System air SAVE VSR 150/B User manual

Document translated from English | 212963 · v01_1.8.0
SAVE VSR 150/B
GB User Manual................................................2
SV Användarhandbok .....................................16
DE Bedienungsanleitung .................................32
FI Käyttöohje................................................48

212963 | v01_1.8.0
GB
User Manual GB
© Copyright Systemair UAB
All rights reserved
E&OE
Systemair UAB reserves the rights to change their products without notice.
This also applies to products already ordered, as long as it does not affect the previously agreed specifications.

212963 | v01_1.8.0
Contents
1 Overview ......................................................5
1.1 General Description ................................5
1.2 Warranty..............................................5
1.3 Type label.............................................5
2 Warnings.......................................................5
3 Control Panel..................................................6
3.1 Home Screen And Menu ..........................6
3.2 How to Select User Mode.........................6
3.3 How to Change Temperature ....................7
3.4 How to Change Airflow............................7
3.5 How to Set Week Schedule.......................8
3.5.1 Schedule airflow settings .............9
3.6 Status Line and Alarms ............................9
4 Maintenance................................................ 10
4.1 Maintenance Schedule .......................... 10
4.2 Open the side cover.............................. 10
4.3 Changing filters.................................... 11
4.3.1 Resetting the Filter Change
Time...................................... 11
4.4 Check and Clean a Heat
Exchanger .......................................... 11
4.5 Check and Clean Fans............................ 12
4.6 Replacing rotor drive belt ....................... 13
4.6.1 Temporary belt repair
solution.................................. 13
4.7 Duct System Maintenance...................... 13
4.7.1 Cleaning extract louvres and
supply air diffusers ................... 13
4.7.2 Checking the outdoor air
intake .................................... 13
4.7.3 Checking the roof cowl (if
fitted).................................... 14
4.7.4 Checking and cleaning the
duct system ............................ 14
5 Troubleshooting............................................ 14
6 Electrical data............................................... 15
7 Disposal and recycling .................................... 15

GB Overview |5
1 Overview
1.1 General Description
This manual describes basic information how to operate and perform maintenance on the unit and the system it is con-
nected to.
Read the instructions carefully and in its entirety.
For description of advanced settings and installation of accessories see Service and Accessories Installation manual.
All documents can be found in our online catalogue at www.systemair.com.
1.2 Warranty
For the assertion of warranty claims, the products must be correctly connected and operated, and used in accordance
with the data sheets. Further prerequisites are a completed maintenance plan with no gaps and a commissioning re-
port. Systemair will require these in the case of a warranty claim.
1.3 Type label
Before calling your service representative, make a note of the specification and production number from the type label,
which can be found next to the external connections and inside of the unit.
Fig. 1 Type label
Position Description
1Product code (product specification)
2Product item number
3Production order number
4Serial number
5Production date (YY.MM.DD)
6QR code for manufacturing order (MO) number and software version
7QR code for the spare parts list and documentation
2 Warnings
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections and maintenance work must be carried out by an authorized installer and in
accordance with local rules and regulations.
212963 | v01_1.8.0

6| Control Panel GB
Warning
• This product must only be operated by a person who has suitable knowledge or training within this field
or carried out with the supervision of a suitably qualified person.
• Beware of sharp edges during mounting and maintenance. Use protective gloves.
Warning
• All though the mains supply to the unit has been disconnected there is still risk for injury due to rotating
parts that have not come to a complete standstill.
3 Control Panel
SAVE Touch is a new generation control panel with a touch screen.
Settings are done by touching the icons or options. The touch screen is sensitive and it is not necessary to press too
hard.
3.1 Home Screen And Menu
1. Menu
2. Active user mode
3. Airflow settings
4. Temperature settings
5. Alarms and warnings
6. Status line
A.Return to home screen
B. Basic read-only information about the unit
C. Currently active alarms and alarm history
D. Configure and check week schedule
E. Check and change remaining time till filter change
F. General system preferences
G.Configuration of all system parameters
H.Help and troubleshooting menu
3.2 How to Select User Mode
For more information about user modes and functions, please check Help menu.
The top circle on the home screen indicates a currently active user mode. Touch the symbol to change the mode.
212963 | v01_1.8.0

GB Control Panel | 7
Duration have to be set for temporary user modes. SAVE VSR 150/B will return to its previous working mode after the
set time expires.
Note:
AUTO mode is available for selection only if the optional Demand Control,Week Schedule and/or
external fan control functions are activated.
3.3 How to Change Temperature
Touch the thermometer symbol on the home screen to open the temperature settings window.
Use up and down arrows to increase or decrease a value. The default setting is 18 °C.
ECO mode is a power saving function which partially limits heater operation and
can only be activated if a heater is installed.
3.4 How to Change Airflow
Touch the fan symbol on the home screen. In the open window use up or down arrows to increase or decrease the
speed of fans.
212963 | v01_1.8.0

8| Control Panel GB
Note:
Airflow regulation is available only in Manual mode.
3.5 How to Set Week Schedule
While in home screen, touch menu icon and select Week Schedule.
The menu is locked by default. Enter a password (default password is 1111).
Touch icon at the bottom left corner of the screen to add a new schedule or press EDIT button to modify already added
schedule.
212963 | v01_1.8.0

GB Control Panel | 9
Week Schedule is active only during AUTO mode.
Touch the slider to the right to activate scheduled period.
Set the time. Touch the START TIME or END TIME values to change time. Use arrow buttons and to increase or
decrease value. Confirm with OK button.
Note:
Scheduled time can start but never end at midnight (00:00). The latest END TIME period is 23:59. Scheduled
time cannot go to the next day.
12 or 24 hour time format can be changed in System Preferences menu.
If necessary, activate second scheduled period and set up time.
Once time is set, click on the day(s) when schedule should be active. It is possible to set a separate schedule for each
day. Already scheduled days are not available for selection for new schedules.
Confirm schedule with OK button.
3.5.1 Schedule airflow settings
Touch settings icon to go to SCHEDULE AIRFLOW SETTINGS menu. In this
menu set airflow level for scheduled and unscheduled periods. Available lev-
els: Off,Low,Normal,High or Demand.
Set temperature setpoint offset for both periods (-10°C – 0°C).
Demand level is available only if Demand Control or External fan function is active.
3.6 Status Line and Alarms
Status line indicates all currently active functions. Touch the status line to see descriptions of active functions in more
detail.
For more information about user modes and functions, please check Help menu.
Alarms
Touch the alarm indicator on the home screen to see all active alarms.
Touch HELP button to know more about the alarm. To clear the alarm, touch ACKNOWLEDGE button.
Note:
The underlying cause of the alarm must be resolved first otherwise the alarm will appear again.
212963 | v01_1.8.0

10 |Maintenance GB
4 Maintenance
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
Warranty claims can only be made if maintenance work is carried out correctly and written evidence thereof is
provided.
4.1 Maintenance Schedule
Task 6 months 1 year 3 years When necessary
General inspection X
Filter change X X
Fan cleaning X
Heat exchanger cleaning X X
Belt replacement X
Checking and cleaning louvres/
diffusers
X
Checking and cleaning outdoor air
intake
X
Checking and cleaning roof cowl (if
fitted)
X
Cleaning of duct system X1
1. It is recommended to do this every 5 years and is normally carried out by authorized companies specialized in this area.
• Use original spare parts from Systemair only.
• Scan QR code on the type label to find a spare part list.
4.2 Open the side cover
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• If the unit is ceiling mounted with the side cover facing downwards, be careful when opening the side
cover.
212963 | v01_1.8.0
1

GB Maintenance |11
Note:
Do not forget to tighten screws back after the maintenance!
4.3 Changing filters
The filters cannot be cleaned and must be changed as necessary. This is normally done 1–2 times per year depending
on the air pollution at the installation site.
It is very important to change filters regularly for performance and energy efficiency of the unit.
When it’s time to change the filters an alarm is shown on
the control panel display. When this occurs do the
following:
1. Stop the unit by disconnecting the mains.
2. Remove the filter cover plates.
3. Pull out the filters towards you. Some force may be
needed.
4. Insert the new filters. Make sure that the correct filter
types are inserted.
5. Remount and fasten the filter cover plates and connect
the unit to mains.
6. Reset the filter time. See chapter 4.3.1
4.3.1 Resetting the Filter Change Time
Once filter is changed, it is necessary to reset filter time. Go to Filter menu
(see 3.1 Home Screen And Menu, page 6, pos. E) or if filter alarm is present,
click on alarm status line (see 3.1 Home Screen And Menu, page 6, pos. 5)
and select filter alarm. Select CHANGE FILTER, in the pop up menu define a
new filter period and press OK to confirm selection.
Note:
The menu is locked by default. Enter a password (default
password is 1111).
4.4 Check and Clean a Heat Exchanger
Danger
Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
Warning
Risk of personal injury! The heat exchanger weighs about 10 kg. There is a risk that the heat exchanger falls
out of the unit.
If the unit is ceiling mounted with side cover facing downwards, the heat exchanger may fall out if not
secured.
Make sure that small children are not beneath the unit when the heat exchanger is removed!
Caution
• Beware of sharp edges during mounting and maintenance. Use protective gloves.
212963 | v01_1.8.0

12 |Maintenance GB
Even if the required maintenance is carried out, dust will
build up in the exchanger block. It is therefore of vital im-
portance for the upkeep of a high efficiency that the ex-
changer block is removed from the unit and cleaned
periodically as described below. Clean the heat exchanger
at least every 3 years or when required.
1. Stop the unit by disconnecting the mains.
2. Open the side cover. See chapter 4.2.
3. Disconnect the rotor power supply and the rotor sensor.
The cables are found beside the rotor at the back.
4. Take out the heat exchanger package.
5. Gently vacuum the heat exchanger.
Warning
Ensure the rotor motor is not exposed to
moisture
6. Remount the rotor. Don’t forget to reconnect the rotor
power and sensor cables.
7. Close and fasten the side cover and connect the unit to
mains.
4.5 Check and Clean Fans
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
Warning
• Risk of injury due to rotating parts that have not come to a complete standstill after mains supply to the
unit have been disconnected.
Warning
• Beware of sharp edges during mounting and maintenance. Use protective gloves.
The motor bearings are life time lubricated and mainte-
nance free.
Even if the required maintenance, such as changing of fil-
ters is carried out, dust and grease may slowly build up in-
side the fans. This will reduce the efficiency.
1. Disconnect the fan power cables. The cables are found
beside the fans.
2. Remove knobs that hold fans in place.
3. Pull out the fans towards you. Some force may be
needed.
4. Clean the fans with a cloth or a soft brush. Do not use
water. White spirit can be used to remove obstinate
deposits.
Allow the fans to dry properly before remounting.
5. Remount the fans. Don’t forget to reconnect the fan
power cables.
6. Close and fasten the side cover and connect the unit to
mains.
212963 | v01_1.8.0

GB Maintenance |13
4.6 Replacing rotor drive belt
Danger
• Make sure that the mains supply to the unit is disconnected before performing any maintenance or
electrical work!
Warning
• Risk of personal injury! The heat exchanger weighs about 10 kg. There is a risk that the heat exchanger
falls out of the unit.
• Make sure that small children are not beneath the unit when the heat exchanger is removed!
If the alarm Rotor guard is raised the rotor drive belt may be damaged or broken, see chapter 3.6.
SAVE VSR 150/B units are delivered with two welded drive belts (1) — one mounted and one as extra if replacement is
required. Spare belt is enclosed in a plastic pocket with manuals.
4.6.1 Temporary belt repair solution
In case both welded belts break it is possible to use joint nipple as a temporarily quick repair solution until the welded
belt can be replaced with a new one. Depending of how the unit is installed, it may be not necessary to remove the
heat exchanger package in order to temporary repair a broken drive belt if the belt pulley can be accessed.
4.7 Duct System Maintenance
4.7.1 Cleaning extract louvres and supply air diffusers
The system supplies fresh air to your home and extracts the used indoor air via the duct system and diffusers/louvres.
Diffusers and louvres are mounted in ceilings/walls in bedrooms, living room, wet rooms, WC etc. Remove diffusers
and louvres and wash in hot soapy water as required (diffusers/louvres must not be exchanged). Cleaning of diffusers/
louvres can be done as necessary.
4.7.2 Checking the outdoor air intake
Leaves and pollution could plug up the air intake grille and reduce the capacity. Check the air intake grille, and clean as
necessary. It is recommended to do this at least twice a year.
212963 | v01_1.8.0

14 | Troubleshooting GB
4.7.3 Checking the roof cowl (if fitted)
The roof cowl (if fitted) connected to the exhaust air duct needs to be checked at least twice a year and cleaned if
necessary.
4.7.4 Checking and cleaning the duct system
Dust and grease deposits may build up in the duct system, even if required maintenance such as changing of filters is
being carried out. This will reduce the efficiency of the installation.
The duct runs should therefore be cleaned/changed when necessary. Steel ducts can be cleaned by pulling a brush
soaked in hot soapy water through the duct via diffuser/louvre openings or special inspection hatches in the duct sys-
tem (if fitted).
It is recommended to do this every 5 years and is normally carried out by authorized companies specialized in this area.
5 Troubleshooting
If problems should occur, please check the items below before calling your service representative.
Fans do not start
1. Check the control panel for alarms.
2. Check that all fuses and fast couplings are connected (main power supply and fast couplings for supply and extract
air fans).
3. Check the week schedule. Fans may be set to OFF in the Schedule airflow settings menu.
Reduced airflow
1. Check the control panel for alarms. Some alarms can reduce the airflow to LOW if active.
2. The unit could be in defrost mode. This reduces the fan speed and in some cases shuts down the supply air fan com-
pletely during the defrosting cycle. The fans go back to normal after defrosting. There should be a defrosting function
icon visible on the home screen if defrosting is active.
3. Speed of fans is linearly reduced when the outdoor air temperature is below 0°C and an outdoor airflow compensa-
tion function is enabled.
4. Check if temporary user mode that reduces airflow is not activated, for example Away,Holiday, etc. Also check dig-
ital inputs Central Vacuum Cleaner and Cooker Hood.
5. Check the airflow settings in the control panel.
6. Check week schedule settings (chapter 3.5).
7. Check filters. Is change of filters required?
8. Check diffusers/louvres. Is cleaning of diffusers/louvres required?
9. Check fans and heat exchange block. Is cleaning required?
10.Check if the buildings air intake and roof unit (exhaust) have been clogged.
11.Check visible duct runs for damage and/or build up of dust/pollution.
12.Check diffuser/louvre openings.
The unit cannot be controlled (control functions are stuck
1. Reset control functions by disconnecting mains power for at least 10 seconds.
2. Check the modular contact connection between the control panel and the main printed circuit board.
Low supply air temperature
1. Check the control panel for alarms.
2. Check the active user functions on the control panel if defrosting function is running.
3. Check set supply air temperature on the control panel.
4. Check if ECO mode is activated on the control panel (it is a power saving function and prevents the heater from
activating).
5. Check if user modes Holiday,Away or Crowded are activated on the control panel or via a hardwired switch.
6. Check the analogue inputs in the service menu to verify that the temperature sensors are functioning correctly.
7. In case of installed electrical/other re-heater battery: Check if the overheat protection thermostat is still active. If
necessary, reset by pressing the red button on the front plate of the electrical re-heater.
212963 | v01_1.8.0

GB Electrical data | 15
8. Check if the extract filter must be changed.
9. Check if the unit has a re-heater battery connected. At very cold outdoor conditions an electrical or water heating
battery might be necessary. A re-heater battery can be acquired as an accessory.
Noise/vibrations
1. Clean fan impellers.
2. Check that the screws holding the fans are tightened.
3. Check that the anti vibration lists are fitted to the mounting bracket and to the back of the unit.
4. Check that the rotor belt is not slipping if the unit has rotating heat exchanger.
6 Electrical data
Re-heater 500 W
Fans 172 W
Total power consumption 1172 W
Fuse 10 A
Voltage 230V 1~, 50Hz
7 Disposal and recycling
This product is compliant to the WEEE directive. When disposing the unit, follow your local rules
and regulations.
This product packing materials are recyclable and can be reused. Do not dispose in household
waste.
212963 | v01_1.8.0

2129631 | v01_1.8.0
SV
Användarhandbok SE
© Upphovsrätt Systemair AB
Alla rättigheter förbehållna
Med förbehåll för eventuella fel och förbiseenden
Systemair AB förbehåller sig rätten att ändra produkterna utan föregående meddelande.
Detta gäller även redan beställda produkter, så länge det inte påverkar tidigare överenskomna specifikationer.

2129631 | v01_1.8.0
Innehåll
1 Översikt......................................................19
1.1 Allmänt.............................................. 19
1.2 Garanti............................................... 19
1.3 Märkskylt ........................................... 19
2 Varning.......................................................19
3 Manöverpanel .............................................. 20
3.1 Hemskärm och meny ............................ 20
3.2 Val av användarläge ............................. 20
3.3 Ändring av temperatur .......................... 21
3.4 Ändring av luftflöde .............................. 21
3.5 Förinställning av veckoprogram............... 22
3.5.1 Schema för
luftflödesinställningar................ 23
3.6 Statusrad och larm................................ 23
4 Underhåll..................................................... 24
4.1 Underhållsschema ................................ 24
4.2 Öppna sidopanelen. .............................. 24
4.3 Filterbyte............................................ 25
4.3.1 Återställning av larmtid för
filterbyte ................................ 25
4.4 Kontrollera och rengör
värmeväxlare ...................................... 25
4.5 Kontrollera och rengör fläktar.................. 26
4.6 Byte av rotordrivrem............................. 27
4.6.1 Tillfällig remreparation............... 28
4.7 Underhåll av kanalsystemet.................... 28
4.7.1 Rengöring av frånluftsgaller
och tilluftsdiffusorer.................. 28
4.7.2 Kontroll av uteluftsintag............. 28
4.7.3 Kontroll av takhuv (om sådan
finns)..................................... 28
4.7.4 Kontroll och rengöring av
kanalsystemet......................... 28
5 Felsökning ................................................... 29
6 Elektriska data .............................................. 30
7 Avfallshantering och återvinning ...................... 30

SV Översikt |19
1 Översikt
1.1 Allmänt
Den här handboken innehåller grundläggande information om hur man kör och utför underhåll på aggregatet och det
system det är anslutet till.
Läs instruktionerna noggrant och i sin helhet.
Läs i manualen “Installation service och tillbehör” för beskrivning av avancerade inställningar och installation av
tillbehör.
Alla dokument finns att tillgå i vår online-katalog, www.systemair.com.
1.2 Garanti
För att garantianspråk ska kunna åberopas måste produkten anslutas, användas och hanteras på rätt sätt och enligt an-
visningar i instruktionsdokumentation. Ytterligare förutsättningar är en fullständigt ifylld underhållsplan och driftsä-
ttningsrapport. Systemair krävs vid garantianspråk.
1.3 Märkskylt
Ha aggregatets huvuddata och tillverkningsnummer till hands när du kontaktar servicetekniker. Uppgifterna finns på
märkskylten som är placerad nära de externa anslutningarna inuti aggregatet.
Fig. 1 Märkskylt
Position Beskrivning
1Produktkod (produktspecifikation)
2Artikelnummer för produkten
3Produktionsordernummer
4Serienummer
5Tillverkningsdatum (ÅÅ.MM.DD)
6QR kod för tillverkningsorder (MO) nummer och version av programvara
7QR kod för reservdelslista och dokumentation
2 Varning
Fara
• Säkerställ att spänningsmatningen är bruten före underhållsarbete och elarbete.
• Arbete med elektriska anslutningar och underhåll får endast utföras av behörig personal och i enlighet
med gällande krav och föreskrifter.
2129631 | v01_1.8.0

20 | Manöverpanel SV
Varning
• Denna produkt får endast användas av en person som har lämplig kunskap eller utbildning inom detta
område eller står under överinseende av en person med lämpliga kvalifikationer.
• Se upp för vassa kanter vid installation och underhåll. Använd skyddshandskar.
Varning
• Det dröjer något innan alla rörliga delar stannat helt efter att aggregatet kopplats bort från elnätet – risk
för personskada.
3 Manöverpanel
SAVE Touch är en ny generation av manöverpanel med en pekskärm.
Inställningar görs genom att röra vid ikonerna eller alternativen. Pekskärmen är känslig och det är inte nödvändigt att
trycka för hårt.
3.1 Hemskärm och meny
1. Meny
2. Aktivt användarläge
3. Luftflödesinställningar
4. Inställning av temperatur
5. Larm och varningar
6. Statusrad.
I. Gå tillbaka till hemskärmen
J. Grundläggande skrivskyddad information om
aggregatet
K. Aktiva larm och larmhistorik
L. Konfigurera och kontrollera veckoschema
M.Kontrollera och ändra återstående tid till filterbyte
N.Allmänna systeminställningar
O.Konfiguration av alla systemparametrar
P. Hjälp- och felsökningsmeny
3.2 Val av användarläge
Läs information om användarlägen och funktioner, se Hjälp menyn.
Cirkeln högst upp på hemskärmen visar det aktuella aktiva användarläget. Tryck på symbolen för att ändra läget.
2129631 | v01_1.8.0
