(1) Time code（SDI）
Under SDI input, the monitor can display Time code information (LTC, VITC1&2). If no Time
code info is detected, it will display “TC UNLOCKED”. User can set function keys F1～F5 or GPI
pins as “Time Code” to turn on or off this function.
(2) On screen TALLY
Display TALLY signal from GPI port.
(3) Source ID/UMD
Display TSL 3.1/4.0 UMD or User input Source ID.
(4) Colour gamut chart
Displays the current video colour gamut, which can be set by the user in the "Main Menu" -
"Colour Management" - "Colour Gamut
(5) Lissajous
Lissajous diagram showing audio signal. Users can set the shortcut keys (F1～F5) or GPI pins
on the front panel to “Lissajous” function and turn it on/off.
(6) Waveform
The display waveform can be selected from Y/Cb/Cr/R/G/B/RGB types, and single line display
mode selectable. The waveform display positions, colors, background are adjustable. User
can set function keys F1～F5 or GPI pins as “Waveform” to turn on or off this function.
(7) Vector
Display vector scope with 100% and 75% markers for SDI and HDMI® video. The vector scope
pattern display positions, colors, background are adjustable. User can set function keys F1～
F5 or GPI pins as “Vector” to turn on or off this function
(8) eye pattern
Tests the quality of the SDI signal, the larger the eye pattern, the stronger the quality.
(9) ColorChecker
After auto calibration, the color gamut and chromatic aberration (△E) “Automatic colour
correction”-“Start colour proofing” and "Auto Calibration" - "Measure" pops up the gamut
value and color difference value (△E) of the previous calibration and this measurement.
08
·OSD
TC:00:15:13:07
CAMERA 1
Y
64
256
512
768
940
M
T
U
E
M
T
U
E
M
T
U
E
M
T
U
E
M
T
U
E
M
T
U
E
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
U
N
L
O
C
K
E
D
1 2 3 4 5 6 7 8 9 10111213141516
-
50
-
20
-
10
L -32DB 01CH R -13DB 02CH
-
60
-
40
-
30
in phase
LR
(1)
(2)
(3)
(5)
(6)
(7)
(9) (8)
R
R75
Mg
Mg75
B
B75
Cy
Cy75
G
G75
YI
YI75
W
Delta = 1.0
Before Calibration After Calibration
R
R75
Mg
Mg75
B
B75
Cy
Cy75
G
G75
YI
YI75
W
Delta = 0.9
B
G
R
0.2
0.2
0.4
0.4
0.6
0.6
0.8
0.8
(4)
400mV
-400mV
200mV
-200mV
（10）（11）
DCI-P3
(10) Histogram
Parallel display R/G/B/Y histogram for SDI and HDMI® video. User can set function keys F1～F5
or GPI pins as “Histogram” to turn on or off this function.
(11) Audio VU/PPM meters
Display meters of SDI/HDMI® embedded audio or analog audio. The audio meter display
channels, on screen positions, markers and background colors are adjustable. User can set
function keys F1～F5 or GPI pins as “Audio Bar” to turn on or off this function.
