Elm™Tub/Hand Shower Trim
Operation & Maintenance Manual
Operation
Temperature Control Diverter Control
1) Turn shower handle counterclockwise approximately
1/4 turn to put valve in cold position.
2) Turn shower handle counterclockwise approximately
1/2 turn to put valve in warm position.
3) Turn shower handle counterclockwise approximately
3/4 turn to put valve in hot position .
1) Turn diverter lever left for tub spout operation.
2) Turn diverter lever right for hand shower operation.

7Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■www.symmons.com ■[email protected] ■ZV-3029 REV A 082114
S-5504-TRM
Elm™Tub/Hand Shower Trim
Operation & Maintenance Manual
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
