AMU-II Interface Options
Installation of the Interface Option
2
1. Installation of the Interface Option
WARNING
Electrical shock hazard
Before opening the housing, disconnect the AMU-II transmitter
from the power supply.
CAUTION
Observe precautions for handling electrostatic discharge
sensitive devices.
A
B
C
D
Housing
Mainboard
Display board
Pins for interface
option
CD
B
A

110820 / 290421
AMU-II Interface Options
Installation of the Interface Option
3
To install an interface option, proceed as follows:
1Switch power off.
2Loosen the four screws at the back of the AMU-II transmitter and
remove the backplate.
3Pull the mainboard [B] completely out of the housing.
4Plug the interface option onto the pins [D] on the mainboard.
5Reinsert the mainboard into the housing, making sure to insert
both boards into the correct guide grooves.
6Carefully press the mainboard [B] against the display board [C]
until it snaps into place.
Connector
Field
7Remove the cover [F] from the connector field.
8Apply the supplied sticker [G], [H] or [I] to the connector field.
9Reinstall the backplate [E] onto the housing.
Mainboard:
Interface option:
Fourth guide groove from the bottom
First guide groove from the right
E
F
Backplate
Covered connector field
(condition at delivery)
G
H
I
Labeling for USB option
Labeling for RS485 option
Labeling for HART option
910L/+ N/- 11 12 131415 16
17 18 19 20 21
12345678
COM
F
E
G H I

110820 / 290421
AMU-II Interface Options
USB Option
4
2. USB Option
Menu item After the USB option has been installed, the <Operation>/<Eject
USB Stick> menu item becomes visible.
Calling up this menu item performs the following actions:
the calibration history and the event history are copied to the
USB stick,
the logger file is completed (the next time the USB stick is inserted,
a new file will be created),
the USB stick is deactivated and can be removed.
Pushbutton Pressing the pushbutton [J] has the same effect as calling up the
<Eject USB Stick> menu item.
Blue LED The blue LED is on if the USB stick is plugged in and ready to
record data.
The blue LED is off when the USB stick has been deactivated and is
ready to be removed.
J
K
Pushbutton
Blue LED
LUSB stick
J
K
L
Log Interval 30 Minutes
Logger
noClear Logger
Eject USB Stick <Enter>

110820 / 290421
AMU-II Interface Options
USB Option
5
2.1. Firmware Upload
Only Swan trained and authorized personnel should perform the
tasks described in this section.
Note: This method updates the AMU-II transmitter firmware with
all files with the extension *.a37 and *.hex that are present in the
root directory of the USB stick.
Preparations Since all data and settings are deleted during the firmware upload,
perform the following steps beforehand:
1Write down all customer-specific firmware settings (parameters
for instrument operation, configuration of signal outputs and re-
lays etc.).
2Download logger, message list and cal. history.
Start upload 1 Copy all files you need (“aout.a37”; “.hex) to the root directory of
the USB stick.
2Insert the USB stick into the USB socket of the transmitter.
3Navigate to <Installation>/<Miscellaneous>/<Load Firmware>.
Press [Enter] and select “yes”.
 The firmware upload starts. After the upload has been
finished, the AMU-II transmitter restarts.
4Navigate to <Installation>/<Miscellaneous>/<Set defaults>,
press [Enter] and select “completely”.
5Press [Enter], [Exit] and confirm with “yes”.
 The AMU-II transmitter restarts and all settings are set to
factory defaults.
6Enter the customer-specific settings according to the notes
taken.

110820 / 290421
AMU-II Interface Options
RS485 Option
6
3. RS485 Option
Menu items After the RS485 option has been installed, the <Interface> menu
item becomes visible in the <Installation> menu. Select Modbus RTU
or Profibus as protocol. After that, further settings of the selected
protocol become visible.
Settings for
Modbus RTU
Settings for
Profibus
Terminating
resistor
On the last RS485 interface in the network, move the switch to the
position marked “Ron” to activate the terminating resistor.
Interface
Description
The Modbus and Profibus interface descriptions can be downloaded
from www.swan.ch.
Protocol Modbus RTU
Interface
126Device Address
Baud Rate 115200 Baud
Parity even
Protocol Profibus
Interface
126Device Address
ID Number Manufacturer
Local Operation Enabled
MSwitch for terminating resistor
M

110820 / 290421
AMU-II Interface Options
HART Option
7
4. HART Option
Menu items After the HART option has been installed, the following menu items
become visible:
<Installation>/<Signal Outputs>/<Signal Output 3>:
<Installation>/<Interface>/<Device Address>:
Field Device
Description
The HART® 7.x Field Device Specification can be downloaded from
www.swan.ch.
Signal Output 1
Signal Outputs
Signal Output 2
Signal Output 3
Protocol HART
Interface
0Device Address
