Swegon GLOBAL PX Troubleshooting guide

GLOBAL PX
GLOBAL RX TOP
GLOBAL LP
GLOBAL RX
Operation and maintenance instructions
GLOBAL PX/RX/LP
Applicable to program versions TAC6 – Version 1.0.0.5

2Operation and maintenance instructions

3
Operation and maintenance instructions
1.0 Safety precautions
2.0 Symbols and abbreviations
3.0 Product Overview
4.0 Wiring Overview
5.0 Functions
6.0 Commissioning
6.1 Commissioning with Touchscreen interface
7.0 Preventive maintenance
8.0 Troubleshooting
9.0 Parameters/Commissioning Sheet
10.0 CE Declaration
GLOBAL PX/RX/LP
Table of content

4Operation and maintenance instructions
1.0 Installation manual
Applicable for the following units
EXCHANGER SIZES INTEGRATED
PREHEATING
INTEGRATED
POSTHEATING HANDING FAN
GLOBAL PX
Counterow
04/05/08/10/12/
13/14/16/18/20/24/26 Yes, electrical Yes, electrical or water Right Forward
GLOBAL PX TOP
Counterow 05/08/10/12/14/18 Yes, electrical Yes, electrical or water Le/ Right Backward
GLOBAL RX
Rotary
05/08/10/12/13/
14/16/18/20/24/26 No Yes, electrical or water Le/ Right Backward
GLOBAL RX TOP
Rotary
05/08/10/12/
13/14/16 No Yes, electrical or water Le/ Right Backward
GLOBAL LP
Counterow
02/04/06/08
10/12/13/14/16/18 Yes, electrical Yes, electrical or water Le/ Right Backward

5
Operation and maintenance instructions
Disclaimer
Danger/Warning/Caution
• All sta concerned shall acquaint themselves with
these instructions before beginning any work on the
unit. Any damages to the unit or its components
caused by improper handling or misuse by the
purchaser or the installer cannot be considered
subject to guarantee if these instructions have not
been followed correctly.
• Make sure that the power supply to the unit is
disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out by an
authorized installer and in accordance with local
rules and controls.
• Although the mains supply to the unit has been
disconnected there is still risk for injury due to
rotating parts that have not come to a complete
standstill.
• Beware of sharp edges during mounting and
maintenance. Make sure that a proper liing device
is used. Use protective clothing.
• Unit should always be operated with closed doors
and panels.
• If the unit is installed in a cold place make sure that
all joints are covered with insulation and are well
taped.
• Duct connections/duct ends should be covered
during storage and installation, in order to avoid
condensation inside of the unit.
• Check that there are no foreign objects in unit,
ducting system or functional sections.
• The unit is packed to prevent damage of the
external and internal parts of the unit, dust and
moisture penetration. If the unit is not to be installed
immediately, it should be stored in a clean, dry
area. If stored externally, it should be adequately
protected from the weather inuence.
RANGE OF APPLICATION
The GLOBAL units are designed for use in comfort
ventilation applications.
Depending on the variant selected, GLOBAL units can be
utilised in buildings such as oce buildings, schools, day
nurseries, public buildings, shops, residential buildings,
etc.
GLOBAL units equipped with plate heat exchangers can
also be used for the ventilation of moderately humid
buildings; however not where the humidity is continuously
high, such as in indoor swimming baths, saunas, spas or
wellness centres.
Please do contact us if you have a need for a unit that is
suited for such an application.
HOW TO READ THIS DOCUMENT
Please make sure that you have read and understood the
safety precautions below.
Please read chapter 2 where the Symbols and
Abbreviations used for GLOBAL are listed and Chapter 5
where the operating principles of a GLOBAL air handling
unit are described. The commissioning of the unit is
described in chapter 6.

6Operation and maintenance instructions
2.0 Symbols and abbreviations
BW BACKWARD
CURVED FAN
BF BAG FILTER PF PLEATED FILTER
RX ROTARY HEAT
EXCHANGER PX PLATE HEAT EXCHANGER
WARNING
Electronic boards contains ESD
sensitive components.
Wear antistatic wrist strap connected
to protective earth before to manipulate
them.
In alternative, discharge by
touching the unit, handle boards at cor-
ners only
and use antistatic gloves.
Must be connected by a qualied
Electrician.
Warning! Hazardous voltage.
OUTDOOR AIR Air from outdoor to the AHU (OA)
SUPPLY AIR Air from the AHU to the building (SA)
EXTRACT AIR Air from the building to the AHU (ETA)
EXHAUST AIR Air from the AHU to outdoor (EHA)
COOLING COIL BA- IBA/ KW HEATING COIL
(WATER /ELECTRICAL)
SILENCER GD CTm MOTORIZED
DAMPER
PRESSURE SENSOR PTx TEMPERATURE SENSOR
Nr = x (1,2,3…)
SLIP CLAMP
Sliding bar and screws are
not included
SC MS FLEXIBLE
CONNECTION
CIRCULAR DUCT CONNECTION ER For inlet SR For outlet

7
Operation and maintenance instructions
GENERAL OVERVIEW
3.0 Product Overview
RIGHT HAND UNIT SUPPLY AIR TO THE RIGHT LEFT HAND UNIT SUPPLY AIR TO THE LEFT
GLOBAL RX GLOBAL RX
GLOBAL RX TOP GLOBAL RX TOP
GLOBAL PX GLOBAL PX
OA OA
OA
OA OA
SA SA
SA
SA
SA SA
ETA ETA
ETA
ETA
ETA ETA
EHA
EHA
EHA
EHA
EHA
EHA
OA

8Operation and maintenance instructions
ATTENTION
Right and le hand units have dierent article numbers and should be ordered accordingly.
Main version described in the manuals is always the hand right version.
The dierence between le and right LP units is the factory placement of the controls box on opposite sides.
RIGHT HAND UNIT SUPPLY AIR TO THE RIGHT LEFT HAND UNIT SUPPLY AIR TO THE LEFT
GLOBAL LP (TOP view) GLOBAL LP (TOP view)
OA
OA
SA
SA
ETA
ETA
EHA
EHA

RIGHT HAND UNIT SUPPLY AIR TO THE RIGHT LEFT HAND UNIT SUPPLY AIR TO THE LEFT
9
Operation and maintenance instructions
GLOBAL PX TOP 05 - 10
GLOBAL PX TOP 12 - 18
GLOBAL PX TOP 05 - 10
ETA
GLOBAL PX TOP 12 - 18
OA
ETAEHA OA
OA
OA SA
SA
SA
SA
ETA
ETA
EHA
EHAEHA

GLOBAL PX
10 Operation and maintenance instructions
1. Main power switch
2. Main power switch for electrical coils
(both internal pre-hating and post-heating)
3. Wiring box TAC controller
4. Supply fan
5. Extract fan
6. Kit CA -airow measurement (option)
7. Outdoor air lter (bag or pleated)
8. Extract air lter (bag or pleated)
9. Heat exchanger (Plate)
10. Modulating 100% by-pass
11. Drain pan and drain pipe
12. Pre-heating electrical antifrost coil
13. Internal post-heating water or electrical coil (accessory)
14. Motorized damper (at outdoor air side - accessory)
15. Motorized damper (at exhaust air side - accessory)
17. Flexible connection(accessory)
18. Slip Clamps (accessory)
19. Water connection for postheating (accessory)
1, 2 and 3 must be installed by an accredited electrician
Note: internal electrical coils, motorized dampers, internal fan-pressure sensors, exible connections and
slip-clamps have to be ordered initially and are all pre-mounted and factory wired. Internal heating water-
coil accessory is pre-mounted but has to be hydraulically and electrically connected by the installer.
COMPONENTS GLOBAL PX

11
Operation and maintenance instructions
EXCHANGER SIZE AIR VOLUME A [mm] B [mm] C [mm] Weight [kg]
GLOBAL PX
Counterow
04
05 1060 m³/h 295 l/s 610 1680 1465 330
08 1680 m³/h 465 l/s 815 1680 1465 370
10 1860 m³/h 515 l/s 995 1680 1465 410
12 2300 m³/h 640 l/s 1182 1680 1465 420
13 2530 m³/h 700 l/s 1182 1680 1465 420
14 3000 m³/h 830 l/s 1382 1680 1465 480
16 3230 m³/h 895 l/s 1640 1680 1465 520
18 4200 m³/h 1200 l/s 2015 1880 1465 670
20 4700 m³/h 1300 l/s 1640 2557 1825 930
24 6260 m³/h 1740 l/s 2015 2557 1825 1120
26 7080 m³/h 1960 l/s 2396 2557 1825 1260
AIR VOLUMES AND DIMENSIONS  GLOBAL PX
GLOBAL PX

12 Operation and maintenance instructions
EXCHANGER SIZE AIR VOLUME A [mm] B [mm] C [mm] Weight [kg]
m²/h l/s
GLOBAL PX TOP
Counterow
05 200-940 60-260 610 1680 1465 330
08 200-1500 60-410 815 1680 1465 380
10 300-1900 80-520 815 1960 1725 470
12 300-2550 80-700 995 1960 1725 530
14 300-2850 80-790 1182 1960 1725 590
18 400-3700 110-1020 1382 1960 1725 670
COMPONENTS GLOBAL PX TOP
AIR VOLUMES AND DIMENSIONS GLOBAL PX TOP
3
11
8
5
6
74
2
9
11
10
1. EC Plug fan w/ composite fan blades (aluminium blades optional)
2. Fresh air lter ePM1≥60% lter class
3. Extract air lter ePM1≥50% lter class
4. Integrated TAC controller
5. High efciency counterow plate heat exchanger
6. Modulating 100% bypass
7. Stainless steel drain pan
8. Base frame for easy on site transport
9. Integrated post-heating (water / electrical)
10. Integrated pre-heating (electrical)
11. Silencer

13
Operation and maintenance instructions
1. Main power switch
2. Main power switch for electrical coils
(both internal pre-hating and post-heating)
3. Wiring box TAC controller
4. Supply fan
5. Extract fan
6. Kit CA -airow measurement (option)
7. Outdoor air lter (bag or pleated)
8. Extract air lter (bag or pleated)
9. Heat exchanger (Plate)
10. Modulating 100% by-pass
11. Drain pan and drain pipe
12. Pre-heating electrical antifrost coil
13. Internal post-heating water or electrical coil (accessory)
14. Motorized damper (at outdoor air side - accessory)
15. Motorized damper (at exhaust air side - accessory)
16. Access panel
17. Flexible connection(accessory)
18. Slip Clamps (accessory)
19. Water connection for postheating (accessory)
1, 2 and 3 must be installed by an accredited electrician
Note: internal electrical coils, motorized dampers, internal fan-pressure sensors, exible connections and
slip-clamps have to be ordered initially and are all pre-mounted and factory wired. Internal heating water-
coil accessory is pre-mounted but has to be hydraulically and electrically connected by the installer.
COMPONENTS GLOBAL LP
5
4
3
2
6
7
8
9
9
10
11
19
13
20
20
18
18
GLOBAL LP

14 Operation and maintenance instructions
EXCHANGER SIZE AIR VOLUME A [mm] B [mm] C [mm] Weight [kg]
GLOBAL LP
Counterow
02 580 m³/h 160 l/s 1300 890 350 105
04 650 m³/h 180 l/s 1300 1100 350 125
06 1000 m³/h 280 l/s 2100 1050 435 195
08 1420 m³/h 395 l/s 2100 1300 435 230
10 1800 m³/h 500 l/s 2180 1600 435 285
12 2200 m³/h 610 l/s 2350 1700 510 335
13 2550 m³/h 705 l/s 2350 1700 510 335
14 2870 m³/h 795 l/s 2350 1940 510 370
16 3300 m³/h 915 l/s 2900 1935 660 610
18 3720 m³/h 1030 l/s 2900 1935 660 610
AIR VOLUMES AND DIMENSIONS  GLOBAL LP
GLOBAL LP
GLOBAL LP

15
Operation and maintenance instructions
1, 2 and 3 must be installed by an accredited electrician
Note: internal electrical coils, motorized dampers, internal fan-pressure sensors, exible connections and
slip-clamps have to be ordered initially and are all pre-mounted and factory wired. Internal heating water-
coil accessory is pre-mounted but has to be hydraulically and electrically connected by the installer.
GLOBAL RX TOP
GLOBAL RX
1
2
3
4
5
6
6
7
8
9
13
15
14
17
17
18
18
19
COMPONENTS GLOBAL RX
1. Main power switch
2. Main power switch for electrical coils
(both internal pre-hating and post-heating)
3. Wiring box TAC controller
4. Supply fan
5. Extract fan
6. Kit CA -airow measurement (option)
7. Outdoor air lter (bag)
8. Extract air lter (bag)
9. Heat exchanger (Rotary)
13. Internal post-heating water or electrical coil (accessory)
14. Motorized damper (at outdoor air side - accessory)
15. Motorized damper (at exhaust air side - accessory)
17. Flexible connection(accessory)
18. Slip Clamps (accessory)
19. Water connection for postheating (accessory)

16 Operation and maintenance instructions
Duct connections: see drawings downloadable on our website.
EXCHANGER SIZE AIR VOLUME A [mm] B [mm] C [mm] Weight [kg]
GLOBAL RX TOP
Rotary
05 1050 m³/h 290 l/s 815 1530 1315 310
08 1400 m³/h 390 l/s 815 1530 1315 315
10 1690 m³/h 470 l/s 885 1680 1465 370
12 2140 m³/h 590 l/s 885 1680 1465 365
13 2430 m³/h 680 l/s 995 1680 1465 390
14 3050 m³/h 850 l/s 1182 1680 1465 425
16 3140 m³/h 870 l/s 1182 1680 1465 430
GLOBAL RX
Rotary
05 1160 m³/h 320 l/s 815 1530 1315 305
08 1680 m³/h 465 l/s 815 1530 1315 310
10 1750 m³/h 485 l/s 885 1680 1465 360
12 2350 m³/h 650 l/s 885 1680 1465 340
13 2900 m³/h 800 l/s 995 1680 1465 365
14 3150 m³/h 875 l/s 1182 1680 1465 385
16 4500 m³/h 1250 l/s 1382 1880 1725 535
18 5500 m³/h 1525 l/s 1382 1880 1725 535
20 5500 m³/h 1525 l/s 1382 1880 1725 535
24 6640 m³/h 1840 l/s 1640 1880 1725 575
26 7100 m³/h 1970 l/s 1640 1880 1725 590
AIR VOLUMES AND DIMENSIONS  GLOBAL RX
GLOBAL RX TOP

17
Operation and maintenance instructions
4.0 Wiring Overview
AO1 = outpout 0-10V for external hydraulic postheater (option) T1 = from outdoors T° sensor (prewired)
DO1 = KWout = output PWM for KWout power regulation (option - prewired) T2 = from indoors T° sensor (prewired)
DO2 = KWin- PX: output PWM for KWin power regulation (option - prewired)
| RX SPEED PWM - RX (prewired)
T3 = to outdoors T° sensor (prewired)
AO2 = RX SPEED 0-10V - RX (option) T5 = supply T° sensor for IBA/KWout coil (option)
AO3 = 0-10 V output to control cooling capacity T7 = IBA/EBA anti freeze protection T° sensor (option - prewired for IBA)
AO4 = outpout 0-10V for internal hydraulic postheater (option - prewired) T8 = Cooling coil frost protection sensor
DO3 = BYPASS OPEN- PX (with rotary actuator) (prewired) IN1 = FIRE ALARM
DO4 = BYPASS CLOSE - PX (with rotary actuator) (prewired) IN2 = BOOST
DO5 = DAMPER 1 (with or without spring return, Imax = 0.5A DC) (option - prewired) IN3 = BYPASS ACTIVATION OVERRIDE
DO6 = DAMPER 2 (with or without spring return, Imax = 0.5A DC ) (option - prewired) IN4 = Drain pan full contact (only for LP Unit - prewired)
DO7 = HEAT OUTPUT (open collector; Vmax=24 VDC; Imax=0,1 A) K1: Airow MODE = m³/h K1
DO8 = COOL OUTPUT (open collector; Vmax=24 VDC; Imax=0,1 A) Demand/Pressure control = START/STOP
DO9 = ALARM OUTPUT (open collector; Vmax=24 VDC; Imax=0,1 A) Torque MODE = %torque K1
DO10 = AL dPA OUTPUT (open collector; Vmax=24 VDC; Imax=0,1 A) K2: Airow control = m³/h K2
DO11 = FAN ON OUTPUT (open collector; Vmax=24 VDC; Imax=0,1 A) Demand/Pressure control = 0-10V INPUT
ADI1 = BYPASS POS - PX | RX SPEED FEEDBACK - RX (prewired) Torque control = %torque K2
ADI2 = SUPPLY FILTER dPa K3: Airow control = m³/h K3
ADI3 = EXTRACT FILTER dPa Demand/Pressure control = % ON K3 or 0-10 V INPUT
Torque control = %torque K3
F1 = FAN 1 (SUPPLY) RJ1 = RJ12 connector for TACtouch (option)
F3 = FAN 3 (EXHAUST) RJ2 = RJ12 connector for Modbus Pressure CP mode (option)
RJ3 = RJ12 connector for Modbus Pressure CA mode on supply ow (option - prewired)
SAT COM = SAT MODBUS or SAT KNX or SAT ETHERNET or SAT WIFI - (option) RJ4 = RJ12 connector for Modbus Pressure CA mode on exhaust ow and defrost
detecting (option - prewired)
SAT RELAY: only used for global lp, then premounted and prewired
SAT RELAY OR1 - linear actuator for LP linear bypass actuator - forward) GREEN LED ON = POWERED ON
SAT RELAY OR2 - linear actuator for LP linear bypass actuator - backward RED LED ON = ALARM
+24 = +24V DC (min: +22V DC; max: +26V DC). 0,8 A max
+12 = +12V DC (min: +11,49V DC; max: +12,81V DC). 0,3 A max
MAIN CONTROL BOARD TAC  CID026006

18 Operation and maintenance instructions
4.1 DIGITAL OUTPUTS
The digital outputs DO7 to DO11 may be used to activate a
relay (1 N/O contact. Input voltage: 24 V DC). See gure 1 for
example with DO7.: output for heat circulator pump, gure 2
for DO9: output for alarm indication, gure 3 for DO10pressure
alarm indication. Same principle for DO8 and DO11.
Fig. 3
Fig. 2
Fig. 1
4.2 PRESSURE SWITCHES
In application where pressure switches are used, follow gure
4 wiring, with pressure switch for supply lter connected on X4
and the exhaust one on X2.
N.B.: connectors X2/X4 may be ordered separetely
(CID522223) if other pressure switches are used instead of the
ones in the dedicated kit CID360025.
Fig. 4

19
Operation and maintenance instructions
Fig. 6
4.3 CIRCUIT BOARD SAT IO  CID3 72 144
SAT IO is a satellite circuit designed to be tted on the main control
board. It permits to extend the number of inputs and outputs.
Installation
The SAT IO must be plugged onto the control board circuit (see Fig.5).
Attention: The SAT IO must be plugged in before the circuit is
powered. SAT must be plugged in correctly, wrong positioning can
damage both circuits permanently.
Wiring
The terminals of the SAT IO are displayed in g.6
OR3 OR3 = BYPASS STATUS. Output relay: 30VDC/42VAC max, 2A
DC/2.8A AC max
AO5 = 0-10V OUTPUT (airow/ pressure).
AO6 = 0-10V OUTPUT (airow/ pressure)
IN5 = MASTER SELECTION
IN6 = HEAT OFF
IN7 = SUPPLY RUN IN FIRE ALARM (open)
IN8 = EXHAUST RUN IN FIRE ALARM (open)
Fig. 5

20 Operation and maintenance instructions
4.4 EXTERNAL COILS CONTROL
In case of addition of external coil, the kit EBA or KWext will be necessary to connect respectively the EBA (external
hydraulic/evaporation/condensation battery) or KWext (external electrical coil) to the control board TAC. Both kits
consist simply in extender cable, anyway necessary to reach the external battery, connectorized at the control board
side extremity.
KWext (external elecrical coil) CID522128
010V CONTROLLED PWM CONTROLLED
EBA (external hydraulic/evaporation/condensation coil) CID522129
COOLING/REVERSIBLE HEATING
M : 3 WAYS VALVE SERVOMOTOR M : 3 WAYS VALVE SERVOMOTOR
T8 : TEMPERATURE SENSOR FOR THE FROST PROTEC
TION OF THE BATTERY.
T7 : TEMPERATURE SENSOR FOR THE FROST PROTEC
TION OF THE BATTERY.
Do not use (can be
insulated )
Do not use (can
be insulated)
To insulate
To insulate
To insulate
To insulate
To insulate To insulate
Kit KWext
KIT EBA M
YELLOW RED (0-10 V)
BROWN BROWN (+24V)
BLUE & GREEN BLUE (GND)
WHITE TO INSULATE
KIT EBA M
WHITE RED (0-10 V)
BROWN BROWN (+24V)
BLUE & GREEN BLUE (GND)
YELLOW TO INSULATE
KIT KWEXT KWEXT
WHITE V
GREEN 0
BROWN
TO INSULATE
KIT KWEXT KWEXT
BROWN +
GREEN -
WHITE
TO INSULATE
