OPERATION
MANUAL
2.0 Multimedia Speaker System
SPS-700

Congratulations on your purchase of the Sven speaker system!
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information in this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. BUYER RECOMMENDATIONS ..................................................
.............
2. PACKAGE CONTENTS............................................................. ............
3. SAFETY PRECAUTIONS .................................................. ...................
4. TECHNICAL DESCRIPTION .................................................... ................
5. PREPARATION AND OPERATION .......................................... ......................
6. TROUBLESHOOTING................................. ...............................................
7. TECHNICAL SPECIFICATIONS .................................................... ...........
1
2
2
2
3
4
5
1. BUYER RECOMMENDATIONS
•Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
•Check up the package contents and availability of the warranty card. Make sure the warranty card
has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the goods
number corresponds to that in the warranty card. Remember: in case of warranty card loss or
discrepancy of numbers you forfeit the right for warranty repairs.
• Do not switch on the speaker system immediately after you bring it into a room from environment
with negative temperature! After unpacking, the speaker system should be kept in conditions of
room temperature for at least 4 hours.
•Before installing and using the speaker system, read this Manual carefully and keep it for future
reference.
Technical support is on www.sven.fi.
ENG
1
Operation Manual sPS-700

2. PACKAGE CONTENTS
• Speakers — 2 pcs
• 2RCA to mini-jack (Ø 3.5 mm) stereo signal cable — 1 pc
• Audio cable — 1 pc
• Operation manual — 1 pc
• Warranty card — 1 pc
3. SAFETY PRECAUTIONS
•To avoid electric shock, do not open the MSS and do not perform repairs by yourself. Service and
repairs should be performed only by qualified specialists in an authorized service center. The list of
authorized service centers is available on www.sven.fi.
•Do not allow the circuit of wires (including the grounded ones) between the speakers, on the
power amplifier or the ground, for it causes damage to the power amplifier output stage.
•Do not touch the MSS power cord plug pins for 2 seconds after unplugging it from the mains.
•Do not put foreign objects inside the holes of the MSS.
•Protect the MSS from high humidity, water and dust.
•Protect the MSS from heating: do not place it closer than 1 m from a heat source. Do not expose
it to direct sunlight.
•Do not place any open flame sources on or close to MSS.
•Do not place the MSS in poorly ventilated areas. Leave an air gap of 10 cm or more. When ope-
rating the MSS, do not put any devices on it, do not cover it with cloth or other objects preventing it
from cooling.
•Do not use any chemical agents for cleaning. Clean it with dry soft cloth only.
4. TECHNICAL DESCRIPTION
SPS-700 2.0 Multimedia Speaker System (MSS) is designed to play music and sound games,
movies, etc. The MSS has a built-in transformer power supplyallowing to connect it to virtually any
audio source (CD/DVD-player, TV, PC, etc.). The speaker with an audio input and a control panel
is named the active one. The MSS can be connected to an active subwoofer.
Special features
• Speaker system is compatible with PCs, DVD/Media-players, mobile devices
and other sound sources
• Control knobs on the active speaker side panel
•Smooth timbre control
•Active subwoofer output
•Magnetic shielding
•Slotted bass reflex ports
•MDF speaker cabinets
Caution! High voltage inside! To avoid the risk of electric
shock do not open or touch elements inside.
ENG
2
2.0 Multimedia Speaker System

Fig. 2. Connection diagram
~220V/50Hz
AUDIO IN
SUB.OUT L-SPK
RIGHT
LEFT
ƴ udio cable
AUDIO INPUT
or
CD
PC
DVD
Player
Active
speaker
Passive
speaker
2RCA to 2RCA
signal cable
2RCA to mini-jack
signal cable
Subwoofer
a
b
d
c
Fig. 1. Control panel
Control panel
aVOLUME: volume control knob
bTREBLE: treble control knob
cBASS: bass control knob
dPOWER: power control knob
5. PREPARATION AND OPERATION
Speaker placement
•Place the speakers symmetrically to the listener at least
one meter away.
•Place MSS far away from monitors and TV sets, as insigni-
ԛcant image distortion in these supersensitive devices is
possible.
MSS Connecting
SPS-700 Multimedia Speaker System can be connected to
virtually any audio source: DVD/CD, PC sound card, etc. (see
Fig. 2).
ENG
3
Operation Manual sPS-700

•Plug the RCA connectors of the 2RCA to 3.5 mm mini-jack stereo signal cable (included) into the
AUDIO IN LEFT/RIGHT input, and the 3.5 mm mini-jack of the signal cable – into the output of your
PC sound card or an audio output of another sound source, as shown in Fig. 2.
Notes:
• To connect the MSS to a CD/DVD/MP3 player or TV, use the 2RCA to 3.5 mm mini-jack
stereo signal cable (included) with a mini-jack to 2RCA adapter (not included) or a 2RCA to
2RCA stereo signal cable (not included), as shown in Fig. 2.
• To connect a subwoofer to the MSS, plug the signal cable supplied with the subwoofer
into SUB.OUT on the rear panel of the active speaker (see Fig. 2).
•Plug the power cord into a mains outlet. Set the master volume level to the minimum by turning
the VOLUME control knob acounterclockwise until it stops.
•Switch on power supply by turning the POWER knob don the active speaker side panel clock-
wise until it clicks.
•Turn on your audio source.
•Adjust the volume level by turning the VOLUME control knob a. By turning the knob clockwise,
you increase volume level; by turning the knob counterclockwise, you reduce it.
•Adjust the treble and bass levels by turning the TREBLE control knob band BASS control knob
crespectively. By turning the knobs clockwise, you increase the treble/bass level; by turning the
knobs counterclockwise, you reduce it.
Notes:
• After using the MSS, mind to switch it off on the active speaker side panel by turning the
POWER knob dcounterclockwise until it clicks, and unplug the power cord.
• To enhance the sound quality, use the Line-Out output of the sound card.
If none of the above methods can solve the problem, please seek professional advice at your
nearest service center. Never attempt to repair the product yourself.
Problem
The MSS does not
turn on.
No sound.
There is too quiet
sound of speakers.
Distortion of
sound.
Cause
The MSS isn’t connected to a mains outlet.
The power switch is oԚ.
The volume level is set at minimum value.
Improperly connected audio source.
The volume level is set at minimum value.
Large amplitude of the input signal.
Solution
Check the connection.
Turn on the switch.
Adjust the volume control knob.
Connect audio sources correctly.
Adjust the volume control knob.
Turn down the source volume
and MSS volume.
6. TROUBLESHOOTING
4
ENG
2.0 Multimedia Speaker System

Value
40 (2 × 20)
40 – 20,000
Ø 20
Ø 115
~220/50
150 × 255 × 195
4.74
Parameter, measurement unit
Output power (RMS), W
Frequency range, Hz
Speaker diameter, mm
tweeter
woofer
Power supply, V/Hz
Dimensions (one speaker) (W × H × D), mm
Weight, kg
Notes:
• Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
• Technical specifications and package contents are subject to change without notice due
to the improvement of SVEN production.
7. TECHNICAL SPECIFICATIONS
ENG
5
Operation Manual sPS-700

Модель: SPS-700
Импортер вРоссии: ООО «СКАНДИТРЕЛ», 111024, РФ,
г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi .
Гарантийный срок: 12 мес.
Срок службы: 5 лет.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
