Topvex SC03-11
Compact Air Handling Unit
Operation and Maintenance Instructions GB

151624 | A002
© Copyright Systemair AB
All rights reserved
E&OE
Systemair AB reserves the rights to alter their products without notice.
This also applies to products already ordered, as long as it does not affect the previously agreed specifications.

151624 | A002
Contents
1 Warnings.......................................................1
2 Product description..........................................2
2.1 Internal components ...............................2
2.2 Description of internal components ............3
2.2.1 Supply and extract air
fans ........................................3
2.2.2 Pressure sensor fans/
filters.......................................3
2.2.3 Supply and extract air
filters.......................................3
2.2.4 Heat exchanger .........................3
2.2.5 Dampers ..................................3
2.2.6 Switch module...........................3
2.2.7 Temperature sensor....................3
2.2.8 Water heating battery .................3
2.2.9 Electrical heater .........................4
2.3 Internal components electrical
connection box ......................................5
2.4 Free cooling description .... ... ... ... ... .... ... ... .6
3 Defrost function . ... .... .... ... .... ... .... ... .... .... ... .... ..7
4 Maintenance .. ... ... ...... ... ... ... .... ... ... ...... ... ... ... ..7
4.1 Important .............................................7
4.2 Maintenance intervals .............................7
4.3 Maintenance instructions .........................8
4.3.1 Changing supply/extract air
filter........................................8
4.3.2 Checking the heat
exchanger ................................9
4.3.3 Checking the fans..................... 10
4.3.4 Checking the hot water
heating battery........................ 11
4.3.5 Checking the electrical heating
battery .................................. 11
4.3.6 Cleaning the extract louvres
and inlet diffusers..................... 11
4.3.7 Checking the outdoor air
intake .. ... ...... ... .................. ... . 12
4.3.8 Checking the duct
system .................................. 12
4.3.9 Changing the internal
battery .................................. 12
5 Troubleshooting............................................ 13
6 Service .......................................................13

Warnings |1
1 Warnings
The following admonitions will be presented in the different sections of the document:
Danger
• Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or
serious injury.
Warning
• Indicates a potentially hazardous situation that may result in minor or moderate injuries.
Caution
• Indicates a risk of damaging the product or prevent optimal operation.
Important
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
151624 | A002

2| Product description
2 Product description
2.1 Internal components
Fig. 1 Internal components with air connections symbols (Drawn as a right hand unit)
Position Description Symbol
AConnection supply air
BConnection exhaust air
CConnection outdoor air
D Connection extract air
1Fan supply air
2 Fan extract air
3Filter supply air
4Filter extract air
5Heat exchanger
6Electric compartment
7Damper bypass extract air
8Damper bypass outdoor air
9Damper bypass heat exchanger
10 Pressure sensor extract air filter/extract air fan
11 Pressure sensor supply air fan/supply air filter
12 Pressure sensor defrosting exchanger
13 Extract air sensor
14 Outdoor air sensor
15 Efficiency temperature sensor
16 Air flow sensor
1
1Only valid for units with electrical re-heater battery
151624 | A002

Product description | 3
2.2 Description of internal components
2.2.1 Supply and extract air fans
The fans have external rotor motors of EC type which are steplessly controlled individually by setting the control signal
to a fixed value. It is possible to program the speed in 2 steps (normal/reduced) depending on the programming of the
week schedule. The motor bearings are life time lubricated and maintenance free. It is possible to remove the fans for
cleaning, see chapter 4 for more information.
2.2.2 Pressure sensor fans/filters
Two pressure sensors are installed (figure 1), each of the sensors has two functions. One function is to measure the dif-
ferential pressure over the inlet cone of the fan impellers to maintain the airflow at constant level (CAV function as
standard). The other function, is to measure the differential pressure over the supply and extract air filters so that when
the pressure drop reaches the set value, an alarm is triggered in the main regulator, which indicates that the filter needs
to be replaced.
2.2.3 Supply and extract air filters
The filters are of bag filter type with filter quality ePM1 60% (F7) for the supply air filter and ePM10 60% (M5) for the
extract air filter. The filters need to be replaced when polluted. New sets of filters can be acquired from your installer or
wholesaler.
2.2.4 Heat exchanger
Topvex SC03-11 models are equipped with a highly efficient, counterflow heat exchanger. Required supply air temper-
ature is therefore normally maintained without adding additional heat. The operation of the heat exchanger is auto-
matic and depends on the set temperature.
The heat exchanger is removable for cleaning and maintenance, see chapter 4 for more information.
For defrosting a pressure transmitter is installed which measure the differential pressure over the heat exchanger.
2.2.5 Dampers
For extract air and outdoor air the unit has double by-pass damper for low internal pressure drop. Topvex SC is also
equipped with a shut off damper to the heat exchanger when no heat demand is required. The damper closes when
the extract/exhaust air by-pass dampers opens.
2.2.6 Switch module
A switch module with HMI and 2 TCP/IP connections is mounted in the heat recovery units. Connection is made through
the panel outlet in the air handling unit (see figure 3).
Note:
24V HMI connection dedicated for the display. The connection is only for HMI and no other
connections is permitted.
2.2.7 Temperature sensor
4 temperature sensors (PT1000) are included in the unit from factory. The sensors are as follows:
• Supply air sensor
• Extract air temperature sensor
• Outdoor air temperature sensor
• Efficiency temperature sensor
The supply air sensor is loosely delivered with the unit and needs to be installed in the supply air duct externally from
the unit. See Installation instructions for more information.
2.2.8 Water heating battery
In units with built in water heating battery the hot water coil is located next to the supply air connection. The hot water
coil can be either HWL (hot water coil, low power) or HWH (hot water coil, high power). The coil material is copper
151624 | A002

4| Product description
piping with a frame of galvanized sheet steel and aluminium fins. The coil is equipped with venting and immersion sen-
sor for frost protection.
2.2.9 Electrical heater
In units with built in electrical heater the heating rods are located after the supply air fan in the airflow direction. The
material is stainless steel. The electric heating coil has both automatic and manual overheating protection. The manual
overheat protection is reset by pushing the red button on the side of the electrical heater frame (figure 2). The power
demand of the electric heating coil is controlled by the main regulator, which controls the heat steplessly by a TTC triac
control according to the desired supply/extract or room air temperature that is set in the control panel.
Danger
• Make sure that the mains power supply to the unit is disconnected before performing any maintenance
or electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Fig. 2 Reset of the manual over heat protection in Topvex SC03-11.
151624 | A002

Product description | 5
2.3 Internal components electrical connection box
Danger
• Make sure that the mains power supply to the unit is disconnected before performing any maintenance
or electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Topvex SC03-11 are equipped with a built in regulator and internal wiring (figure 3).
The figure shows the electrical connection box for the Topvex SC03-11 units.
Fig. 3 Electric components
Position Description
1Control unit CU283W-4
2Transformer 230/24V AC
3Terminals for internal and external components
4Terminals for internal wiring
5Terminals for mains power supply to the unit
6Contactor (K1)
7Contactor (K2) On/Off Pump control water (HW units only, not present
in EL-units)
8Automatic fuse
9Automatic fuse for heater
10 Contactor (K3) EL heater
11 TTC El heater control
12 Switch module
13 Panel outlet
151624 | A002

6| Product description
2.4 Free cooling description
This function is used during the warm period to save energy by using cold outdoor air, e.g. during night time, to cool
down the building and thereby reducing the need for cooling during the day time.
Note:
The following is only valid if the free cooling function is activated in the program menu.
Free cooling is only activated when the following starting conditions are met.
Starting conditions:
• Less than 4 days have passed since the unit was last in running mode
• The outdoor temperature during the previous running period exceeded a set limit (+22°C)
• It is between 00:00 and 07:00:00 in the day (settable)
• The timer outputs for normal speed, Extended running normal and External stop are Off
• A time channel will be On sometime during the recently started 24 hours.
The unit checks the night temperature (indoor and outdoor temperature) during 3 minutes at the set starting hour when
the fans are started so that the sensors can perform a temperature measurement. If above conditions are met the free
cooling function is started, if not the unit goes back to OFF position.
If the outdoor sensor is not located in the outdoor air inlet duct and a room sensor has been selected, the unit will not
start free cooling as long as all the temperatures are not within the start and stop temperature intervals.
Stop conditions:
• Outdoor temp above the set max value (+18°C) or below the set min value (condensation risk, +10°C)
• The room temp/extract air temp is below the set stop value (+18°C)
• One of the timer outputs for normal speed, External stop or Extended running normal is On
• The time has past 07:00:00.
If any stop conditions is fulfilled after three minutes, the unit will stop again. Otherwise, operation will continue until a
stop condition is fulfilled.
When free cooling is active, the fans run at normal speed or the set value for pressure/flow control and the digital out-
put free cooling is active. The outputs block heating, cooling and heat exchanger. After free cooling has been activated,
the heating output is blocked for 60 minutes (configurable time). When using free cooling, an offset to normal fan con-
trol setpoint is adjustable.
151624 | A002

Defrost function | 7
3 Defrost function
By measuring the pressure difference over the exchangers extract/exhaust side the need for defrosting can be de-
tected. The differential pressure transmitter is auto calibrated by the system to obtain the correct pressure in relation to
the airflow. Manual calibration is possible, e. g. after cleaning of exchanger. Defrosting is possible with by-pass or stop
defrosting, adjustable in the display.
Defrosting is stopped when the desired, adjustable decrease in pressure over the heat exchanger is obtained. If the de-
crease of pressure does not happens during defrost cycle, the air handling unit is stopped and an alarm is shown in the
display.
4 Maintenance
4.1 Important
Danger
• Make sure that the mains power supply to the unit is disconnected before performing any maintenance
or electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Warning
• Although the mains power supply to the unit has been disconnected there is still risk for injury due to
rotating parts that have not come to a complete standstill.
• Beware of sharp edges during mounting and maintenance. Use protective clothing.
4.2 Maintenance intervals
The table below shows recommended maintenance intervals for the unit and the installation. To ensure a long opera-
tion lifetime for the unit it is important to perform maintenance according to below recommendations and that they are
performed according to the operation and maintenance instructions. A thorough and recurrent maintenance is a must
for a valid guarantee.
Type of maintenance Once a year When necessary
Cleaning the heat exchanger. X
Cleaning the fans. X
Cleaning extract louvres and supply
air diffusers.
X
Cleaning the outdoor air intake. X
Cleaning the duct system. X1
1Or in accordance with local rules and regulations
151624 | A002

8|Maintenance
4.3 Maintenance instructions
4.3.1 Changing supply/extract air filter
The bag filter cannot be cleaned and must be changed when necessary. New filters can be ordered from Systemair. Op-
eration time between filter changes depends on the air pollution at the installation site. A differential pressure switch
indicates when it’s time to change the filters. This will trigger an alarm in the control panel.
When this occurs do the following:
1. Replace the filters with new ones as described infigure 4.
2. Press on the alarm symbol
on the control panel.
3. Choose Filter alarm and press acknowledge.
See enclosed “Quick Guide NaviPad” for more information.
Fig. 4 Changing filters
151624 | A002

Maintenance |9
4.3.2 Checking the heat exchanger
After a long time of use dust may build up in the exchanger and block the airflow. It is important to clean the exchanger
regularly (once a year) to maintain high efficiency. The heat exchanger can be taken out of the unit for maintenance.
Wash in hot soapy water or use pressure air. Do not use detergent containing ammonia.
Caution
The heat exchanger is heavy and sensitive for impacts. Handle with care.
1 Remove the sealing between the exchanger blocks
2 Loosen the 2 bolts (pos.1) on the upper bar (pos.2)
and pull the bar slightly upwards. Tilt the exchanger
and lift it out.
151624 | A002

10 |Maintenance
4.3.3 Checking the fans
Even if the required maintenance, such as change of filters, is carried out dust and grease may slowly build up inside
the fans. This will reduce the efficiency.
The fans can be dismounted by loosening the bolts which attach the rack to the units inner wall section. The complete
fan rack can then be pulled out after all the attached fast couplings to the electric wires and the two tubes have been
disconnected. The fans may be cleaned with a cloth or a soft brush. Do not use water. White spirit can be used to re-
move accumulations which are otherwise difficult to remove. Allow drying properly before remounting.
The fan motor bearings are life time lubricated and should not be re-greased.
1 On supply air side for size 3-4, loosen the two bolts
(pos.1) on the rail (pos.2) to dismount the fan.
2 For size SC06-11 loosen the bolt (pos.1) in the sup-
port rail in the units roof. Pull the level (pos.2) slightly
forward and down. Then release the locking handle
(pos.3). Be careful, the motor is heavy and moves by
its own weight.
151624 | A002

Maintenance |11
3 For the exhaust air side the fans are dismounted by
loosening two bolts (pos.1) for size 3-4 and three for
size 6-11 and remove the rail (pos.2).
4.3.4 Checking the hot water heating battery
After long periods of operation (usually several years) dust may have deposited on the surface of the battery. This may
reduce batteries capacity. The battery can be cleaned with a pressure washer with misting jets, or with compressed air.
Cleaning should be carried out carefully so as not to damage the batteries aluminium fins. Once a year the battery
water circuit needs to be vented to maintain the batteries capacity.
4.3.5 Checking the electrical heating battery
After long period of time dust and pollutants can build up on the heating rods. This can cause unpleasant odors and in
the worst case fire. Clean with compressed air, vacuum or brush. The automatic safety function needs to be tested and
verified.
4.3.6 Cleaning the extract louvres and inlet diffusers
The system supplies treated outdoor air to the building and extracts the used indoor air via the duct system and diffus-
ers/louvres. Diffusers and louvres are mounted in ceilings/walls in bedroom, living room, wet rooms, WC etc. Remove
diffusers and louvres and wash in hot soapy water if required. Diffusers/ louvres must be put back with their original
settings and positions in order not to unbalance the system.
The cleaning of these parts is done when necessary.
151624 | A002

12 |Maintenance
4.3.7 Checking the outdoor air intake
Leaves and pollution could plug up the air intake grille and reduce the unit’s capacity. Check the air intake grille at least
twice a year and clean if necessary.
4.3.8 Checking the duct system
Dust and grease settlements may build up in the duct system even if filters are changed regularly. This will reduce the
efficiency of the installation. The ducts should therefore be cleaned/changed when necessary. Steel ducts can be
cleaned by pulling a brush, soaked in hot soapy water through the duct via diffuser/louvre openings or special inspec-
tion hatches in the duct system (if fitted).
4.3.9 Changing the internal battery
Note:
This procedure requires knowledge of proper ESD protection; i.e. an earthed wristband must be used!
When the alarm ”Internal Battery” is activated and the battery LED lights up red, the battery for backup of program
memory and real-time clock has become too weak. The battery is replaced as described below. A backup capacitor
saves the memory and keeps the clock running for at least 10 minutes after the power supply is removed. Therefore, if
the battery replacement takes less than 10 minutes, there will be no need to reload the program, and the clock will
continue to run normally.
The replacement battery must be of the type CR2032.
1 Remove the cover by pressing down the locking tor-
ques at the edge of the cover using a small screw-
driver, and at the same time pulling the edges
outwards.
2 Grip the battery firmly with your fingers and lift it up-
wards until it rises from its holder.
Press the new battery firmly down into place. Note
that to preserve correct polarity, the battery can only
be inserted the “right way round”.
151624 | A002

Troubleshooting | 13
5 Troubleshooting
Should problems occur, please check or correct the following before contacting your service representative. Always
check if there are any alarms active in the control panel.
1. Fan(s) do not start
• Check if there are any alarm messages
• Check that the fuses are not defect (figure 3)
• Check the settings in the control panel (times, week schedule, auto/manual operation etc.)
2. Reduced airflow
• Check the settings for medium and low fan speed
• Check that the outdoor/exhaust air damper (if used) opens
• Check if filters need changing
• Check if diffusers and louvres need cleaning
• Check diffuser/louvre openings
• Check if fans and exchanger block need cleaning
• Check if the roof unit or air intake is clogged
• Check ducts for visible damage and/or build up of dust/pollution
3. Cold supply air
• Check the control temperature on the control panel
• Check if the overheating thermostat has tripped. If necessary press the red button, on the electrical heater (figure
3).
• Check if the extract filter must be changed
• Check if the fans have stopped due to overheating. If so the thermal contact might have tripped (shows as fan
alarm in the control panel).
4. Noise/vibrations
• Check that the unit is completely levelled
• Clean the fan impellers
• Check that the screws holding the fans are tightened properly
6 Service
Before calling your service representative, make a note of the specification and production number from the type label
(figure 5)
230/400V 25 A 50Hz
Systemair Sverige AB
Industrivägen 3
SE-73930 Skinnskatteberg
Sweden
4016 W IP23 225kg
Ver. A
Serial. no: 1234/567891-0001/140214
Topvex XXXX
16kW 16kW
www.systemair.com
2 3 4
5
Fig. 5 Type label
Position Description
1Item number
2Production order number
3Consecutive number
4Production date
5Product code (product specification)
151624 | A002

14 |Service
151624 | A002

Service |15
151624 | A002

Topvex SC03-11 · Operation and Maintenance Instructions · 151624 · en_GB · 2018-10-11 · A002
Systemair Sverige AB
Industrivägen 3
SE-739 30 Skinnskatteberg, Sweden
Phone [phone]
Fax [phone]
www.systemair.com
