Synergy N7 User manual

Congratulations on your purchase of the Synergy N7 radio controlled helicopter kit. The Synergy N7 was
designed and developed by Botos Design & Distribution Inc.. The design of the Synergy N7 emerged from
many years of experience in the hobby including design, research & development, and last but not least
as a world class pilot who truly enjoys this wonderful hobby.
This radio controlled helicopter is NOT A TOY. It is a sophisticated piece of equipment, it was designed
and intended for hobby use only. If not properly assembled, maintained, and operated, it is capable of
causing property damage and bodily harm to both the operator and/or spectators. Botos Design &
Distribution Inc., its affiliates, and its authorized distributors assume no liability for damage that could occur
from the assembly or use/misuse of this product. If you are new to the hobby we strongly recommend
seeking the help and advice from an experienced modeler.
Operating a model helicopter requires a high degree of diligence and skill. If you are new to the hobby, it
is best to seek help and guidance from experienced radio controlled helicopter pilots. This will both greatly
speed up the learning process and make it much safer for you.
For those pilots who will be operating their Synergy N7 in the United States, we strongly recommend
joining the AMA. The AMA is a non-profit organization that provides services to the model aircraft pilots. As
an AMA member, you will receive a monthly magazine entitled Model Aviation and most importantly a
liability insurance plan to cover against a possible accident or injury. All AMA charter aircraft clubs require
individuals to hold a current AMA sporting license prior to operation of their models
For further information, you can contact the AMA at
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302
[phone]

Fuel Tank Assembly
200-414 Vent Assembly
110-332 Fuel Clunk
110-333 Fuel Clunk Tubing
106-810 Fuel Tank Stopper Grommet
110-331 Fuel Tank Stopper
317-600 N7 Fuel Tank
Note - Sealant may be required on
fuel tank vent assembly threads. Any
sealant which does not break down
when exposed to nitro fuels may be used.
Page 1
WWW.SYNERGYRCHELICOPTERS.COM

Page 2
Landing Gear Assembly
Complete Landing Gear
101-308 M3x8 Button Head
610-324 Landing Gear Strut
610-322 Skid Tube Lock x4
610-321 Skid Tube
106-966 Skid Tube Plug x4
WWW.SYNERGYRCHELICOPTERS.COM

317-206 Hex Adapter
108-615 6x15x5 Bearing
317-207 Start Shaft Support Bearing Block
100-464 M4x4 Flat Point Set Screw
317-203 Pinion Nut (DO NOT OVER TIGHTEN)
108-105 10x19x5 Bearing
317-202 Clutch Stack Bearing Block
109-103 10x14x3 Brass Spacer
108-105 10x19x5 Bearing
317-017 N7 Helical Pinion(Factory Installed)
610-125 Clutch Bell
108-614 6x12x4 Bearing
317-205 N7 Clutch Liner (Factory Installed)
317-204 N7 Start Shaft
100-266 M2.5x6 Socket Head
NOTE - Ensure set screw meets flat spot
on start shaft.
Upper Clutch Stack Assembly
Page 3
WWW.SYNERGYRCHELICOPTERS.COM

108-102 10x14x12 One Way, Clutch(Factory Installed 200-501)
200-501 Clutch Assembly
100-410 M4x10
101-306 M3x6 Button Head
110-170 Cooling Fan
317-200 N7 Fan Hub
100-312 M3x12 Socket Head(Loctite not required on pinch bolts)
Engine Washer (Included with Engine)
NOTE - Engine washer must be used for
correct spacing!
Fan Hub install note- Important!
1. Slide Fan Hub on to crank shaft then take up
end play with engine nut.(engine washer manditory!)
2. Tighten down pinch bolts evenly.
3. Insert crank locking tool (not included) and
finish tightening engine nut. Do not over tighten
crank shaft nut, only snug! It is possible to distort
fan hub by over tightening.
Crank Nut (Included with Engine)
O.S. Engine 1.05
Engine/Clutch Assembly
N7 Tested with *-
- OS 1.05
- OS .91
(multiple versions)
- YS .91
*Other motors may have high
vibration levels or may not run
properly. Please use only motors
that have been tested by Synergy.
One-Way Clutch -IMPORTANT!-
If operating in temperatures below 50F, remove grease
from 10x14x12 One way. Grease will cause the rollers to
stick in the outward position.
Page 4
WWW.SYNERGYRCHELICOPTERS.COM

317-403 Fan Shroud Spacer
317-403 Fan Shroud Spacer
100-376 M3x16 Set Screw
100-212 M2x12 Socket Head
106-326 26mm Hex Standoff
100-376 M3x16 Set Screw
100-212 M2x12 Socket Head
100-326 26mm Hex Standoff
317-403 Fan Shroud Spacer
317-403 Fan Shroud Spacer
NEVER APPLY LOCTITE TO BOLTS
SECURING INTO PLASTIC!!!
100-376 M3x16 Set Screw
100-376 M3x16 Set Screw
110-342 Fan Shroud Right
110-343 Fan Shroud Left
Important!
The included fan shroud will work with every
motor on the market as of 2013. However in
order to accommodate all of these motors,
the fan shroud will require modifications based
on your motor selection and muffler selection.
Fan Shroud Installation
DO NOT OVER TIGHTEN M2x12 BOLTS.
THESE ARE IN PLASTIC!
Page 5
WWW.SYNERGYRCHELICOPTERS.COM

103-256 M2.5x6 Cross Recess
310-104 Sensor Mount Plate
310-110 Frame Spacer
Gyro Mount Plate Assembly
Page 6
WWW.SYNERGYRCHELICOPTERS.COM

310-105 CF Lower Frame Brace
310-110 Frame Spacer
103-256 M2.5x6 Cross Recess
Rear Frame Brace Assembly
Page 7
WWW.SYNERGYRCHELICOPTERS.COM

100-206 M2.5x6 Cross Recess
310-110 Frame Spacer
317-103 CF Radio Plate
Radio Plate Assembly
Tip - Sanding carbon edges to
prior to assembly will prevent
wire chafing.
Page 8
WWW.SYNERGYRCHELICOPTERS.COM

317-503 N7 Auto Hub Sleeve
317-505 N7 Auto Hub Delrin Shim
108-166 16x22x16 One-Way Bearing, Auto Hub
317-502 N7 Bronze Bushing
200-415 N7 Auto Hub Assembly
Includes -
317-501 Auto Hub (not sold separately) •
108-166 16x22x16 One-Way Bearing •
610-153 N7 Bronze Bushings •
317-502 N7 Bronze Bushing
317-139 139T Helical Main Gear
101-308 M3x8 Button Head
317-505 N7 Auto Hub Delrin Shim
103-256 M2.5x6 Cross Recess
320-154 54T Spur Gear
317-500 N7 Spur Gear Hub
Important - Bronze bushings
must be secured with green
or red loctite!
Main Transmission Assembly
DO NOT OVER TIGHTEN!
DO NOT OVER TIGHTEN!
IMPORTANT!
Do not use grease for one way clutch lubrication!
Use light oil such as Triflow.
Page 9
WWW.SYNERGYRCHELICOPTERS.COM

Front Tail Transmission Assembly
108-124 12x18x4 Radial Bearing
320-301 Front Mushroom Gear Bearing Block
320-218 18T Front Trans Mushroom Gear
100-351 M3 Nylock Nut
100-372 M3x12 Set Screw
100-354 M3 Washer
108-510 5x10x4 Radial Bearing
320-302 Bevel Gear Top Bearing Block
320-406 11mm Pin for 18T Bevel Gear
320-303 Spur Gear Bottom Bearing Block
108-593 5x9x3 Radial Bearing
320-408 Spur Gear Shaft
320-111H 11T Hard Coat Spur Gear
320-407 2mm Spur Gear Pin
320-101 TranSupport CF Plate
320-103 TranSupport Standoff
101-306 M3x6 Button Head x12
100-372 M3x12 Set Screw
Important! - TIghten and
secure set screw with loctite.
This set screw secures bevel
gear pin.
Page 10
320-118 Front Trans Bevel Gear
IMPORTANT! - Any screw which is metal to metal needs loctite! Clean oil from bolts and apply blue loctite.

101-306 M3x6 Button Head
310-111 Main Boom Clamp
310-111 Main Boom Clamp
317-104 N7 CF Lateral Frame Brace
100-310 M3x10 Socket Head
Main Boom Clamp Assembly
Do not tighten boom pinch bolts yet!
Pinch bolts do not apply loctite!
Page 11
WWW.SYNERGYRCHELICOPTERS.COM

100-316 M3x16 Socket Head
108-373 3x7x3 Radial
107-106 Pivot Ball
107-106 Pivot Ball
108-373 3x7x3 Radial
106-301 M3 Shim
317-301 Tail Offset Bell Crank Mount
109-352 3x5x2 Brass Spacer
317-300 Tail Offset Bell Crank
Tail Offset Bell Crank Assembly
Page 12
WWW.SYNERGYRCHELICOPTERS.COM

Main Shaft Bearing Blocks
Page 13
108-105 10x19x5 Radial Bearing
108-105 10x19x5 Radial Bearing
310-150 Main Shaft Bearing Block E6/7
310-151 Third Main Shaft Bearing Block
Important - Keep this orientation
in mind for future reference. Make
sure bearing block and bearing
orientation is correct. Top bearing
is facing up, middle beaing is facing
down, lower bearing is facing up.
WWW.SYNERGYRCHELICOPTERS.COM

Right Frame Assembly Step 1
100-308 M3x8 Socket Head
100-308 M3x8 Socket Head
100-306 M3x6 Socket Head
101-408 M4x8 Button Head
305-121 Key Chain Canopy Mount, Female 21mm
100-372 M3x12 Set Screw
317-102 Front Frame Doubler
310-110 Frame Spacer
317-400 4mm Frame Spacer
317-400 4mm Frame Spacer
317-101 N7 Rear CF Frame
317-100 N7 Front CF Frame
101-408 M4x8 Button Head
Completed View
DO NOT FULLY TIGHTEN BOLTS! FRAMES MUST BE SQUARED IN FUTURE STEP!
Page 14
WWW.SYNERGYRCHELICOPTERS.COM

Right Frame Assembly Step 2
610-123 Standard Servo Mount
100-212 M2x12 Socket Head
106-115 Servo Hold Down
100-206 M2x6 Socket Head
Page 15
WWW.SYNERGYRCHELICOPTERS.COM

101-306 M3x6 Button Head
100-306 M3x6 Socket Head
Right Frame Assembly Step 3
Page 16
WWW.SYNERGYRCHELICOPTERS.COM

Right Frame Assembly Step 4
101-306 M3x6 Button Head
Important!
Frame is slotted to allow for two
different tail gear ratios!
11T(4.9:1) Slide Fore (Stock Ratio)
12T(4.5:1) Slide Aft (Optional Ratio)
Page 17
WWW.SYNERGYRCHELICOPTERS.COM

610-123 Standard Servo Mount
100-212 M2x12 Socket Head
106-115 Servo Hold Down
100-206 M2x6 Socket Head
Standard size throttle servo
Please choose throttle servo that is same
speed or faster than your cyclic servos.
Not Included
317-100 N7 Front CF Frame
Left Front Frame and Throttle Servo Assembly
Page 18
