Symmons Unity SLS-6612 Series Reference guide

Step 2
Connect supply hoses
HOT COLD
Step 3
Flush lines and
check for leaks
Step 1
Attach faucet assembly
Optional
Adjust limit stop washer
to limit handle turn to the
hot position if desirable
Quick Install Guide Lavatory Faucet, SLS-6612 Series
HOT COLD
ON
OFF
+
-
2.5 mm
PLUMBERS
PUTTY
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
Model Numbers
SLS-6612 Lavatory faucet only
Decorative Finishes
Append finish suffix code to
replacement part numbers when
applicable
-Polished chrome (standard)
Model SLS-6612
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer,
birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
 Need Help?
Contact Symmons customer service at
P: [phone], F: [phone]
Email: [email protected]
Monday - Friday 7:30 am - 6:00 pm EST
Please check Symmons website
for technical help, the latest product
information and warranty policy.
www.symmons.com/service
Tools & Materials
Installation Brief
Unity®
Lavatory Faucet
SLS-6612 Series

Dimensions Unity Lavatory Faucet, SLS-6612 Series
Symmons Industries, Inc. ■ 31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2020 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-1039 REV P ■011320
handle
set screw
plug
cartridge
ow restrictor,
with housing
mounting hardware kit
Replacement Parts
PART NUMBER DESCRIPTION
LN-06099 HANDLE, WITH SET SCREW AND PLUG
LN-06100 CARTRIDGE, 25 MM
LN-06101 MOUNTING HARDWARE KIT
LN-06102 KIT, HOT AND COLD HOSE
FLR-06103 FLOW RESTRICTOR, WITH HOUSING
length: 27-1/2" (700 mm)
COLD: blue stripe
HOT: red stripe
3/8" compression
2.5 mm wrench
included
