System air fantech CSF4 Manual

Installation, Operations, and Maintenance instruction EN
CSF4
Crawlspace Ventilation Fan

Table of contents
1 Introduction .............................................................1
1.1 Product Description ........................................1
1.2 Intended Use................................................. 1
1.3 Document Description .....................................1
1.4 Fantech Warranty........................................... 1
1.5 Product Overview........................................... 1
1.6 Name Plate................................................... 1
1.6.1 Type Designation ...............................2
2 Safety ....................................................................2
2.1 Safety definitions............................................2
2.2 Safety Instructions.......................................... 2
2.3 Personal protective equipment .......................... 3
3 Installation ..............................................................3
3.1 To Install the Product....................................... 3
4 Electrical connection ................................................. 4
4.1 To do before the electrical connection ................. 4
4.2 Motor Protection ............................................ 4
4.3 Wiring Diagrams ............................................ 4
5 Troubleshooting ....................................................... 5
6 Maintenance............................................................6
6.1 To Maintain the Product ................................... 6
7 Product Dimensions ..................................................6

1 Introduction
1.1 Product Description
This product is made to pull stale air from non-conditioned
areas, such as a non-encapsulated crawlspace, to bring fresh
air in.
This fan has rotating parts and personnel must exercise safety
precautions during installation, operations, and maintenance.
1.2 Intended Use
Use this product only in the manner intended by Fantech. If you
have any questions, please contact a Fantech representative.
1.3 Document Description
This document contains instructions for installation, operation
and maintenance of the product. The procedures must be done
by approved personnel only.
Speak to a Fantech representative for more information on how
to install the product in different installation locations.
1.4 Fantech Warranty
Make a scan of the code above to access Fantech’s warranty
in English, French, or Spanish. This product has a 5 year
warranty.
If additional support is needed to retrieve the warranty, visit fan-
tech.net; call (800) 747–1762 (US), (800) 565–3548 (Canada),
or [phone] (Latin America); email support@fantech.
net; or mail us at 10048 Industrial Blvd, Lenexa, KS 66215
United States or at 50 Kanfläkt Way, Bouctouche, NB E4S 3M5
Canada.
1.5 Product Overview
1
2
1. Casing, quantity 1
2. Electrical Box, quantity 1
1.6 Name Plate
1
23
10
5678
4
9
ALSO LISTED AS POWER VENTILATOR
SUITABLE FOR OUTDOOR USE
CFM: 100 @ 0.20” w.c.
Volts:
MODEL#: CSF4
Hz: Watts: Amps:
ITEM#:
E77545
DOM: 03/22
Serial# 1234567890
Note:
Do a check of the voltage at the fan to see if it corresponds
to the motor name plate.
1. Cubic Feet per Minute at 0.20 Inches of Water Column
2. Voltage, Volt
3. Type Designation: Product Name, Dimension, and Motor
Type. Refer to the 1.6.1 Type Designation section.
4. Frequency, Hertz
5. Input Power, Watt
6. Item Number
7. Current, Ampere
8. Serial Number
9. Date of manufacture (MM/YY)
10. Certifications
1

1.6.1 Type Designation
Product Name CSF4 #79415 and CSF4
#79415A
Duct Collar Dimensions in in-
ches (mm) 4 (102)
Motor Type AC: Alternating Current,
1–phase
2 Safety
2.1 Safety definitions
Warnings, cautions and notes are used to point out specially
important parts of the manual.
Warning
If you do not obey these instructions, there
is a risk of death or injury.
Caution
If you do not obey these instructions, there
is a risk of damage to the product, other
materials or the adjacent area.
Note:
Information that is necessary in a given situation.
2.2 Safety Instructions
Warning
This product is intended for general ventila-
tion use only. If you have questions, contact
Fantech. To decrease the risk of fire, elec-
tric shock, or injury, read and obey the fol-
lowing warning instructions before you do
work on the product:
• The ventilation contractor and the operator are responsible
for correctly installing the product.
• When installing the product, obey all applicable local condi-
tions and laws, and fire-rated construction codes and
standards.
• Because the product has rotating parts, exercise safety pre-
cautions when installing, operating, and maintaining the
product.
• Before installing, servicing, or cleaning, set the product’s
electrical power supply source in the OFF position, and lock
the service disconnecting means. If the service disconnect-
ing means cannot be locked, tightly attach a large warning
device to the service panel.
• When installing the product over a tub or shower, identify as
appropriate for the application and connect to a GFCI
(Ground Fault Circuit Interrupter) – protected branch circuit.
• Do not place the switch where it can be touched from a
shower or tub.
Caution
To decrease the risk of product malfunction
or damage to the product or surrounding
finishes and walls, read and obey the fol-
lowing caution instructions before you do
work on the product:
• When cutting or drilling into walls or ceilings, watch for elec-
trical wiring and other hidden utilities to prevent damage.
2

• Ducted exhaust fans must always be released to the
outdoors
• Install screen guards within 7 feet (2.1 meters) from the
working area of the product.
• Do not release air into spaces within walls or into attics,
crawl spaces, or garages.
• Do a check of the voltage at the fan to see if it corresponds
to the motor name plate.
Ducting has a strong effect on the air flow, noise and energy
use of the fan. Use the shortest, straightest duct routing possi-
ble for best performance, and avoid installing the fan with
smaller ducts than recommended. Insulation around the ducts
can reduce energy loss and inhibit mold growth. Fans installed
with existing ducts may not achieve their rated air flow.
2.3 Personal protective equipment
Use personal protective equipment during all work on the
product.
• Approved eye protection
• Approved protective helmet
• Approved hearing protection
• Approved protective gloves
• Approved protective shoes
• Approved work clothing
3 Installation
3.1 To Install the Product
1Using supplied hardware with FC 4 Mounting Clamps
(#411295, not provided), attach the two (2) clamps to the
inlet and outlet of the CSF4 #79415 or of the CSF4
#79415A.
2Attach steel wire (not provided) to the two (2) tabs of each
clamp.
3Using attached steel wire, hang the product correctly.
4Attach one (1) section of 4 inch (102mm) duct to the ex-
haust side of the CSF4 #79415 or of the CSF4 #79415A.
1
1
23
5
4 4
1. Exhaust point
2. 4 inch (102mm) duct
3. FC 4 Mounting Clamps (#411295)
4. Steel wire
5. CSF4 #79415 or CSF4 #79415A
3

4 Electrical connection
4.1 To do before the electrical
connection
• Make sure that the electrical connection agrees with the
product specification on the motor name plate.
• Make sure that the environment for electrical connection is
clean and dry.
• Make sure that the wiring diagram that is included with the
supply of the product agrees with the terminals in the con-
nection box.
4.2 Motor Protection
This product has integrated motor thermal overload protection.
Reset the motor protection by disconnecting the fan from power
supply for 60 seconds.
4.3 Wiring Diagrams
Legend for Diagram
English Terminology Meaning
Supply Voltage 115V Supply Voltage 115 Volts
(White) N White wire
Neutral
(Black) L Black wire
Line voltage
Capacitor Capacitor
Speed Control Speed Control
Blue Blue wire
Black Black wire
Brown Brown wire
Motor Leads Motor Leads
SPST Switch Single Pole Single Throw
Switch
Multiple location
switching
Multiple location switching
Caution
Do not apply more than 0.79 nanometers
(7 pounds per inch) of torque to the termi-
nal block screws.
Note:
To connect power to this product, use a minimum of 14
American Wire Gauge (AWG) conductor with temperature
rating of at least 90° Celsius (190° Fahrenheit).
Note:
All product motor and capacitor connections are prewired
from the factory.
Note:
There are two open ports on the terminal strip: Neutral (white
wire) and Line (black wire).
Note:
Since the fan motor is isolated within a plastic housing,
grounding is not necessary.
Note:
Refer to the following wiring diagrams to attach the wires of
the product to the wires of the house.
1Remove and save the screws that secure the terminal box
cover plate to the terminal box from the CSF4 #79415 or
from the CSF4 #79415A.
2Using a 3/8 inch (10mm) flat cable strain relief, insert the
wiring through the strain relief.
3Insert the strain relief through the hole on the side of the
terminal box.
4Place the connector nut of the strain relief over the wiring
coming into the terminal box.
5Using a small regular screwdriver, tighten the neutral
(white) wire of the incoming supply into the open terminal
strip port shown as “N”.
6Using a small regular screwdriver, tighten the line (black)
wire of the incoming supply into the open terminal strip port
shown as “L”.
7Safety the strain relief to the terminal box.
8Safety the incoming supply with the strain relief.
9Using the removed screws from the terminal box cover
plate, attach the cover plate to the terminal box again
correctly.
Without Motor Speed Controller
Blue
Black
Brown
White (N)
Black (L)
Supply
Voltage
115V
Motor
Leads
Capacitor
4

With Motor Speed Controller
Blue
Black
Brown
White (N)
Speed Control Capacitor
Black (L)
Supply
Voltage
115V
Motor
Leads
Multiple Location Switching
Blue
Black
Brown
White (N)
Multiple Location Switching
SPST
Switch
Capacitor
Black (L)
Supply
Voltage
115V
Motor
Leads
5 Troubleshooting
Problem Cause Solution
The product does
not operate at
startup.
Incorrect wiring
Refer to section
4.3 Wiring
Diagrams. Then,
do a check of the
wire connections
to make sure they
are correctly
connected
The capacitor is
faulty.
1. Disconnect
the capacitor.
2. Using a
multimeter,
test for
continuity
across the
product motor
leads.
If motor leads
show continuity,
speak to Fantech
for a replacement
capacitor.
5

6 Maintenance Warning
Set the service disconnect switch in the
OFF position before you do maintenance
unless the instructions tell you differently.
Make sure that the switch is not
accidentally set in the ON position.
6.1 To Maintain the Product
Note:
Because the product bearings are sealed and provided with an internal lubricating material, no additional maintenance is
necessary.
7 Product Dimensions
A
B
C
D
D
E
Note:
Dimensions are given in inches (mm).
A B C D E
CSF4 #79415
3–31/32 (101) 4–31/32 (127) 10 (254) 1 (25) 10–9/16 (268)
CSF4 #79415A
6

7

Document in original language 2023-09-14
498047 - 002
© Copyright Fantech
All rights reserved
Fantech reserves the rights to alter their products without notice. This also applies to products already ordered, as long as it
does not affect the previously agreed specifications.
USA
[phone]
[email protected]
Canada
[phone]
[email protected]
Latin America
[phone]
[email protected]
last page
