in amplifierallowing to connect it to virtually any audio source
(CD/DVD-player, TV, PC, etc.) without using an additional power amplifier.
2. SAFETY PRECAUTIONS
• To avoid electric shock do not open the MSS and do not perform repairs by yourself.
• Do not allow circuit of wires (including grounded ones) between speakers, power amplifier or
ground, for it causes damage of power amplifier output stage.
• Do not put foreign objects inside the holes of the MSS. Make sure that needles, hair pins, coins,
insects etc. do not get inside.
• Protect the MSS from high humidity, water and dust. Do not locate it in areas with high level of
humidity and dust.
• Protect the MSS from heating: do not locate it near a heat source or expose to direct sunlight.
• Do not use gasoline, alcohol or other solvents when cleaning, since they may damage the paint-
coated surface of the MSS. Clean it with dry soft cloth only.
• If the MSS does not operate, unplug it and address your dealer.
3. PACKAGE CONTENTS
• Subwoofer — 1 pc
• Satellites — 2 pcs
• Mini-jack to mini-jack 3.5 mm signal cable — 1 pc
• Operation manual — 1 pc
• Warranty card — 1 pc
4. SPECIAL FEATURES
• Built-in transformer power supply
• Separate master volume control and bass control knobs
• Easy connection to various audio devices
• Magnetic shielding
• Wooden (MDF) subwoofer cabinet

ENG
3
Operation Manual M S - 9 0 6
a
b
c
d
e
f
5. LOCATING
• Place the speakers symmetrically to the listener at least one meter away.
• The MSS has a bas reflex port on the side panel, therefore it should be installed at the distance of
20-30 cm from a wall or other obstacle. The subwoofer emits non-directional sound, therefore it
can be located in any place of the room where it sounds the best.
• Place the speaker system far away from TV sets, as insignificant image distortion in supersen-
sitive monitors and TV sets is possible.
6. SUBWOOFER REAR PANEL
a VOLUME: master volume control knob
b BASS: subwoofer volume control knob
c AUDIO INPUT: audio source input
d AUDIO OUTPUT L/R: satellite outputs
e POWER SOURCE ON/OFF: POWER switch
f Power cord
7. INSTALLATION AND OPERATION GUIDE
MS-906 Multimedia Speaker System can be
connected to virtually any audio source (see
connection diagram, Fig. 2).
• Before making any connections, make sure that
the MSS is unplugged. Connect the built-in audio
cables to the AUDIO OUTPUT L/R d jacks on the
rear panel of the subwoofer (see Fig. 2).
Note that the red RCA jack of the right
speaker should be connected to the red jack
of the subwoofer and the white RCA jack of
the left speaker – to the white jack of the
subwoofer (AUDIO OUTPUT R/L). The
correctness and reliability of the cable con-
nections directly affect the quality of sound.
• The mini-jack of the stereo signal cable should
be inserted into the AUDIO INPUT c jack of the subwoofer, and the other mini-jack of the cable
should be plugged into a Ø 3.5 mm LINE OUT port of the computer sound card or audio output of a
CD/MP3 player, as shown in the diagram (see Fig. 2).
Note. To connect the MSS to a DVD/VCD/CD-player or a TV it is necessary to use a mini-
jack (Ø 3.5 mm) to 2RCA stereo signal cable (not included) or a mini-jack (Ø 3.5 mm) to
2RCA adapter (not included).
• Plug the power cord f on the rear panel of the subwoofer into an outlet.
• Set the master volume level to the minimum by turning the VOLUME control knob a counter-
clockwise until it stops.
• Switch on the device (e, ON position).
• Turn on the audio source.
• Adjust the master volume level by turning the VOLUME control knob a. Turn the knob clockwise
to increase the volume level, and turn it counterclockwise to reduce the volume level.
Fig. 1. Subwoofer rear panel

ENG
4
2.1 Multimedia Speaker System
Fig. 2. Connection diagram
Right speaker Left speaker
• Adjust the subwoofer volume level by turning the BASS control knob b. Turn the knob clockwise
to increase the subwoofer volume level, and turn it counterclockwise to reduce the subwoofer
volume level.
Notes:
• If the MSS is left unused for a long period of time, please mind to switch it off using the
power switch (e, OFF position) on the subwoofer rear panel and unplug the power cord
f.
• To improve the sound quality, use the Line-Out output of your PC sound card.
DVD/CD, TV
Audio cable
PC
PLAYER
CD
Audio cable
Power
cord

ENG
5
Operation Manual M S - 9 0 6
Parameter, measurement unit
Output power (RMS), W
subwoofer
satellites
Frequency range, Hz
subwoofer
satellites
Speaker dimensions, mm
subwoofer
satellites
Power supply, V / Hz
Dimensions (W × H × D), mm
subwoofer
satellites (one satellite)
Weight, kg
Value
22 (10 + 2 × 6)
10
2 × 6
50 – 140
140 – 20 000
Ø 110
Ø 50
~220/50
190 × 185 × 250
205 × 62 × 80
3.1
9. TECHNICAL SPECIFICATIONS
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
8. TROUBLESHOOTING
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications are subject to change without notice due to improvement of SVEN
production.
Problem
The MSS does not
turn on.
No sound or sound
of speakers is too
quiet.
Distortion of
sound.
Cause
The MSS is not connected to the mains
outlet.
Power switch is off.
Volume level is set at minimum value.
The audio source is improperly connected.
Large amplitude of the input signal.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect audio sources correctly.
Turn down the source volume
and MSS volume.

Модель: MS-906
Импортер в России: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите в
гарантийном талоне или на сайте www.sven.fi
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Модель: MS-906
Постачальник/імпортер в Україні: ТОВ «СВЕН Центр».
Київська область, м. Переяслав-Хмельницький,
вул. Героїв Дніпра, 31.
Призначення, споживчі властивості та відомості
про безпеку товару див. у керівництві з експлуатації.
Умови гарантійного обслуговування дивіться в
гарантійному талоні або на сайті www.sven.fi
Гарантійний термін: 12 міс.
Строк служби: 5 років.
Товар сертифіковано/має гігієнічний висновок.
Шкідливих речовин не містить.
Зберігати в сухому місці.
Виготовлено під контролем «Свен Скандинавія
Лімітед», 48310, Фінляндія, Котка, Котолахдентіє, 15.
Зроблено в Китаї.
Produced under the control of Oy Sven Scandinavia Ltd.
15, Kotolahdentie, KOTKA, Finland, 48310.
Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland. m s - 9 0 6
2.1 Multimedia Speaker System
