System Build 1452015COM User manual

1452015COM
Mudroom Cabinet
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B341452015COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
P
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Parts are labeled on the surface or edge of the part
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
Press CAM BOLT into hole.
Press parts together so CAM BOLT inserts
into edge hole.
Using a screwdriver, turn the CAM LOCK clockwise to
lock the CAM LOCK and CAM BOLT into their holes
and fastening parts together.
Press CAM LOCK into hole.
End hole
Arrow to point towards end
hole in edge of part.

4
systembuild.com
Before You Start
Quick
Tip
Assembly
Tube
You
Please Note:
You may need to lightly tap the wood dowels into the holes during
your assembly process.

5
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
31452015010 Right Panel 31452015020
Partition
31452015030
Top
31452015040 Bottom
31452015050 Upper Shelf
31452015060
Lower Shelf
31452015070 Back Panel
K145201500
ABC
DEF
GH

6
systembuild.com
Board Identification
Not actual size
Tube
You
A
B
C
D
E
F
G
H

7
systembuild.com
Part List
Actual Size
Tube
You
Not Actual Size
(x14)
#A22710
cam bolt
(x14)
#A22700
cam lock
(x14)
#A21670
wood dowel
(x6)
#A23030
confirmat screw
(x2)
#A11080
7/16" screw
(x8)
#A12420
5/8" screw
(x4)
#A12930
1-1/8" screw
(x40)
#A21110
nail
(x2)
9 -#A82010 (white)
11 -#A82020 (black)
rod bracket
(x4)
#A44140
foot
(x1)
#I20700
clothes rod
(x1)
#A84050
safety bracket
1234
5
6
7
8
9
10
11
5a
5b
5c
5d
12
13

8
systembuild.com
STEP1
Tube
You
13
(x4) (x4)
Proper orientation of CAM LOCK
Tip
Assembly
Quick
D
3
1
1
3
3
3
1
1

9
systembuild.com
STEP2
Tube
You
13
3
1
1
3
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
3
1
3
F
(x4)
(x4)

10
systembuild.com
STEP3
Tube
You
G
3
1
1
3
12
3
(x4)
(x4) (x2)
Proper orientation of CAM LOCK
Tip
Assembly
Quick
2
3
1
1
3
2

11
systembuild.com
STEP4
Tube
You
C
13
1
3
1
3
Proper orientation of CAM LOCK
Tip
Assembly
Quick
(x2) (x2)

12
systembuild.com
STEP5
Tube
You
29
(x6) (x1) (x1)
9
2
2
2
2
2
2
A
6
6

13
systembuild.com
STEP6
Tube
You
29
(x1)
(x1)
(x6)
2
9
2
2
2
2
2
B
6
6

14
systembuild.com
STEP7
Tube
You
UNLOCKLOCK
A
G
F
D
finished edges face up

15
systembuild.com
STEP8
Tube
You
D
F
G
B
UNLOCKLOCK
finished edge up

16
systembuild.com
STEP9
Tube
You
CG
UNLOCKLOCK
finished edges face up

17
systembuild.com
STEP10
Tube
You
4
4
4
4
4
4
4
(x6)
E
C
A
B
finished edges face up

18
systembuild.com
STEP11
Tube
You
7
(x8) (x4) (x4)
7
7
8
8
12
12
12

19
systembuild.com
STEP12
Tube
You
(x40)
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
AND MUST BE INSTALLED PROPERLY.
Carefully turn your unit on its front side.
Attached the back panel as shown nailing straight into the raw edges.
Assure that the unit is square.
Distance from corner to corner must be equal as shown.
H
Flush bottom edge of the back
panel with the bottom edge of
bottom (E).
Assure that our unit is square.
Distance from corner to corner
must be equal as shown.
10
10
finished edge

20
systembuild.com
STEP13
Tube
You
13
