Swisscom Aton CL311 User manual

Aton CL311/CLT311
User manual

Safety precautions
This DECT cordless telephone is designed for transmitting voice calls over the Swiss analogue
telephone network. Any other use whatsoever is not permitted and is regarded as in violation
of the provisions. The user manual with safety precautions is a part of the product package
and must be passed on to the new owner on reselling.
Caution: Warning/danger statement, follow safety precautions!
➭Please note that the ringer for incoming calls as well as signal tones are emitted on
the handset loudspeaker. Do not therefore hold the handset close to your ear while
one of these functions is on, otherwise your hearing may be affected.
➭Use only the supplied mains adapters 6V 600mA SSA-5W-05 EU 060060F for the
base station!
Rechargeable batteries
Use only rechargeable NiMH AAA batteries. Using other rechargeable batteries or non-
rechargeable batteries/primary cells can be dangerous and cause malfunctions in or
damage to the telephone. Insert the batteries/type indication see chapter “Setting up
the handsets”.
Please note:
➭Do not immerse batteries in water or throw in the fire.
➭Rechargeable batteries can become warm while recharging. This is normal and not dangerous.
➭Do not use any other type of charging unit since this may damage the batteries.
➭Before using the telephone, wearers of hearing aids should note that radio signals can
be picked up by the hearing aid and cause an unpleasant buzzing noise.
➭Do not use your DECT cordless telephone in environments at risk from explosion (e.g. paint-
works, petrol stations etc.)
➭Do not position the base station in bathrooms or showers.
➭The radio signals may influence the working of medical equipment.
➭In the event of a power cut or if the batteries are discharged, your DECT cordless telephone
will not function!
➭The handset must not be charged up without batteries or the battery cover in place.
➭Do not touch open contacts!
Disposal
Please dispose of batteries, base station, handset and mains units in an ecological
manner. Do not dispose of them in domestic waste.

1
20405097en_ba_a0
Contents
Environmental benefits of the Aton CL311/CLT311
The Aton CL311/CLT311 has a low level of energy consumption and reduces radiation.
Reduced power consumption
Your telephone has a power-saving adapter plug and uses up to 60% less power than
standard devices. Power consumption in standby mode is approx. 1.3 watt.
Minimal radiation
The Aton CL311/CLT311 with its preset Ecomode plus switches off all radiation when
in idle status. During a call, the handset reduces the transmission power according to
the distance from the base station.
Detailled information on page 9 and 62.
Safety precautions
Introduction……………………………………………………………………………………9
Ecomode plus …………………………………………………………………………………9
Multi Handset Low Radiation Mode………………………………………………………9
Radiation reduction in communication …………………………………………………9
Electrical consumption reduction …………………………………………………………9
Setting up the telephone …………………………………………………………………10
Contents of the package ……………………………………………………………………10
Location ………………………………………………………………………………………10
Repeater ………………………………………………………………………………………11
Setting up the base station …………………………………………………………………11
Listening protection …………………………………………………………………………11
The stand ………………………………………………………………………………………12
Inserting the stand ………………………………………………………………………12
Removing the stand………………………………………………………………………12
Connecting the phone ………………………………………………………………………13

2
20405097en_ba_a0
Contents
*Function dependent on network operator.
Contact your network operator to find out whether this service is supported.
Setting up the handset ………………………………………………………………………14
Inserting the rechargeable batteries ……………………………………………………14
Charging the batteries……………………………………………………………………15
Language choice/Installation assistant ………………………………………………………16
Getting to know your telephone ………………………………………………………17
Handset keys …………………………………………………………………………………17
Handset display symbols ……………………………………………………………………19
About the menus ……………………………………………………………………………20
Menu navigation …………………………………………………………………………20
Back to previous menu …………………………………………………………………20
End menu …………………………………………………………………………………20
Aton CLT311 base station with answer machine …………………………………………21
Aton CL311 base station ……………………………………………………………………22
Telephoning …………………………………………………………………………………23
Making an external call ………………………………………………………………………23
Call preparation …………………………………………………………………………23
Ending a call ………………………………………………………………………………23
Accepting a call ………………………………………………………………………………23
Send DTMF/keypad information ……………………………………………………………23
Handsfree operation …………………………………………………………………………24
Handset/handsfree volume …………………………………………………………………24
Handset secrecy ………………………………………………………………………………24
Redial …………………………………………………………………………………………25
Redialling a number from the list ………………………………………………………25
Copying numbers from the redial list …………………………………………………25
Deleting individual entries/entire redial list ……………………………………………25
Sending SMS messages from the redial list* …………………………………………26
Automatic Redial………………………………………………………………………………26

3
20405097en_ba_a0
Contents
*Function dependent on network operator.
Contact your network operator to find out whether this service is supported.
Group call (paging) ……………………………………………………………………………26
Keypad lock ……………………………………………………………………………………27
Internal calls……………………………………………………………………………………27
Internal enquiry call …………………………………………………………………………28
Brokering (switching between two calls) ……………………………………………………28
Call transfer to another handset ……………………………………………………………29
Conference calls ………………………………………………………………………………29
External enquiry call …………………………………………………………………………30
Directory………………………………………………………………………………………31
Directory entries ………………………………………………………………………………31
Adding a new entry ………………………………………………………………………31
Tips for entering names/numbers ………………………………………………………31
Editing entries ……………………………………………………………………………32
Deleting directory entries/entire directory ………………………………………………32
Dialling numbers from the directory…………………………………………………………32
Sending SMS messages from the directory* ………………………………………………32
Copying directory entries ……………………………………………………………………33
Copying entries/entire directory to another handset …………………………………33
Calls list* ……………………………………………………………………………………34
Viewing/dialling a number from the calls list ………………………………………………34
Sending SMS messages from the calls list* …………………………………………………34
Saving numbers from the calls list to the directory…………………………………………35
Deleting individual entries ……………………………………………………………………35
Deleting the entire calls list …………………………………………………………………35
Audio …………………………………………………………………………………………36
Handset/base station ringer …………………………………………………………………36

4
20405097en_ba_a0
Contents
Ringer melodies ………………………………………………………………………………36
Personal ringer melodies …………………………………………………………………36
Recording ringer melodies ………………………………………………………………36
Beeps …………………………………………………………………………………………37
Key beep …………………………………………………………………………………37
Range beep ………………………………………………………………………………37
Charging beep ……………………………………………………………………………37
Accu beep …………………………………………………………………………………37
Confirmation beep ………………………………………………………………………37
Family …………………………………………………………………………………………38
Direct call (baby call) …………………………………………………………………………38
Room monitoring (baby surveillance) ………………………………………………………39
Games …………………………………………………………………………………………39
Charges ………………………………………………………………………………………40
Cost of last call ………………………………………………………………………………40
Summary ………………………………………………………………………………………40
Settings ………………………………………………………………………………………40
Type of Display ……………………………………………………………………………40
Charge factor ……………………………………………………………………………40
Currency …………………………………………………………………………………40
Calendar/clock ………………………………………………………………………………41
Alarm …………………………………………………………………………………………41
Appointments …………………………………………………………………………………41
Adjust time/date ………………………………………………………………………………41
Network functions (supplementary services) …………………………………………42
Call forwarding ………………………………………………………………………………42
Unconditional ……………………………………………………………………………42
No reply……………………………………………………………………………………42
Busy ………………………………………………………………………………………42

5
20405097en_ba_a0
Contents
Call waiting ……………………………………………………………………………………43
Activating/deactivating call waiting ……………………………………………………43
Accepting a waiting call …………………………………………………………………43
Anonymous call (Identification restriction) …………………………………………………44
Callback ………………………………………………………………………………………44
Call back on busy (Completion of Calls to Busy Subscriber/CCBS) …………………44
Combox (Network answer machine) ………………………………………………………45
Provider ………………………………………………………………………………………45
Access to the Swisscom Contact Center ………………………………………………46
SMS ……………………………………………………………………………………………47
SMS – Short Messaging Service ……………………………………………………………47
Writing SMS messages ………………………………………………………………………47
Inbox……………………………………………………………………………………………48
Drafts …………………………………………………………………………………………48
Outbox …………………………………………………………………………………………48
Templates………………………………………………………………………………………49
Settings ………………………………………………………………………………………49
Service centres ……………………………………………………………………………49
Send service ………………………………………………………………………………49
SMS mailbox ………………………………………………………………………………49
New SMS alert ……………………………………………………………………………50
Answer machine (Aton CLT311 only) ……………………………………………………51
Operating the answer machine from the handset …………………………………………51
On/off……………………………………………………………………………………51
Outgoing message ………………………………………………………………………51
Recording/playing back an outgoing message …………………………………………52
Selecting the outgoing message ………………………………………………………52
Restoring the standard outgoing message ……………………………………………52
End message………………………………………………………………………………52

6
20405097en_ba_a0
Contents
Record memo ……………………………………………………………………………52
Message playback ………………………………………………………………………53
Delete messages …………………………………………………………………………53
Listening over the handset ………………………………………………………………53
Recording a call …………………………………………………………………………54
Remaining time …………………………………………………………………………54
VIP number* ………………………………………………………………………………54
SMS notification*…………………………………………………………………………54
Operating the answer machine on the base station ………………………………………55
On/off……………………………………………………………………………………55
Playing, repeating, deleting and skipping messages …………………………………55
Delete all listened messages ……………………………………………………………55
Listening over the base station …………………………………………………………55
Answer machine settings ……………………………………………………………………56
Answer mode ……………………………………………………………………………56
Answer delay and toll saver mode ………………………………………………………56
Time limit …………………………………………………………………………………56
Language …………………………………………………………………………………56
Remote access…………………………………………………………………………………56
Remote access PIN ………………………………………………………………………56
Remote activation of answer machine …………………………………………………57
PIN alarm …………………………………………………………………………………57
Operating the answer machine from an external telephone …………………………57
Settings ………………………………………………………………………………………58
Language ………………………………………………………………………………………58
Presentation……………………………………………………………………………………58
*Function dependent on network operator.
Contact your network operator to find out whether this service is supported.

7
20405097en_ba_a0
Contents
Display ……………………………………………………………………………………58
•Wallpaper ………………………………………………………………………………58
• Menu color ……………………………………………………………………………58
• Font ……………………………………………………………………………………58
• Contrast …………………………………………………………………………………59
• Backlight ………………………………………………………………………………59
• Screen Saver ……………………………………………………………………………59
Keypad backlight …………………………………………………………………………59
Handset Name ……………………………………………………………………………59
Telephony………………………………………………………………………………………60
Automatic DTMF …………………………………………………………………………60
Auto Talk …………………………………………………………………………………60
System PIN ……………………………………………………………………………………60
PBX ……………………………………………………………………………………………61
Repeater ………………………………………………………………………………………61
Ecomode plus …………………………………………………………………………………62
Multi Handset Low Radiation Mode ……………………………………………………62
Radiation reduction in communication …………………………………………………62
Additional handsets/base stations ………………………………………………………63
Registering additional handsets………………………………………………………………63
Deregistering a handset ………………………………………………………………………63
Selecting the base station ……………………………………………………………………63
PBX access ……………………………………………………………………………………64
Compatibility…………………………………………………………………………………64
Access Code …………………………………………………………………………………64
Entering the Access Code ………………………………………………………………64
Incoming Code on/off……………………………………………………………………64

8
20405097en_ba_a0
Contents
Maintenance …………………………………………………………………………………65
Reset……………………………………………………………………………………………65
Software version ………………………………………………………………………………65
Installation assistant …………………………………………………………………………65
Faults and trouble-shooting …………………………………………………………………65
Important information ……………………………………………………………………66
Approval and conformity ……………………………………………………………………66
CE symbol ……………………………………………………………………………………66
Warranty and support ………………………………………………………………………67
Support ……………………………………………………………………………………67
Warranty …………………………………………………………………………………67
Restrictions ………………………………………………………………………………67
Help ……………………………………………………………………………………………67
Cleaning – when necessary …………………………………………………………………67

9
20405097en_ba_a0
Introduction
Ecomode plus
Your Aton CL311/CLT311 is fitted with the latest innovations in terms of reduction
of electromagnetic radiation (so called “electro-smog”) as well as electrical power
consumption reduction.
The Ecomode plus includes three main features:
Multi Handset Low Radiation Mode
When in standby, the electromagnetic radiation is automatically shut down between the
base station and the handset(s). This works with one ore more handsets declared to the
base station. The handset(s) and the base station are waiting for a wake-up signal should
a call come in, when you activate one handset or when the system synchronises some
data.
In other terms, electromagnetic radiation is generated only when the system is in use!
(refer to chapter Settings/Ecomode plus for settings).
Radiation reduction in communication
Up to 70% radiation reduction of the handset is achieved when it is near the base
station. The handset’s power transmission are regulated; the power transmitted from
the handset is automatically reduced to the lower level, depending on the distance to
the base station (refer to chapter Settings/Ecomode plus for settings).
Electrical consumption reduction
The efficiency of the switching power supply reduces the electrical consumption of the
telephone up to 60%. Combined with the Radiation Reduction and Multi Handset Low
Radiation Mode it contributes to save energy and costs.

10
20405097en_ba_a0
Contents of the package
➭1 base station
➭1 connector cable
➭1 mains unit 6V 600 mA SSA-5W-05 EU 060060F
➭1 handset
➭2rechargeable batteries
➭1 user manual (3 languages ger/fr/it)
➭1 belt clip (mounted)
Location
To obtain the best possible range, we recommend positioning the telephone in a location
central to your sphere of activity. Avoid positioning the telephone in niches, recesses and
behind steel doors.
The maximum range between the base station and handset is approximately 40 meters
indoors and 250 meters outdoors. Depending on the surrounding conditions as well as
spatial and structural factors, the range may be smaller. Silent zones can occur due to the
digital transmission in the frequency range used – even within the range, depending on
the structural environment. In this case the transmission quality may be reduced through
the increased incidence of short breaks in transmission. Normal call quality can be restored
if you move slightly out of the silent zone. If the range is exceeded, the call will be dis-
connected unless you move back into range within five seconds.
To avoid radio signal interference from other electronic equipment, we recommend that
the base station and handset are situated at the greatest possible distance (min. 1 meter)
from other equipment.
Setting up the telephone

11
20405097en_ba_a0
Repeater
You can use a repeater to extend the range and receiving power of your base station.
The repeater must first be registered and activated on the base station. (Your telephone
is delivered with the default setting “off”).
Note For settings refer to chapter “Settings, Repeater”.
Setting up the base station
➭Do not expose the base station to direct sunlight.
➭Protect the base station against moisture. Do not position the base station in rooms
exposed to condensation, corrosive steam or excessive dust. Condensation can be pre-
sent in basements, garages, conservatories or sheds.
➭The ambient temperature must be between 5 °C and 40 °C.
Position the base station in a clean, dry and well-aired location. Choose a place which is
stable, level, and not subject to vibrations. To avoid mutual interference, do not position
the base station in the immediate vicinity of electronic equipment such as hi-fi systems,
office equipment or microwave ovens. Avoid positioning the telephone near heat sources
such as heating elements or near obstacles such as metal doors, thick walls, niches and
cupboards.
There is no mains switch on the base station. For this reason the socket to which it is
connected must be easy to access.
Listening protection
When you are on the telephone, the base station and handset are connected to each
other over a radio link. The base station handles switching between the telephone net-
work and the handset. To ensure that no-one can eavesdrop or telephone at your cost,
the base station and handset exchange codes. If the codes do not match, the connection
with third-party handsets cannot be set up.
Setting up the telephone

12
20405097en_ba_a0
Setting up the telephone
The stand
Inserting the stand
1. Lay the base station down on the table
(front side down).
2. Insert the stand in the grooves ➀of the
base station and press it on lightly.
3. Make sure that the lower support
tabs ➁click into the slots provided.
There is a definite click when the stand
is properly seated.
Removing the stand
1. Lay the base station down on the table (front side down).
2. Fix the base station with one hand.
3. With the other hand press the two tabs ➀right and left simultaneously and pull
the stand out.
1
1
1
12
22
2

13
20405097en_ba_a0
Setting up the telephone
Connecting the phone
Before you can start using your telephone you must plug in the telephone connector
cable and the mains cable.
Note The cables must pass above the stand to assure the proper standing of the
base station.
Safety note
Use only the supplied mains adapter 6V 600 mA SSA-5W-05 EU 060060F
for the base station!
➀Telephone connector cable
The telephone connector cable has two different plugs. Insert the smaller plug in the
socket marked with the telephone symbol on the base station. Insert the larger plug in
your telephone connection socket.
➁Mains cable
First, insert the mains cable in the socket marked with the mains connector symbol on
the base station. Then insert the mains plug in the 230 V socket.
Note Your telephone will not function if the mains connector is not plugged in or
during a power failure.
➀Socket for telephone connector cable➁Socket for mains cable

14
20405097en_ba_a0
Setting up the handset
Your handset will be ready for operation (for making or accepting calls) only once the
batteries have been fully charged for the first time.
Inserting the rechargeable batteries
The bottom part of the handset contains a battery compartment for housing two type
AAA batteries (microcells).
Removing the battery
compartment cover:
Slide the battery compart-
ment cover downwards
(approx.3 mm) and lift.
Inserting the two rechargeable batteries (note the polarity!):
Insert the batteries in the battery compartment. Make sure the polarity is correct. Insert
the batteries so that the flat end (negative polarity) of the battery is pressing against the
spring. The handset will not function if the batteries are incorrectly inserted. This may
result in damage. Replace the compartment cover by placing it approximately 3 mm off-
set and slide it upwards until it clicks into place.
Setting up the telephone
Removing the belt clip:
Press on the top of the clip and
shift it upwards to remove it.

15
20405097en_ba_a0
Setting up the telephone
Charging the batteries
The batteries are not yet charged when you first unpack the telephone. Insert the hand-
set in the base station for charging. The flashing battery symbol on the handset shows
the charging status. The batteries will take around 14 hours to fully charge.
Note •Do not insert the handset in the base station without batteries.
•Do not use any other type of charging unit since this may damage the
batteries.
The following symbols indicate the charging status on the handset display:
Charging status “full”
Charging status “1/2”
Charging status “empty”
Once the new batteries have been inserted, the display on the handset indicates the
actual charging status only after a complete charging cycle.
Your telephone is now ready to use.
Important!
Please note: after you have inserted the batteries for the first time, the battery display will
indicate the correct information on the charging status only after a complete charging cycle.
Use only approved rechargeable batteries NiMH AAA. Never use disposable
batteries/primary cells.
Approved models: – GP80AAAHC – GN85AAAHC
– H-AAA750A-UN – H-AAA900A
– GP75AAAHC

16
20405097en_ba_a0
Setting up the telephone
Note You can replace the handset in the base station after every call. Charging is
electronically controlled to ensure optimal charging of batteries in different
charge states. Avoid removing the batteries from the handset for no good
reason, since this affects the optimum charging cycle.
Because your telephone is fitted with a low-radiation mechanism, the antenna
automatically switches off in standby mode and cannot therefore emit any
radiation. Your telephone is delivered with this function switched on.
You can telephone for up to 12 hours with fully charged batteries.
The handset has a standby time of up to 120 hours.
If the battery charge status has reached its lower limit, the battery symbol ()
flashes in the display and a warning signal is heard. You have 10 minutes of
talk time left.
Language choice/Installation assistant
The language choice appears. Press to scroll to the desired language and press OK
to confirm.
An installation assistant guides you then step by step through the setup procedure for
your telephone.
Enter time and date according to the displayed instructions.
Note The installation assistant will re-appear following a reset of the telephone
(reset to default settings).

17
20405097en_ba_a0
Getting to know your telephone
Handset keys
6
3
9
5
8
4
7
R
MNO
DEF
2
JKL
ABC
TUV
GHI
PQRS WXYZ
0
1
Int
Backlit display
Earpiece
Asterisk key
Alphanumerical
keypad
Talk key
Enquiry key with
flash function
“End call” key
Key “Write SMS message”
Microphone
Softkey
(multifunctional key)Softkey (multifunctional key)
Internal call key
Navigation key
Activating
the key lock
Redial
Message key/Calls list
Directory

18
20405097en_ba_a0
Getting to know your telephone
Softkeys (multifunctional keys) Right softkey: Choose menu options,
confirms entries/settings. Left softkey: returns to previous menu step.
In idle mode: Call Swisscom Hotline.
Navigation key For scrolling up/down or right/left.
In answer machine mode, message playback: right = skip forward,
left = replay message; double click = skip back.
Redial Open redial list.
Message key Access to the calls list (answered/missed calls), SMS* or
answer machine messages.
Opens the Directory.
Internal call key For conducting handset-to-handset calls.
Call key For conducting and accepting calls and switching to hands-
free.
“End call” key Press briefly to end a call or return to standby mode.
Press and hold down to switch the handset on/off.
Alphanumerical keypad For dialling telephone numbers. Letters printed
on housing. Press and hold down “0” when entering a telephone number
to insert a dialling pause between two digits.
Combox Press and hold down for direct access to network answer
machine messages.
Call anonymously Press and hold down to suppress caller ID for next call.
Asterisk key For entering asterisks. Press and hold down to switch
handset ringer on/off.
Hash key For entering the hash symbol. Press and hold down to
switch keylock on.
Keypad locked A locked keypad prevents numbers being dialled
inadvertently.
Enquiry key Press key R to activate some network functions.
Key “Write SMS*”.
0
…
9
WXYZ
1
3
DEF
Int
R
*Function dependent on network operator.
Contact your network operator to find out whether this service is supported.
