Symmetry Switchback Series User manual

#2 Phillips Screwdriver or Bit Cordless Drill/Driver
M10x16mm Screw
S-B
M5x20mm Screw
S-A
M4x22mm Screw
S-C
B(x2)
D(x2)
C(x4)
A(x1)
No. C6264 Rev. B
Date: 2/19/2020
IMPORTANT: PLEASE READ ALL INSTRUCTIONS BEFORE STARTING ASSEMBLY.
For more information, visit www.symmetryoffice.com.
To report any issues with this product, please contact our customer service department at [phone].
REQUIRED TOOLS
FINAL ASSEMBLY EXAMPLE
COMPONENTS
S-B
(x8)
S-A
(x18)
S-C
(x2)
E(x1)
5mm Allen Key
1:1 SCALE
SWITCHBACK 2-LEG 3-STAGE ASSEMBLY INSTRUCTIONS
S-B (Alternate)
(x8)
M10x30mm Screw
S-B (Alternate)
E-A(x1)
6mm Allen Key
(Alt - only for specific models)

For more information, visit www.symmetryoffice.com.
To report any issues with this product, please contact our customer service department at [phone].
1
1. Rotate the columns into upright position.
2. Install end pipes into columns.
3. Tighten the 4 bolts (already in place) on each side that secure the motor
housing for each of the columns using the Allen wrench provided.
SWITCHBACK 2-LEG 3-STAGE ASSEMBLY INSTRUCTIONS
A
E
B
2
1
3

1. Install table feet using 4 screws per leg (M10x16mm) with provided Allen
key.
C-Leg
1
For more information, visit www.symmetryoffice.com.
To report any issues with this product, please contact our customer service department at [phone].
2
SWITCHBACK 2-LEG 3-STAGE ASSEMBLY INSTRUCTIONS
T-Leg
Note: For C-Leg make sure the end pipes and feet are extended in the same direction.
30", C-Leg
Alternate Design
S-B
(Alternate)
S-BS-B

1. Place the frame assembly onto the underside of the table top. Extend
the frame to the desired length (This may require loosening of set screws
in base assembly using the provided Allen wrench). Once the legs are
located, center the U-Pipe and tighten the set screws as shown in the
illustration.
2. Connect the handset to the control box. Tuck the control box cord
through the frame notch. Note: This must be done before securing base to top.
For more information, visit www.symmetryoffice.com.
To report any issues with this product, please contact our customer service department at [phone].
3
SWITCHBACK 2-LEG 3-STAGE ASSEMBLY INSTRUCTIONS
E
1 2
1
2

1. Attach the frame assembly to the top using supplied wood screws.
2. Attach the handset to the front of the top with the two smaller wood
screws provided.
3. Attach power cord. Tuck all excess cords in the frame.
1
For more information, visit www.symmetryoffice.com.
To report any issues with this product, please contact our customer service department at [phone].
4
SWITCHBACK 2-LEG 3-STAGE ASSEMBLY INSTRUCTIONS
S-C
2
1
3
SIZE
24” 16
24
18
1830”
C-Leg T-Leg

1. Flip the table to the normal position and reset it before the first use.
1
1
For more information, visit www.symmetryoffice.com.
To report any issues with this product, please contact our customer service department at [phone].
5
SWITCHBACK 2-LEG 3-STAGE ASSEMBLY INSTRUCTIONS
Resetting the table:
Press and hold the up and down buttons at the same time for 3 seconds. Continue pressing until
the columns are in the lowest position. When finished resetting, the control box will make a sound
and the buttons can be released. Now the system is operational.
