Symmons Degas 543TB-18 Manual

543RH, 543TB-18, 543TB-24, 543TP, 543TR
Degas®Accessories
Operation & Maintenance Manual
Model Numbers Specifications
543RH Robe Hook
543TB-18 18" Towel Bar
543TB-24 24" Towel Bar
543TP Toilet Paper Holder
543TR Towel Ring
All premium accessories made from brass plated in
standard polished chrome nish.
Modifications Warranty
-ORB Oil rubbed bronze finish
-STN Satin nickel finish
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Note: Append appropriate -sufx to model number.
WARNING: This product can expose you to chemicals
including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.

2
Dimensions
Measurements
A 1 7/8", 48 mm
B 1 5/8", 41 mm
C 3 3/16", 81 mm
D 6 9/16", 167 mm
E 4 5/8", 118 mm
F 7 3/8", 187 mm
G 4 7/8", 124 mm
H 18", 457 mm
I 19 3/4", 502 mm
J 24", 610 mm
K 25 3/4", 654 mm
Required for Installation
Allen wrench
(3/16")
Phillips head
screwdriver
Power drill
Note: Dimensions are subject to change without notice.
543RH
543TB-18
543TB-24
543TPL
543TR
GG
H
H
I
I
J
J
K
K
D
D
E
E
B
B
B
B
B
B
A
A
C
C
F
F
C
C
C
C
C
C
C
C
543TPR
GG
F
FC
C
Replacement Parts
Description Part Number
Mounting
Hardware Kit
Less Bracket
RA-017
Mounting
Hardware Kit
With Bracket
RA-019

Installation
Symmons Industries, Inc. ■31 Brooks Drive, Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3095 REV A ■ 080118
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
1) Measure and mark centerlines
for mounting bracket installation
using dimensions on page 2.
Notes: 543TB-18 and 543TB-24
only. Make sure both centerline
marks are level.
2a) Dry Wall Option: Place
mounting brackets into desired
position. Using brackets as a
guide, mark holes. Screw tile
anchors into wall.
2b) Stud Option: Place mounting
brackets into desired position.
Using brackets as a guide,
carefully drill 3/16" holes
into wall.
3) With mounting brackets in
position, secure to wall using
screws.
4) Hang top of accessory on
mounting bracket. Lower into
position.
5) Secure with set screw.
1
2
1
2
1
2
1
3
3
2
