Symbol SC-960RL User manual

SC-960RL/SC-960L
User’s Guide

2
On December 1, 2000 Symbol Technologies, Inc. completed the purchase
of Telxon Corporation. References made hereinto "Telxon" or "Telxon
Corporation" should reflect "Symbol" or "Symbol Technologies, Inc.",
respectively. Any questions, contact your Symbol representative.
©2000 by SymbolTechnologies,Inc. Allrightsreserved.
No part of this publication may be reproduced or used in any form, or by any electrical or
mechanical means, without permission in writing from Symbol. This includes electronic or
mechanical means, such as photocopying, recording, or information storage and retrieval
systems. The material in this manual is subject to change without notice.
Symbol reservestheright tomake changes toany softwareor productto improvereliability,
function, or design.
Symbol does not assume any product liability arising out of, or in connection with, the
application or use of any product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwiseunder any
SymbolTechnologies, Inc., intellectual property rights. An implied license only exists for
equipment, circuits, and subsystems contained in Symbol products.
Symbol is a registered trademark of Symbol Technologies, Inc. Other product names
mentioned in this manual may be trademarks or registered trademarks of their respective
companies and are hereby acknowledged.
SymbolTechnologies, Inc.
One SymbolPlaza
Holtsville, New York 11742-1300
http://www.symbol.com
Symbol Support Center: 1-800-653-5350

SC-960RL/SC-960L
User’s Guide

SC-960RL/SC-960L
User’s Guide
Part Number: 21570-701-04
Release Date: 3/17/97

Telxon is a registered trademark of Telxon
Corporation.
All other product or trade references are either the
trademarks or registered trademarks of their
respective owners and are used for identification.
The information contained in this manual is subject
to change without notice.
Telxon Corporation shall not be liable for technical or
editorial omissions or mistakes in this manual nor
shall it be liable for incidental or consequential
damages resulting from your use of the information
contained in this manual.
This manual is copyrighted. All rights are reserved.
No part of this manual may be photocopied or
reproduced in any form without the prior written
consent of Telxon.
© Copyright 1997 Telxon Corporation
All Rights Reserved.

Contents
Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
General regulations . . . . . . . . . . . . . . . . . . . . . 7
FCC statement . . . . . . . . . . . . . . . . . . . . . 7
DOC statement . . . . . . . . . . . . . . . . . . . . . 7
If your SC-960RL/SC-960L has an internal modem . . . . 8
FCC regulations . . . . . . . . . . . . . . . . . . . . . 8
DOC statement . . . . . . . . . . . . . . . . . . . . . 10
Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Disposing of nickel-cadmium batteries . . . . . . . . . . . 12
Scope of the manual . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Document conventions . . . . . . . . . . . . . . . . . . . 13
Cautions . . . . . . . . . . . . . . . . . . . . . . . . . 13
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Overview of the SC-960RL/SC-960L . . . . . . . . . . . . . . . . . . . . 14
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Unpacking the SC-960RL/SC-960L . . . . . . . . . . . . . 15
Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cradle base . . . . . . . . . . . . . . . . . . . . . . . . . 16
Modem module (optional) . . . . . . . . . . . . . . . . . . 16
Power pack . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4

Installing a single cradle . . . . . . . . . . . . . . . . . . . . . . . . . 20
Mounting the SC-960RL/SC-960L . . . . . . . . . . . . . 20
Mounting to a horizontal surface . . . . . . . . . . . . 21
Mounting to a wall . . . . . . . . . . . . . . . . . . . 22
Connecting to a host computer or external modem . . . . 22
Connecting the internal modem . . . . . . . . . . . . . . . 23
Connecting cradles together . . . . . . . . . . . . . . . . . . . . . . . 25
Inserting and removing a PTC . . . . . . . . . . . . . . . . . . . . . . . 28
Inserting a PTC into the cradle . . . . . . . . . . . . . . . 28
Removing a PTC from the cradle . . . . . . . . . . . . . . 28
Inserting and removing a spare battery pack . . . . . . . . . . . . . . . . 29
Inserting a spare battery pack into the cradle . . . . . . . 29
Removing a spare battery pack from the cradle . . . . . . 29
Charging battery packs . . . . . . . . . . . . . . . . . . . . . . . . . 30
Charging precautions . . . . . . . . . . . . . . . . . . . . 30
The charging process . . . . . . . . . . . . . . . . . . . . 30
Communicating data . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Flashing through the cradle . . . . . . . . . . . . . . . . . . . . . . . 32
Flashing guidelines . . . . . . . . . . . . . . . . . . . . . 32
Maintaining the SC-960RL/SC-960L . . . . . . . . . . . . . . . . . . . . 33
Operating conditions . . . . . . . . . . . . . . . . . . . . . 33
Handling the cradle . . . . . . . . . . . . . . . . . . . . . 33
Cleaning the cradle . . . . . . . . . . . . . . . . . . . . . 33
Storing the cradle . . . . . . . . . . . . . . . . . . . . . . 34
Servicing the cradle . . . . . . . . . . . . . . . . . . . . . 34
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
The cradle fails to communicate with the host computer or
external modem . . . . . . . . . . . . . . . . . . . . . . 35
The PTC fails to communicate through the cradle . . . . . 35
5

The PTC’s battery pack or the spare battery pack fails to
recharge . . . . . . . . . . . . . . . . . . . . . . . . . . 36
The Power LED does not light . . . . . . . . . . . . . . . 36
The PTC bay Charging LED does not light when a PTC
is in the cradle . . . . . . . . . . . . . . . . . . . . . . . 36
The spare battery bay Charging LED does not light
when a spare battery pack is in the cradle . . . . . . . . 37
Other problems . . . . . . . . . . . . . . . . . . . . . . . 37
Appendix A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 38
Communication . . . . . . . . . . . . . . . . . . . . . 38
Electrical . . . . . . . . . . . . . . . . . . . . . . . . 38
Environmental . . . . . . . . . . . . . . . . . . . . . 39
Physical . . . . . . . . . . . . . . . . . . . . . . . . . 39
Appendix B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Accessory part numbers . . . . . . . . . . . . . . . . . . . 40
Appendix C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Communication connections . . . . . . . . . . . . . . . . 41
Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Appendix D . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
LED status indicators . . . . . . . . . . . . . . . . . . . . 49
Power LED . . . . . . . . . . . . . . . . . . . . . . . 49
PTC bay Busy LED . . . . . . . . . . . . . . . . . . . 49
PTC bay Charging LED . . . . . . . . . . . . . . . . . 49
Spare battery bay Charging LED . . . . . . . . . . . 49
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6

Regulations 1
General regulations
FCC statement
This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant
to Part 15 of the Federal Communications
Commission (FCC) rules.These limits are designed
to provide reasonable protection against harmful
interference when the equipment is operated in a
commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and,
if not installed and used in accordance with this
instruction manual, may cause harmful interference
to radio communications. Operation of this equipment
in a residential area is likely to cause harmful
interference,in which case users will be required
to correct the interference at their own expense.
DOC statement
This digital apparatus does not exceed the Class A
limits for radio noise emissions from digital
apparatus as outlined in the Radio Interference
Regulations of the Canadian Department of
Communications (DOC).
This Class A digital apparatus meets all requirements
of the Canadian Interference-causing Equipment
Regulations.
Cet appareil numerique de la classe A respecte toutes
les exigences du Reglement sur le material broilleur
du Canada.
7

If your SC-960RL/SC-960L has an internal
modem
FCC regulations
This device has been granted a registration number
by the FCC, under Part 68 rules and regulations for
direct connection to the telephone lines. In order to
comply with these FCC rules, the following
instructions must be carefully read and applicable
portions followed completely:
1. The FCC has established rules that permit this
device to be directly connected to the telephone
network. Standardized jacks are used for these
connections. This equipment should not be used
on party lines or coin lines.
2. If this device is malfunctioning, it may also be
causing harm to the telephone network; this
device should be disconnected until the source of
the problem can be determined and until repair
has been made. If this is not done, the telephone
company may temporarily disconnect service.
3. The telephone company may make changes in its
technical operations and procedures; if such
changes affect the compatibility or use of this
device, the telephone company is required to give
adequate notice of the changes.
4. If the telephone company requests information on
what equipment is connected to their lines, inform
them of the following:
a. The telephone number this unit is connected
to
b. The ringer equivalence number (REN)
c. The USOC (RJ-11) jack required
d. The FCC registration number
8

Items b, c, and d are indicated on the label. The
REN is used to determine how many devices can
be connected to your telephone line. In most areas,
the sum of the RENs of all devices on any one line
should not exceed five (5.0). If too many devices
are attached, they may not ring properly.
5. In the event of equipment malfunction, all repairs
should be performed by our Company or an
authorized agent. It is the responsibility of users
requiring service to report the need for service to
our Company or to one of our authorized agents.
Service information can be obtained at:
Telxon Corporation
3330 West Market Street
Akron, OH 44334-0582
6. If, through abnormal circumstances, harm to the
telephone lines is caused, the device should be
unplugged until you determine if your device or
the telephone is the source; it should not be
reconnected until necessary repairs are effected.
7. Should the telephone company notify you that
your device is causing harm, the device should
be unplugged. The telephone company will,
where practicable, notify you that temporary
discontinuance of service may be required.
However, where prior notice is not practicable,the
telephone company may temporarily discontinue
service, if such action is reasonably necessary. In
such cases, the telephone company must
a. promptly notify you of such temporary
discontinuance,
b. afford you the opportunity to correct the
condition, and
c. inform you of your rights to bring a complaint
to the FCC under their rules.
9

8. The telephone company may make changes in its
communications facilities, equipment, operations,
or procedures,where such action is reasonably
required in the operation of its business and is not
inconsistent with FCC rules. If such changes can
be reasonably expected to render any customer’s
devices incompatible with telephone company
facilities, or require modification or alteration, or
otherwise materially affect their performance,
written notification must be given to the user to
allow uninterrupted service.
DOC statement
Notice: The Canadian Department of
Communications (DOC) label identifies certified
equipment. This certification means that the
equipment meets certain telecommunications
network protective, operational, and safety
requirements.The Department does not guarantee
the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure
that it is permissible to be connected to the facilities
of the local telecommunications company. The
equipment must also be installed using an acceptable
method of connection. In some cases, the company’s
inside wiring associated with a single line individual
service may be extended by means of a certified
connector assembly (telephone extension cord). The
customer should be aware that compliance with the
above conditions may not prevent degradation of
service in some situations.
Repairs to certified equipment should be made by
Telxon. Any repairs or alterations made by the user to
this equipment, or equipment malfunctions, may give
the telecommunications company cause to request the
user to disconnect the equipment.
10

!Users should not attempt to make
such connections themselves but
should contact the appropriate
electric inspection authority, or
electrician, as appropriate.
Users should ensure for their own protection that the
electrical ground connections of the power utility,
telephone lines, and internal metallic water pipe
system, if present, are connected together. This
precaution may be particularly important in rural
areas.
The load number (LN) assigned to each terminal
device denotes the percentage of the total load to be
connected to a telephone loop, which is used by the
device to prevent overloading. The termination on a
loop may consist of any combination of devices subject
only to the requirement that the total of the load
numbers of all the devices does not exceed 100. An
alphabetic suffix is also specified in the load number
for the appropriate ringing type (A or B), if applicable.
For example, LN = 20 A designates a load number of
20 and an “A” type ringer.
11

Safety information 2
Disposing of nickel-cadmium batteries
The nickel-cadmium batteries that are recharged by
the SC-960RL/SC-960L contain chemically active
materials that are hazardous to the environment;
therefore, they must be disposed of properly. Never
attempt to incinerate a nickel-cadmium battery; doing
so could cause it to explode. Telxon urges you to
contact the Environmental Protection Agency, the
Department of Natural Resources, a local hazardous
waste disposal agency, or the Telxon Customer
Support Center for assistance prior to disposing of
your nickel-cadmium batteries.
12

Scope of the manual 3
This manual provides general information on how to
install, operate, and maintain the SC-960RL and
SC-960L Single-bay Communication Cradles. Use this
manual as an introduction to your cradle along with
the manual or instructions provided by your
supervisor.
This manual does not provide instructions on how
to perform the tasks specific to your job in your
organization. For that information, refer to the
manual or instructions provided by your supervisor.
Document conventions
The following conventions are used throughout this
manual.
Cautions
Cautions indicate potential damage to equipment.
They are set off in the left-hand columns of this
manual by the following symbol: !.
Notes
Notes provide supplementary information. They are
set off in the left-hand columns of this manual and
are not preceded by a symbol.
13

Overview of the SC-960RL/SC-960L 4
The SC-960RL and SC-960L Single-bay
Communication Cradles are accessories for the
PTC-960RL and PTC-960L, respectively. The cradles
work with the PTCs in two ways.
First, the cradle acts as a communication link
between the PTC and a host computer. It can send
data to and receive data from both units. The PTC
and the cradle communicate with each other through
their optical couplers and with the host computer via
a cable or modem.
Second, the cradle automatically charges a PTC’s
nickel-cadmium battery pack and a spare battery
pack when the PTC and spare pack are inserted into
the cradle. It requires approximately 12 hours to
charge both packs (plus the amount of time the PTC
spends communicating with a host computer).
Light-emitting diodes (LEDs) on the cradle’s front
panel indicate power, communication, and battery
charging status.
A modem is an electronic device that
allows the cradle to send and receive
signals over standard telephone lines.
The SC-960RL/SC-960L can be equipped with one of
six country-specific internal modems that provides
one-way or two-way communication.The cradle can
also be connected to an external modem. See
Appendix A for more information about modem
options.
The cradle can be used by itself or can be connected
directly to other SC-960RL/SC-960Ls to form a
system of up to 32 cradles.
14

Getting started 5
Unpacking the SC-960RL/SC-960L
Any additional accessories are
shipped separately. Each shipping box contains
•an SC-960RL or an SC-960L,
•a 12-VDC, 800-mA power pack,
•a cradle base (if your cradle was ordered as a
table-top version),
•an SC-960RL/SC-960L Read-Me-First Sheet,
and
•an SC-960RL/SC-960L User’s Guide.
See Appendices B and Cfor cable
part numbers and information. If you will be connecting the cradle to a host computer,
you need a properly wired cradle-to-host cable,
available separately.
1. Remove the cradle from the box.
2. Remove all packing material from the cradle.
Save the packaging in case the cradle is ever
stored or shipped to Telxon for service.
3. Check the contents of the package to make sure
you have received everything ordered.
If anything is missing or
damaged, notify your Telxon
sales representative.
4. Check the cradle and accessories for shipping
damage.
15

Parts 6
Figures 1 and 2on pages 17 and 18 show and describe
the parts of the SC-960RL/SC-960L. The parts listed
below are not shown in either figure.
Cradle base
A cradle base is shipped with every table-top version
of the SC-960RL or SC-960L. The base holds the
cradle in place on a flat horizontal surface. It can be
permanently mounted through its four mounting
holes.
Modem module (optional)
See Appendix A for a list of available
modem modules. See page 23 for
information on connecting the
internal modem to telephone lines.
The SC-960RL/SC-960L can be equipped with an
internal modem module that provides communication
capability over standard telephone lines between a
PTC installed in the cradle and a host computer.
Either one-way half-duplex or two-way full-duplex
communication is available.
Power pack
The power pack,which provides power to the cradle,
plugs into the cradle’s power connector and into an
electrical outlet (110 volts AC in the U.S. or Canada).
It provides 12 volts of direct current (VDC) at 800
milliamperes (mA).
Each cradle, whether installed individually or as part
of a system of connected cradles, must have its own
power pack.
16

1. This area of the cradle holds a PTC-960RL or a PTC-960L. The bay contains the cradle’s optical coupler and battery charging contacts.
2. This area of the cradle holds a spare nickel-cadmium battery pack. The bay contains battery charging contacts.
3. This female 25-pin connector connects via cable to a host computer or external modem. When cradles are connected together, this connector
(on all cradles in the system except the one in the left-most position) plugs into the daisychain connector of another SC-960RL/SC-960L.
4. These light-emitting diodes indicate power, communication, and battery charging status. See Appendix D for an explanation of the LEDs.
5. This male 25-pin connector plugs into the host connector of another SC-960RL/SC-960L to form a system of daisychained cradles. You
can connect up to 32 cradles in a system.
6. The SC-960RL/SC-960L’s optical coupler provides an optical communication path to and from a PTC residing in the cradle’s PTC bay.
3. Host connector
5. Daisychain connector
4. LEDs
6. Optical coupler (in bottom of PTC bay)
1. PTC bay
2. Spare battery bay
Figure 1. The SC-960RL/SC-960L (front view)
17

* This view of the SC-960RL/SC-960L shows the cradle in its wall-mount configuration.
1. These mounting holes allow table-top versions of the cradle to be secured in a cradle base and wall-mount versions to be mounted on a wall
via a standard telephone wall mounting plate. See Chapter 8 for details.
2. A 12-VDC, 800-mA power pack plugs into this connector and an electrical outlet to supply power to the cradle.
3. Sliding the power pack’s cable under this hook helps to prevent the cable from becoming unplugged.
4. If your SC-960RL/SC-960L was ordered with an internal modem, it will have an RJ-11 jack, a standard modular telephone-type jack. It can be
used to connect the cradle directly to a telephone line.
If your SC-960RL/SC-960L was not ordered with an internal modem, it can be connected to most standard external modems. You will need to
connect a cradle-to-modem cable to the cradle’s host connector and to the connector on the external modem. See Appendix B for cable
part numbers.
2. Power connector
Figure 2. The SC-960RL/SC-960L (back and bottom view)*
1. Mounting holes
3. Power pack cable hook (not pictured)
4. RJ-11 jack (optional)
18
