Synology RackStation RS2414+/RS2414RP+
Quick Installation Guide

2
Table of Contents
Chapter 1: Before You Start
Package Contents............................................................................................................................................... 3
Synology RackStation at a Glance...................................................................................................................... 4
Safety Instructions............................................................................................................................................... 6
Chapter 2: Hardware Setup
Tools and Parts for Hard Disk Installation........................................................................................................... 7
Install Hard Disks ................................................................................................................................................ 7
Add a RAM Module on RackStation.................................................................................................................... 9
Replace a Malfunctioning Fan........................................................................................................................... 12
Start Up Your RackStation ................................................................................................................................ 14
Chapter 3: Install DSM on RackStation
Install DSM with Web Assistant......................................................................................................................... 15
Learn More........................................................................................................................................................ 16
Appendix A: Specifications
Appendix B: LED Indication Table

3
Chapter
1
Chapter 1: Before You Start
Thank you for purchasing this Synology product! Before setting up your new RackStation, please check the
package contents to verify that you have received the items below. Also, make sure to read the safety
instructions carefully to avoid harming yourself or damaging your RackStation.
Package Contents
Main unit x 1 AC power cord x 11
Screws for 3.5" hard drives x 52
Screws for 2.5" hard drives x 52
---------
1AC power cord: RS2414+ x 1; RS2414RP+ x 2

4 Chapter 1: Before You Start
Synology RackStation at a Glance
No. Article Name Location Description
1) Power Button
Front Panel
1.Press to power on the RackStation.
2.To power off the RackStation, press and hold until you hear a beep
sound and the Power LED starts blinking.
2) LED Indicators Displays the status of internal disks and the system. For more
information, see "Appendix B: LED Indication Table".
3) Beep off Button Press to deactivate beep sound when malfunctions occur.
4) Hard Drive Trays Install hard disks here
5) Power Supply On/Off
Switch
Back Panel
Press to turn on/off the power supply.
6) Power Port Connect power cords here to supply power to your RackStation.
7) Fan Disposes of excessive heat and cools the system. If a fan malfunctions,
the RackStation will emit a beeping sound.
8) Console Port For manufacturing use only
9) USB 3.0 Ports Connect external hard drives, USB printers, or other USB devices to your
Synology RackStation here.
10) USB 2.0 Ports
11) LAN Ports For connecting RJ-45 cables to your Synology RackStation.
12) RESET Button
1.Press and hold until you hear a beep sound to restore the default IP
address, DNS server, and passwords for users belonging to the
administrators group.
2.Press and hold until you hear a beep sound, then press and hold again
until you hear three beep sounds to return the RackStation to “Not
Installed” status so that DiskStation Manager can be reinstalled.

5 Chapter 1: Before You Start
No.
Article Name
Location
Description
13) Expansion Port
Back Panel
Connect Synology Expansion Units1
14)
to your Synology RackStation.
Power Supply
Safety Latch Secures the power supply in place.
15) Power Supply
Beep Off Button Press to deactivate beep sound when malfunctions occur.
16) Redundant Power LED Displays status of redundant powers supplies, alerting the user of power
supply or fan failure.
---------
1For more information about Synology Expansion Unit supported by your RackStation, visit www.synology.com.

6 Chapter 1: Before You Start
Safety Instructions
Keep away from direct sunlight and away from chemicals.
Make sure the environment does not
experience abrupt changes in temperature or humidity.
Do not place near any liquids.
Before cleaning, unplug the power cord. Wipe with damp paper towels. Do not use chemical or
aerosol cleaners.
To prevent the unit from falling over, do not place on carts or any unstable surfaces.
The power cord must plug in to the correct
supply voltage. Make sure that the supplied AC
voltage is correct and stable.
To remove all electrical current from the device, ensure
that all power cords are disconnected
from the power source.
Risk of explosion if battery is replaced with an incorrect type. Dispose of used batteries
appropriately.

7
Chapter
2
Chapter 2: Hardware Setup
Tools and Parts for Hard Disk Installation
A screwdriver
At least one 3.5” or 2.5” SATA hard disk (please visit www.synology.com for compatible hard disk models.)
Warning: If you install a hard disk that already contains data, the system will format the hard disk and erase all data.
If you still need the data, please back it up before installation.
Install Hard Disks
Please follow the steps below to install hard disks.
1 Find the small button located on the hard drive tray handle. Press the button down and pull the hard drive tray
handle out as illustrated below.
2 Remove the hard drive tray and place the hard disk in as follows:
For 3.5” Hard Disks: Place the hard disk in the hard drive tray. Turn the tray upside down and tighten
screws into the four spots indicated below to secure the hard disk.

8 Chapter 2: Hardware Setup
For 2.5” Hard Disks: Place the hard disk in the hard drive tray. Turn the tray upside down and tighten
screws into the four spots indicated below to secure the hard disk.
3 After securing the hard disk and tray, insert the loaded hard drive tray into the empty hard drive bay.
Important: Make sure the hard drive tray is completely inserted. Otherwise, the hard disk might not function
properly.
4 Push the handle to secure the hard drive tray.
5 Repeat the steps above to install all prepared hard disks.
6 Hard disk positions are numbered as shown below.
Note: If you want to set up a RAID configuration, we recommended all installed hard disks be the same size in
order to optimize hard disk capacity usage.

9 Chapter 2: Hardware Setup
Add a RAM Module on RackStation
Synology offers 2GB RAM modules which allow you to expand the memory capacity of your RackStation. To
install, check, or remove your RAM module, please follow the steps below.
Install a RAM Module
1 Shut down your RackStation, and disconnect all connected cables to prevent any possible damage.
Important: Before installing the RAM module, please wait for at least 30 seconds after detaching the power
cord(s) from the RackStation to ensure complete discharge. Also, please remove any static electricity before
installation by touching water pipes, a metal conduit, or another person to get rid of excess charge and avoid
damaging the motherboard, peripherals, and other components.
2 Slide the latches on the sides and lift to remove the fan cover from your RackStation.
3 To remove the screws securing the top cover, follow the steps below:
a Remove the two screws illustrated below.

10 Chapter 2: Hardware Setup
b Remove the two screws located on the back of your RackStation. Then slide the top cover in the direction
indicated below and lift.
Important: Removing the cover will expose sensitive internal components to possible harm. Please avoid touching
any other components when adding or removing memory.
4 To insert the new memory module, follow the steps below:
a Align the notch on the gold edge of the module with the notch in the memory slot.
b Use two fingers to apply firm, even pressure and push the memory module downward.
c When the memory is inserted correctly, the ejectors will snap into place.
5 Replace the top cover, slide it into place, and tighten the two screws on the back of your RackStation.
