Swordfish OmniPoint User manual

OmniPoint
Mechanical Pencil Sharpener
Operating Instructions

Please read the following instructions before operating
your sharpener.
Operating Instructions
●Secure the sharpener to the desktop with the clamp provided.
●Press the button to open the pencil jaws (A).
●Push the slide forward to extend the front plate (B).
●Insert pencil and release pressure on the button.
A
B

Setting
●The pencil jaws will automatically adjust to t any pencil from 8mm
to 12mm diameter.
●Twist the sharpness control to the right for a blunt point, to the left
for a sharp point.
Sharpening
●Turn the handle in clockwise direction.
●The pencil will be automatically drawn into the sharpener.
●Sharpening will cease when the desired point has been achieved.

Clean or replace the blade assembly
WARNING - the edges of the helical blade are sharp!
●Remove the shavings tray.
●Remove the screw indicated.
●Withdraw the blade assembly.
●Clean the helical blade with a sti brush.
●Clear any blockage with a thin sharp object.
●Replace the blade assembly (code 40306) when it becomes blunt.
Shavings Tray
●Pull the shavings tray forward to remove it from the sharpener.
●Do not allow the shavings tray to over-ll as this can cause
permanent damage to the sharpener mechanism.
For troubleshooting and product support,
please visit www.snopakebrands.com
