Tack life HGDDC1A User manual

User Manual
Drain Cleaner
Model: HGDDC1A
Drain Cleaner
HGDDC1A

NOTICE
WARNING
CAUTION
Safety Identifier
Some safety identification symbols and professional vocabulary are used to express the important
safety precautions and safety practices in this manual and the product. This section is intended to help
readers better understand these symbols and terms.
Basic Safety Code
Warning
Please read all safety precautions and safety instructions carefully. Failure to comply with these safety
instructions may result in electric shock
Please keep these safety precautions and safety instructions for future reference.
Power tool means two types of equipment: one with power cord and directly powered by external power
supply and another without power cord and powered by battery.
Work Area Safety
1.
2.
3.
Electrical Safety
1.
2.
3.
Keep the workplace clean and tidy and with sufficient lighting. Chaos and darkness of the environment
are likely to cause safety accidents.
Do not operate the machine in hazardous environments that is flammable and explosive, such as
flammable and explosive liquids, gases or dust. Power tools are prone to generate sparks that can
ignite these dusts or gases.
When operating the machine, keep unrelated personnel (including children, bystanders, non-staff,
etc.) away from the work site. Distraction could easily lead to the occurrence of safety accidents.
The power tool plug should match the socket. Do not change the plug at all times. Do not connect
the adapter of the plug of grounded power tool to be used together. Not changing the plug and
matching the socket will reduce the occurrence of electric shock.
Do not place the power tools in rain or in a humid environment. Liquid entering the power tool will
increase the risk of electric shock.
Do not damage the power cord. Do not use the power cord to drag and pull the power tool. Keep the
power cord away from hot, oil, sharp edges or moving objects. Damage to the power cord or other
objects twined can increase the risk of electric shock.
This is the safety warning symbol - used as a warning of some potential personal injury
hazards. Follow the guidance of safety information to avoid possible injury accidents, or
even death.
Danger warning symbol - indicating that there are dangerous situations around which, if not
avoided, could result in death and serious injury accidents.
Warning symbol-indicating dangerous situations which, if not avoided, could result in death
or serious injury accidents.
Caution symbol- indicating dangerous situations which, if not avoided, could result in minor
or moderate injury accidents.
Notice symbols - indicating safety information related to the protection of the property,
which means that the user must read the operation manual carefully before using the tool,
since important safety precautions and proper method of application are introduced in the
operation manual.
This symbol indicates that you must always wear safety cover and safety goggles and pay
attention when operating the tools.
The symbol indicates that there are certain risks that the hand, finger or other parts of the
body may be bruised.
This symbol indicates the risk of electric shock.
4.
5.
Personal Safety
1.
2.
3.
4.
Use and Maintenance of Battery
1.
2.
3.
4.
Important safety instructions for battery pack
1.
2.
3.
4.
5.
6.
(1)
(2)
(3)
7.
8.
9.
Please keep this instruction
Prompt for Maintaining Maximum Battery Pack Service Life
1.
When power tools are used outdoor, please use suitable outdoor special extension cord, which
might reduce risk of electric shock.
Avoid using the power tools in a humid environment. Please use the GFCI protection device, which
can reduce the risk of electric shock.
When using the power tools, keep a clear head and concentrate.
Do not use power tools in the event of fatigue or affected by medicine, alcohol or drugs. Careless
operation will lead to serious injury accidents.
Use personal protective equipment properly and always wear safety goggles. Personal protective
equipment includes dust masks, non-slip safety shoes, hard mats or thermal protection devices.
Appropriate use of the protective equipment will reduce the personal injury accidents.
Keep the body in balance and do not lose balance when operating the machine. This will help you
better control the tools in the case of accidents.
In prevention of unexpected startup, when connected to power or battery.
Please use designated charger specified by the manufacturer only. It might cause fire when one type
of charger is used for another type of battery pack.
Electric power tool can apply the designated battery packs, otherwise application of other battery
packs might cause personal injuries or fire.
When battery pack is not used, please place it away from metallic objects like paper clips, coins,
keys, nails, screws or other small metal materials, which may form connection from one end to the
other, short circuit the battery terminal and cause burning or fire.
When overused, there may be liquid flowing out of the battery. Please avoid direct body contact. If
there is accidental contact with battery drain, please rinse with water. In case of eye exposure,
please see a doctor. Battery drain might cause allergic inflammation or burns.
Before use of battery pack, please review all relevant instructions and warning labels of the (1)
charger, (2)battery pack and products that (3) need to use battery pack.
Non-detachable battery pack.
If the working hours are too short, it shall immediately stop operation; otherwise, it may cause
overheating, burning or even exploding.
In case of eye exposure to electrolyte, rinse eyes with water immediately and ask for doctor’s advice,
otherwise, it might cause blindness.
When the battery pack is not used, be sure to use the battery cover to cover the battery pack
terminal.
Do not make the battery pack short circuited
Do not make any conductor contact the terminal of the battery pack
Do not place the battery pack in the containers with iron nails, coins and other metallic objects.
Do not place the battery pack in areas with water or may be affected by rain.
Battery short circuit will cause a huge current to pass and overheat, which might result in burning or
even accidents.
Do not place the host machine and battery pack in areas above 50°(122°F).
Even if the battery pack is seriously damaged or completely depleted, do not burn it, otherwise the
battery pack will be exploded in the fire.
Be careful not to cause falling off or collide with the battery pack.
Charge the battery pack before full discharge.
When the machine is found to be underpowered, be sure to stop operating the machine and charge
the battery pack.
2.
3.
4.
Service
Product repair service shall be only conducted by the qualified maintenance personnel with
accepted parts, so as to ensure use safety and correct maintenance of tools.
Product Safety Precautions
Warning!
This section is important safety information specific to the tool. Please read the specification
carefully before use, so as to reduce electric shock or serious injury accidents.
Please keep the safety instructions well!
Pipe Dredger Safety Guidelines
The operation manual contains some specific machine safety information and operating instructions to
prevent the following serious personal injuries:
●
●
●
Read and follow the safety labels on the machine and familiarize yourself with the positions and
functions of all controllers before using the machine.
Warning:
The flexible shaft may wrap or break the fingers and palms, or cause damage to other parts of
the body.
●
●
●
Machine safety:
1.
2.
3.
4.
Do not charge the charged battery pack. Overcharging will shorten the service life of the battery
pack.
Charge the battery pack with ambient temperature at 10°-40°(50°F-104°F), please cool down the
heated before charging.
When battery pack is not used for over six months, charge the ni-mh battery pack.
It will cause injury to fingers, hands, arms or other body parts if clothes or gloves are drawn into the
rotating parts.
It will cause electric shock or burn when contacting the motor or other electric components.
Eye injury caused by the flexible shafts, cables or flying debris.
Wear rubber gloves.
Wear protective goggles.
Make the machine close to the pipe inlet.
Do not use soft gloves or cloth to hold the rotating flexible shaft, which may cause serious injury if
twined in the flexible shaft.
Do not over-deliver the flexible shaft, excessive deliver due to blockage may cause the winding or
break off of flexible shaft and cause serious injury.
Keep the tool as close as possible to the pipe. When the tool is difficult to approach the pipe, use the
front guide tube. If the distance is too long, it may cause the winding or break off of flexible shaft.
Do not operate the machine while reversing (pressing the forward and reverse rotation button R).
Operating in the (R) state can cause damage to the flexible shaft. The button (R) is only used to exit
the flexible axis in case of blocking.
5.
6.
7.
8.
Product Overview
HGDDC1A is a handheld pipe dredger, which is used to dredge the 19~76mm of the pipes such as:
kitchen pipes and bathroom pipes.
HGDDC1A dredger has an independent handle to operate the rolling jaw with automatic driving and
reversing mechanism that can achieve automatic advance and retraction of the flexible shaft to reduce
manual operations.
HGDDC1A Specification
Use the guide hose to prevent the flexible shaft from bringing foreign matter when jittering.
After using detergent in the pipe, avoid direct contact with skin or eyes. Some detergents can cause
severe burns.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
Check before Operation
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Notice: Please use the standard power cord.
When using the power tool outdoors, use extension cable marked with “W-A” or “W\” and the wire insulation
layer must be thick enough.
These cables are suitable for outdoor use and can reduce the occurrence of electric shock.
Make sure the battery pack is unplugged.
Check if the cable plug is damaged.
Check if the waterproof plug on the drum is installed and the wrench is removed.
Check if there are damaged machine parts that may pose a threat to your safety.
Lubricate the flexible shaft in according to the operation manual.
Selection of appropriate accessories for pipe dredge can improve the efficiency and quality of
dredging.
Before using, clean up the dirt on handle and the machine body.
Check if the flexible shaft is worn or damaged. In the cases of worn flat, corrosion and bending
deformation, please immediately replace the flexible shaft.
Check the workplace to ensure sufficient lighting, no flammable liquid, gas or dust. Check the
connection of cable and socket to ensure that the cable will not be damaged.
Do not place the side of the flexible shaft towards the operator or other people.
- 01 -
DANGER

Safety Identifier
Some safety identification symbols and professional vocabulary are used to express the important
safety precautions and safety practices in this manual and the product. This section is intended to help
readers better understand these symbols and terms.
Basic Safety Code
Warning
Please read all safety precautions and safety instructions carefully. Failure to comply with these safety
instructions may result in electric shock
Please keep these safety precautions and safety instructions for future reference.
Power tool means two types of equipment: one with power cord and directly powered by external power
supply and another without power cord and powered by battery.
Work Area Safety
1.
2.
3.
Electrical Safety
1.
2.
3.
Keep the workplace clean and tidy and with sufficient lighting. Chaos and darkness of the environment
are likely to cause safety accidents.
Do not operate the machine in hazardous environments that is flammable and explosive, such as
flammable and explosive liquids, gases or dust. Power tools are prone to generate sparks that can
ignite these dusts or gases.
When operating the machine, keep unrelated personnel (including children, bystanders, non-staff,
etc.) away from the work site. Distraction could easily lead to the occurrence of safety accidents.
The power tool plug should match the socket. Do not change the plug at all times. Do not connect
the adapter of the plug of grounded power tool to be used together. Not changing the plug and
matching the socket will reduce the occurrence of electric shock.
Do not place the power tools in rain or in a humid environment. Liquid entering the power tool will
increase the risk of electric shock.
Do not damage the power cord. Do not use the power cord to drag and pull the power tool. Keep the
power cord away from hot, oil, sharp edges or moving objects. Damage to the power cord or other
objects twined can increase the risk of electric shock.
4.
5.
Personal Safety
1.
2.
3.
4.
Use and Maintenance of Battery
1.
2.
3.
4.
Important safety instructions for battery pack
1.
2.
3.
4.
5.
6.
(1)
(2)
(3)
7.
8.
9.
Please keep this instruction
Prompt for Maintaining Maximum Battery Pack Service Life
1.
When power tools are used outdoor, please use suitable outdoor special extension cord, which
might reduce risk of electric shock.
Avoid using the power tools in a humid environment. Please use the GFCI protection device, which
can reduce the risk of electric shock.
When using the power tools, keep a clear head and concentrate.
Do not use power tools in the event of fatigue or affected by medicine, alcohol or drugs. Careless
operation will lead to serious injury accidents.
Use personal protective equipment properly and always wear safety goggles. Personal protective
equipment includes dust masks, non-slip safety shoes, hard mats or thermal protection devices.
Appropriate use of the protective equipment will reduce the personal injury accidents.
Keep the body in balance and do not lose balance when operating the machine. This will help you
better control the tools in the case of accidents.
In prevention of unexpected startup, when connected to power or battery.
Please use designated charger specified by the manufacturer only. It might cause fire when one type
of charger is used for another type of battery pack.
Electric power tool can apply the designated battery packs, otherwise application of other battery
packs might cause personal injuries or fire.
When battery pack is not used, please place it away from metallic objects like paper clips, coins,
keys, nails, screws or other small metal materials, which may form connection from one end to the
other, short circuit the battery terminal and cause burning or fire.
When overused, there may be liquid flowing out of the battery. Please avoid direct body contact. If
there is accidental contact with battery drain, please rinse with water. In case of eye exposure,
please see a doctor. Battery drain might cause allergic inflammation or burns.
Before use of battery pack, please review all relevant instructions and warning labels of the (1)
charger, (2)battery pack and products that (3) need to use battery pack.
Non-detachable battery pack.
If the working hours are too short, it shall immediately stop operation; otherwise, it may cause
overheating, burning or even exploding.
In case of eye exposure to electrolyte, rinse eyes with water immediately and ask for doctor’s advice,
otherwise, it might cause blindness.
When the battery pack is not used, be sure to use the battery cover to cover the battery pack
terminal.
Do not make the battery pack short circuited
Do not make any conductor contact the terminal of the battery pack
Do not place the battery pack in the containers with iron nails, coins and other metallic objects.
Do not place the battery pack in areas with water or may be affected by rain.
Battery short circuit will cause a huge current to pass and overheat, which might result in burning or
even accidents.
Do not place the host machine and battery pack in areas above 50°(122°F).
Even if the battery pack is seriously damaged or completely depleted, do not burn it, otherwise the
battery pack will be exploded in the fire.
Be careful not to cause falling off or collide with the battery pack.
Charge the battery pack before full discharge.
When the machine is found to be underpowered, be sure to stop operating the machine and charge
the battery pack.
2.
3.
4.
Service
Product repair service shall be only conducted by the qualified maintenance personnel with
accepted parts, so as to ensure use safety and correct maintenance of tools.
Product Safety Precautions
Warning!
This section is important safety information specific to the tool. Please read the specification
carefully before use, so as to reduce electric shock or serious injury accidents.
Please keep the safety instructions well!
Pipe Dredger Safety Guidelines
The operation manual contains some specific machine safety information and operating instructions to
prevent the following serious personal injuries:
●
●
●
Read and follow the safety labels on the machine and familiarize yourself with the positions and
functions of all controllers before using the machine.
Warning:
The flexible shaft may wrap or break the fingers and palms, or cause damage to other parts of
the body.
●
●
●
Machine safety:
1.
2.
3.
4.
Do not charge the charged battery pack. Overcharging will shorten the service life of the battery
pack.
Charge the battery pack with ambient temperature at 10°-40°(50°F-104°F), please cool down the
heated before charging.
When battery pack is not used for over six months, charge the ni-mh battery pack.
It will cause injury to fingers, hands, arms or other body parts if clothes or gloves are drawn into the
rotating parts.
It will cause electric shock or burn when contacting the motor or other electric components.
Eye injury caused by the flexible shafts, cables or flying debris.
Wear rubber gloves.
Wear protective goggles.
Make the machine close to the pipe inlet.
Do not use soft gloves or cloth to hold the rotating flexible shaft, which may cause serious injury if
twined in the flexible shaft.
Do not over-deliver the flexible shaft, excessive deliver due to blockage may cause the winding or
break off of flexible shaft and cause serious injury.
Keep the tool as close as possible to the pipe. When the tool is difficult to approach the pipe, use the
front guide tube. If the distance is too long, it may cause the winding or break off of flexible shaft.
Do not operate the machine while reversing (pressing the forward and reverse rotation button R).
Operating in the (R) state can cause damage to the flexible shaft. The button (R) is only used to exit
the flexible axis in case of blocking.
5.
6.
7.
8.
Product Overview
HGDDC1A is a handheld pipe dredger, which is used to dredge the 19~76mm of the pipes such as:
kitchen pipes and bathroom pipes.
HGDDC1A dredger has an independent handle to operate the rolling jaw with automatic driving and
reversing mechanism that can achieve automatic advance and retraction of the flexible shaft to reduce
manual operations.
HGDDC1A Specification
Use the guide hose to prevent the flexible shaft from bringing foreign matter when jittering.
After using detergent in the pipe, avoid direct contact with skin or eyes. Some detergents can cause
severe burns.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
Check before Operation
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Notice: Please use the standard power cord.
When using the power tool outdoors, use extension cable marked with “W-A” or “W\” and the wire insulation
layer must be thick enough.
These cables are suitable for outdoor use and can reduce the occurrence of electric shock.
Make sure the battery pack is unplugged.
Check if the cable plug is damaged.
Check if the waterproof plug on the drum is installed and the wrench is removed.
Check if there are damaged machine parts that may pose a threat to your safety.
Lubricate the flexible shaft in according to the operation manual.
Selection of appropriate accessories for pipe dredge can improve the efficiency and quality of
dredging.
Before using, clean up the dirt on handle and the machine body.
Check if the flexible shaft is worn or damaged. In the cases of worn flat, corrosion and bending
deformation, please immediately replace the flexible shaft.
Check the workplace to ensure sufficient lighting, no flammable liquid, gas or dust. Check the
connection of cable and socket to ensure that the cable will not be damaged.
Do not place the side of the flexible shaft towards the operator or other people.
Warning:
It may cause serious personal injuries due to improper use or failure to observe the
safety rules specified in this operation manual.
- 02 -

WARNING
Safety Identifier
Some safety identification symbols and professional vocabulary are used to express the important
safety precautions and safety practices in this manual and the product. This section is intended to help
readers better understand these symbols and terms.
Basic Safety Code
Warning
Please read all safety precautions and safety instructions carefully. Failure to comply with these safety
instructions may result in electric shock
Please keep these safety precautions and safety instructions for future reference.
Power tool means two types of equipment: one with power cord and directly powered by external power
supply and another without power cord and powered by battery.
Work Area Safety
1.
2.
3.
Electrical Safety
1.
2.
3.
Keep the workplace clean and tidy and with sufficient lighting. Chaos and darkness of the environment
are likely to cause safety accidents.
Do not operate the machine in hazardous environments that is flammable and explosive, such as
flammable and explosive liquids, gases or dust. Power tools are prone to generate sparks that can
ignite these dusts or gases.
When operating the machine, keep unrelated personnel (including children, bystanders, non-staff,
etc.) away from the work site. Distraction could easily lead to the occurrence of safety accidents.
The power tool plug should match the socket. Do not change the plug at all times. Do not connect
the adapter of the plug of grounded power tool to be used together. Not changing the plug and
matching the socket will reduce the occurrence of electric shock.
Do not place the power tools in rain or in a humid environment. Liquid entering the power tool will
increase the risk of electric shock.
Do not damage the power cord. Do not use the power cord to drag and pull the power tool. Keep the
power cord away from hot, oil, sharp edges or moving objects. Damage to the power cord or other
objects twined can increase the risk of electric shock.
4.
5.
Personal Safety
1.
2.
3.
4.
Use and Maintenance of Battery
1.
2.
3.
4.
Important safety instructions for battery pack
1.
2.
3.
4.
5.
6.
(1)
(2)
(3)
7.
8.
9.
Please keep this instruction
Prompt for Maintaining Maximum Battery Pack Service Life
1.
When power tools are used outdoor, please use suitable outdoor special extension cord, which
might reduce risk of electric shock.
Avoid using the power tools in a humid environment. Please use the GFCI protection device, which
can reduce the risk of electric shock.
When using the power tools, keep a clear head and concentrate.
Do not use power tools in the event of fatigue or affected by medicine, alcohol or drugs. Careless
operation will lead to serious injury accidents.
Use personal protective equipment properly and always wear safety goggles. Personal protective
equipment includes dust masks, non-slip safety shoes, hard mats or thermal protection devices.
Appropriate use of the protective equipment will reduce the personal injury accidents.
Keep the body in balance and do not lose balance when operating the machine. This will help you
better control the tools in the case of accidents.
In prevention of unexpected startup, when connected to power or battery.
Please use designated charger specified by the manufacturer only. It might cause fire when one type
of charger is used for another type of battery pack.
Electric power tool can apply the designated battery packs, otherwise application of other battery
packs might cause personal injuries or fire.
When battery pack is not used, please place it away from metallic objects like paper clips, coins,
keys, nails, screws or other small metal materials, which may form connection from one end to the
other, short circuit the battery terminal and cause burning or fire.
When overused, there may be liquid flowing out of the battery. Please avoid direct body contact. If
there is accidental contact with battery drain, please rinse with water. In case of eye exposure,
please see a doctor. Battery drain might cause allergic inflammation or burns.
Before use of battery pack, please review all relevant instructions and warning labels of the (1)
charger, (2)battery pack and products that (3) need to use battery pack.
Non-detachable battery pack.
If the working hours are too short, it shall immediately stop operation; otherwise, it may cause
overheating, burning or even exploding.
In case of eye exposure to electrolyte, rinse eyes with water immediately and ask for doctor’s advice,
otherwise, it might cause blindness.
When the battery pack is not used, be sure to use the battery cover to cover the battery pack
terminal.
Do not make the battery pack short circuited
Do not make any conductor contact the terminal of the battery pack
Do not place the battery pack in the containers with iron nails, coins and other metallic objects.
Do not place the battery pack in areas with water or may be affected by rain.
Battery short circuit will cause a huge current to pass and overheat, which might result in burning or
even accidents.
Do not place the host machine and battery pack in areas above 50°(122°F).
Even if the battery pack is seriously damaged or completely depleted, do not burn it, otherwise the
battery pack will be exploded in the fire.
Be careful not to cause falling off or collide with the battery pack.
Charge the battery pack before full discharge.
When the machine is found to be underpowered, be sure to stop operating the machine and charge
the battery pack.
2.
3.
4.
Service
Product repair service shall be only conducted by the qualified maintenance personnel with
accepted parts, so as to ensure use safety and correct maintenance of tools.
Product Safety Precautions
Warning!
This section is important safety information specific to the tool. Please read the specification
carefully before use, so as to reduce electric shock or serious injury accidents.
Please keep the safety instructions well!
Pipe Dredger Safety Guidelines
The operation manual contains some specific machine safety information and operating instructions to
prevent the following serious personal injuries:
●
●
●
Read and follow the safety labels on the machine and familiarize yourself with the positions and
functions of all controllers before using the machine.
Warning:
The flexible shaft may wrap or break the fingers and palms, or cause damage to other parts of
the body.
●
●
●
Machine safety:
1.
2.
3.
4.
Do not charge the charged battery pack. Overcharging will shorten the service life of the battery
pack.
Charge the battery pack with ambient temperature at 10°-40°(50°F-104°F), please cool down the
heated before charging.
When battery pack is not used for over six months, charge the ni-mh battery pack.
It will cause injury to fingers, hands, arms or other body parts if clothes or gloves are drawn into the
rotating parts.
It will cause electric shock or burn when contacting the motor or other electric components.
Eye injury caused by the flexible shafts, cables or flying debris.
Wear rubber gloves.
Wear protective goggles.
Make the machine close to the pipe inlet.
Do not use soft gloves or cloth to hold the rotating flexible shaft, which may cause serious injury if
twined in the flexible shaft.
Do not over-deliver the flexible shaft, excessive deliver due to blockage may cause the winding or
break off of flexible shaft and cause serious injury.
Keep the tool as close as possible to the pipe. When the tool is difficult to approach the pipe, use the
front guide tube. If the distance is too long, it may cause the winding or break off of flexible shaft.
Do not operate the machine while reversing (pressing the forward and reverse rotation button R).
Operating in the (R) state can cause damage to the flexible shaft. The button (R) is only used to exit
the flexible axis in case of blocking.
5.
6.
7.
8.
Product Overview
HGDDC1A is a handheld pipe dredger, which is used to dredge the 19~76mm of the pipes such as:
kitchen pipes and bathroom pipes.
HGDDC1A dredger has an independent handle to operate the rolling jaw with automatic driving and
reversing mechanism that can achieve automatic advance and retraction of the flexible shaft to reduce
manual operations.
HGDDC1A Specification
Use the guide hose to prevent the flexible shaft from bringing foreign matter when jittering.
After using detergent in the pipe, avoid direct contact with skin or eyes. Some detergents can cause
severe burns.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
Check before Operation
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Notice: Please use the standard power cord.
When using the power tool outdoors, use extension cable marked with “W-A” or “W\” and the wire insulation
layer must be thick enough.
These cables are suitable for outdoor use and can reduce the occurrence of electric shock.
Make sure the battery pack is unplugged.
Check if the cable plug is damaged.
Check if the waterproof plug on the drum is installed and the wrench is removed.
Check if there are damaged machine parts that may pose a threat to your safety.
Lubricate the flexible shaft in according to the operation manual.
Selection of appropriate accessories for pipe dredge can improve the efficiency and quality of
dredging.
Before using, clean up the dirt on handle and the machine body.
Check if the flexible shaft is worn or damaged. In the cases of worn flat, corrosion and bending
deformation, please immediately replace the flexible shaft.
Check the workplace to ensure sufficient lighting, no flammable liquid, gas or dust. Check the
connection of cable and socket to ensure that the cable will not be damaged.
Do not place the side of the flexible shaft towards the operator or other people.
- 03 -

Safety Identifier
Some safety identification symbols and professional vocabulary are used to express the important
safety precautions and safety practices in this manual and the product. This section is intended to help
readers better understand these symbols and terms.
Basic Safety Code
Warning
Please read all safety precautions and safety instructions carefully. Failure to comply with these safety
instructions may result in electric shock
Please keep these safety precautions and safety instructions for future reference.
Power tool means two types of equipment: one with power cord and directly powered by external power
supply and another without power cord and powered by battery.
Work Area Safety
1.
2.
3.
Electrical Safety
1.
2.
3.
Keep the workplace clean and tidy and with sufficient lighting. Chaos and darkness of the environment
are likely to cause safety accidents.
Do not operate the machine in hazardous environments that is flammable and explosive, such as
flammable and explosive liquids, gases or dust. Power tools are prone to generate sparks that can
ignite these dusts or gases.
When operating the machine, keep unrelated personnel (including children, bystanders, non-staff,
etc.) away from the work site. Distraction could easily lead to the occurrence of safety accidents.
The power tool plug should match the socket. Do not change the plug at all times. Do not connect
the adapter of the plug of grounded power tool to be used together. Not changing the plug and
matching the socket will reduce the occurrence of electric shock.
Do not place the power tools in rain or in a humid environment. Liquid entering the power tool will
increase the risk of electric shock.
Do not damage the power cord. Do not use the power cord to drag and pull the power tool. Keep the
power cord away from hot, oil, sharp edges or moving objects. Damage to the power cord or other
objects twined can increase the risk of electric shock.
4.
5.
Personal Safety
1.
2.
3.
4.
Use and Maintenance of Battery
1.
2.
3.
4.
Important safety instructions for battery pack
1.
2.
3.
4.
5.
6.
(1)
(2)
(3)
7.
8.
9.
Please keep this instruction
Prompt for Maintaining Maximum Battery Pack Service Life
1.
When power tools are used outdoor, please use suitable outdoor special extension cord, which
might reduce risk of electric shock.
Avoid using the power tools in a humid environment. Please use the GFCI protection device, which
can reduce the risk of electric shock.
When using the power tools, keep a clear head and concentrate.
Do not use power tools in the event of fatigue or affected by medicine, alcohol or drugs. Careless
operation will lead to serious injury accidents.
Use personal protective equipment properly and always wear safety goggles. Personal protective
equipment includes dust masks, non-slip safety shoes, hard mats or thermal protection devices.
Appropriate use of the protective equipment will reduce the personal injury accidents.
Keep the body in balance and do not lose balance when operating the machine. This will help you
better control the tools in the case of accidents.
In prevention of unexpected startup, when connected to power or battery.
Please use designated charger specified by the manufacturer only. It might cause fire when one type
of charger is used for another type of battery pack.
Electric power tool can apply the designated battery packs, otherwise application of other battery
packs might cause personal injuries or fire.
When battery pack is not used, please place it away from metallic objects like paper clips, coins,
keys, nails, screws or other small metal materials, which may form connection from one end to the
other, short circuit the battery terminal and cause burning or fire.
When overused, there may be liquid flowing out of the battery. Please avoid direct body contact. If
there is accidental contact with battery drain, please rinse with water. In case of eye exposure,
please see a doctor. Battery drain might cause allergic inflammation or burns.
Before use of battery pack, please review all relevant instructions and warning labels of the (1)
charger, (2)battery pack and products that (3) need to use battery pack.
Non-detachable battery pack.
If the working hours are too short, it shall immediately stop operation; otherwise, it may cause
overheating, burning or even exploding.
In case of eye exposure to electrolyte, rinse eyes with water immediately and ask for doctor’s advice,
otherwise, it might cause blindness.
When the battery pack is not used, be sure to use the battery cover to cover the battery pack
terminal.
Do not make the battery pack short circuited
Do not make any conductor contact the terminal of the battery pack
Do not place the battery pack in the containers with iron nails, coins and other metallic objects.
Do not place the battery pack in areas with water or may be affected by rain.
Battery short circuit will cause a huge current to pass and overheat, which might result in burning or
even accidents.
Do not place the host machine and battery pack in areas above 50°(122°F).
Even if the battery pack is seriously damaged or completely depleted, do not burn it, otherwise the
battery pack will be exploded in the fire.
Be careful not to cause falling off or collide with the battery pack.
Charge the battery pack before full discharge.
When the machine is found to be underpowered, be sure to stop operating the machine and charge
the battery pack.
2.
3.
4.
Service
Product repair service shall be only conducted by the qualified maintenance personnel with
accepted parts, so as to ensure use safety and correct maintenance of tools.
Product Safety Precautions
Warning!
This section is important safety information specific to the tool. Please read the specification
carefully before use, so as to reduce electric shock or serious injury accidents.
Please keep the safety instructions well!
Pipe Dredger Safety Guidelines
The operation manual contains some specific machine safety information and operating instructions to
prevent the following serious personal injuries:
●
●
●
Read and follow the safety labels on the machine and familiarize yourself with the positions and
functions of all controllers before using the machine.
Warning:
The flexible shaft may wrap or break the fingers and palms, or cause damage to other parts of
the body.
●
●
●
Machine safety:
1.
2.
3.
4.
Do not charge the charged battery pack. Overcharging will shorten the service life of the battery
pack.
Charge the battery pack with ambient temperature at 10°-40°(50°F-104°F), please cool down the
heated before charging.
When battery pack is not used for over six months, charge the ni-mh battery pack.
It will cause injury to fingers, hands, arms or other body parts if clothes or gloves are drawn into the
rotating parts.
It will cause electric shock or burn when contacting the motor or other electric components.
Eye injury caused by the flexible shafts, cables or flying debris.
Wear rubber gloves.
Wear protective goggles.
Make the machine close to the pipe inlet.
Do not use soft gloves or cloth to hold the rotating flexible shaft, which may cause serious injury if
twined in the flexible shaft.
Do not over-deliver the flexible shaft, excessive deliver due to blockage may cause the winding or
break off of flexible shaft and cause serious injury.
Keep the tool as close as possible to the pipe. When the tool is difficult to approach the pipe, use the
front guide tube. If the distance is too long, it may cause the winding or break off of flexible shaft.
Do not operate the machine while reversing (pressing the forward and reverse rotation button R).
Operating in the (R) state can cause damage to the flexible shaft. The button (R) is only used to exit
the flexible axis in case of blocking.
5.
6.
7.
8.
Product Overview
HGDDC1A is a handheld pipe dredger, which is used to dredge the 19~76mm of the pipes such as:
kitchen pipes and bathroom pipes.
HGDDC1A dredger has an independent handle to operate the rolling jaw with automatic driving and
reversing mechanism that can achieve automatic advance and retraction of the flexible shaft to reduce
manual operations.
HGDDC1A Specification
Use the guide hose to prevent the flexible shaft from bringing foreign matter when jittering.
After using detergent in the pipe, avoid direct contact with skin or eyes. Some detergents can cause
severe burns.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
Check before Operation
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Notice: Please use the standard power cord.
When using the power tool outdoors, use extension cable marked with “W-A” or “W\” and the wire insulation
layer must be thick enough.
These cables are suitable for outdoor use and can reduce the occurrence of electric shock.
Make sure the battery pack is unplugged.
Check if the cable plug is damaged.
Check if the waterproof plug on the drum is installed and the wrench is removed.
Check if there are damaged machine parts that may pose a threat to your safety.
Lubricate the flexible shaft in according to the operation manual.
Selection of appropriate accessories for pipe dredge can improve the efficiency and quality of
dredging.
Before using, clean up the dirt on handle and the machine body.
Check if the flexible shaft is worn or damaged. In the cases of worn flat, corrosion and bending
deformation, please immediately replace the flexible shaft.
Check the workplace to ensure sufficient lighting, no flammable liquid, gas or dust. Check the
connection of cable and socket to ensure that the cable will not be damaged.
Do not place the side of the flexible shaft towards the operator or other people.
- 04 -
Charger
Input Voltage (EU)
Output Voltage (EU)
Charging Time
Protection class
220~240VAC 50~60Hz 60W
18VDC 2200mA
60~70min
/ II
Battery pack Voltage (EU)
Battery cell
Switch
Rotating speed
Dredging capability
Flexible shaft size
18V
Li-Ion 2.0Ah
Infinitely variable speed switch, reversible
0560RPM
φ19~76mm 3/4"~3")
L*D=7.6m25Ft* φ7mm

Safety Identifier
Some safety identification symbols and professional vocabulary are used to express the important
safety precautions and safety practices in this manual and the product. This section is intended to help
readers better understand these symbols and terms.
Basic Safety Code
Warning
Please read all safety precautions and safety instructions carefully. Failure to comply with these safety
instructions may result in electric shock
Please keep these safety precautions and safety instructions for future reference.
Power tool means two types of equipment: one with power cord and directly powered by external power
supply and another without power cord and powered by battery.
Work Area Safety
1.
2.
3.
Electrical Safety
1.
2.
3.
Keep the workplace clean and tidy and with sufficient lighting. Chaos and darkness of the environment
are likely to cause safety accidents.
Do not operate the machine in hazardous environments that is flammable and explosive, such as
flammable and explosive liquids, gases or dust. Power tools are prone to generate sparks that can
ignite these dusts or gases.
When operating the machine, keep unrelated personnel (including children, bystanders, non-staff,
etc.) away from the work site. Distraction could easily lead to the occurrence of safety accidents.
The power tool plug should match the socket. Do not change the plug at all times. Do not connect
the adapter of the plug of grounded power tool to be used together. Not changing the plug and
matching the socket will reduce the occurrence of electric shock.
Do not place the power tools in rain or in a humid environment. Liquid entering the power tool will
increase the risk of electric shock.
Do not damage the power cord. Do not use the power cord to drag and pull the power tool. Keep the
power cord away from hot, oil, sharp edges or moving objects. Damage to the power cord or other
objects twined can increase the risk of electric shock.
4.
5.
Personal Safety
1.
2.
3.
4.
Use and Maintenance of Battery
1.
2.
3.
4.
Important safety instructions for battery pack
1.
2.
3.
4.
5.
6.
(1)
(2)
(3)
7.
8.
9.
Please keep this instruction
Prompt for Maintaining Maximum Battery Pack Service Life
1.
When power tools are used outdoor, please use suitable outdoor special extension cord, which
might reduce risk of electric shock.
Avoid using the power tools in a humid environment. Please use the GFCI protection device, which
can reduce the risk of electric shock.
When using the power tools, keep a clear head and concentrate.
Do not use power tools in the event of fatigue or affected by medicine, alcohol or drugs. Careless
operation will lead to serious injury accidents.
Use personal protective equipment properly and always wear safety goggles. Personal protective
equipment includes dust masks, non-slip safety shoes, hard mats or thermal protection devices.
Appropriate use of the protective equipment will reduce the personal injury accidents.
Keep the body in balance and do not lose balance when operating the machine. This will help you
better control the tools in the case of accidents.
In prevention of unexpected startup, when connected to power or battery.
Please use designated charger specified by the manufacturer only. It might cause fire when one type
of charger is used for another type of battery pack.
Electric power tool can apply the designated battery packs, otherwise application of other battery
packs might cause personal injuries or fire.
When battery pack is not used, please place it away from metallic objects like paper clips, coins,
keys, nails, screws or other small metal materials, which may form connection from one end to the
other, short circuit the battery terminal and cause burning or fire.
When overused, there may be liquid flowing out of the battery. Please avoid direct body contact. If
there is accidental contact with battery drain, please rinse with water. In case of eye exposure,
please see a doctor. Battery drain might cause allergic inflammation or burns.
Before use of battery pack, please review all relevant instructions and warning labels of the (1)
charger, (2)battery pack and products that (3) need to use battery pack.
Non-detachable battery pack.
If the working hours are too short, it shall immediately stop operation; otherwise, it may cause
overheating, burning or even exploding.
In case of eye exposure to electrolyte, rinse eyes with water immediately and ask for doctor’s advice,
otherwise, it might cause blindness.
When the battery pack is not used, be sure to use the battery cover to cover the battery pack
terminal.
Do not make the battery pack short circuited
Do not make any conductor contact the terminal of the battery pack
Do not place the battery pack in the containers with iron nails, coins and other metallic objects.
Do not place the battery pack in areas with water or may be affected by rain.
Battery short circuit will cause a huge current to pass and overheat, which might result in burning or
even accidents.
Do not place the host machine and battery pack in areas above 50°(122°F).
Even if the battery pack is seriously damaged or completely depleted, do not burn it, otherwise the
battery pack will be exploded in the fire.
Be careful not to cause falling off or collide with the battery pack.
Charge the battery pack before full discharge.
When the machine is found to be underpowered, be sure to stop operating the machine and charge
the battery pack.
2.
3.
4.
Service
Product repair service shall be only conducted by the qualified maintenance personnel with
accepted parts, so as to ensure use safety and correct maintenance of tools.
Product Safety Precautions
Warning!
This section is important safety information specific to the tool. Please read the specification
carefully before use, so as to reduce electric shock or serious injury accidents.
Please keep the safety instructions well!
Pipe Dredger Safety Guidelines
The operation manual contains some specific machine safety information and operating instructions to
prevent the following serious personal injuries:
●
●
●
Read and follow the safety labels on the machine and familiarize yourself with the positions and
functions of all controllers before using the machine.
Warning:
The flexible shaft may wrap or break the fingers and palms, or cause damage to other parts of
the body.
●
●
●
Machine safety:
1.
2.
3.
4.
Do not charge the charged battery pack. Overcharging will shorten the service life of the battery
pack.
Charge the battery pack with ambient temperature at 10°-40°(50°F-104°F), please cool down the
heated before charging.
When battery pack is not used for over six months, charge the ni-mh battery pack.
It will cause injury to fingers, hands, arms or other body parts if clothes or gloves are drawn into the
rotating parts.
It will cause electric shock or burn when contacting the motor or other electric components.
Eye injury caused by the flexible shafts, cables or flying debris.
Wear rubber gloves.
Wear protective goggles.
Make the machine close to the pipe inlet.
Do not use soft gloves or cloth to hold the rotating flexible shaft, which may cause serious injury if
twined in the flexible shaft.
Do not over-deliver the flexible shaft, excessive deliver due to blockage may cause the winding or
break off of flexible shaft and cause serious injury.
Keep the tool as close as possible to the pipe. When the tool is difficult to approach the pipe, use the
front guide tube. If the distance is too long, it may cause the winding or break off of flexible shaft.
Do not operate the machine while reversing (pressing the forward and reverse rotation button R).
Operating in the (R) state can cause damage to the flexible shaft. The button (R) is only used to exit
the flexible axis in case of blocking.
5.
6.
7.
8.
Product Overview
HGDDC1A is a handheld pipe dredger, which is used to dredge the 19~76mm of the pipes such as:
kitchen pipes and bathroom pipes.
HGDDC1A dredger has an independent handle to operate the rolling jaw with automatic driving and
reversing mechanism that can achieve automatic advance and retraction of the flexible shaft to reduce
manual operations.
HGDDC1A Specification
Use the guide hose to prevent the flexible shaft from bringing foreign matter when jittering.
After using detergent in the pipe, avoid direct contact with skin or eyes. Some detergents can cause
severe burns.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
The function of this tool is to clean and dredge the pipes. Please follow the instructions in the opera-
tion manual. Wrong use can cause injury.
Check before Operation
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Notice: Please use the standard power cord.
When using the power tool outdoors, use extension cable marked with “W-A” or “W\” and the wire insulation
layer must be thick enough.
These cables are suitable for outdoor use and can reduce the occurrence of electric shock.
Make sure the battery pack is unplugged.
Check if the cable plug is damaged.
Check if the waterproof plug on the drum is installed and the wrench is removed.
Check if there are damaged machine parts that may pose a threat to your safety.
Lubricate the flexible shaft in according to the operation manual.
Selection of appropriate accessories for pipe dredge can improve the efficiency and quality of
dredging.
Before using, clean up the dirt on handle and the machine body.
Check if the flexible shaft is worn or damaged. In the cases of worn flat, corrosion and bending
deformation, please immediately replace the flexible shaft.
Check the workplace to ensure sufficient lighting, no flammable liquid, gas or dust. Check the
connection of cable and socket to ensure that the cable will not be damaged.
Do not place the side of the flexible shaft towards the operator or other people.
Operating handle
Forward and reverse rotation pusher
Switch
Waterproof plug
Ratchet
Flexible shaft
Power pack
1.
2.
3.
4.
5.
6.
7.
Figure1
18V-DCDrain Cleaner
HGDDC1A
- 05 -
Minimum Wire Gauge for Extension Cord
Total Length(in feet)
Nameplate
Amps
0-6
6-10
10-12
12-16
0-25
18AWG
18AWG
16AWG
14AWG
26-50
16AWG
16AWG
16AWG
12AWG
51-100
16AWG
14AWG
14AWG
NOT RECOMMENDED

- 06 -
Operating instructions
Before using, please read all safety warnings and all insituations.Failure to follow the warnings and
instructions may result in damage the tools or cause personal injury; Check the battery power and install
the battery correctly.
Warning: If the flexible shaft is blocked, twisted or knotted, please release the switch and stop working
immediately, push the R&L switch(on the handle) to opposite position, retract the flexible shaft into the
drum.
1.
(1)
(2)
(3)
(4)
F-O-ROperating
handle
Control forward and
reverse
R-S-L Switch
Controlling the
direction of rotation
Setting switch L
F: Forward Rotation
R: Right Switch
Reverse rotation
S:Safety Lock
Avoid sudden startup
L:Left Switch
Normal forward rotation
O: Rotation Only
Stop forward
Setting switch L
R: Retreat Rotation
When the flexible shaft advances to the blockage:
Press forward rotary L switch (on the handle), flexible shaft forward rotation .
Push the lever forward (F), press the switch, the flexible shaft extends out and starts working ;
Extend the flexible shaft into the pipe, keep the tool head at a distance at most of 4"(10cm) of the
pipe opening (usually is it 2" - 8"(5~20cm)).
Gently press the switch, the flexible shaft extending to the blockage. Note: The harder you press the
switch, the faster the flexible shaft will rotate.
Release the switch, the flexible shaft stops moving forward.
Drain Cleaner
HGDDC1A
(2)setting F
F
F
(1)setting L
L
R
18V-DC Drain Cleaner
HGDDC1A
DrainCleaner
HGDDC1A
2"
1"
(3)/(4)
AttentionKeep the tool head at a distance at
most of 4" (10cm)of the pipe opening (usually is
it 2" - 8"(5~20cm)). If the distance is too long, it
will cause the flexible shaft to be twisted and
knotted. When the too head is difficult to
approach the pipe, pls use the front guide tube,
preventing injury.
2.
1
2
3.
1
2
Repeat the above steps 1, 2, 3. Until the garbage is completely cleared and the pipe is clear.
4.
1
Rotating flexible shaft and entangling the rubbish
Push the lever to the middle(O);
Gently press the switch, at this time, the flexible shaft only rotates in place. Observe, until it is
wrapped rubbish;
Retract the flexible shaft and bring out the rubbish
Push the lever reverse (R),
Press the switch, the flexible shaft take back to the ratchet, will bring out the rubbish.
Cleaning and maintenance
Clean the rubbish on the flexible shaft and drain all the dirty water in the drum, store it in a shade and
dry place. The battery needs to be fully charged after work. And store it in a shade and dry place; If
it is not used for a long time, please check the battery regularly for 2 ~ 3 months, discharge it first,
then charge it.
Having problems when cleaning pipes?
1.
2 .
(1)
(2)
(3)
(4)
(5)
When the flexible shaft and rubbish are stuck in the pipe and cannot be retracted:
A.1Press the R switch (on the handle),the flexible shaft will rotate in reverse; 2Push the lever
forward to “F”; 3Press the switch, the flexible shaft take back to the ratchet.
B. If still cannot retract the flexible shaft and rubbish according to method A. Please pull out the
flexible shaft by hand.
1Put on gloves and remove the battery;2Push the lever to middle“O”F-O-R, this will let the
lever release the flexible shaft3Pull the flexible shaft out of the pipe by hand and plug it back into
the drum.
When the flexible shaft cannot wrap rubbish
Push the lever to middle“O”(F-O-R), flexible shaft will works stay in the current position (not forward
or backward).
Press the R switch (on the handle R-S-L), let the flexible shaft reverse rotation several turns;
Press the L switch (on the handle R-S-L), let the flexible shaft forward rotation several turns;
Repeat this operation (2) / (3) several times, observe, until it is wrapped rubbish;
Press the L switch (on the handle R-S-L), push the lever forward to “R”(F-O-R); Start the machine to
retract the flexible shaft or pull out the flexible shaft by hand according to Method B.
3.
1
2
3
(4)
Warning: If you are unable to clear the pipe or encounter problems that cannot be resolved,
please contact a professional to avoid causing more serious blockages and distress.
4.
(1)
(2)
(3)
Warning: If all the broken flexible shafts connected to the machine end are retracted into the hub, the
flexible shafts will be caught inside the machine and cannot be extended any more, resulting in the
failure to replace the new flexible shafts.
Replace the flexible shaft
Search TACKLIFE HGD1C drain snake on Amazon that you can buy the replacement flexible shaft.
When the flexible shaft got twisted together
Release the switch immediately to stop rotation.
Push the lever to middle“O”(F-O-R),avoid twisting the flexible shaft tighter.
Adjust the switch (R-S-L )on the handle)to reverse the direction of rotation; a. When twisting it is
forward rotation L(R-S-L), please adjust to R reverse rotation. b. When twisting it is reverse R
(R-S-L), adjust to forward L.
Slowly start the switch, the speed must be slow, and then the flexible shaft will automatically unlock.
If the flexible shaft is broken:
Release the start switch immediately, stop rotation, and remove the battery.
Put on gloves, grasp the soft shaft inside the pipe and pull out the soft shaft. Pay attention to the
elasticity of the flexible shaft to avoid injury.
Push the lever to middle“O”(F-O-R), pull out the flexible shaft until the joint is exposed, and replace
the new flexible shaft.

- 07 -
Operating instructions
Before using, please read all safety warnings and all insituations.Failure to follow the warnings and
instructions may result in damage the tools or cause personal injury; Check the battery power and install
the battery correctly.
Warning: If the flexible shaft is blocked, twisted or knotted, please release the switch and stop working
immediately, push the R&L switch(on the handle) to opposite position, retract the flexible shaft into the
drum.
1.
(1)
(2)
(3)
(4)
When the flexible shaft advances to the blockage:
Press forward rotary L switch (on the handle), flexible shaft forward rotation .
Push the lever forward (F), press the switch, the flexible shaft extends out and starts working ;
Extend the flexible shaft into the pipe, keep the tool head at a distance at most of 4"(10cm) of the
pipe opening (usually is it 2" - 8"(5~20cm)).
Gently press the switch, the flexible shaft extending to the blockage. Note: The harder you press the
switch, the faster the flexible shaft will rotate.
Release the switch, the flexible shaft stops moving forward.
2.
1
2
3.
1
2
Repeat the above steps 1, 2, 3. Until the garbage is completely cleared and the pipe is clear.
4.
1
Rotating flexible shaft and entangling the rubbish
Push the lever to the middle(O);
Gently press the switch, at this time, the flexible shaft only rotates in place. Observe, until it is
wrapped rubbish;
Retract the flexible shaft and bring out the rubbish
Push the lever reverse (R),
Press the switch, the flexible shaft take back to the ratchet, will bring out the rubbish.
Cleaning and maintenance
Clean the rubbish on the flexible shaft and drain all the dirty water in the drum, store it in a shade and
dry place. The battery needs to be fully charged after work. And store it in a shade and dry place; If
it is not used for a long time, please check the battery regularly for 2 ~ 3 months, discharge it first,
then charge it.
Drain Cleaner
HGDDC1A
0
(1)setting O
0
setting L
L
R
18V-DC Drain Cleaner
HGDDC1A
1"
(2)
setting L
(1)setting R
R
18V-DC Drain Cleaner
HGDDC1A
R
DrainCleaner
HGDDC1A
L
R
18V-DC Drain Cleaner
HGDDC1A
1"
L"
(2)
Having problems when cleaning pipes?
1.
2 .
(1)
(2)
(3)
(4)
(5)
When the flexible shaft and rubbish are stuck in the pipe and cannot be retracted:
A.1Press the R switch (on the handle),the flexible shaft will rotate in reverse; 2Push the lever
forward to “F”; 3Press the switch, the flexible shaft take back to the ratchet.
B. If still cannot retract the flexible shaft and rubbish according to method A. Please pull out the
flexible shaft by hand.
1Put on gloves and remove the battery;2Push the lever to middle“O”F-O-R, this will let the
lever release the flexible shaft3Pull the flexible shaft out of the pipe by hand and plug it back into
the drum.
When the flexible shaft cannot wrap rubbish
Push the lever to middle“O”(F-O-R), flexible shaft will works stay in the current position (not forward
or backward).
Press the R switch (on the handle R-S-L), let the flexible shaft reverse rotation several turns;
Press the L switch (on the handle R-S-L), let the flexible shaft forward rotation several turns;
Repeat this operation (2) / (3) several times, observe, until it is wrapped rubbish;
Press the L switch (on the handle R-S-L), push the lever forward to “R”(F-O-R); Start the machine to
retract the flexible shaft or pull out the flexible shaft by hand according to Method B.
3.
1
2
3
(4)
Warning: If you are unable to clear the pipe or encounter problems that cannot be resolved,
please contact a professional to avoid causing more serious blockages and distress.
4.
(1)
(2)
(3)
Warning: If all the broken flexible shafts connected to the machine end are retracted into the hub, the
flexible shafts will be caught inside the machine and cannot be extended any more, resulting in the
failure to replace the new flexible shafts.
Replace the flexible shaft
Search TACKLIFE HGD1C drain snake on Amazon that you can buy the replacement flexible shaft.
When the flexible shaft got twisted together
Release the switch immediately to stop rotation.
Push the lever to middle“O”(F-O-R),avoid twisting the flexible shaft tighter.
Adjust the switch (R-S-L )on the handle)to reverse the direction of rotation; a. When twisting it is
forward rotation L(R-S-L), please adjust to R reverse rotation. b. When twisting it is reverse R
(R-S-L), adjust to forward L.
Slowly start the switch, the speed must be slow, and then the flexible shaft will automatically unlock.
If the flexible shaft is broken:
Release the start switch immediately, stop rotation, and remove the battery.
Put on gloves, grasp the soft shaft inside the pipe and pull out the soft shaft. Pay attention to the
elasticity of the flexible shaft to avoid injury.
Push the lever to middle“O”(F-O-R), pull out the flexible shaft until the joint is exposed, and replace
the new flexible shaft.

- 08 -
Operating instructions
Before using, please read all safety warnings and all insituations.Failure to follow the warnings and
instructions may result in damage the tools or cause personal injury; Check the battery power and install
the battery correctly.
Warning: If the flexible shaft is blocked, twisted or knotted, please release the switch and stop working
immediately, push the R&L switch(on the handle) to opposite position, retract the flexible shaft into the
drum.
1.
(1)
(2)
(3)
(4)
When the flexible shaft advances to the blockage:
Press forward rotary L switch (on the handle), flexible shaft forward rotation .
Push the lever forward (F), press the switch, the flexible shaft extends out and starts working ;
Extend the flexible shaft into the pipe, keep the tool head at a distance at most of 4"(10cm) of the
pipe opening (usually is it 2" - 8"(5~20cm)).
Gently press the switch, the flexible shaft extending to the blockage. Note: The harder you press the
switch, the faster the flexible shaft will rotate.
Release the switch, the flexible shaft stops moving forward.
2.
1
2
3.
1
2
Repeat the above steps 1, 2, 3. Until the garbage is completely cleared and the pipe is clear.
4.
1
Rotating flexible shaft and entangling the rubbish
Push the lever to the middle(O);
Gently press the switch, at this time, the flexible shaft only rotates in place. Observe, until it is
wrapped rubbish;
Retract the flexible shaft and bring out the rubbish
Push the lever reverse (R),
Press the switch, the flexible shaft take back to the ratchet, will bring out the rubbish.
Cleaning and maintenance
Clean the rubbish on the flexible shaft and drain all the dirty water in the drum, store it in a shade and
dry place. The battery needs to be fully charged after work. And store it in a shade and dry place; If
it is not used for a long time, please check the battery regularly for 2 ~ 3 months, discharge it first,
then charge it.
18V-DC Drain Cleaner
HGDDC1A
R
Having problems when cleaning pipes?
1.
2 .
(1)
(2)
(3)
(4)
(5)
When the flexible shaft and rubbish are stuck in the pipe and cannot be retracted:
A.1Press the R switch (on the handle),the flexible shaft will rotate in reverse; 2Push the lever
forward to “F”; 3Press the switch, the flexible shaft take back to the ratchet.
B. If still cannot retract the flexible shaft and rubbish according to method A. Please pull out the
flexible shaft by hand.
1Put on gloves and remove the battery;2Push the lever to middle“O”F-O-R, this will let the
lever release the flexible shaft3Pull the flexible shaft out of the pipe by hand and plug it back into
the drum.
When the flexible shaft cannot wrap rubbish
Push the lever to middle“O”(F-O-R), flexible shaft will works stay in the current position (not forward
or backward).
Press the R switch (on the handle R-S-L), let the flexible shaft reverse rotation several turns;
Press the L switch (on the handle R-S-L), let the flexible shaft forward rotation several turns;
Repeat this operation (2) / (3) several times, observe, until it is wrapped rubbish;
Press the L switch (on the handle R-S-L), push the lever forward to “R”(F-O-R); Start the machine to
retract the flexible shaft or pull out the flexible shaft by hand according to Method B.
Drain Cleaner
HGDDC1A
(1)setting R
(2)setting F
F
F
2"
(3)
R"
0
(2)setting R
(3)setting L
(1)setting O
0
R
L
3.
1
2
3
(4)
Warning: If you are unable to clear the pipe or encounter problems that cannot be resolved,
please contact a professional to avoid causing more serious blockages and distress.
4.
(1)
(2)
(3)
Warning: If all the broken flexible shafts connected to the machine end are retracted into the hub, the
flexible shafts will be caught inside the machine and cannot be extended any more, resulting in the
failure to replace the new flexible shafts.
Replace the flexible shaft
Search TACKLIFE HGD1C drain snake on Amazon that you can buy the replacement flexible shaft.
When the flexible shaft got twisted together
Release the switch immediately to stop rotation.
Push the lever to middle“O”(F-O-R),avoid twisting the flexible shaft tighter.
Adjust the switch (R-S-L )on the handle)to reverse the direction of rotation; a. When twisting it is
forward rotation L(R-S-L), please adjust to R reverse rotation. b. When twisting it is reverse R
(R-S-L), adjust to forward L.
Slowly start the switch, the speed must be slow, and then the flexible shaft will automatically unlock.
If the flexible shaft is broken:
Release the start switch immediately, stop rotation, and remove the battery.
Put on gloves, grasp the soft shaft inside the pipe and pull out the soft shaft. Pay attention to the
elasticity of the flexible shaft to avoid injury.
Push the lever to middle“O”(F-O-R), pull out the flexible shaft until the joint is exposed, and replace
the new flexible shaft.

- 09 -
Operating instructions
Before using, please read all safety warnings and all insituations.Failure to follow the warnings and
instructions may result in damage the tools or cause personal injury; Check the battery power and install
the battery correctly.
Warning: If the flexible shaft is blocked, twisted or knotted, please release the switch and stop working
immediately, push the R&L switch(on the handle) to opposite position, retract the flexible shaft into the
drum.
1.
(1)
(2)
(3)
(4)
When the flexible shaft advances to the blockage:
Press forward rotary L switch (on the handle), flexible shaft forward rotation .
Push the lever forward (F), press the switch, the flexible shaft extends out and starts working ;
Extend the flexible shaft into the pipe, keep the tool head at a distance at most of 4"(10cm) of the
pipe opening (usually is it 2" - 8"(5~20cm)).
Gently press the switch, the flexible shaft extending to the blockage. Note: The harder you press the
switch, the faster the flexible shaft will rotate.
Release the switch, the flexible shaft stops moving forward.
2.
1
2
3.
1
2
Repeat the above steps 1, 2, 3. Until the garbage is completely cleared and the pipe is clear.
4.
1
Rotating flexible shaft and entangling the rubbish
Push the lever to the middle(O);
Gently press the switch, at this time, the flexible shaft only rotates in place. Observe, until it is
wrapped rubbish;
Retract the flexible shaft and bring out the rubbish
Push the lever reverse (R),
Press the switch, the flexible shaft take back to the ratchet, will bring out the rubbish.
Cleaning and maintenance
Clean the rubbish on the flexible shaft and drain all the dirty water in the drum, store it in a shade and
dry place. The battery needs to be fully charged after work. And store it in a shade and dry place; If
it is not used for a long time, please check the battery regularly for 2 ~ 3 months, discharge it first,
then charge it.
Having problems when cleaning pipes?
1.
2 .
(1)
(2)
(3)
(4)
(5)
When the flexible shaft and rubbish are stuck in the pipe and cannot be retracted:
A.1Press the R switch (on the handle),the flexible shaft will rotate in reverse; 2Push the lever
forward to “F”; 3Press the switch, the flexible shaft take back to the ratchet.
B. If still cannot retract the flexible shaft and rubbish according to method A. Please pull out the
flexible shaft by hand.
1Put on gloves and remove the battery;2Push the lever to middle“O”F-O-R, this will let the
lever release the flexible shaft3Pull the flexible shaft out of the pipe by hand and plug it back into
the drum.
When the flexible shaft cannot wrap rubbish
Push the lever to middle“O”(F-O-R), flexible shaft will works stay in the current position (not forward
or backward).
Press the R switch (on the handle R-S-L), let the flexible shaft reverse rotation several turns;
Press the L switch (on the handle R-S-L), let the flexible shaft forward rotation several turns;
Repeat this operation (2) / (3) several times, observe, until it is wrapped rubbish;
Press the L switch (on the handle R-S-L), push the lever forward to “R”(F-O-R); Start the machine to
retract the flexible shaft or pull out the flexible shaft by hand according to Method B.
3.
1
2
3
(4)
Warning: If you are unable to clear the pipe or encounter problems that cannot be resolved,
please contact a professional to avoid causing more serious blockages and distress.
4.
(1)
(2)
(3)
Warning: If all the broken flexible shafts connected to the machine end are retracted into the hub, the
flexible shafts will be caught inside the machine and cannot be extended any more, resulting in the
failure to replace the new flexible shafts.
Replace the flexible shaft
Search TACKLIFE HGD1C drain snake on Amazon that you can buy the replacement flexible shaft.
When the flexible shaft got twisted together
Release the switch immediately to stop rotation.
Push the lever to middle“O”(F-O-R),avoid twisting the flexible shaft tighter.
Adjust the switch (R-S-L )on the handle)to reverse the direction of rotation; a. When twisting it is
forward rotation L(R-S-L), please adjust to R reverse rotation. b. When twisting it is reverse R
(R-S-L), adjust to forward L.
Slowly start the switch, the speed must be slow, and then the flexible shaft will automatically unlock.
If the flexible shaft is broken:
Release the start switch immediately, stop rotation, and remove the battery.
Put on gloves, grasp the soft shaft inside the pipe and pull out the soft shaft. Pay attention to the
elasticity of the flexible shaft to avoid injury.
Push the lever to middle“O”(F-O-R), pull out the flexible shaft until the joint is exposed, and replace
the new flexible shaft.

- 10 -
Please check if the battery pack is unplugged before replacing it
Before inspection and maintenance, please switch off tool power and take off the battery pack!
After each use, rotate manually the drum until the waterproof plug is exposed out of the housing
and remove the waterproof plug with allen wrench. Erect tools with head down so that liquid
inside the drum will drain out and reinstall the waterproof plug.(Figure10)
Do remember to take off the wrench in case of tossing out when started next time, causing
personal injuries.
Please clean the flexible shaft and drum carefully. If it is not to be used for a long time, please
apply butter on the surface of the flexible shaft to prevent rust.
How to replace the flexible shaft
HGDDC1A pipe dredger provides a quick flexible shaft replacement device.
1.
2.
3.
4.
5.
Do not start the tool to retract the flexible shaft, because the exposed flexible shaft can lead to unpredict-
able personal injury, tool damage, damage to indoor objects, fire, electric shock and other dangerous
situations.
If the flexible shaft cannot be replaced normally, please send it to the designated service center for repair.
Storage and Maintenance of the Machine
Place the operating handle in the O position;
Take out the flexible shaft to expose the connector;
Unscrew the M4 set screws with an Allen wrench and remove the unwanted flexible shaft (Fig. 9);
Insert the new flexible shaft into the connector, align the screw holes, and tighten the M4 set
screws again;
Push the flexible shaft manually to the inside of the drum.
Connector
M4 screw
1
2
3
4
≈7.5m
Connector
M4 screw
8
7
6
5
≈7.5m
18V-DCDrain Cleaner
HGDDC1A
18V-DCDrain Cleaner
HGDDC1A

Warranty Registration
We are glad to invite to register the warranty information at
www.tacklifetools.com.After registration,you may kindly
enjoy the exclusive service

Shenzhen Take Tools Co., Ltd.
www.tacklifetools.com
www.facebook.com/Tacklife.US
[email protected]
No.B714,Niulanqian Building, Minzhi Road, Longhua
District, Shenzhen, Guangdong, China 518000

Step 1 Preparation: Before using the tool, please make sure the battery pack is fully charged. Press the power button to check the battery power: 3 green lights means fully charged; red lights means insufficient, please charge it (about 60 minutes). Step 3 Extend the Cable Set the front operation handle forward to the position of "F", press the start switch to start the machine so that the cable feeds forward to the clogged position.
Step 2 Adjust the Switch Correctly Press switch L: forward rotation ATTENTION: The reverse lever "R" in the reverse direction must only be used to release the tension of the cable for a short time. Step 4 Tips: Keep the length of the exposed cable about 10cm, while putting the cable into the pipe. WARNING: Too long exposed cable makes it easy to knot and twist, while too short make it inconvenient to clean up the garbage.
F
10cm
4 inch
www.tacklifetools.com www.facebook.com/Tacklife.US[email protected]
EN

Step 5 Rotate to Entangle the Blockage Set the front operation handle to the position of "O", the cable keeping rotating only and no forward or backward, so that the blockage can be wrapped tightly and easy to clean.
Step 6 Retract the Cabe and Clean up the Blockage Push the front operation handle to the position of "R", start the machine, retract the cable back to the nozzle, and then remove the garbage. Note: Repeat the above steps until the garbage completely cleaned.
Step 7 Cleaning and Maintenance Clean work is done, please dry the cable and then retract it to the machine to avoid rusting of the cable. If the hub is filled with water, loosen the screws on the hub with a hexagonal wrench to drain it out. Warning: Please keep it fully charged after using it. Check every two or three months, charge and discharge to avoid insufficient battery power or damage.
Step 8 Attention: Cables are consumables and easily damaged. When the flexible shaft is damaged, please purchase a new one (model: Tacklife-HGD1C) to replace or contact us. Tips: 1. If the damaged cable is retracted completely into the machine, the cable is unable to be replaced. 2. While replacing the cable, please unplug the battery, manually pull out/plug back the cable to avoid tangling and injury.
OR
No.B714,Niulanqian Building, Minzhi Road, Longhua District, Shenzhen, Guangdong, China 518000
Shenzhen Take Tools Co., Ltd.
