Sven MS-1060R User manual

www.sven.fi
OPERATION
MANUAL
2.1 Multimedia Speaker System
MS-1060R

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION .......................................... ......................
6. TROUBLESHOOTING................................. ...............................................
7. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
4
6
6
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual MS-1060R

2. PACKAGE CONTENTS
• Subwoofer — 1 pc
• Satellites — 2 pcs
• Remote control (RC) — 1 pc
• AAA type batteries — 2 pcs
• 2RCA to mini-jack (Ø 3.5 mm) signal cable — 1 pc
•Аudio cables — 2 pcs
• Operation manual — 1 pc
• Warranty card — 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi
•Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplifier or the ground, for it causes damage to the power amplifier output stage.
•Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
•Disconnect the MSS from the mains system during a fuse replacement. Use fuses of the same
type and rated value. Do not use hand-made fuses.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When
operating the MSS, do not put any devices on it, do not cover it with cloth or other objects pre-
venting it from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
MS-1060R 2.1 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies, etc. The MSS has a built-in power amplifier allowing to connect it to virtually any audio
source (CD/DVD-player, TV, PC, etc.) without using an additional power amplifier. Remote control is
included.
Special features
•Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound sources
•Remote control
•Front panel operation controls
•Two switchable stereo inputs
•Active input LED indication
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
ENG
2
2.1 Multimedia Speaker System

•Separate bass and treble controls, subwoofer volume control
•StandBy, Mute modes
•Wooden (MDF) subwoofer and satellites cabinets
Subwoofer front and rear control panels
aSTANDBY: standby mode LED
bPOWER: standby mode on/offbutton
cIR: IR receiver
dPC/AUX: active input LEDs
eVOL-/VOL+: volume control LEDs
fPC/AUX: input selection buttons
gVOL-/VOL+: master volume down/up buttons
hAUDIO INPUT: PC/AUX audio inputs
iAUDIO OUTPUT: satellite output terminals
jSafety fuse
kON/OFF: power switch
lPower cord
f
g
Fig. 2. Rear panel
Fig. 1. Front panel
OFF
ON
~220V/50Hz
h
i
a
b
c
d
k
j
l
e
ENG
3
Operation Manual MS-1060R

Remote control
aSTANDBY: on/offbutton (standby mode)
bPC: PC input selection button
cAUX: AUX input selection button
dTREBLE +/-: treble level up/down
eBASS +/-: bass level up/down buttons
fSAT VOL +/-: satellites volume up/down buttons
gSUB VOL +/-: subwoofer volume up/down buttons
hVOLUME +/-: master volume up/down buttons
iMUTE: sound on/offbutton
jRESET: return to default settings
Remote control (RC) battery installation
• Open the battery compartment on the back of the
remote control.
• Insert the included AAA batteries.
• Close the battery compartment.
Notes:
• Use the RC at an angle no more than 30° at a dis-
tance of no more than 7 meters.
• Direct the remote control at the IR receiver on
the subwoofer.
• If the remote control does not work, check the
batteries or replace the discharged batteries
with new ones.
• Remove the batteries from the RC if you don’t
intend to use it for a long time.
5. PREPARATION AND OPERATION
Speaker placement
• Place the speakers symmetrically to the listener at least
one meter away. The subwoofer emits non- directional
sound, therefore it can be located in any place of the
room where it sounds the best.
• Place MSS far away from monitors and TV sets, as
insignificant image distortion in these supersensitive
devices is possible.
MSS сonnecting and control
MS-1060R speaker system can be connected to virtually any audio devices: DVD/CD players, PCs,
laptops, etc. (see connection diagram in Fig. 4).
• Before making any connections, make sure the MSS is offand unplugged. Connect the satellites
to the subwoofer using audio cables (included), observing polarity. Speaker cable ends of the audio
cable plug into the subwoofer AUDIO OUTPUT L+/L– iterminals and another ones plug into the
left speaker terminals «+» and «-». The same way plug the cable ends of the another audio cable into
Fig. 3. Remote control
a
d
c
b
i
j
VOLUME
SUB VOL
SAT VOL
BASS
TREBLE
RESET
PC AUX
MUTE
STANDBY
e
f
g
h
ENG
4
2.1 Multimedia Speaker System

the subwoofer AUDIO OUTPUT R+/R– iterminals, and then another ones plug into the right
speaker terminals «+» and «-» (see Fig. 4).
Note. Check the reliable fixation of wires in the terminals, polarity of connection and
absence of contact of the bared wires with each other and the metal parts of the hardware.
• To connect the MSS to a PC, МР3/CD player, use a 2RCA to mini-jack signal cable (included).
Insert the RCA jacks of the signal cable into the L and R jacks of the PC AUDIO INPUT h, and the
mini-jack of the signal cable – into the LINE OUT port of your PC sound card or an audio output of
your МР3/ CD player, as shown in Fig. 4.
• To connect the MSS to a TV or DVD/CD player, use a 2RCA to 2RCA signal cable (not included).
Insert the RCA jacks of the signal cable into the L and R jacks of the AUX AUDIO INPUT h, and the
other RCA jacks – into your TV or DVD/CD player audio output jacks, as shown in Fig. 4.
•Connect the subwoofer to the mains outlet with the power cord l.
•Turn on the MSS power supply using the POWER switch (k, ON) on the subwoofer rear panel.
MSS goes into STANDBY mode and indicator STANDBY alights up.
• Turn on the MSS with STANDBY button aon the remote control (see Fig. 3) or POWER button b
on the front panel (see Fig. 1), the system will go into operation mode. PC stereo input is active by
default. Choose an input with corresponding buttons on the remote control or the subwoofer front
panel. Adjust the volume with corresponding remote control or front panel buttons.
• RESET button jreturns the system to default settings.
• To enter/exit STANDBY mode, press STANDBY button bon the front panel or button aon the RC.
• To enter the MUTE mode, press the MUTE ibutton on the RC. To exit the MUTE mode, press
this button again.
• After using the MSS, mind to switch it offusing the POWER switch (k, OFF position) and unplug
the power cord lfrom the socket.
Power
cord
Right
speaker
Fig. 4. Connection diagram
Audio cable
Left
speaker
OFF
ON
~220V/50Hz
CD
PC
DVD
Player
2RCA to 2RCA
signal cable
2RCA to mini-jack
signal cable
ENG
5
Operation Manual MS-1060R

If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
The MSS does not
turn on.
No sound or the
sound is too quiet.
Distortion of sound.
The remote control
is not working.
Cause
The MSS isn’t connected to a mains
outlet.
The power switch is off.
Volume level is set at minimum value.
Improperly connected audio source.
Large amplitude of the input signal.
The battery is discharged.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect the audio sources correctly.
Turn down the source volume and
the MSS volume.
Replace the battery with a new one.
6. TROUBLESHOOTING
7. TECHNICAL SPECIFICATIONS
Parameter, measurement unit
Output power (RMS), W
subwoofer
satellites
Frequency response, Hz
subwoofer
satellites
Speaker diameter, mm
subwoofer
satellites
Power supply, V/Hz
Dimensions (one speaker), mm
subwoofer
satellites
Weight, kg
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due to
the improvement of SVEN production.
Value
60 (30 + 2 × 15)
30
2 × 15
45 – 150
150 – 20,000
Ø 165
full-range Ø 76
~220/50
170 × 300 × 310
110 × 120 × 95
6.0
ENG
6
2.1 Multimedia Speaker System

2.0 Multimedia Speaker System
Automatic Voltage Regulator
Стабилизатор напряженияСтабилизатор напряжения
Automatic Voltage Regulator
2.0 Multimedia Speaker System2.0 Multimedia Speaker System
SPS-619
MS-1060R
Модель: MS-1060R
Импортер вРоссии: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед», 176
Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка, Котолахдентие,
15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
2.1 Multimedia Speaker System
