CONTENTS
RUS ......................................................................................................
UKR ....................................................................................................
ENG ..............................................................................................
1. BUYER RECOMMENDATION....................................................................
2. PACKAGE CONTENTS ...........................................................................
3. SAFETY PRECAUTIONS .........................................................................
4. TECHNICAL DESCRIPTION .....................................................................
5. PREPARATION AND OPERATION .............................................................
6. TROUBLESHOOTING ............................................................................
7. TECHNICAL SPECIFICATIONS .................................................................
Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2017. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted eorts to make this Manual more exact, some discrepancies may occur. The
information of this Manual is given on «as is» terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
1. BUYER RECOMMENDATIONS
!Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the rm, which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
!Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the sellers stamp and purchase date, and the
goods number corresponds to that in the warranty card. Remember: in case of warranty card
loss or discrepancy of numbers you forfeit the right for warranty repairs.
!Do not switch on the speaker system immediately after you bring it into a room from environ-
ment with negative temperature! After unpacking, the speaker system should be kept in
conditions of room temperature for at least 4 hours.
!Before installing and using the speaker system, read this Manual carefully and keep it for
future reference.
!Shipping and transportation equipment is permitted only in the original container.
!Does not require special conditions for realization.
!Dispose of in accordance with regulations for the disposal of household and computer
equipment.
Technical support is at www.sven..
12
ENG
2.0 USB Multimedia Speaker System
2. PACKAGE CONTENTS
Speakers — 2 pcs
Operation manual — 1 pc
Warranty card — 1 pc
3. SAFETY PRECAUTIONS
Do not open the MSS and do not perform repairs by yourself. Service and repairs should be
performed only by qualied specialists at authorized service centers. The list of authorized
service centers is on www.sven.
Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplier or the ground, for it causes damage to the power amplier output stage.
Make sure that foreign objects do not get inside the holes of the MSS.
Protect the MSS from high humidity, water and dust.
Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not
expose it to direct sunlight.
Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
If the MSS does not operate, unplug it and address your dealer.
4. TECHNICAL DESCRIPTION
Sven 120, Sven 140, Sven 150, Sven 170 USB Multimedia Speaker Systems 2.0 (MSS) are
designed to play music and sound games, movies etc. MSS has built-in bridge amplier,
acoustic and signal cable due to which it can be connected to virtually any audio source
(CD/DVD-players, TV, PC, etc.). MSS is connected to power supply via USB-port of a PC,
laptop or 5V DC power supply with a cable USB.
MSS special features
U.S.S. (Ultra Sound System) built-in bridge amplier ensures output power 4 times higher
than that of AB class ampliers
Speaker system is compatible with PCs, DVD/Media-players, mobile devices and other sound
sources
Power supply via USB-port of a PC, laptop or 5V DC power supply
Volume control on the cable
Audio sources stereo audio input
Plastic speakers cabinets
13
ENG
Operation Manual SVEN 120, SVEN 150
SVEN 170, SVEN 140
USB
Computer
mini-jack
Ø 3,5 mm
5. PREPARATION AND OPERATION
Speaker placement
!Place the speakers symmetrically to the listener at least one meter away.
!Place MSS far away from monitors and TV sets, as insignicant image distortion in these
super-sensitive devices is possible.
MSS Connecting
Sven 120,!Sven 140, Sven 150, Sven 170!Multimedia Speaker Systems can be connected to
virtually any audio source:!DVD/CD, PC sound card, etc. (see connection diagram below).!
Before connecting, make sure that MSS is unplugged. Connect signal cable mini-jack 3,5 mm!
built-in speaker to audio output of the sound source, for example computer, as shown in the
diagram below.
Connect USB-connector to USB-port of PC (laptop or 5V DC power supply) via built-in USB-
cable.
Set volume level to minimum by turning VOLUME +/- control wheel on the cable counterclock-
wise until it stops.
Turn on PC power supply, turn on audio source.
!Adjust volume level by turning VOLUME +/- control wheel.
Notes:
!After nishing operation with MSS, mind to turn off the USB-cable from the PC, laptop USB
port or 5V DC power supply.
!To enhance sound quality, use Line-Out output of soundcard.
Connection diagram
VOLUME +/-
control
ENG
2.0 USB Multimedia Speaker System
14
ENG
If none of the above methods can not solve the problem, please seek professional advice at
your nearest service center.!Never attempt to repair the product yourself.
Problem
MSS does not
turn on.
No sound.
There i s to o qu iet
sound of speakers.
Distortion of
sound.
Cause
MSS is not connected to the mains outlet.
Power switch is o.
Volume level is set at minimum value.
Improperly connected audio source.
Volume level is set at minimum value.
Large amplitude of the input signal.
Solution
Check the connection.
Turn on the switch.
Adjust volume control knob.
Connect audio sources correctly.
Adjust volume control knob.
Turn down source volume
and MSS volume.
6 TROUBLESHOOTING
Parameter,
measurement unit
Output power (RMS), W
Frequency range, Hz
Speaker diameter, mm
Power supply, V
Dimensions (one speaker) (W × H × D), mm
Weight, kg
SVEN 120/
5 (2 × 2.5)
100 20 000
Ø 45
USB/DC 5
65 × 65 × 65
0.31
SVEN 150
5 (2 × 2.5)
100 20 000
Ø 45
USB/DC 5
75 × 75 × 75
0.32
SVEN 170
5 (2 × 2.5)
100 20 000
Ø 45
USB/DC 5
85 × 85 × 70
0.345
Notes:
Technical specications given in this table are supplemental information and cannot
give occasion to claims.
Technical specications and package contents are subject to change without notice
due to the improvement of SVEN production.
7. TECHNICAL SPECIFICATIONS
15
SVEN 120, SVEN 150
SVEN 170, SVEN 140
Operation Manual
Value
SVEN 140
i:
!SVEN 120, SVEN 140, SVEN 150, SVEN 170
: OOO «», 109052,
, . , . , . 86, . .
: «-»,
105082, . , . , . 75,
. 5. -
www.sven..
: 12 .
: 2 .
: « . »,
176 , 02-02, , 427447.
«
», 48310, , ,
, 15.! .
:
SVEN 120, SVEN 140, SVEN 150, SVEN 170
/ :
« », 08400, ,
. -, . , 31,
. (044) 233-65-89/98. ,
.
www.sven.
.
: 12 .
: 2 .
/ .
. .
: « . », 176 ,
02-02, , 427447.
« », 48310, , ,
, 15. .!!
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
02-02, Singapore, 427447. Produced under the control
of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka,
Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
USB
2.0
SVEN 120
SVEN 140
SVEN 150
SVEN 170
Other manuals for 120
2
This manual suits for next models
3
Table of contents
Other Sven Speakers System manuals
