Sylvania SMPK1021 User manual

1
User Manual-SMPK1021
Overview
●Refined exterior design
Unique design fits for hand.
●Multi file format support
This player recognize MP3, WMA ,WAV and video in AMV formats.
●Firmware upgrade available
You can download and upgrade software from website enhancing player’s function.
●E-BOOK You can download text files into the player
●Driver free USB memory
Manage your files in USB memory without specified software, no need drivers in WIN2000 or furthers.
●Recorder / Repeat
Voice can be recorded and saved in WAV or ACT format. Snippet/Contrast repeat available.
●Equalizer
Normal, Rock, Pop, Classic, Soft, Jazz, DBB

2
●Play modes
Normal, Repeat One,Folder, Repeat Folder, Repeat All,Random,Intro
●Timing turning off
The player provides Sleep and battery saving mode, more convenience for you!
●Complete dynamical menu
Visualized dynamical menus with text instructions make you easy control.
Declarations
Please read this manual carefully.
Functions and performance may change without prior notice.

3
Know your player
zExterior and Key
`
1. DISPLAY SCREEN
2. EARPHONE
3.USB
4.MENU/MODE
5.NEXT/VOL+
6.POWERON/OFF
7. PLAY/PAUSE/STOP
8. VOL
9. PREVIOUS/VOL-
6
9
1
4
2
3
8
7
5

4
zDisplayer
zBattery Level
The player shows capacity in 9 levels
Battery is full on 3.8V. As time goes on, capacity indication will monish.
Indicator shows blank when battery almost ran out. You should charge your battery at that time.
Please switch on the player before charge. This player cannot be charged in case of power off/
Replay Mode
Repeat Mode
Battery Reveal
Play Time
Number
File Formats
Bit Rate
Volume
Title/Artist
Sound Effects Mode
Earphone

5
Please switch off power when not using the player.
Basic Functions
zAccess to Menus
PressMode to access menus.
zScrolling
○Scroll music, menus
○Fast Forward / Reverse when playing music.
zList of Menus
To access different menu functions from main menu.
Main menu: (Hold Mode to access)

6
Music Mode: Recorder Mode: Play Mode:
Settings: E-Documents:

7
Browsing pictures: USB Mode (Connect to PC):
zVolume Adjust
Press VOL to adjust volume, press Next/PREVIOUS to increase or decrease volume.

8
zSwitch on/off
Press and hold Play to switch on when the player is off.
Press and hold Play to switch off when the player is on.
zPlay & Pause; exit from submenu
On music mode, Press Play to play music.
When playing music, press Play to pause; press and hold to stop playing.
zStart / Stop recording
On recording mode, press Play to stop.
Keys Processing
zKeys Functions Definition
1．Play: Power On/Off, Play, Pause, Stop
2．MODE (Menu ): Enter main menu or exit from current menu.
3．Next: Next, FF, Volume increase
4．PREVIOUS: Previous, Rev, Volume decrease
5．USB: USB outlet
6．Earphone:Standard earphone outlet
7．ON/OFF: Power switch

9
zKey Processing Definition
Keys processing includes 2 actions: Press , Press and Hold
Press: Press a key and work immediately;
Press and Hold: Press a key and hold it at least 2s
4、Play music
zSimple actions
1.Put earphone plug into earphone outlet;
Power switch On : Press and hold Play Key to open the player, then enter Main Menu.
2. Choose“Music”option，and press“MENU”key to enter and press “ PLAY” key to play music。
3.Select music: PREVIOUS: Previous music;
Next: Next music.
zEqualizer Mode
1. When playing music
2. Press Mode to enter play submenu;
3. Press Next choosing Equalizer Mode;

10
4. Press Mode to enter ‘Equalizer Mode’ submenu.
Select an equalizer:
5. Detail of each equalizer (EQ):
Natural, Rock, Pop, Classical, Soft, Jazz, DBB
6. Press Next to select an EQ and press Mode to confirm.
zSynchronous Lyric Display
The player supports lyric files with *.LRC suffix, and displays synchronously.
How to use lyric files?
Please make sure the lyric has the same name to the music, For example:
Music file: Journey.mp3 Lyric file: Journey.lrc

11
zHow to know if lyric available?
If lyric matched, a green icon will be displayed on the left down corner of screen,
1. When marched lyric available：2. Press and hold Mode to enter lyric interface;
3. Lyricdisplays 4. PressMode return to music mode.
Voice Recording
Please make sure the battery has enough capacity before making record.
Each fold can save up to 99 voice recording files.
zRecording on “Record mode”
1. .Enter main menu.

12
2. Press Next scroll to Record mode
3. Press Mode to select Record mode, screen will display as below:
4. Press Play to start recording.
Voice will be recorded in current fold which set through ’Record stop / Main fold’
If displayed “Memory full”, it means no space to save new record files, please delete other files to
release memory space.
If “Fold full” shown, it means there are 99 record files in this fold. Please choose another one.
The player only responses to Play and A-B when record processing

13
zSelect Record Type
1. When in the interface of ‘Record stop’
2. Press Mode to enter record submenu 3. Press next scrolling into ‘Rec type’
submenu then presses Mode to select it.
Fine REC wav file，fine quality
Long REC act file, normal quality
Fine VOR wav file, (Recording controlled by voice, pause when mute)
Long VOR act file, (Recording controlled by voice, pause when mute)
4. Press Next to choose appropriate type and press Mode to select it

14
5. Press Play to start recording.
zPlay recorded files
1. Enter main menu
2. Press Next to choose ‘VOICE’
3. Press Mode to enter playing interface
4. Press Play key to start playing the file.
5. Choose voice record files:
PREVIOUS: Select previous file;
Next: Select the next file;
Convert ACT Files into WAV format
The ACT file which produced by this player can be converted into WAV format by using software provided.
1. Imply “Sound Converter” program. 2. Select the ACT files you would like
Clock“OPEN”button toconvert

15
3. Click ‘CONVERT’ button, the program will start converting,

16
PS: This tool can also play WAV and MP3 files.

17
Settings
zEnter Settings
You can set system performances here,
options may vary in different firmware version
1. Enter main menu
2. Press Next Scrolling into “SETUP”
3. Press Mode to enter.
zOptions introduction:
(Clock) Setting date and time when saving recorded file
(LCD set) Screensaver setting
(Language) Choosing different languages
(Power off) Setting a count down time in minutes, the player will shut
off when time out.
(Replay mode) Setting Replay status
(Online Device) MTP and USB Disk setting
(Online Mode) Connect PC mode
(Memory info) Check memory space and usage status

18
zList of menus:
○’Clock’ Setting
1. System setting interface
2. Press Mode to enter ‘Clock’ interface recording time:
3. Press VOL setting from years. While setting, year on twinkling.
4. Press Next the value will increase (PREVIOUS on opposite)
(DRM Time) Greenwich Mean Time
(Firmware version) Version of player’s firmware
(Firmware upgrade) Use for upgrade firmware
(Remove MTPinfo) Exit MTP mode
(Exit) Exit from Setting interface

19
5. After setting, press Mode to exit.
○“LCD set” Setting
1. Press Mode enter “LCD set”
2. Press PREVIOUS or Next for choosing corresponding submenu .
3. press“Mode”key to enter and press “PREVIOUS or Next” key
to adjust time
4. press Mode to exit.
○Language Setting
This player have 18 display languages: Simplified Chinese, English, Traditional Chinese ect.
1. Press Mode to enter ‘Language’ setting
2．Press PREVIOUS or Next to choosing and press “Mode” key to enter.
3．press play to exit.
○”Power off” setting
Please note:
You can set time in seconds on ‘Battery saving’ mode, allow the player shut down automatically
when player become stop and idle for the period you have set. This function id void if the time set to 0.
You can set time in minutes on ‘Sleep mode’, allow the player shut down automatically when the
player become idle (regardless current status) for the period you have set. It is designed for listening

20
music before sleep. Please note: Sleep mode valid only once after setting, you have to set again if you
want to use it next time.
○“Replay mode” Settings
Note: in “Manual Mode” you should set repeat point manually.
In “Automatic Mode” the player can identify sentence automatically when on A-B repeat. (This
function is designed for repeat sentences in language studies.)
○“Online Device” Settings
press“Mode”key to enter and Press PREVIOUS or Next to select it and press“Mode”key to confirm
○“Online Mode” Settings
press“Mode”key to enter and Press PREVIOUS or Next to select it and press“Mode”key to confirm
○’Memory info’ check
You can check total memory space and the percentage of usage.
○”DRM Time” check
press“Mode”key to enter and check
○’Firmware version’
You can find the player’s firmware’s version.
○’Firmware upgrade’
press“Mode”key to enter. Use for upgrade player’s firmware.
○’Remove MTPinfo’
