Swisscom Aton CL103 User manual

1
Gigaset E36 / Schweiz-PTT / English for Internet / cover.fm / 30.08.2006
Handset Aton CL103
User guide

2
Gigaset E36 / Schweiz-PTT / English for Internet / cover.fm / 30.08.2006

1
The handset at a glance
Gigaset E36 / Schweiz-PTT / English for Internet / overview.fm / 30.08.2006
Version 4, 16.09.2005
The handset at a glance 1Direct dialling keys (I to III)
2Display in idle status (example)
3Battery charge level
eVU(1/3 charged to
fully charged)
= flashes: battery almost flat
eVUflashes: battery charging
4Display keys (page 8)
5Control key (page 7)
6End call key, On/off key
End call, cancel function, go back one menu
level (press briefly), back to idle status
(press and hold), activate/deactivate hand-
set (press and hold in idle status)
7hash key
Keypad lock on/off (press and hold in idle
status, page 7)
Insert a pause (press and hold for dialling)
Switch between uppercase/lowercase let-
ters and digits for text entry (page 17)
8Microphone
9Recall key
Enter flash (press and hold)
10 Connection socket for headset
11 Talk key
Answer a call, start dialling
12 handsfree key
Toggle between earpiece and handsfree
mode
Lights up: handsfree activated
Flashing: incoming call
13 Voice portal key
11
3
4
6
1
9
2
7
8
10
5
12
U
09:19
§§Menu §
13

2
Contents
Gigaset E36 / Schweiz-PTT / English for Internet / E36IVZ.fm / 30.08.2006
Version 4, 16.09.2005
Contents
The handset at a glance . . . . . . . . 1
Safety precautions . . . . . . . . . . . . 3
Aton CL103 –
more than just a telephone . . . . . 4
First steps . . . . . . . . . . . . . . . . . . . . 4
Pack contents . . . . . . . . . . . . . . . . . . . . 4
Setting up the handset for use . . . . . . . 4
Making calls . . . . . . . . . . . . . . . . . . 7
Making an external call/ending a call . . 7
Answering a call . . . . . . . . . . . . . . . . . . 7
Handsfree operation . . . . . . . . . . . . . . 7
Operating the handset . . . . . . . . . 7
Switching the handset on/off . . . . . . . . 7
Activating/deactivating the keypad lock 7
Control key on the handset . . . . . . . . . 7
Display keys . . . . . . . . . . . . . . . . . . . . . 8
Returning to idle status . . . . . . . . . . . . 8
Menu guidance . . . . . . . . . . . . . . . . . . 8
"Swisscom Voice Portal" key . . . . . . . . . 9
Correcting incorrect entries . . . . . . . . . 9
Using the directory, direct dialling
keys and lists . . . . . . . . . . . . . . . . . 9
Directory . . . . . . . . . . . . . . . . . . . . . . . . 9
Direct dialling keys . . . . . . . . . . . . . . . 10
Last number redial list . . . . . . . . . . . . 11
Opening the message list with the display
key . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Handset settings . . . . . . . . . . . . . 12
Changing the display language . . . . . 12
Screensaver . . . . . . . . . . . . . . . . . . . . 12
Auto answer . . . . . . . . . . . . . . . . . . . . 12
Adjusting the loudspeaker volume . . 12
Changing ringtones . . . . . . . . . . . . . . 12
Advisory tones . . . . . . . . . . . . . . . . . . 13
Using the handset as an alarm clock . 13
Restoring the handset default settings 13
Appendix . . . . . . . . . . . . . . . . . . 14
Symbols and typographical
conventions used . . . . . . . . . . . . . . . . 14
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Contact with liquid . . . . . . . . . . . . . . . 14
Questions and answers . . . . . . . . . . . . 14
Faults and Self-help with
Troubleshooting . . . . . . . . . . . . . . . . . 14
Warranty/Maintenance/Repair/
Authorisation . . . . . . . . . . . . . . . . . . . 15
Repair/Maintenance . . . . . . . . . . . . . . 15
Technical data . . . . . . . . . . . . . . . . . . . 16
Writing and editing a text message . . 17
Index . . . . . . . . . . . . . . . . . . . . . . 18
Accessories . . . . . . . . . . . . . . . . . 20
Assembling the charging cradle 20

3
Safety precautions
Gigaset E36 / Schweiz-PTT / English for Internet / security.fm / 30.08.2006
Version 4, 16.09.2005
Safety precautions
Caution:
Read the safety precautions and the user guide before use.
Explain their contents to your children as well as the potential hazards associated with using the tel-
ephone.
Only fit the recommended rechargeable batteries of the same type (page 16)
! In other words, do not use any other battery type or non-rechargeable batteries
as this could result in significant health risks and personal injury.
Fit rechargeable batteries with the correct polarity and use them according to
this user guide (polarity symbols can be seen in the handset's battery compart-
ment, page 4).
The operation of medical appliances may be affected. Be aware of the technical
conditions in your particular environment, for example doctor's surgery.
Do not hold the reverse side of the handset to your ear if the handset is ringing
or if the handsfree function is switched on. Otherwise, you risk developing seri-
ous, permanent hearing damage.
The handset may cause an unpleasant humming noise in hearing aids.
Do not install the charging cradle in bathrooms or shower rooms. The handset
is not splash proof (page 14).
Do not use the phone in environments with a potential explosion hazard, for
example auto paint shops.
If you give your Aton CL103 to someone else, make sure you also give them the
user guide.
Information about disposal
At the end of its service life this product must not be disposed of among the
normal household refuse. Instead, it must be handed in at a sales outlet or at a
collection point for recycling electrical and electronic devices in accordance with
regulations governing the return, taking back and disposal of electrical and elec-
tronic devices (ORDEA).
The materials can be recycled as indicated. By recycling materials and reusing or
utilising old appliances in any other way you are making an important contribu-
tion to the protection of the environment.
Note:
uNot all of the functions described in this user guide are available in all countries.
uCLIP (Calling Line Identification Presentation), SMS (Short Message Services) and
"Swisscom Voice Portal": these functions depend on the network provider.
‹
Œ
ƒ

4
Aton CL103 – more than just a telephone
Gigaset E36 / Schweiz-PTT / English for Internet / starting.fm / 30.08.2006
Version 4, 16.09.2005
Aton CL103 –
more than just a telephone
Your phone not only enables you to store
up to 100 telephone numbers (page 9) – it
can do a whole lot more:
uYou can programme the direct dialling
keys of your phone with important
phone numbers. The number is then
dialled by simply pressing a key
(page 10).
uUse the handsfree function (page 7) to
keep your hands free when making a
call.
uUse your handset as an alarm clock
(page 13).
A special SOS procedure is available to you
when your handset is registered on an
Aton CL103 base station; for details see
the user guide for your CL103 base sta-
tion.
Have fun using your new telephone!
First steps
Pack contents
The packaging contains an Aton CL103
handset, two batteries, a battery cover, a
belt clip, a user guide and a headset.
The Aton CL103 charging station is a sep-
arate product.
Setting up the handset for use
Please refer to the end of this user guide
for information on connecting and, if
appropriate, wall-mounting the charging
cradle.
Fitting the batteries and closing
the cover
¤Fit the batteries with the correct polar-
ity (see diagram).
The polarity is indicated in the battery
compartment.
¤First align the notches on the side of
the battery cover with the protrusions
on the inside of the casing.
¤Then press down the cover so that it
clicks into place.
Attaching the belt clip
There are notches for attaching the belt
clip on the side of the handset at the same
height as the display.
¤Press the belt clip onto the back of the
handset so that the protrusions on the
belt clip engage with the notches.
Caution:
Use only the rechargeable batteries recom-
mended on page 16. In other words, never use
a conventional (non-rechargeable) battery or
other battery types as this could result in sig-
nificant health risks and personal injury. For
example, the outer casing of the batteries or
accumulators could be destroyed or the batter-
ies could explode. The phone could also mal-
function or be damaged as a result of using
batteries that are not of the recommended
type.

5
First steps
Gigaset E36 / Schweiz-PTT / English for Internet / starting.fm / 30.08.2006
Version 4, 16.09.2005
You can also attach a cord for carrying the
handset in your hand or wearing it around
your neck.
Opening the battery cover
¤If fitted, remove the belt clip.
¤Reach into the housing cavity and pull
the battery cover upwards.
Registering
You have to register your Aton CL103 on a
base station before you can use it. It can
be registered on up to four base stations.
The registration process depends on the
particular base station.
Automatically registering the handset on
the Aton CL103 base station
Requirement: the handset must not
already be registered on any base station.
Registering the handset on the Aton
CL103 base station occurs automatically.
¤Place the handset in the charging cra-
dle of the base station with its display
facing forward.
You will hear a confirmation tone.
Automatic registration can take up to
5 minutes. While registration is in
progress the screen displays Registering.
The handset is assigned the lowest unas-
signed internal number (1–4). If several
handsets are registered on the base, the
internal number is shown in the display
after registration, for example 2. This
means that the handset has been
assigned the internal number 2.
Manually registering the handset on
the Aton CL103 base station
You must activate manual registration of
the handset on both the handset and the
base station.
After it has registered, the handset returns
to idle status. If several handsets are regis-
tered on the base, the internal number is
shown in the display after registration, for
example 2.
The registration process is cancelled after
60 seconds. If the handset has not regis-
tered within this time, repeat the process.
Notes:
– Automatic registration is only possible if
the base station on which you wish to reg-
ister the handset is not being used to make
a call.
– A key press cancels automatic registration.
– If four handsets are already registered on a
base station there are two options:
– The handset with the internal number 4
is in idle status: the handset you wish to
register is assigned the number 4. The
handset that was previously number 4 is
de-registered.
– The handset with the internal number 4
is being used: the handset you wish to
register cannot be registered.
– If automatic registration does not work, the
handset will have to be registered manu-
ally.

6
First steps
Gigaset E36 / Schweiz-PTT / English for Internet / starting.fm / 30.08.2006
Version 4, 16.09.2005
On the handset
Menu§ ¢Settings ¢§OK§ ¢Handset ¢§OK§
¢Register Handset ¢§OK§ ¢Enter
system PIN of base station
(default status: 0000) ¢§OK§
On the base station
Press and hold the registra-
tion/paging key on the base
station (min. 1 sec.).
Registering the handset Aton CL103
on other GAP-enabled base stations
On the handset: §Menu§ ¢Settings ¢§OK§
¢Handset ¢§OK§ ¢Register Handset
¢§OK§ ¢Enter system PIN of base
station (default status: 0000) ¢§OK§.
On the base station: Start to register the
handset on the base station as described
in its user guide.
Charging the batteries
¤Plug the mains adapter of the charging
cradle into the power socket.
¤Place the handset in the charging cra-
dle with its display facing forward.
To charge the batteries, leave the handset
in the charging cradle. Battery charging is
indicated in the top right of the display by
a flashing battery icon eif the handset
is switched on. During handset operation,
the battery icon indicates the charge sta-
tus of the batteries (page 1).
Initial charging and discharging of
batteries
The correct charge status can only be dis-
played when the batteries are first fully
charged and discharged through use.
¤To do this, leave the handset in the
charging cradle without interruption
until the battery icon stops flashing in
the display (approx. 6 hours).
¤Once the batteries are fully charged,
remove the handset from the charging
cradle and do not put it back again until
the batteries are fully discharged.
Please ensure the following:
uAlways repeat the charging and dis-
charging procedure if you remove the
batteries from the handset and re-
insert them.
uThe batteries may warm up as they are
charging. This is not dangerous.
uAfter a time the charge capacity of the
batteries will decrease for technical
reasons.
Setting the date and time
§Menu§ ¢Settings ¢§OK§ ¢Date/Time
¢§OK§
~Enter the day, month and year
with 6 digits and press §OK§.
Use qto move between the
fields.
~Enter hours and minutes with
4 digits (e.g. 0 7 1 5 for
07.15 hrs) and press §OK§. Use
qto move between the
fields.
Once the phone is registered and the
time set, the idle display looks as shown
on page 1.
Your phone is now ready for use.
Note:
After the first battery charge and discharge
you may replace your handset in the charging
cradle after every call.
Note:
You will find explanations for the symbols and
typographical conventions used in this user
guide in the appendix, page 14.

7
Making calls
Gigaset E36 / Schweiz-PTT / English for Internet / telephony.fm / 30.08.2006
Version 4, 16.09.2005
Making calls
Making an external call/ending
a call
External calls are calls using the public tel-
ephone network.
~ (Enter phone number) ¢c.
The number is dialled. (You can also first
press the ckey [ringtone] and then enter
the number.) The earpiece volume can be
adjusted during the call with the tkey.
End a call/cancel dialling:
Press the end call key a.
Answering a call
The handset indicates an incoming call in
three ways: by ringing, by a display on the
screen and by the flashing handsfree
key d.
You can answer the call by:
¤Pressing the talk key c.
¤Pressing the handsfree key d.
¤Pressing the display key §Accept§.
If the handset is in the charging cradle and
the Auto Answer function is activated
(page 12), the handset will answer a call
automatically when you lift it out of the
charging cradle.
If the ringtone is intrusive, press §Silence§.
The ringtone is switched off for this call.
You can answer the call so long as it is dis-
played on the screen.
Handsfree operation
You can make calls immediately in hands-
free mode (the dkey lights up perma-
nently) after entering the phone number
by pressing the handsfree key d.
Toggle between earpiece and handsfree
mode during a call by pressing the
dkey. The volume can be adjusted
during handsfree operation with the
tkey.
Operating the handset
Switching the handset on/off
aPress and hold the end
call key.
You will hear the confirmation tone.
Activating/deactivating the
keypad lock
#Press and hold the hash key.
You will hear the confirmation tone. The
icon Øappears in the display when the
keypad lock is activated.
Control key on the handset
1 Control key
The side of the control key you have to
press in the given operating situation is
shown in black (top, bottom) in this user
guide. Example: tfor "press the top of
the control key".
The control key has a number of different
functions:
1

8
Operating the handset
Gigaset E36 / Schweiz-PTT / English for Internet / telephony.fm / 30.08.2006
Version 4, 16.09.2005
When the handset is in idle status
sOpen the directory.
tAdjust the ringer melody vol-
ume of the handset (page 12).
In lists and menus
t/ sScroll up/down line by line.
In an input field
t/ sMove the cursor left or right.
During an external call
sOpen the directory.
tAdjust loudspeaker volume for
earpiece and handsfree mode.
Display keys
The current display functions are shown in
the bottom display line in reverse video.
The functions of the display keys change
depending on the particular operating
situation.
Example:
1 Current display key functions
2 Display keys
The most important display symbols are:
§Back§ Go back one menu level or
cancel operation.
§Menu§ Open the main menu or a con-
text-dependent menu.
§OK§ Confirm highlighted selection.
§Delete§ Delete key: backspace delete
one character at a time.
§Redial§ Open the last number redial
list (base station dependent).
Returning to idle status
You want to return to idle status from any-
where in the menu: Press and hold the
end call key a.
If you do not press any key, the display will
automatically revert to idle status after 2
minutes.
Changes that you have not confirmed/
stored by pressing §OK§ will be rejected.
For an example of the display in idle sta-
tus: page 1.
Menu guidance
Your telephone's functions are accessed
using a menu that has a number of levels.
Main menu (first menu level)
¤To open the main menu, press §Menu§
with the handset in idle status.
Accessing a function
¤Scroll to the function with the control
key q and press §OK§.
The corresponding submenu (the next
menu level) is opened.
Submenus
The functions in the submenus are dis-
played as lists.
To access a function:
¤Scroll to the function with the control
key q and press §OK§.
Briefly pressing the end call key a
returns you to the previous menu level /
cancels the operation.
2
1
§Redial§ §Menu §
